LCD Screen 31.5-inch diagonal TFT Active Matrix
Resolution 1366 x 768
Aspect Ratio 16:9
Contrast Ratio 1500:1
H/V Viewing Angle 178o by 178o
Response Time 8 milliseconds
TV formats 1080i, 720p, 480i, 480p
Input Connectors:
RF
HDMI
Video Composite
Video Component
PC
RS232 Serial
Antenna/CATV (NTSC/ATSC/QAM)
HDMI Input x2
S-Video x1 and Composite Video x1, L/R Audio Inputs x1
YCbCr/YPbPr x2 and audio L/R channels x2
15-pin D-sub VGA plus Stereo Audio
Full-featured command set with discrete on/off, input select
and volume control
Discrete IR Control Codes for Power On/Off and Input Select
Input Power 100-240 VAC, 50-60 Hz 2.5A Max
Audio 8-watt x 2 channels, water-resistant speaker module
(detachable), SPDIF Audio output connector inside rear cover
Operating Temp. -24o to 122o F. (-31o to 50o C.)
Non-op. Temp.
(Off-mode with
power applied)
-24o to 140o F. (-31o to 60o C.)
Accessories Included Water-resistant remote control with lithium battery
Removable table top stand
TV Dimensions 32.07 in. W x 23.20 in. H x 6.29 in. D
Weight 37.5 lbs., 41.6 lbs w/speakers, 46 lbs w/ speaker module and
table top stand
Shipping Dimensions 37.0 in. W x 31.0 in. H x 11.7 in. D
Shipping Weight 54 lbs.
Warranty One-year, in-factory, parts and labor
Optional Accessories
Specifications
Specifications subject to change without notice
Side View Front View
SunBriteTV Model 3220HD
(All dimensions are in inches)
TV Dimensions are:
32.066 in. W x 23.204 in. H x 6.287 in. D
Height dimension with table top stand is 23.458 in.
TV with optional wall mount measures 9.008 in. when folded flush against the wall.
Model 3220HD
Shown with detachable speaker module
5069 Maureen Lane, Unit A Moorpark, CA 93021
866.357.8688
www.sunbritetv.com
Model 3220HD
Super Bright 32” LCD HDTV Screen
All-weather enclosure protects internal components from
rain, dirt, insects and scratches
Dual-fan airflow system keeps unit cool and dry in
temperatures up to 122 degrees F.
Internal thermostatically-controlled heater protects TV in
temperatures as low as -24 degrees F.
Innovative watertight cable entry system with pass-through
design keeps cables dry and allows for easy hook-ups
Detachable speaker module can be removed when the TV is
integrated with external speakers
Optional wall mounts and deck planter poles are weatherized
and include stainless steel hardware
SB-
CM32A12
Ceiling mount with tilt and swivel. Includes adjustable extension column that
provides 3”-9” above unit to ceiling in 1” increments without disassembly, and 4”
x 4” designer ceiling plate. Meets VESA standards.
SB-WM32 Articulating wall mount with tilt and swivel, and extends up to 11-7/8” from the
wall. Meets VESA standards.
SB-DP32X Deck/Planter pole (requires purchase of wall mount). Special order item.
SB-FMT32C RadioFMTM, transmits audio from TV to FM radio
SB-DC322 Outdoor TV dust cover
Patent pending. All rights reserved. (C) 2008 SunbriteTV LLC
All Weather Outdoor LCD Television
Temperature range is for operation in shaded location
