SUNCOURT® RADON FAN MODEL: RDN04 & RDN04-3, RDK04 &
RDK04-3 INSTALLATION INSTRUCTIONS
READ THESE INSTRUCTIONS BEFORE PLANNING YOUR INSTALLATION PLEASE
READ AND SAVE THESE INSTRUCTIONS:
DO NOT CONNECT POWER SUPPLY UNTIL FAN IS COMPLETELY INSTALLED.
CAUTION: BEFORE CARRYING OUT ANY MAINTENANCE OR SERVICING, ENSURE
THE UNIT IS DISCONNECTED FROM THE MAIN POWER SUPPLY.
DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS AND VAPORS
OR DUST.
NEVER EXPOSE THIS FAN TO TEMPERATURES EXCEEDING 140°F (60°C).
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING:
1. Do not use fan in hazardous environments where fan electrical system could provide
ignition to
combustible or flammable materials.
2. Do not use fan to exhaust explosive or corrosive gases.
3. Check voltage at the fan to insure it corresponds with product nameplate.
4. Normal operation of this device may affect the supply of fresh air needed for safe
operation of fuel burning equipment. Follow safety standards, codes, and heating
equipment manufacturer’s procedures guide lines.
5. There are no user serviceable parts located inside the fan unit. Do NOT attempt to open
(this will void manufacturer’s warranty). Return unit to the factory with original purchase
receipt for service after obtaining a Return Goods Authorization (RGA).
6. All wiring must be in accordance with local and national electrical codes. When installed
outside, power must be supplied from a GFCI (Ground Fault Circuit Interruptor).
7. Operate unit only in the manner intended. If you have questions, contact the
manufacturer.
8. Before servicing or cleaning the unit, switch power to off at service panel to prevent
power from being switched on accidentally. When the service disconnecting means cannot
be locked, securely fasten a prominent warning device such as a tag to the service panel.
9. Installation work and electrical wiring must be done by a qualified person(s) in
accordance with all
applicable codes and standards, including fire-rated construction.
Radon Print http://www.suncourt.com/Radon Print.html
1 of 7 1/2/2012 2:01 PM

10. This unit has an unguarded impeller. Do not use in locations where the impeller is
readily accessible to people or animals.
11. This unit can be used with the Suncourt VS100 or VS200 solid state speed control.
(1) Running watts at zero static pressure
(2) Watts range at varying static pressure
FAN SPECIFICATIONS
Electric Motor • External Rotor • Ball Bearing • Class B • Thermally Protected • Conforms
To ANSI-UL 705 & CSA 22.2 • ETL Listed • Housing Material FRABS • UV Protected •
Flame Rating UL 94V0 • Housing Color White
Radon Print http://www.suncourt.com/Radon Print.html
2 of 7 1/2/2012 2:01 PM

INSTALLATION
Retain original packaging.
The fan can be mounted indoors or outdoors. (It is suggested that EPA recommendations
be followed in choosing the fan location.) The fan may be mounted directly on the system
piping or fastened to a
supporting structure by means of mounting brackets provided.
MOUNTING
Mount the fan vertically with outlet up. Insure the unit is plumb and level. When mounting
directly on the system piping ensure that the fan does not contact any building surface to
avoid vibration noise. Use the flexible couplers provided to secure the fan to the piping.
MOUNTING BRACKET
The fan may be further secured with the mounting brackets provided.
Radon Print http://www.suncourt.com/Radon Print.html
3 of 7 1/2/2012 2:01 PM

The flexible couplings will provide means of disconnect for cleaning the impeller and also
to isolate vibration.
ELECTRICAL WIRING
The fans operate on standard 120V 60 Hz AC. All wiring must be performed in accordance
with the National Electrical Code and state and local building codes. A qualified electrician
should perform all
electrical work. Outdoor installations require the use of UL Listed watertight conduit and
power supplied from a GFCI (Ground Fault Circuit Interruptor).
ELECTRICAL CONNECTION
Connect wiring with terminal block provided, observing proper connections.
Radon Print http://www.suncourt.com/Radon Print.html
4 of 7 1/2/2012 2:01 PM

CONDENSATION & DRAINAGE
Condensation is formed in the piping of a mitigation system when the air in the piping is
chilled below its dew point. This can occur at points where the system piping goes through
unheated space such as an attic, garage or outside. The system design must provide a
means for water to drain back to a slab hole to remove the condensation. The fan MUST
be mounted vertically plumb and level, with the outlet
pointing up for proper drainage through the fan. Avoid mounting the fans in any orientation
that will allow water to accumulate inside the fan housing. The fans are NOT suitable for
underground burial.
Under some circumstances a condensate bypass should be installed in the outlet ducting
as shown Figure 1. This may be particularly true in cold climate installations, which require
long lengths of outlet ducting or when the outlet ducting is likely to produce large amounts
of condensation because of high soil moisture or outlet duct material. Schedule 20 piping
and other thin-walled plastic ducting or aluminum downspout piping will normally produce
much more condensation than Schedule 40 piping.
Radon Print http://www.suncourt.com/Radon Print.html
5 of 7 1/2/2012 2:01 PM

The bypass is constructed with a 45 degree Wye fitting at the bottom of the outlet stack.
The bottom of the Wye is capped and fitted with a tube that connects to the inlet piping or
other drain. The condensation produced in the outlet stack is collected in the Wye fitting
and drained through the bypass tube. The bypass tubing may be insulated to prevent
freezing.
Failure to install a proper condensate collection system voids the product warranty.
MAINTENANCE
Inspect the product at least once every 12 months for excessive dust and dirt build up on
the impeller (more often in dusty environments). Clean as necessary. The unit must be
disconnected from power during inspection and/or cleaning.
“SYSTEM ON” INDICATOR
A properly designed system should incorporate a “System On” Indicator to confirm system
operation mode or status. A manometer, such as a U-Tube, or a vacuum alarm is
recommended for this purpose.
SLAB COVERAGE
The Suncourt Radon Fan provides coverage up to 2000 sq. ft. per slab penetration
depending on type of sub slab material. If one slab penetration does not sufficiently
mitigate the Radon then additional slab penetration points can be added as required.
Detailed Radon information is available on the EPA’s website at: http://www.epa.gov/radon/
Radon Print http://www.suncourt.com/Radon Print.html
6 of 7 1/2/2012 2:01 PM

FIVE YEAR LIMITED WARRANTY
Subject to the following limitations, Suncourt Inc. (manufacturer) warrants that the fan will,
for 5 (five) years from date of original purchase, remain free from appearance of defects in
workmanship or materials. This warranty is subject to the following limitations: (a)
manufacturer’s liability is limited to the replacement or repair of the unit, as decided by the
manufacturer; (b) a defective unit must be returned, prepaid, with proof of purchase, to
Suncourt; and (c) this warranty does not apply to defects resulting from the alteration,
abuse, accidental damage, unauthorized repair, or misuse of the unit. This warranty is
given in lieu of all other warranties, guarantees, and conditions on manufacturer’s part, and
the manufacturer shall have no tortious or other liability in respect to this fan. There is no
implied warranty of merchantability and fitness for a particular purpose.
Suncourt shall not be liable for any direct, indirect, special, incidental or consequential
damages arising from, or relating to, the fan or the performance of it. Suncourt’s maximum
liability shall not exceed the amount of the purchase price of the fan. The sole remedy
under this warranty shall be the repair or replacement of the product.
WARRANTY RETURN
Call Suncourt at 1.800.999.3267 for a Return Goods Authorization (RGA) number. Please
have date of original purchase available.
Mark the RGA number clearly on the return shipping box. We do not accept returns without
a valid RGA number.
Package the unit using the original packaging including the styrofoam inserts to avoid
damage in shipping.
