Technical Parameters
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Certification CE,EMC,LVD
EN60950
Safety standard(LVD)
Warranty and Protection
5 years
Protection Reverse Polarity
Warranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~ +55
O
C
T c: +85
O
C
LVD
3 Channel/PWM signal input/Constant voltage output/3KV optoelectronic isolation
Mechanical Structures and Installations
Wiring Diagram
3 Channel Constant Voltage Power Repeater
● 12-36V constant voltage power repeater.
● 3 channel, 10A per channel.
● To receive PWM signal control.
● Power repeater in series or in parallel to expand output unlimitedly.
● Apply to single color or RGB constant voltage LED strip or module.
Features
Output type Constant voltage
Output power 3 x (120-360)W
Output voltage 3 x (12-36)VDC
Output current 3CH,10A/CH
Input voltage 12-36VDC
Input current 30.5A
Input and Output
PWM input +
CH1/R PWM input -
User Manual Ver 1.0.3
Model No.: EV3-X
Page 1
Input signal PWM
CH1/R LED output -
LED output +
Power input -
Power input +
Installation rack
Installation rack
EV3-X 3 Channel Constant Voltage Power Repeater
10 7 .00 m m
75 . 00 mm
24 . 50 mm
75 . 00 mm
POWE R
CH2/G LED output -
CH3/B LED output -
CH2/G PWM input -
CH3/B PWM input -
Power indicator
RGB LED strip
-
++
POWE R
INP UT
PWM S IGNAL
V+ R G B
EV3-X
V3
RGB LED strip
-
++
POWE R
INP UT
PWM S IGNAL
V+ R G B
EV3-X
RGB LED strip
RGB LED strip
Power Supply
12-36VDC
Constant Voltage AC100-240V
Power Supply
12-36VDC
Constant Voltage AC100-240V
Power Supply
12-24VDC
Constant Voltage
AC100-240V
-
++
INP UT
PWM S IGNAL
V+ R G B
Weight
0.256kg
Gross weight
Net weight
0.270kg

Malfunctions analysis & troubleshooting
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain.
3. Good heat dissipation will prolong the working life of the controller,Please ensure good ventilation.
4. Please check if the output voltage of any power supplies used comply with the working voltage of the product.
5. Ensure all wire connections and polarities are correct and secure before applying power to avoid any damages
to the LED lights.
6. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
Safety & Warnings
User Manual Ver 1.0.3 Page 2
Wrong color 1. Wrong connection of R/G/B wires. 1. Reconnect R/G/B wires.
Malfunctions
Causes Troubleshooting
Uneven intensity
between front and
rear,with voltage drop
1. Output cable is too long.
2. Wire diameter is too small.
3. Overload beyond power supply capability.
4. Overload beyond controller capability.
1. Reduce cable or loop supply.
2. Change wider wire.
3. Replace higher power supply.
4. Add power repeater.
1. No power.
2. Wrong connection or insecure.
1. Check the power.
2. Check the connection.
No light
