Sundyne LMV-801S Instruction manual

Installation, Operation
& Maintenance Manual
Sundyne Pumps
Model:
LMV-801S
`
SA-07-11-92, Rev Orig
Oct 2015

http://www.sundyne.com
Copyright
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise without the prior permission of Sundyne LLC.
© 2015 Sundyne LLC
Warranty
Sundyne LLC warrants to Buyer for a period of twelve (12) months from the date of being placed in service (but not to exceed
eighteen (18) months after the date of shipment) that the equipment at the time of shipment will be free from defects of design,
material and workmanship. If any defects or malperformance occur during the warranty period, Sundyne’s sole obligation shall be
limited to alteration, repair or replacement at Sundyne’s expense, F.O.B. Factory, of parts or equipment, which upon return to
Sundyne and upon Sundyne’s examination prove to be defective. Equipment and accessories not manufactured by Sundyne are
warranted only to the extent of and by the original manufacturers’ warranty. Sundyne shall not be liable for damage or wear to
equipment caused by abnormal conditions, vibration, failure to properly prime or to operate equipment without flow or caused by
corrosives, abrasives or foreign objects. THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, WHETHER EXPRESSED OR IMPLIED INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE. In no event shall Sundyne be liable for consequential or incidental damages

Sundyne LLC i http://www.sundyne.com
SA-07-11-92, Rev Orig October 2015
EUROPEAN UNION MACHINERY DIRECTIVE
(CE Mark System)
(where applicable)
This document incorporates information relevant to the Machinery Directive 2006/42/EC. It should be
read prior to the use of any of our equipment. Individual maintenance manuals which also conform to the
EU Directive should be read when dealing with specific models.
EUROPEAN UNION ATEX DIRECTIVE
This document incorporates information relevant to the ATEX Directive 94/9/EC (Directive on equipment and
protective systems intended for use in potentially explosive atmospheres). It should be read prior to the use
of any our equipment.
Compliance to the Directive is based on Atmospheres having pressures ranging from 0.8 to 1.1 bar and
temperatures ranging from –20 C to + 60 C.
As indicated in the ATEX Directive 94/9/EC, It is the responsibility of the user of the pump to indicate to HMD
Sealless Pumps the Zone and Corresponding group (Dust or Gas) that the pump is to be installed within.
Service
Americas
Sundyne LLC Tel: [phone]
14845 W. 64th Avenue Fax: +1=303-425-0896
Arvada, CO 80007 Email: [e-mail]
Web: www.sundyne.com
Europe
HMD Sealless Pumps Ltd Tel: [phone]
Hampden Park Industrial Estate, Fax: [phone]
Eastbourne Email: [e-mail]
East Sussex Web: www.sundyne.com
BN22 9AN
England
Customer Service 24 Hour 07966 525269

Sundyne LLC ii http://www.sundyne.com
SA-07-11-92, Rev Orig October 2015

Sundyne LLC iii http://www.sundyne.com
SA-07-11-92, Rev Orig October 2015
Revisions
October 2015 Original Release

Sundyne LLC iv http://www.sundyne.com
SA-07-11-92, Rev Orig October 2015
Contents
Contents.............................................iv
INTRODUCTION..................................1
Sundyne Centrifugal Pumps...........................1
Text Symbols....................................................2
Equivalent Terms...........................................3
Units...............................................................3
Equipment and Safety Precautions................4
Wearing Personal Protective Equipment.......4
Lifting .............................................................4
Using Forklifts................................................4
Ensuring Electrical Safety..............................5
Testing Equipment.........................................5
Magnets.........................................................5
Using Chemicals............................................5
Protection from Falling...................................5
Preventative Machine Guards .......................5
Pre-Commission Checklist..............................6
Familiarizing Yourself with the Pump ............6
Driver Instructions..........................................6
Verifying Auxiliaries .......................................6
Checking Driver Rotation...............................6
Piping Connections........................................6
General..............................................................7
Application or Use..........................................7
Temperature Classification - (ATEX Directive
94/9/EC).............................................................7
INSTALLATION...................................9
Inspection .........................................................9
Storing Your Pump Short-Term......................9
Storing Your Pump Long-Term ......................9
Installation Guidelines...................................10
Location .......................................................10
Foundations.................................................10
Electrical Installation & Grounding..............11
Suction and Discharge Piping......................12
Pitfalls to Avoid On Suction Pipework .........14
Net Positive Suction Head (NPSH).............14
Discharge Pipework.....................................15
Protection Systems .......................................16
Power Control Monitor (PCM) .....................16
Temperature Sensor....................................16
Differential Pressure Switches ....................16
Liquid Sensing Probe ..................................17
Secondary Containment or Control.............17
VapourView®...............................................17
Precautions ....................................................19
Installation Considerations ..........................19
Commissioning..............................................21
General........................................................21
Venting ........................................................21
Direction of Rotation....................................21
START UP .........................................22
Start-Up Procedures......................................22
Run-In..........................................................22
Start Up .......................................................22
Operating Guidelines ....................................23
Precautions..................................................23
Controlling the Pump During Startup..........26
Single Operation..........................................26
Parallel Operation........................................26
OPERATION & CONTROL................27
Operation of Sundyne Pumps ......................27
Suction Conditions.......................................27
Minimum Flow Conditions ...........................27
Entrained Gases..........................................27
System Head Curve ....................................27
Parallel Operation........................................28
Servicing.........................................................29
Maintenance Schedule................................29
Vibration Levels...........................................29
Dismantling..................................................29
Fault Finding ..................................................30
Flowcharts ...................................................30
Pump Diagnostics..........................................35

Sundyne LLC v http://www.sundyne.com
SA-07-11-92, Rev Orig October 2015
Maintenance ...................................................37
General Safety.............................................37
Tools Required.............................................38
Lifting Points ................................................39
DISASSEMBLY OF PUMP................40
Disassembly - Stage 1 -Removal of Pump
from Pipe Work...............................................41
Disassembly - Stage 2 - Motor and Motor
Support (Close Coupled)...............................43
Disassembly - Stage 3 – Magnet Drive Unit 50
Disassembly - Stage 4 – Casing and
Diffusers..........................................................62
ASSEMBLY OF PUMP......................64
Assembly - Stage 1 – Casing and Diffuser..65
Assembly - Stage 2 – Magnet Drive Unit.....67
Assembly - Stage 3 – Motor & Motor Support
(Close Coupled) .............................................84
Assembly - Stage 4 – Re-Install Pump.........92
REPLACEMENT OF BUSHES &
THRUST PAD....................................94
Quick Reference Torque Settings................98
Pump Parts List............................................100
LMV801S Pump Cross Section (No
Secondary Containment) ............................102
Index................................................103

Instruction and Operation Manual
SA-07-11-92, Rev Orig 1 October 2015
INTRODUCTION
Sundyne Centrifugal Pumps
Sundyne API pumps provide high-energy
performance and competitive efficiencies in a
compact unit that is easy to maintain. Sundyne
pumps are single stage and are closely coupled
(OH4). Designed to increase the pressure of a
continuous flow of fluid by applying centrifugal
action, Sundyne pumps are most commonly
used in HPI, CPI, and Boiler Feed applications.
Commonly applied in refineries, petrochemical
plants, and power generation plants, Sundyne
pumps are used in high-head, low-to-medium
flow processes.
This manual presents installation, servicing,
troubleshooting, maintenance, and spare parts
information for the latest Sundyne LMV 801S
centrifugal pump. It is important that the manual
is read thoroughly before installing and
operating the pump. Images provided in this
manual are based on typical configurations.
Refer to the drawings provided with the order for
the actual configuration. Questions regarding
parts, service or operation should be directed to
your Authorized Service Center or a listed
Sundyne location.
Note: Parenthetical numbers included in the
text correspond to item numbers on the
illustrated figures. The item number
serves as a location identifier and not a
part number. The correct spare part
can be ordered referencing the item
and serial numbers. From there the
correct part number can be obtained.
Whilst every care is taken to ensure that the
information is correct, no liability can be
accepted by Sundyne or HMD Sealless Pumps
for loss, damage or injury caused by errors in or
omission from the information given.
Sundyne LLC RESERVES THE RIGHT TO
CHANGE THEIR RECOMMENDATIONS
WITHOUT PRIOR NOTICE OR
CONSULTATION.

Instruction and Operation Manual
SA-07-11-92, Rev Orig 2 October 2015
Text Symbols
In accordance with general safety and handling,
OSHA 1910.145, BS EN 809 and other local
directives, the following warning symbols and
signs are used in this manual.
DANGER: Text accompanied by this
symbol indicates failure to avoid hazards
identified with this symbol will result in
death.
WARNING: Text accompanied by this
symbol indicates that failure to recognize
these hazards could result in injury or
even death.
ELECTRICAL HAZARD: Text
accompanied by this symbol indicates
that failure to follow directions could
result in electrical damage to equipment
or electrical shock.
RECOMMENDED: Text accompanied by
this symbol indicates recommended
usage.
REMINDER: Text accompanied by this
symbol indicates a reminder to perform
an action.
EQUIPMENT USE ALERT: Text
accompanied by this symbol indicates
that failure to follow directions could
result in damage to equipment.
RECOMMENDED TOOL: Text
accompanied by this symbol identifies
the tool required for the operation.

Instruction and Operation Manual
SA-07-11-92, Rev Orig 3 October 2015
To assist in global understanding the following equivalent terminology is used: -
Used in this manual Also known as
Alignment Pad Support Gasket
Bush Radial Bearing or Journal Bearing
Bearing Assembly Power Frame
Containment Shell Shroud
Gasket Joint
Spanner Wrench
Fit Install
Grounding Earthing
Check Valve Non Return Valve
Both Metric and equivalent US units are shown in this manual where appropriate.
Conversion factors between units are: -
°C to °F multiply by 1.8 and add 32
mm to inches divide by 25.4
Nm to lbf-ft divide by 1.356
ml to US Fl.oz divide by 29.6
Equivalent Terms
Units
