Sunex Tools 8750 Parts list manual

8750 Rev. 4/21/03
OPERATING INSTRUCTIONS AND PARTS BREAKDOWN
Refer to Engine Service Manual
for Correct Lifting Points,
Mounting Points and Mounting
Bolts! Mounting bolts should
be torqued at appropriate
amount to maintain load.
DO NOT CRAWL UNDER ENGINE OR PLACE
ANY PART OF YOUR BODY UNDER ENGINE AT
ANY TIME DURING MOUNTING OF ENGINE,
USE OF STAND, OR REMOVAL OF ENGINE.
OWNER/USER RESPONSIBILITY
The owner and/or user must have a thorough understanding of the
manufacturer’s operating instructions and warnings before using this
engine stand. Personnel involved in the use and operation of
equipment shall be careful, competent, trained, and qualified in the
safe operation of the equipment and its proper use when servicing
motor vehicles and their components. Warning information should be
emphasized and understood. If the operator is not fluent in English,
the manufacturer’s instructions and warnings shall be read to and
discussed with the operator in the operator’s native language by the
purchaser/owner, making sure that the operator comprehends
its contents.
Owner and/or user must study and maintain for future reference
the manufacturer’s instructions. Owner and/or user is responsible
for keeping all warning labels and instruction manuals legible
and intact. Replacement labels and literature are available from
the manufacturer.
DO NOT OVERLOAD. OVERLOADING CAN
CAUSE DAMAGE TO, OR FAILURE OF
THE STAND.
THIS STAND IS DESIGNED FOR USE ONLY
ON HARD LEVEL SURFACES CAPABLE OF
SUPPORTING THE LOAD. USE ON OTHER
THAN HARD LEVEL SURFACES CAN
RESULT IN STAND INSTABILITY AND
TIPPING OF LOAD.
LOCK THE MOUNTING-PLATE ROTATING
MECHANISM BEFORE APPLYING A LOAD.
RELEASE ROTATIONAL LOCKING DEVICE
SLOWLY AND CAREFULLY.
ALWAYS USE HIGH STRENGTH SAE GRADE
8 BOLTS FOR ENGINE MOUNTING BOLTS.
MAKE SURE WIDEST SET OF MOUNTING
HEAD FINGERS ARE NEAREST THE
GROUND WHEN MOUNTING AN ENGINE
TO THE STAND.
ALWAYS BE SURE THAT THE LOAD IS
CENTERED AND SECURED TO THE
MOUNTING PLATE. OFF-CENTER LOADS
MAY MAKE THE LOAD AND HANDLE
ROTATE IN EITHER DIRECTION WHEN
THE ROTATIONAL LOCKING DEVICE IS
RELEASED.
NEVER LOOSEN MOUNTING BOLTS
UNLESS ENGINE IS SUPPORTED BY A
CRANE OR HOIST.
DO NOT USE STAND TO DOLLY OR
TRANSPORT ENGINES.
NO ALTERATIONS TO THE STAND OR
ADAPTERS SHALL BE MADE.
DO NOT ROTATE MOTOR UNLESS REAR
LEGS ARE SECURED FROM TIPPING.
READ, STUDY AND UNDERSTAND ALL
INSTRUCTIONS BEFORE OPERATING.
FAILURE TO HEED THESE WARNINGS MAY
RESULT IN LOSS OF LOAD, DAMAGE TO
STANDS, AND/OR FAILURE RESULTING IN
PROPERTY DAMAGE, PERSONAL OR
FATAL INJURY.
MODEL #8750
750 Lb. Capacity Engine Stand
MAINTENANCE
Apply motor oil to support base wheels and casters. Apply chassis
grease to mounting head hub. Rotate head to distribute grease.

8750 Rev. 4/21/03
OPERATING INSTRUCTIONS
Drain oil and coolant and remove flywheel from engine before
mounting. Mount engine as directed in procedures which
follow. Refer to engine service manuals and technical bulletins
when mounting engines. Lift engine (block) with crane or hoist
until even with head of engine stand. Bolt through adjustable
fingers to back of block at bell housing mounting holes. Fasten
securely to mounting plate. Slowly lower crane or hoist so that
the engine stand supports full weight of engine. To check
engine balance, carefully loosen hex bolt at back of rotating
head, making sure stand is secured from tipping, and turn
handle to rotate engine. If balance is not satisfactory, rotate
engine to its original position and raise with crane or hoist just
enough to take weight off the stand. Loosen bolts on adjustable
fingers and realign so that weight is evenly distributed. Tighten
all bolts securely and recheck balance. For safe and secure
operation: do not rotate engine more than 90° for any one
location of the positioning handle. In general, keep the handle
within 45° of horizontal. Keep a firm hold on positioning
handle while rotating engine. To remove an engine from stand,
attach a crane or hoist and raise engine just enough to take
engine weight off stand. Carefully remove bolts attaching
fingers to engine. Be aware that there will be a slight
movement of stand as total engine weight is transferred
to crane.
INSPECTION
Visual inspection should be made before each use of the
engine stand, checking for damaged, loose or missing parts.
Each stand must be inspected by a manufacturer’s repair
facility immediately, if accidentally subjected to an abnormal
load or shock. Any stand which appears to be damaged in
any way, found to be badly worn, or operates abnormally
MUST BE REMOVED FROM SERVICE until necessary
repairs are made by a manufacturer’s authorized repair
facility. It is recommended that an annual inspection of the
stand be made by a manufacturer’s authorized repair facility
and that any defective parts, decals or warning labels be
replaced with manufacturer’s specified parts. A list of
authorized repair facilities is available from the manufacturer.
DO NOT CRAWL UNDER ENGINE OR PLACE
ANY PART OF YOUR BODY UNDER ENGINE AT
ANY TIME DURING MOUNTING OF ENGINE,
USE OF STAND, OR REMOVAL OF ENGINE.
FEATURES
Sturdy Tubular Steel Construction for Strength
Multi-Position Locking Mount
Adjustable Locking Mechanism Allows 360°
Rotation of Engine
T-Shaped Designed for Added Stability
4 Wheel Design
ASSEMBLY INSTRUCTIONS
1. Bolt front leg (#4) to base connector (#2) using (2)
3/8" x 2-1/2" Hex Bolts (#22), (2) 3/8" washers
(#21), (2) 3/8" lock washers (#20) and (2) 3/8"
nuts (#19). Bolt from outside towards center of
engine stand.
2. Bolt rear leg (#3) to base connector (#2) using (2)
3/8" x 2-1/2" Hex Bolts (#22),(2) 3/8" washers
(#21), (2) 3/8" lock washers (#20) and (2) 3/8"
nuts (#19).
3. Insert post (#1) into post tube on base connector (#2)
using a 1/2" x 4" full thread bolt (#25). Screw into
welded nut on post tube, through post (#1) until tight.
4. Insert head (#5) into rotator tube on top of post.
Tighten with 1/2" x 1" hex head bolt (#16) screwed
into rotator tube.
5. Insert handle (#8) through rear of head tube.
6. Place grips (#9) on both ends of handle.
7. Attach fingers (#6,7) to head plate using (4) 1/2" x
3" hex head bolts (#23), (4) washers (#24) and (4)
nuts (#18).
SPECIFICATIONS
Capacity................................................................750 Lbs.
Length....................................................................32-1/2"
Width....................................................................28-1/2"
Height ..........................................................................38"
Shipping Wt. ..........................................................59 Lbs.
▲
▲▲ ▲▲

8750 Rev. 4/21/03
Item Part
No. No. Description Qty.
1Post 1
2Base Connector 1
3Rear Leg 1
4Front Leg 1
5RS530056 Head 1
6RS500091 Short Finger 2
7RS500092 Long Finger 2
8RSESHDL Handle (incl. grips) 1
9Grip 2
10 RSW301 3" Wheel 2
11 RSSC301A 3" Swivel Caster 2
*12 5/16" x 3/4" Hex Bolt 8
*13 5/16" Lock Nut 8
Item Part
No. No. Description Qty.
*14 3/8" x 2-1/2" Hex Bolt 2
*15 3/8" Washer 6
*16 1/2" x 1" Hex Bolt 1
*17 3/8" Lock Washer 2
*18 1/2" Hex Nut 4
*19 3/8" Hex Nut 6
*20 1/2" Lock Washer 4
*21 1/2" Washer 4
*22 3/8" x 2-1/2" Hex Bolt 4
*23 1/2" x 3 Hex Bolt 4
*24 1/2" Flat Washer 4
*25 1/2" x 3-1/4" Hex Bolt 1
*26 5/16" Washer 8
*These parts available in Bolt Kit #RS8750BK (includes items12 - 26).
LIMITED WARRANTY:
SUNEX INTERNATIONAL, INC. WARRANTS TO ITS CUSTOMERS THAT THE COMPANY’S SUNEX TOOLS®
BRANDED PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS.
Sunex International, Inc. will repair or replace its Sunex Tools®branded products which fail to give satisfactory
service due to defective workmanship or materials, based upon the terms and conditions of the following
described warranty plans attributed to that specific product.
This product carries a ONE-YEAR warranty. During this warranty period, Sunex Tools will repair or replace at our
option any part or unit which proves to be defective in material or workmanship.
Other important warranty information...
This warranty does not cover damage to equipment or tools arising from alteration, abuse, misuse, damage and
does not cover any repairs or replacement made by anyone other than Sunex Tools or its authorized warranty
service centers.
The foregoing obligation is Sunex Tools’ sole liability under this or any implied warranty and under no
circumstances shall we be liable for any incidental or consequential damages.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Return equipment or parts to Sunex Tools, transportation prepaid. Be certain to include your name and address,
evidence of the purchase date, and description of the suspected defect.
If you have any questions about warranty service, please write to Sunex Tools. This warranty gives you specific
legal rights and you may also have other rights which vary from state to state.
Repair kits and replacement parts are available for many of Sunex Tools products regardless of whether or not
the product is still covered by a warranty plan.
Shipping Address: Sunex Tools • 315 Hawkins Rd. • Travelers Rest, SC 29690
Mailing Address: Sunex Tools • P.O. Box 4215 • Greenville, SC 29608

8750 Rev. 4/21/03
MODEL #8750
750 Lb. Capacity Engine Stand
