Sunfire OLE-2SF User manual

2
Safety
WARNING – TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
Important Safety Instructions
1. Read Instructions
2. Keep these Instructions
3. Heed all Warnings.
4. Follow all Instructions
5. Do not use this apparatus near
water.
6. Clean only with dry cloth.
7. Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
ampliers) that produce heat.
8. Refer all servicing to qualied ser-
vice personnel. Servicing is required
when the apparatus has been dam-
aged in any way, such as a cord or
plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
9. The apparatus should only be
connected to equipment of the type
described in these operation instruc-
tions or as marked on the apparatus.
10. Object and Liquid Entry — Care
should be taken so that objects do
not fall into and liquids are not spilled
into the inside of the apparatus.
11. Servicing — The user should not
attempt to service the apparatus
beyond those means described in
this operating manual. All other ser-
vicing should be referred to qualied
service personnel.

Contents
Important Safety Instructions......................2
Introduction ................................................. 4
Features...................................................... 7
System Design, Installation and
Connections.............................................. 10
Connectors/Pinout ................................. 12
System Connections.............................. 16
Programming ............................................ 18
Feature Enable/Disable ............................ 19
Specications............................................ 20
Troubleshooting ........................................ 21
Warranty ...................................................23
Service Assistance.................................... 23
3
For more information on this and other Sunre
products, please visit our website:
www.sunre.com
Introduction Features System Program

Introduction
The Olé®-2SF Film Interactive
Touchpad (FIT) is a revolutionary
in-wall controller for your Sunre
receiver or processor. Using a
photographic lm overlay instead of
hard buttons, it marries the beauty
of a touchscreen with the simplicity
of a keypad –seamlessly controlling
all major functions of your home
theater or secondary room.
The backlit lm transparency
provides system control icons and
functions, while a 4-line 2" color
OLED displays multiple pages of
source control and feedback to the
user. Multiple IR commands, or
‘Sequences’, can be issued from a
single press of any button. Program-
ming is accomplished with Sunre’s
SunTools™ setup software, and is
done through a direct link from a
computer to the mini-USB download
port on the front of the Olé-2SF.
Each button location (or “hot
spot”) is assigned a command
that controls sources such as
A/V equipment, HVAC systems,
drapes, shades, lighting systems,
or even replaces! Your Olé-2SF is
congured out of the box to control
your Olé-ready Sunre receiver or
processor’s Zone 2 output. Custom-
programming by your authorized
Sunre dealer will allow recongur-
ing of the Olé-2SF to control the
main theater system and a variety of
functions required for your specic
system.
Unpacking
Your Olé-2SF touchpad should
reach you in perfect condition. If
you do notice any shipping damage,
please contact Sunre immediately.
Gently lift out the touchpad and all
the packing material. It is important
to save all the packing materials and
the box in case your touchpad ever
needs to be moved or shipped for
repair.
Make sure that you keep your
sales receipt. It is the only way
to establish the duration of your
Limited Warranty and it may come in
useful for insurance purposes.
4

Features
• Plug-and-play. Right out of the
box, the Olé-2SF controls Zone
2 on Olé-ready Sunre receivers
and processors
• Simple SunTools™ PC program-
ming for customization
• Sunre Optimized™ graphics and
programming
• Full touchpad design, with no hard
buttons
• Two inch color OLED (Organic
LED)
• Two-way feedback for artist/song
data from SIRIUS satellite radio
and VIA!migo™ iPod® cradle
• Automatic brightness-adjusting via
light sensor
• Audible ‘click’ to indicate a button
press (can be disabled in soft-
ware)
• Built-in IR receiver for passing IR
commands back to the main room
• Connectivity for Local IR Output
and Remote IR Receiver
• Virtually unlimited IR command
sequences issued from any button
press
• System sense sequence capabil-
ity
• Fits in a double-gang electrical
box
• Stylish Euro wall plate in optional
colors
• Patent pending design
Care
If your Olé-2SF touchpad needs
servicing, please read the Trouble-
shooting section on page 21. If a
problem persists, please contact
your nearest authorized Sunre
Dealer.
Please take a moment to ll out
and mail the Sunre Customer Re-
sponse card. Also record the serial
number and your details here:
5
Serial Number:
Purchased from:
Date:

Installation & Usage Tips
• When properly installed, nothing
should be applying contact pres-
sure to the touchpad except for
the operator’s nger. If something
is touching the touchscreen
window, a false signal can be
generated causing the touchpad
not to respond to a nger press
(Sunre does not recommend
wrapping the removable frame
with wallpaper as this can cause
the aforementioned symptom).
Too much force on the front of the
touchpad, or concentrated pres-
sure, can damage the polyester
lm or break the underlying glass
plate.
• Avoid installation in direct sunlight
or strong ultraviolet light (such
as grow lamps, plant lights, or
compact uorescent lights). This
can degrade and discolor the
polyester lm.
• Avoid installation over heat
generating devices and/or in moist
areas where condensation can
form on the polyester lm. Both
heat and condensed moisture can
affect touch screen performance.
• Avoid installation next to thermo-
stats. The touch screen generates
heat that can affect thermostat
control and readings.
• Avoid applying any foreign ob-
jects, such as adhesive labels, on
the touchscreens polyester lm.
This can release chemicals that
can discolor the clear lm.
• The touchpad should not be
mounted near electronics that
emit radio frequencies or elec-
tromagnetic interference (such
as the deection circuits of CRT
monitors, light dimmers, and some
power supplies)
• The edge of the touchpad has
exposed sharp glass. Be careful
when handling the assembly in
order to avoid injury.
Cleaning the touch screen
To clean the polyester lm, rst
use a soft dry cloth to remove
contamination. If dust or smudges
are still present, disconnect the
touchpad, and use a damp cloth
that has been squeezed of excess
water to remove the contaminant. If
contaminants are still present, use
a non-abrasive cleaner or detergent
to clean the polyester lm. Use
of strong chemicals and/or some
cleaning agents may discolor the
polyester lm. The following cleans-
ers have been tested and approved
for cleaning an Olé-2SF touchpad:
• Windex® Glass Cleaner
• Formula 409® Cleaner
• Mr. Clean®
6

Features
1. Mounting Screw (x 4)
Use these screws to mount the
touchpad into a standard 32 cu in.
double-gang electrical box.
2. Program Button
This button is for future use.
3. Light Sensor
When this sensor is enabled, the
Olé-2SF backlight will brighten
or dim depending on the room's
ambient light conditions. Do not
cover the small hole (3a) in the
wall plate.
1 1
1 1
4
3
2
4. Download Port
This mini USB download port is
used to program the touchpad, by
connecting it to the USB port of
a PC, using a standard USB-A to
USB-mini-B cable.
5. Wall plate
This stylish wall plate clips over
the top panel once the touchpad
has been installed into a double-
gang electrical box. It can be
easily removed to access the
download port.
Top Panel
7
5
3a

8
11
910
12
12
6
5
13
5. Power
Turns system audio on and off.
6. System
Bass/Treble control and other
system options.
7. Home
This toggles between the main
source selection screen and the
current source control.
8. Source selection
View/change the source selection
pages.
9. Display
This display is used for source
selection and system information
such as the artist/song data from
SIRIUS satellite radio and the
VIA!migo™ iPod® dock.
10.Volume up/down
Adjust the volume in your system.
11. Mute
Mute the sound in your system.
12.Page up/down
Page through different sources, or
control pages within a source.
13.Navigation buttons
Controls various functions on
source components depending on
programming.
Touchpad display
7
8

14. Z•NET/VIA!NET
Switch
You must set this switch to
VIA!NET for use with Sunre
receivers and processors.
15.System RJ-45 Jack
Connect this jack with Cat-5 cable
to the TP1 or TP2 RJ-45 con-
nectors on the rear panel of your
Sunre receiver or processor.
16.Local IR Port
This port allows the connection of
local IR emitters and IR receivers,
local contact switches etc. See
pages 13–15 for connections.
14 15 16
Rear Panel
9

System Design, Installation and
Connections
Planning
Before installing the Olé-2SF, it is
essential to have a detailed and ac-
curate system design. An authorized
Sunre installer should be con-
tracted for proper installation and
programming of your touchpad. The
rst step to a good design is to map
the system. It is advisable to mark
up a copy of the house oor plan
with speaker, keypad, touch panel,
volume control, and equipment
locations etc. Make sure that all
locations are decided upon before
pre-wiring commences, so that all
necessary wiring and installation
hardware is in place.
It is essential that ALL system
components are accounted for prior
to the pre-wire stage. After estab-
lishing design goals, make a de-
tailed list of all components. Include
source equipment, keypads, touch
panels, volume controls, ampliers,
communications gear, etc. Gather
up any IR remote controls that may
be necessary for nal programming,
or ensure that the IR codes for all
equipment to be installed are avail-
able in the SunTools IR Library.
Installation
The Olé-2SF is designed to t into
a standard 32 cu. in. double-gang
electrical box. Consult local building
codes for specics in your geo-
graphic area. Note that the Olé-2SF
is not designed for outdoor use.
Pre-Wire
The Olé-2SF requires power,
control, and status to function cor-
rectly. Each touchpad has an RJ-45
jack on the back to allow for easy
connection. Run Cat-5 wire from the
receiver/processor location (head-
end) to the location where each
touchpad will be installed.
Note: Use of wire other than Cat-5
may produce undesired results (IR
bandwidth may be narrowed or
interference may occur).
Warning: Never connect
the Olé-2SF Cat-5 cable to
computer Ethernet or LAN
systems, DSL routers etc.
Make sure that Cat-5 cable
used with the Olé-2SF is clearly
marked to avoid any confusion.
Note: Maximum wire run is 500
feet.
10

Rough-In
Roughing-in the Olé-2SF requires
careful attention to the design plan
made previously. Review the previ-
ous page and make a list of things
to factor in to specic mounting loca-
tions, before deciding exactly where
to place the unit. In order to avoid
Electro-Magnetic Interference (EMI),
do not mount touchpads close to
light dimmers. Leave at least one
stud-bay open between touchpads
and dimmers (leave more space if
multiple dimmers are present). Avoid
installing Olé-2SF touchpads in ar-
eas that will receive direct sunlight.
Sunlight can ood the IR receiver
and make the system inoperative.
Do not mount touchpads outdoors!
Corrosion will damage them. Sunre
does not warrant Olé touchpads for
outdoor use.
Mounting Height
The Olé-2SF has no viewing
angle limitations, so mounting
height should be determined by the
average height of the user. Typical
mounting height is 56-60 inches
from the oor to the bottom of the
frame. This will provide optimum
viewing for the largest number of
people.
11

Connectors/Pinout
The Olé-2SF has a system RJ-45
connector and a ve-pin Interface
Port connector which each perform
specic functions. All applications
use the RJ-45 connector, while
certain situations will require the use
of the Local interface port.
RJ-45 Connector
Use Cat-5 cable to connect the
Olé-2SF to a Sunre receiver or pro-
cessor. The Sunre standard pinout
conguration is shown below.
12
Sunre TGR-401 Theater Grand Receiver

Local IR Interface Port
Use this connector when utilizing
the Olé-2SF’s local control features,
such as local source control, local
IR sensors, or sense-enabled auto-
mated sequences.
Warning: The connection
labeled “+12 Volts Out” is a
voltage output. Do not con-
nect a power supply to this
connection!
IR-Emitter Out
The Local IR-EMITTER OUT is
typically used to control a device
that is not part of the main IR
system, such as a TV or DVD player
located within the same room as
the touchpad or electronic volume
controls. IR is routed to an emitter
or IR distribution block connected to
the Local IR output in two ways:
1. Any IR signal that is received from
the Local IR-RECEIVER IN is sent
out both the Local IR-EMITTER
OUT and the system IR output.
2. IR signals may be specied in
programming as “Local” and be
routed through the Local IR-EMIT-
TER OUT.
Connect IR-EMITTER OUT and
-GROUND as shown here.
Controlling a single local device
Controlling multiple local devices
13

Local IR Input
The Local IR-RECEIVER IN is
typically used to connect an external
IR sensor to the touchpad. Typical
applications include a plasma-
friendly IR sensor placed near a TV,
or an auxiliary IR sensor placed in
an area more convenient than the
location of the touchpad. IR signals
that are received by the IR Input are
sent out both the Local IR-EMITTER
OUT and the System Port.
Connect IR-RECEIVER IN,
-GROUND and +12VOLTS OUT (if
required) as shown below. Consult
the instruction manual that came
with your external equipment
before making connections.
Note: In certain cases, the built-in
IR sensor on the Olé-2SF can be
ooded with plasma TV interference
or other ambient light interference.
In this case, connect a plasma-
friendly IR sensor to the Local IR
Input and disable the built-in IR
sensor in SunTools.
14

Local Sense In
The LOCAL SENSE IN port allows
a contact-closure to trigger IR se-
quences programmed into the Olé-
2SF using SunTools. Use a motion
sensor to activate a contact-closure
and cause automated actions such
as system power on, drapes closed,
and lights dimmed, for example.
Connect LOCAL SENSE IN and
-GROUND to a contact-closure
device as shown below.
Contact-Closure
Device
15

System Connections
Zone 2 Control
The most common application
(and default conguration out of
the box) is to use your Olé-2SF as
a Zone 2 controller. Without any
programming you will be able to:
• Select Zone 2 sources
• Adjust Zone 2 volume (with feed-
back)
• Control the AM/FM/SIRIUS tuners
(with RDS and metadata feed-
back)
• Basic control of VIA!migo iPod
cradle (with metadata feedback)
• Adjust Zone 2 bass and treble
CAT-5
ZONE 2 SPEAKERS
ZONE 2 Olé-2SF
USE EITHER
CONNECTION
NOTE: The two TP (touchpad)
ports on your Sunre receiver or
processor are identical.
All programming is stored in the
Olé-2SF, so to recongure your
Olé-2SF to control the main zone, or
to add source IR control (play/stop/
pause on a CD player, for example),
you will need to connect the Olé-
2SF to your PC for programming.
16

CAT-5
USE EITHER
CONNECTION
MAIN ZONE SPEAKERS
MAIN ZONE Olé-2SF
Home Theater Control
(PC required)
The Olé-2SF is perfectly suited as
an in-wall Home Theater controller.
You may want to include one by the
entrance to startup or shutdown the
system. In this case, you will need
to connect your Olé-2SF to a PC
running SunTools to recongure it
to control the main zone. The main
zone template allows you to control
the following:
• Select Main Zone sources
• Adjust Main Zone volume (with
feedback)
• Control the AM/FM/SIRIUS tuners
(with RDS and metadata feed-
back)
• Basic control of VIA!migo iPod
cradle (with metadata feedback)
• Adjust Main Zone bass and treble
• Select DSP modes
• Control OSD menu functions
NOTE: Of course you can go
wild with custom programming - the
above functions are simply included
in the default template and repre-
sent the most commonly needed
functions.
17

Programming
The Olé-2SF must be pro-
grammed with Sunre’s SunTools
setup software using a PC running
Windows XP. Downloads are facili-
tated through the USB download
port on the front of the unit.
Note: A standard USB-A to USB-
mini-B cable must be utilized for
programming and is not included
with the Olé-2SF.
To download a SunTools
project:
• Ensure that your PC is running
the latest version of SunTools
software. Visit sunre.com for
software downloads and updates.
• Remove the wall plate to access
the USB download port.
• Connect a standard USB-A to
USB-mini-B cable between a
USB port on the PC and the USB
download port on the front of the
Olé-2SF touchpad.
• Navigate to the SunTools Olé
transfer page to begin the transfer.
• Wait until “DONE OK” is displayed
on the Olé-2SF’s screen before
disconnecting the USB cable from
the USB Download Port.
USB download port
Laptop running
SunTools
USB-A to USB-mini-B cable
18

Feature Enable/Disable:
Speaker
The Olé-2SF contains a small
speaker that allows audible feed-
back signals to be heard as a result
of button pushes. This feature can
be disabled in the SunTools setup
software.
IR Sensor
The Olé-2SF features a built-in IR
Sensor. IR signals from a hand-held
IR remote control pass through the
IR sensor and travel to the head-
end location where they control
IR sources located there. These
sources may be connected to a 3rd-
party Multi-Zone Controller or an IR
distribution network.
The IR Sensor can be disabled in
SunTools setup software.
Light Sensor Enable/Dis-
able
The Olé-2SF touchpad has a light
sensor feature.
1. Install the unit in the wall, using
the wall plate that will be used in
the nal installation.
2. Adjust the room lighting to the
brightest setting possible.
3. Select a source on the touchpad.
The light sensor function only
works when the unit displays the
source icon screen.
4. Press and hold the "SELECT" but-
ton for ve seconds. Depending
on the correct state of the sensor,
a message will be displayed:
“Release button to ENABLE
sensor”
or
"Release button to DISABLE
sensor"
Once the button is released, a
conrmation message will be sent:
Either:
"LIGHT SENSOR ENABLED"
or
"LIGHT SENSOR DISABLED"
When the Light Sensor is enabled,
the Olé-2SF touchpad's backlight
will brighten or dim depend-
ing on the room's ambient light
conditions. When the sensor is
disabled, the Olé-2SF remains at
full brightness no matter what the
ambient light conditions are like.
19

Specications
Viewing Angle
180° up/down,180° left/right
Operating Temp
32°F-104°F / 0°C-40°C
OLED Display
Type: 2” Organic LED (OLED)
Colors: 252K
Resolution: 160 pixels (W) x 128
pixels (H)
Connections
System Port: RJ-45
Interface Port: 5-position screw
terminal
Download Port: Mini USB
Wiring Requirements
Cat-5
Power Requirements
12VDC/150mA or 16VDC/150mA
Power Consumption
Each Olé-2SF touchpad draws
150mA in either 12V or 16V mode
Dimensions
With Wall Plate
Height 4 5/8" (117 mm)
Width 4.5/8" (117 mm)
Depth 1 3/16" (30 mm)
Without Wall Plate
Height 4 7/16" (112 mm)
Width 4. 7/16" (112 mm)
Depth 1 1/8" (26 mm)
Fits into a 32 cu in. double-gang
electrical box
Weight
14 oz./0.4kg
Shipping Weight
16 oz./0.45kg
20
© 2008 Sunre, LLC.
All rights reserved. Sunre, LLC re-
serves the right to improve its products
at any time. Therefore, specications
are subject to change without notice.
Manual 913-144-00 Rev A
