SUNFLEX SCREENLITE 104105 User manual

SUN-FLEX®SCREENLITE
www.sun-ex.comwww.sun-ex.com
Enjoy
your
product
# 4 # 1

Installation Operation
Parts & description Specications
Install the light bar Connect power
Uninstall the light bar
Shade
DC input
Install and uninstall the
light bar as shown.
Please push the button.
Push the button to install
or uninstall
Measurement
80cm
48cm
1.9cm
2.2cm
72cm
17.5cm
Clip gap: 1.5-4.5cm (max)
6500K
DAY LIGHT
ILLUMINANCE (LUX)
WORKING
HEIGHT
4000K
NEUTRAL LIGHT
3000K
WARM LIGHT
30CM 2600LUX 2300LUX 2000LUX
40CM 1700LUX 1600LUX 1465LUX
45CM 1300LUX 1200LUX 1100LUX
50CM 1200LUX 1100LUX 1000LUX
57CM 950LUX 900LUX 800LUX
70CM 625LUX 575LUX 500LUX
• CCT setting: 3000/4000/6500K or stepless
• Dimmable: 10/20/50/70/100% or stepless
• Light source: Samsung LED
• Consumption: 12W
• Touch controls: Yes
• Surrounding light sensor: Yes
• Anti-glare diuser: Yes
• Certicates: CE, RoHS
• Packaging: Single, 12 units in transportation
• Art.no.: 104105, SUN-FLEX®SCREENLITE, black
(GTIN13: 7350042900756)
Touch the top button
for functions
Stepless dimmable
Light sensor
CCT change Light sensor switch
On/o: Touch to turn lamp on/o. Keep touching for 3 seconds to activate timer.
Lamp will turn o automatically after 2 hours.
Light sensor: Press once to adjust the light automatically to the surroundings.
When the indicator is blue, the function is on.
1. Touch once to turn the function on / o
2. When the function is on, the lamp adjusts automatically:
- If the surroundings become brighter, the lamp gradually becomes darker
- If the surroundings become darker, the lamp gradually becomes brighter
3. To deactivate the function, there is two optional methods:
- Touch the function button
- or touch the dimmable button
CCT change: Touch the button once to change the color temperature in step from
3000-4000-5000-6500K; Keep touching the button to change the color
temperature steplessly.
Dimmable: Touch the button once to adjust the brightness in step from
10%-25%-50%-70%-100%; Keep touching the button to adjust the brightness steplessly.
On/o
# 2 # 3
