sunjoe SNOWJOE 24V-SS11-CT User manual

EN
© 2020 by Snow Joe®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
A Division of Snow Joe®, LLC Model 24V-SS11-CT Form No. SJ-24V-SS11-CT-880E-MR2
OPERATOR’S MANUAL
RCORDLESS SNOW SHOVEL – TOOL ONLY
24V MAX* | 11-INCH
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all instructions before using this cordless snow shovel.
Basic safety precautions should always be followed to reduce
the risk of re, electric shock and personal injury.
General Safety WARNINGS!
You and any other operator of this snow shovel must read,
understand and follow these instructions in their entirety, and
should reread them at the start of each snow season. Failure
to follow these instructions may result in ELECTRIC SHOCK,
FIRE and/or serious PERSONAL INJURY.
Notice the personal safety alert symbol mused in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION and
AWARENESS.
1. Keep work area clean and well lit – Cluttered, dark areas
invite accidents.
2. Use the right product – Do not use this machine for any
job except that for which it is intended.
3. Replacement parts – When servicing this unit, use only
identical replacement parts. Replace or repair damaged
cord immediately on the charger.
Do not use on gravel surfaces unless the snow shovel
is adjusted for such surfaces in accordance with the
operator’s manual.
4. Keep children, bystanders and pets away –
All spectators, including pets, should be kept a safe
distance away from the work area.
5. Dress properly – Do not wear loose articles of clothing or
jewelry. They can become caught in moving parts.
Wear rubber boots.
6. Avoid accidental starting – Make sure the safety
switch and the trigger switch are in the o position
before inserting the battery in the unit. Do not carry the
cordless snow shovel with the safety switch and the
trigger switch engaged.
7. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
8. mCAUTION! Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
9. Use safety glasses – Also use safety footwear,
snug-tting clothing, protective gloves, hearing and head
protection.
10. Stay alert – Watch what you are doing. Use common
sense. Do not operate the cordless snow shovel when you
are tired or under the inuence of alcohol or drugs.
11. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it was designed.
12. Do not overreach – Keep proper footing and balance at
all times.
13. If the cordless snow shovel strikes a foreign object,
follow these steps:
• Stop the cordless snow shovel. Remove the battery.
• Inspect for damage.
• Repair any damage before restarting and operating
the snow shovel.
14. Disconnect the tool – Turn o the power switch and
remove the battery when it is not in use, before servicing
it, when changing accessories and when performing any
other maintenance task.
15. Store idle tool indoors – When not in use, the cordless
snow shovel should be stored indoors in a dry,
locked place out of the reach of children.
16. Maintain the cordless snow shovel with care –
Follow the applicable maintenance instructions for
replacing parts and changing accessories. Lubrication is
not required.
mThis is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
Improperly using or maintaining this cordless snow
shovel could result in injury or death. To reduce
this potential, comply with the following safety
instructions.
This cordless snow shovel can amputate hands and
feet if used incorrectly. It can also pick up foreign
objects, which can become dangerous projectiles
when thrown into the air. Failure to observe the
following safety instructions could result in serious
personal injury.
1

2
Training
• Read, understand and follow all instructions on the machine
and in the manual before operating this unit. Thoroughly
familiarize yourself with the controls and the proper use of
the equipment. Know how to stop the unit and disengage
the controls quickly.
• Children should never be allowed access to the equipment.
Adults should never operate the equipment without
carefully reading and understanding these instructions.
• Keep the area of operation clear of all persons, particularly
small children and pets.
• Exercise caution to avoid slipping or falling.
Preparation
• Thoroughly inspect the area where the equipment is to be
used and remove all doormats, sleds, boards, wires and
other foreign objects.
• Do not operate the equipment without wearing adequate
winter garments. Avoid loose tting articles of clothing that
can become caught in moving parts. Wear footwear that will
improve footing on slippery surfaces.
• Do not attempt to clear snow from a gravel or crushed
rock surface. This product is intended for use only on
paved surfaces.
• Never attempt to make any adjustments while the motor
is running (except when specically recommended by the
manufacturer).
• Always wear safety glasses or eye shields during operation
or while performing an adjustment or repair to protect your
eyes from foreign objects that may be thrown from the
machine.
Operation
• Do not put hands or feet near or under rotating parts.
Keep clear of the discharge opening at all times.
• Exercise extreme caution when operating on or crossing
gravel drives, walks or roads. Stay alert for hidden hazards
or trac.
• After striking a foreign object, stop the motor. Thoroughly
inspect the cordless snow shovel for any damage, and
repair the damage before restarting and operating the
cordless snow shovel.
• If the unit should start to vibrate abnormally, stop the motor
and check the unit immediately to ascertain the cause.
Vibration is generally a sign of trouble.
• Stop the motor and remove the battery whenever you leave
the operating position, when transporting the unit, before
unclogging the rotor blade housing and when making any
repairs, adjustments or inspections to the unit.
• When cleaning, repairing or inspecting the cordless snow
shovel, make sure that all moving parts have come to a
complete stop before beginning work.
• Exercise extreme caution when operating on slopes.
• Never operate the cordless snow shovel without proper
guards and other safety devices in place and in proper
working order.
• Never direct the discharge toward people or areas where
property damage can occur. Keep children, pets and other
bystanders away from the work area.
• Do not overload the machine capacity by attempting to
clear snow at too fast a rate.
• Look behind and use care when backing up with the
cordless snow shovel.
• Never operate the cordless snow shovel without good
visibility or light. Always be sure of your footing, and keep
a rm hold on the handles. Walk, never run, with the unit.
Clearing a Clogged Rotor Housing
Hand contact with the rotating rotor blades inside the rotor
housing is the most common cause of injury associated
with cordless snow shovels. Never use your hands to clear a
clogged rotor housing.
To clear the rotor housing:
• Shut the motor o and remove the battery.
• Wait 10 seconds to be sure the rotor blades have come to a
complete stop.
• Always use a clean-out tool, not your hands, to free the
rotating blades.
Maintenance and Storage
• Check all fasteners at frequent intervals for proper tightness
to ensure that the equipment is in safe working condition.
• Always refer to the operator's manual for important details,
such as how to properly store your cordless snow shovel
for an extended period of time.
• Maintain or replace safety and instruction labels as needed.
• Run the machine a few minutes after throwing snow to
prevent the rotor blades from freezing.
Battery + Charger
Safety Instructions
NOTE: This unit is a tool only. The battery and the charger are
not included. They must be purchased separately.
Model 24V-SS11-CT is compatible with the iON+ 24V System
batteries and chargers. See page 14 for more information.
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.

3
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the cordless snow shovel and
cause it to malfunction, which can lead to serious personal
injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
iON+ 24V lithium-ion battery pack only in its designated
iON+ 24V lithium-ion lithium-ion charger. Other types of
chargers present risk of re, personal injury and damage.
Do not wire a battery pack to a power supply plug or car
cigarette lighter. Such misuse will permanently disable or
damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is
41°F – 105ºF (5°C – 40.5°C). Do not charge the battery
outside in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger,
pull the plug, not the cord, from the receptacle to reduce
the risk of damage to the electrical plug and cord.
Never carry the charger by its cord or yank it by the cord
to disconnect it from the receptacle. Keep the cord away
from heat, oil and sharp edges. Make sure the cord will not
be stepped on, tripped over or subjected to damage or
stress when the charger is in use. Do not use the charger
with a damaged cord or plug. Replace a damaged charger
immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
•Check the rated input for the charger before using –
The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery packs
are burned.
• Do not crush, drop or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If a
damaged battery pack leaks battery chemicals, use rubber
or neoprene gloves to safely dispose of it. If skin is exposed
to battery uids, wash the aected area with soap and
water and rinse with vinegar. If eyes are exposed to battery
chemicals, immediately ush with water for
20 minutes and seek medical attention. Remove and
dispose of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool,
dry place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
2. Store the battery pack in a cool place, ideally at
77°F (25°C) and charged fully.

4
3. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your snow shovel,
and therefore pose a safety risk.
4. Do not throw battery packs into an open re as this poses
a risk of explosion.
5. Do not ignite the battery pack or expose it to re.
6. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
7. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not
apparent externally.
8. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
9. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
10. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C).
In particular, do not leave the battery charger in a car that
is parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect

5
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage.
8. Prevent the lithium-ion battery pack from freezing.
Battery packs that were stored below 32°F (0°C) for more
than 60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.

6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on the machine before attempting to assemble and operate.
The rotating part will continuously
run for several seconds after you
turn o the machine.
READ THE OPERATOR'S
MANUAL(S) – Read, understand
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning or a danger.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Keep bystanders and children a
safe distance (at least 11 yd/10 m)
away from the work area.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
CAUTION! Beware of stones and
other foreign objects that could
be thrown from the appliance.
DANGER! Cutting/dismemberment
hazard - Keep hands away from the
rotating auger. Do not use hands to
unclog rotor housing. Stop motor
before removing debris.
DANGER! Cutting/dismemberment
hazard - Keep feet away from the
rotating auger.
Symbols SymbolsDescriptions Descriptions
Indoor use only. Only use
battery charger indoors.
Do not use hands to unclog chute.
Keep hands, feet and clothing
away from the rotating auger to
avoid injury.
Wear safety gloves during use to
protect hands.
Wear safety footwear at all times to
provide protection against objects
that may accidentally fall on feet.

7
Know Your Cordless Snow Shovel
Read the owner’s manual and safety rules carefully before operating your cordless snow shovel. Compare the illustration
below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
1. Upper handle
2. ON/OFF trigger switch
3. Battery compartment
4. Joint-xing knob and bolt (2)
5. Handle knob
6. Middle pole
7. Lower pole
8. Motor housing
9. Scraper blade
10. Shovel blade
11. Auxiliary handle
12. Upper pole
13. Safety switch
1
2
3
4
5
6
10
THE OTHER SIDE
THE OTHER SIDE
8
9
12
13
7
11
SOLD
SEPARATELY
Battery + Charger
options available at
snowjoe.com
24VBAT
24VBAT-LTE 24VBAT-LT
24VBAT-XR
24VCHRG-QC
24VCHRG-DPC

8
Technical Data
Motor......................................................................400 W brush
Battery Voltage Max*................................................... 24V D.C.
Battery Capacity .................................. See page 14 for battery
options and specications
Battery Runtime Max ........................... See page 14 for battery
options and specications
No Load Speed .......................................................... 2500 rpm
Rotor ....................................................... 2-blade paddle auger
Clearing Width ......................................................11 in. (28 cm)
Depth of Snow Cut ............................................. 7 in. (17.8 cm)
Throw Distance Max .................................................. 20 ft (6 m)
Plowing Capacity Max .............................................. 74 lbs/min
(33 kg/min)
Net Weight .............................................................9 lbs (4.1 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless snow shovel upper pole assembly
• Cordless snow shovel lower pole assembly
• Middle pole with auxiliary handle
• Joint-xing knob and bolt (2 sets)
• Manuals with registration card
NOTE: In order to operate this cordless snow shovel you will
need iON+ 24V System batteries and chargers. See page 14 for
battery options and specications, or visit snowjoe.com.
1. Carefully remove the cordless snow shovel and check to
see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless snow
shovel. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils
or small parts. These items can be swallowed and pose a
suocation risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, insert the battery into the charger and charge as
needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
In order to operate this cordless snow shovel you will need
a iON+ 24V System battery and charger. See page 14 for
battery and charger options and specications, or for more
information visit snowjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

9
Charger Operation
mWARNING! Charge only iON+ 24V lithium-ion battery
packs with its compatible iON+ 24V lithium-ion charger. Other
types of batteries may cause personal injury and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24V
Lithium-Ion Battery
NOTE: The iON+ 24V lithium-ion battery packs do not develop
a "memory" when charged after only a partial discharge.
Therefore, it is not necessary to run down the battery pack
before placing it into the charger.
• Use the battery charge indicator lights to determine when to
charge your iON+ 24V lithium-ion battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Press the push lock buttons on the battery to pull the
battery pack out of the equipment (Fig. 1).
2. Depending on your Snow Joe®+ Sun Joe®charger
model, how to recharge your lithium-ion battery will vary.
You may either insert your 24-volt battery into the
24VCHRG-QC Quick Charger (sold separately) or the
24VCHRG-DPC Dual Port Charger (sold separately)
(Figs. 2 – 3).
3. The battery indicator LEDs will illuminate one by one
during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
4. The 24VCHRG-QC Quick Charger (sold separately) and
the 24VCHRG-DPC Dual Port Charger (sold separately)
are also equipped with additional charging indicating
lights which will indicate the charging status (Figs. 2 – 3).
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery.
mWARNING! The chargers do not automatically turn
owhenthebatteryisfullycharged.Please take care not
toleavethebatterypluggedintothecharger.Switchoor
unplug the charger at the mains when charging is complete.
In order to operate this cordless snow shovel you will need
a iON+ 24V System battery and charger. See page 14 for
battery and charger options and specications, or for more
information visit snowjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Fig. 1
Push lock button
Fig. 2 Battery pack
24VCHRG-QC
quick charger
(Sold separately)
red
Charging
green
Fully
Charged
Fig. 3 Battery pack
24VCHRG-DPC
dual port charger
(Sold separately)
red
Charging
green
Fully
Charged

10
5. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
6. When charging is complete, remove the battery from the
charger by pulling the push lock button and sliding the
battery backward to unlock it from the charger.
Assembly
Connecting the Poles
1. Slide the middle pole into the lower pole assembly.
Align the screw holes (Fig. 4).
2. Insert the bolt through the square hole in the pole and
secure the other end with the joint-xing knob (Fig. 5).
Twist until tight.
NOTE: You may have to carefully move the wiring inside
the tube to one side if it blocks the path of the bolt.
3. Slide the upper pole assembly onto the middle pole.
Align the screw holes (Fig. 6).
4. Insert the bolt through the square hole in the pole and
secure the other end with the joint-xing knob (Fig. 7).
Twist until tight.
Operation
mWARNING! Keep the area to be cleared free of stones,
toys or other foreign objects that the rotor blades might pick
up and throw. Such items could be covered by snow and are
easy to overlook, so be sure to conduct a thorough inspection
of the area before beginning work.
Fig. 4
Middle pole
Lower pole
assembly
Fig. 5
Joint-xing
knob Bolt
Fig. 6
Upper pole
assembly
Middle pole
Fig. 7
Joint-xing
knob Bolt
Square hole
In order to operate this cordless snow shovel you will need
a iON+ 24V System battery and charger. See page 14 for
battery and charger options and specications, or for more
information visit snowjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY

11
Starting the Machine
1. Slide the battery down in the battery compartment until it
clicks to lock it into position (Fig. 8).
2. To start the cordless snow shovel, push and hold the
safety lock switch on the side of the handle grip with your
thumb and then squeeze the trigger switch with your
ngers. Once the machine powers on, you can release the
safety lock switch and proceed with operation (Fig. 9).
3. To stop the cordless snow shovel, release the trigger
switch.
Handle Adjustment
To adjust the angle of the auxiliary handle, follow the
instructions below:
1. Stop the machine and remove the battery. Wait until the
blade comes to a complete stop.
2. Loosen the auxiliary handle by turning the handle knob
counterclockwise. Rotate the auxiliary handle to a
comfortable position (Fig. 10).
3. Fix the handle by tightening the handle knob. Insert the
battery and resume working.
To adjust the position of the auxiliary handle, follow the
instructions below:
1. Stop the machine and remove the battery. Wait until the
blade comes to a complete stop.
2. Loosen handle knob slightly and adjust auxiliary handle
as needed to desired position. Retighten handle knob
securely (Fig. 11).
3. Insert the battery and resume working.
NOTE: In order to prevent the auxiliary handle from moving
around or sliding on the pole, be sure to tighten securely.
Operating Tips
• Start the cordless snow shovel. Push the shovel forward
at a comfortable rate, yet slow enough to clear the path
completely. The clearing width of the snow shovel and the
depth of snowfall should dictate your forward speed.
• Direct the snow discharge to the right or to the left by
holding the cordless snow shovel at a slight angle.
• To remove snow most eciently, throw the snow
downwind and slightly overlap each swath.
Fig. 8
Battery
Battery
compartment
Fig. 9
Trigger switch
Safety lock switch
Fig. 10
Handle knob
Auxiliary
handle
Fig. 11
Loosen the
handle knob
Auxiliary
handle

12
• If you need to clear snow from a crushed rock or gravel
surface, push down on the handle to keep the scraper
blade clear of any loose material that the rotor blades
could throw.
• This cordless snow shovel cuts a path 11 in. (28 cm)
wide and up to 7 in. (17.8 cm) deep in one pass.
• When clearing deeper drifts, hold the cordless snow
shovel by the upper and auxiliary handles and use a
swinging or sweeping motion. Remove up to 7 in.
(17.8 cm) of snow with each pass and repeat as many
times as needed.
• Remove the battery after using the cordless snow shovel.
Hang the shovel so it will not be misplaced or damaged.
Maintenance
To order genuine replacement parts or accessories for the
Snow Joe® 24V-SS11-CT cordless snow shovel, please visit
snowjoe.com or contact the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
Proper Care for Battery + Charger
mWARNING! To reduce the risk of injury, always unplug
the charger and remove the battery pack from the charger
before performing any maintenance task. Never disassemble
the battery pack or charger. Contact your Snow Joe® +
Sun Joe®dealer or the Snow Joe®+ Sun Joe®customer
service center for ALL repairs.
1. To reduce the risk of injury and damage, never immerse
your battery pack or charger in liquid or allow any liquid to
ow inside these components.
2. Clean out dust and debris from charger vents and
electrical contacts by blowing with compressed air.
3. Use only mild soap on a damp cloth to clean the battery
pack and charger, keeping away from all electrical
contacts. Certain cleaning agents and solvents are harmful
to plastics and other insulated parts. Some of these
include gasoline, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia and household
detergents containing ammonia. Never use ammable
or combustible solvents around battery packs, battery
chargers or tools.
4. The iON+ 24V lithium-ion battery chargers have no
serviceable parts.
Lubricating the Cordless Snow Shovel
This cordless snow shovel does not need lubrication.
All bearings are lubricated at the factory for the life of the
product.
Storage
1. Examine the cordless snow shovel thoroughly for worn,
loose or damaged parts. Should you need to repair or
replace a part, contact an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
2. Remove the battery from the cordless snow shovel
before storing.
3. Store the cordless snow shovel indoors in a locked,
dry place out of the reach of children to prevent
unauthorized use or damage.
Battery+ChargerO-SeasonStorage
1. Do not expose your battery pack or charger to water,
rain or allow them to get wet. This could permanently
damage the charger and the battery pack. Do not use oil
or solvents to clean or lubricate your battery pack as the
plastic casing can become brittle and crack, causing a
serious risk of injury.
2. Store the battery pack and charger at room temperature
away from moisture. Do not store in damp locations where
corrosion of terminals may occur. As with other battery
pack types, permanent capacity loss can result if the pack
is stored for long periods of time at high temperatures
(over 120ºF/49ºC).
3. iON+ 24V lithium-ion battery packs maintain their charge
during storage longer than other battery pack types.
As a general practice, it is best to unplug the battery
charger and remove the battery pack when they are not
in use. Recharge the battery pack every 6 months to 50%
capacity (2 lights on) during o-season storage to maintain
optimal battery performance.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover the
terminals to prevent the battery pack from shorting,
which could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.

13
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride,
or Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service and Support
If your Snow Joe®24V-SS11-CT cordless snow shovel requires
service or maintenance, please call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model and Serial Numbers
When contacting the company, reordering parts or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
24V-SS11-CT

14
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe®+ Sun Joe®replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless snow shovel. Contact Snow Joe®+ Sun Joe®
if you are unsure whether it is safe to use a particular replacement part or accessory with your cordless snow shovel. The use of
any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe®+ Sun Joe®. Accessories
can be ordered online at snowjoe.com or via phone by contacting the Snow Joe®+ Sun Joe®customer service center
at 1-866-SNOWJOE (1-866-766-9563).
iON+ 24V 2.0 Ah Lithium-Ion Battery
Battery Runtime Max: 35 min (clears up to 145 sq ft of 3 in. snow)
iON+ 24V 2.5 Ah Lithium-Ion Battery
Battery Runtime Max: 40 min (clears up to 186 sq ft of 3 in. snow)
iON+ 24V 4.0 Ah Lithium-Ion Battery
Battery Runtime Max: 1 hr 5 min (clears up to 295 sq ft of 3 in. snow)
iON+ 24V 5.0 Ah Lithium-Ion Battery
Battery Runtime Max: 1 hr 25 min (clears up to 370 sq ft of 3 in. snow)
iON+ 24V Lithium-Ion Battery Quick Charger
iON+ 24V Lithium-Ion Battery Dual Port Charger
24VBAT-LTE
24VCHRG-QC
24VCHRG-DPC
24VBAT-LT
24VBAT
24VBAT-XR
ModelAccessories Item
1
2
3
4
5
6

R4_01282020
SNOW JOE®+ SUN JOE®CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®, or Aqua Joe®product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
15
EN

SP
© 2020 Snow Joe®, LLC
Derechos reservados. Instrucciones originales. GUARDE ESTAS INSTRUCCIONES
17
Una división de Snow Joe®, LLC Modelo 24V-SS11-CT Forma Nº SJ-24V-SS11-CT-880S-MR2
MANUAL DEL OPERADOR
R
PALA QUITANIEVE INALÁMBRICA
– SOLO HERRAMIENTA
24 V MÁX.* | 28 CM
¡IMPORTANTE!
Instrucciones de seguridad
Todos los operadores deberán leer
estas instrucciones antes del uso
Lea todas las instrucciones antes de usar esta pala quitanieve
inalámbrica. Tendrán que tomarse siempre las precauciones
que se indican a continuación para reducir riesgos de
incendios, choques eléctricos o lesiones personales.
¡ADVERTENCIAS generales de
seguridad!
Usted y cualquier otro operador de esta pala quitanieve
deberán leer, entender y seguir estas instrucciones en
su totalidad, y deberán volver a leerlas al inicio de cada
temporada de nieve. No seguir todas las instrucciones puede
causar un CHOQUE ELÉCTRICO, INCENDIO y/o LESIONES
PERSONALES SEVERAS.
Preste atención al símbolo mde alerta de seguridad
personal usado en este manual para enfocar su atención
a una ADVERTENCIA dada junto a una instrucción de
operaciónparticular.Estosignicaquelaoperación
requiere ATENCIÓN, PRECAUCIÓN y CAUTELA especiales.
1. Mantenga el área de trabajo limpia y bien iluminada:
las áreas de trabajo abarrotadas y las áreas oscuras
provocan accidentes.
2. Utilice las herramientas apropiadas: no utilice esta
máquina para ningún otro trabajo excepto para el cual ha
sido creada.
3. Partes de repuesto: al repararla, utilice solamente partes
de repuesto idénticas. Si el cable del cargador está
dañado, reemplácelo o repárelo inmediatamente.
No la use en supercies de grava a menos que la pala
quitanieve esté modicada para dichas supercies,
de acuerdo al manual del operador.
4. Mantenga alejados a los niños y mascotas: todos los
espectadores, incluyendo niños y mascotas, deberán
estar a una distancia segura del área de trabajo.
5. Vístase apropiadamente: no utilice prendas holgadas ni
joyas. Pueden engancharse en las partes móviles.
Use botas de goma.
6. Evite los encendidos accidentales: asegúrese de que
el interruptor de seguridad y el gatillo interruptor estén
en la posición de apagado antes de insertar la batería en
la unidad. No lleve la pala quitanieve inalámbrica con el
interruptor de seguridad y el gatillo interruptor activados.
7. Partes móviles: mantenga alejados pies y manos de las
partes móviles. Mantenga los protectores en su lugar y
funcionando apropiadamente.
8. m¡PRECAUCIÓN! Tenga cuidado y evite resbalar o caer.
Utilice calzado protector que proteja sus pies y mejore su
posición de pie en supercies resbaladizas.
9. Use gafas protectoras: use también calzado protector,
ropa que se ajuste a su cuerpo, guantes protectores y
protección auditiva y para la cabeza.
10. Manténgase alerta: vea lo que está haciendo. Use su
sentido común. No opere esta pala quitanieve inalámbrica
si siente cansancio o está bajo la inuencia del alcohol o
las drogas.
11. No fuerce la herramienta: tendrá un mejor
funcionamiento con menos probabilidades de lesiones
personales o fallas mecánicas si es usada con el nivel de
actividad para el cual fue diseñada.
12. No adopte una postura inclinada: mantenga con sus
pies un balance y posición adecuados todo el tiempo.
13. Si la pala quitanieve inalámbrica golpea un objeto extraño,
siga estas instrucciones:
• Detenga la pala quitanieve inalámbrica y retire la
batería;
• Inspecciónela para ver si existen daños;y
• Repare cualquier daño antes de volver a encender la
pala quitanieve.
14. Desconecte la herramienta: mueva el interruptor a la
posición de apagado y retire la batería de la herramienta
cuando esta no esté siendo usada, antes de ser reparada,
al cambiarle accesorios o al realizar cualquier otra tarea
de mantenimiento en esta.
15. Guarde la herramienta inactiva en interiores:
cuando no esté siendo usada, la pala quitanieve
inalámbrica deberá guardarse bajo techo y en un lugar
seco, bajo llave, y fuera del alcance de los niños.
16. Cuide la pala quitanieve inalámbrica: siga las
instrucciones aplicables de mantenimiento para el
reemplazo de partes y cambio de accesorios. Esta pala
quitanieve inalámbrica no requiere lubricación.

18
mEste es el símbolo de alerta de seguridad.
Es usado para alertarle de potenciales peligros de
lesiones personales. Obedezca todos los mensajes
de seguridad que siguen a este símbolo para evitar
posibles lesiones o la muerte.
El uso o mantenimiento incorrecto de esta pala
quitanieve inalámbrica puede resultar en lesiones
personales o la muerte. Para reducir este riesgo,
obedezca las siguientes instrucciones de seguridad.
Esta pala quitanieve inalámbrica puede amputar
manos y pies si no se usa correctamente. Puede
también recoger objetos extraños que pueden
convertirse en proyectiles peligrosos al ser lanzados
al aire. No seguir las siguientes instrucciones de
seguridad podría causar lesiones personales severas.
Capacitación
• Lea, entienda y siga todas las instrucciones en la máquina
y en el manual antes de empezar a operar esta unidad.
Familiarícese a fondo con los controles y el uso correcto
del equipo. Sepa cómo detener la unidad y desactivar los
controles rápidamente.
• Los niños nunca deben tener acceso a la unidad.
Los adultos nunca deben operar la unidad sin antes leer y
entender cuidadosamente este manual con instrucciones.
• Mantenga el área de operación libre de personas,
particularmente niños pequeños y mascotas.
• Tenga cuidado y evite resbalarse o caerse.
Preparación
• Inspeccione cuidadosamente el área donde esta pala
quitanieve inalámbrica será utilizada, y retire todos los
felpudos, trineos, tablas, alambres y demás objetos
extraños.
• No opere esta pala quitanieve inalámbrica sin usar una
vestimenta de invierno adecuada. Evite usar prendas de
vestir holgadas que puedan engancharse en las partes
móviles. Utilice calzado que mejorará su posición de pie en
supercies resbaladizas.
• No intente retirar nieve de una supercie de grava o de roca
triturada. Esta pala quitanieve inalámbrica solo se debe
usar en supercies pavimentadas.
• Nunca intente realizar ningún ajuste mientras el motor
esté funcionando (excepto cuando sea especícamente
recomendado por el fabricante).
• Use siempre gafas de seguridad o protección ocular
durante la operación, o mientras realice cualquier ajuste o
reparación, para proteger sus ojos de objetos extraños que
puedan ser arrojados por la máquina.
Operación
• No ponga sus manos o pies cerca o debajo de las partes
giratorias. Manténgase alejado de la abertura de descarga
en todo momento.
• Tenga mucho cuidado al operar sobre, o cruzando,
senderos de grava, aceras o caminos. Manténgase alerta
ante peligros ocultos o tráco.
• Después de golpear un objeto extraño, detenga el motor.
Inspeccione detenidamente la pala quitanieve inalámbrica
en busca de cualquier daño, y repárela antes de reiniciarla y
operarla.
• Si la unidad empieza a vibrar de manera anormal,
detenga el motor e inspeccione inmediatamente la unidad
para determinar la causa. Las vibraciones generalmente
son señales de problemas.
• Detenga el motor y retire la batería siempre que deje su
posición de operación, al transportar la unidad, antes de
desatascar la carcasa del rotor y al realizar cualquier trabajo
de reparación, ajuste e inspección en la unidad.
• Al limpiar, reparar o inspeccionar la pala quitanieve
inalámbrica, asegúrese de que todas las partes móviles se
hayan detenido por completo antes de empezar a trabajar.
• Tenga mucho cuidado al operar en pendientes.
• Nunca opere la pala quitanieve inalámbrica sin protectores
y otros dispositivos de seguridad adecuados instalados y
funcionando correctamente.
• Nunca dirija la descarga hacia la gente o hacia áreas donde
puedan ocurrir daños materiales. Mantenga a los niños,
mascotas y otros espectadores lejos del área de trabajo.
• No sobrecargue la capacidad de la máquina intentando
retirar la nieve demasiado rápido.
• Mire hacia atrás y tenga cuidado al retroceder con la pala
quitanieve inalámbrica.
• Nunca opere la pala quitanieve inalámbrica sin buena
visibilidad o luz. En todo momento esté atento a dónde
usted esté pisando, y mantenga las empuñaduras
rmemente sujetas con ambas manos. Camine,
nunca corra, con esta pala quitanieve inalámbrica.
Desatascamiento de carcasa de rotor
El contacto de la mano con las hojas giratorias del rotor dentro
de la carcasa del rotor es la causa más usual de lesiones
asociadas con palas quitanieve inalámbricas. Nunca use sus
manos para despejar la carcasa del rotor atascada.
Para despejar la carcasa del rotor:
• Apague el motor y retire la batería.
• Espere 10 segundos para asegurarse de que las hojas del
rotor se hayan detenido por completo.
• Use siempre una herramienta de limpieza, NUNCA SUS
MANOS, para liberar las hojas giratorias.
Mantenimiento y almacenamiento
• Verique frecuentemente todos los sujetadores para
comprobar un ajuste correcto y asegurarse de que la pala
quitanieve inalámbrica esté en condiciones de trabajo
seguras.
• Consulte siempre el manual del operador para información
importante, tal como el almacenamiento correcto de su
pala quitanieve inalámbrica por un periodo prolongado.
• Conserve o reemplace las etiquetas de seguridad y de
instrucciones según sea necesario.

19
• Haga funcionar la pala quitanieve inalámbrica unos cuantos
minutos luego de quitar nieve para evitar que las hojas del
rotor se congelen.
Instrucciones de seguridad
para la batería y el cargador
NOTA: esta unidad es una solo herramienta. La batería y
el cargador no están incluidos. Deben ser adquiridos por
separado.
El modelo 24V-SS11-CT es compatible con las baterías y
cargadores del sistema iON+ de 24 V. Vea la página 14 para
más información.
Prestamos mucha atención al diseño de cada batería para
garantizar la producción de baterías seguras y durables,
con una alta densidad de energía. Las celdas de la batería
tienen varios dispositivos de seguridad. Cada celda individual
es inicialmente formateada y se registran sus curvas eléctricas
características. Estos datos son luego usados exclusivamente
para poder ensamblar las mejores baterías posibles.
Independientemente de todas las precauciones de seguridad,
se debe tener mucho cuidado al manipular las baterías.
Las siguientes instrucciones deben ser obedecidas en todo
momento para garantizar un uso seguro. Un uso seguro solo
puede ser garantizado si se usan celdas libres de daños.
Una manipulación incorrecta de la batería puede causar daños
en sus celdas.
¡IMPORTANTE! Los análisis han conrmado que el uso
incorrecto y el cuidado deciente de baterías de alto
rendimiento son las causas principales de lesiones personales
y/o daños al producto.
m¡ADVERTENCIA! Use solo baterías de repuesto
aprobadas. Otras baterías pueden dañar la pala quitanieve
inalámbrica y provocar un desperfecto que pueda causar
lesiones personales severas.
m¡ADVERTENCIA! No use una batería o artefacto que
hayan sido dañados o modicados. Las baterías dañadas o
modicadas pueden reaccionar impredeciblemente, causando
un incendio, explosión, o riesgo de lesiones.
No modique ni intente reparar el artefacto o la batería,
a menos que lo haga según lo indicado en las instrucciones de
uso y cuidado.
Su batería deberá ser reparada por una persona calicada
usando únicamente partes de repuesto originales.
Esto mantendrá la seguridad de la batería.
m¡PRECAUCIÓN! Para reducir el riesgo de lesiones,
cargue la batería de iones de litio iON+ de 24 V únicamente
con su cargador de batería de iones de litio iON+ de 24 V
designado. Otros tipos de cargadores presentan riesgos de
incendio, lesiones personales y daños. No conecte una batería
a un tomacorriente doméstico ni encendedor de cigarrillos
en su vehículo. Dicho uso indebido dañará o deshabilitará
permanentemente la batería.
• Evite entornos peligrosos: no cargue la batería bajo la
lluvia o nieve, ni en entornos húmedos o mojados. No use
la batería ni el cargador en atmósferas explosivas (gases,
polvo o materiales inamables), ya que se pueden generar
chispas al insertar o retirar la batería, provocando un
incendio.
• Cárguela en un área bien ventilada: no bloquee los
conductos de ventilación del cargador. Manténgalos
despejados para permitir una ventilación adecuada.
No permita que se fume o haya llamas abiertas cerca de
una batería siendo cargada. Los gases presentes pueden
explotar.
NOTA: el rango seguro de temperaturas para la batería
es de 41°F (5°C) a 105°F (40.5°C). No cargue la batería
en exteriores a temperaturas congelantes. Cárguela a
temperatura ambiente en interiores.
• Cuide el cable del cargador: al desenchufar el cargador
tire de su enchufe, no del cable, para desconectarlo del
tomacorriente y así evitar el riesgo de daños al enchufe
y cable de alimentación. Nunca transporte el cargador
colgado de su cable, ni tire del cable para desconectarlo
del receptáculo. Mantenga el cable alejado del calor,
grasas y bordes alados. Asegúrese de que el cable no sea
pisado, que la gente no se tropiece con éste, ni que esté
sujeto a daños o tensiones mientras el cargador esté siendo
usado. No use el cargador con un cable o enchufe dañado.
Reemplace un cargador dañado inmediatamente.
• No use un cable de extensión a menos que sea
absolutamente necesario: usar un cable de extensión
incorrecto, dañado o conectado de forma inapropiada
puede causar un incendio o choque eléctrico. Si se
debe usar un cable de extensión, conecte el cargador a
un cable de extensión de calibre 16 (o más grueso) de
alambrado adecuado, con el enchufe hembra encajando
perfectamente en el enchufe macho del cargador. Verique
que el cable de extensión esté en buenas condiciones.
• Compruebe la entrada nominal del cargador antes del
uso: el cargador debe estar enchufado a un tomacorriente
apropiado.
• Use solo accesorios recomendados: el uso de un
accesorio no recomendado ni vendido por el fabricante de
la batería o cargador de batería puede resultar en un riesgo
de un choque eléctrico, incendio o lesiones personales.
• Desenchufe el cargador cuando no esté siendo usado:
asegúrese de retirar las baterías de los cargadores
desenchufados.

20
m¡ADVERTENCIA! Para reducir el riesgo de un choque
eléctrico, desenchufe siempre el cargador antes de llevar a
cabo cualquier tarea de limpieza o mantenimiento. No permita
que el agua uya dentro del cargador. Use un interruptor de
circuito por falla a tierra (GFCI) para reducir el riesgo de un
choque eléctrico.
• No queme ni incinere baterías: las baterías pueden
explotar, causando lesiones personales o daños.
Las baterías generan sustancias y humos tóxicos al ser
quemadas.
• No triture, deje caer ni dañe las baterías: no use la
batería ni el cargador si han sido severamente golpeados,
se han dejado caer, se han aplastado, o han sido dañados
de cualquier forma, como por ejemplo perforados con un
clavo, golpeados con un martillo, pisados, etc.
• No los desarme:el re-ensamblado incorrecto puede
representar un riesgo severo de choque eléctrico, fuego o
exposición a químicos tóxicos de la batería.
Si la batería o el cargador están dañados, contacte a un
concesionario autorizado Snow Joe®+ Sun Joe®o llame
a la central de servicio al cliente Snow Joe®+ Sun Joe®al
1-866-SNOWJOE (1-866-766-9563) para obtener ayuda.
• Los químicos de la batería causan quemaduras severas:
nunca deje que una batería dañada haga contacto con
la piel, ojos o boca. Si una batería dañada deja escapar
químicos, use guantes de hule o neopreno para deshacerse
de ella de forma segura. Si la piel es expuesta a los
uidos de la batería, lave el área afectada con jabón y
agua, y enjuague con vinagre. Si los ojos son expuestos
a los químicos, enjuáguelos inmediatamente con agua
durante 20 minutos y busque atención médica. Quítese y
deshágase de las vestimentas contaminadas.
• No provoque un cortocircuito:una batería puede hacer
cortocircuito si un objeto metálico hace conexión entre los
contactos positivo y negativo de la batería. No coloque
una batería cerca de objetos que puedan causar un
cortocircuito tales como monedas, sujetapapeles, tornillos,
clavos, llaves y otros objetos metálicos. Una batería
cortocircuitada representa un riesgo de incendio y lesiones
personales severas.
• Guarde su batería y cargador en un lugar fresco y seco:
no guarde la batería o cargador donde las temperaturas
puedan exceder los 105ºF (40.5ºC), como bajo la luz directa
del sol o dentro de un vehículo o construcción metálica
durante el verano.
Información sobre la batería
1. Para un óptimo rendimiento de la batería, evite ciclos de
descarga baja cargando frecuentemente la batería.
2. Guarde la batería en un lugar fresco, de preferencia a 77°F
(25°C) y cargada al menos a un 40%.
3. Las baterías de iones de litio están sujetas a un proceso
natural de desgaste. La batería debe ser reemplazada
a más tardar cuando su capacidad caiga a un 80% de
su capacidad inicial, cuando estaba nueva. Las celdas
debilitadas en una batería gastada no son capaces de
cumplir con los requisitos de alta potencia necesarios
para la operación adecuada de su pala quitanieve, y por
tanto representan un riesgo de seguridad.
4. No arroje las baterías al fuego abierto ya que esto
representa un riesgo de explosión.
5. No incendie la batería ni la exponga al fuego.
6. No descargue las baterías de forma exhaustiva.
Una descarga exhaustiva dañará las celdas de la
batería. La causa más común de descarga exhaustiva
es el almacenamiento prolongado o la falta de uso de
una batería parcialmente descargada. Deje de trabajar
tan pronto como el rendimiento de la batería caiga
considerablemente o se active el sistema de protección
electrónico. Almacene la batería únicamente luego de
haberla cargado por completo.
7. Proteja las baterías y la herramienta contra
sobrecargas. Las sobrecargas causarán rápidamente un
sobrecalentamiento y daños a las celdas de la batería,
incluso si este sobrecalentamiento no es aparente por
fuera.
8. Evite daños y golpes. Reemplace inmediatamente la
batería que se haya caído desde una altura de más de
un metro o que haya sido expuesta a golpes violentos,
incluso si la carcasa de la batería aparenta no tener
daños. Las celdas dentro de la batería pueden haber
sufrido daños severos. En dichos casos, lea la información
de eliminación para deshacerse apropiadamente de la
batería.
9. Si la batería sufre una sobrecarga y sobrecalentamiento,
el sistema interruptor de protección integrado apagará el
equipo por motivos de seguridad.
¡IMPORTANTE! No presione más el interruptor de
ENCENDIDO/APAGADO si el interruptor de protección se
ha activado. Esto puede dañar la batería.
10. Use únicamente baterías originales. El uso de otras
baterías representa un riesgo de incendio y puede resultar
en lesiones personales o una explosión.
Información sobre el cargador y el proceso
de carga
1. Verique los datos registrados en la placa de
especicaciones del cargador de batería. Asegúrese
de conectar el cargador de batería a una fuente de
alimentación que tenga el voltaje indicado en la placa
de especicaciones. Nunca lo conecte a una fuente de
alimentación con voltaje distinto al indicado.
