OPERATOR’S MANUAL
CORDLESS TILLER + CULTIVATOR
48V MAX* | 2.0 Ah | 14-INCH
R
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
General Safety WARNINGS!
Before using this cordless tool, carefully read and observe the
safety rules and instructions listed below. Before starting work,
make sure that you know how to stop the machine in case of
an emergency. The incorrect use of this machine could cause
serious injury. Keep these instructions in a safe place and on
hand so that they can be consulted when required.
Notice the personal safety alert symbol mused in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION, and
AWARENESS.
1. Keep work area clean and well-lit – Cluttered, dark
areas invite accidents.
2. Replacement parts – When servicing this unit, use only
identical replacement parts. Replace or repair damaged
parts immediately.
3. Keep children, bystanders, and pets away – All
spectators, including pets, should be kept a safe distance
away from the work area.
4. Know your product – Know how to start and stop the
machine. Be thoroughly familiar with the controls.
5. Use the right tool – Do not use this machine for any job
except that for which it was intended.
6. Dress properly – Do not wear loose clothing or jewelry as
such articles can become caught in moving parts. Wear
a protective covering to contain long hair. Wearing rubber
gloves and substantial non-slip footwear is recommended
when working outdoors.
7. Avoid accidental starting – Do not carry the garden tiller
+ cultivator with your nger on the switch.
mCAUTION! Moving parts will continue to run for several
seconds after turning o the machine.
8. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
9. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it was designed.
10. Do not overreach – Keep proper footing and balance at
all times.
If the tiller + cultivator strikes a foreign object, follow these
steps:
• Stop the cordless tiller + cultivator.
• Inspect for damage.
• Repair any damage before restarting and
operating the tool.
11. Use safety glasses – Also use safety footwear,
snug-tting clothing, protective gloves, hearing, and
head protection.
12. Remove the batteries – Remove the batteries from the
tiller + cultivator when it is not in use, before servicing it,
when changing accessories, and when performing any
other maintenance task.
13. Store idle tool indoors – When not in use, the tiller +
cultivator should be stored indoors in a dry and high or
locked-up place out of the reach of children.
14. Maintain the tiller + cultivator with care – Keep the
cutting edges sharp and clean for optimal performance
and to reduce the risk of injury. Keep the handles dry,
clean, and free from oil and grease. Follow the additional
recommendations described in the maintenance section
of this manual.
15. Avoid dangerous environments – Do not use the tiller
+ cultivator in rain or in damp or wet locations. Do not
operate the tiller + cultivator in gaseous or explosive
atmospheres or use the tiller + cultivator near ammable
or combustible liquids. Motors in these tools normally
spark, and the sparks might ignite fumes.
16. Stay alert – Watch what you are doing. Use common
sense. Do not operate the tiller + cultivator when you
are tired or under the inuence of drugs, alcohol, or
other medication.
1

2
17. Check for damaged parts – Before further use of the
appliance, a guard or other part that is damaged should be
carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other condition that may aect its
operation. A guard or other part that is damaged should
be properly repaired or replaced. Contact the Snow Joe®
+ Sun Joe®customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
Training
• Read, understand, and follow all instructions on the tiller
+ cultivator and in the manual before operating this unit.
Thoroughly familiarize yourself with the controls and the
proper use of the equipment. Know how to stop the unit
and disengage the controls quickly.
• Children should never be allowed access to the equipment.
Adults should never operate the equipment without
carefully reading and understanding these instructions.
• Keep the area of operation clear of all persons, particularly
small children or pets.
• Exercise caution to avoid slipping or falling.
• Always plan your cultivating path to avoid discharge of
material toward people, pets, and property (e.g. windows,
cars, etc.). Thrown objects can cause serious personal
injury and property damage. Do not allow anyone in front of
a running machine.
• Keep people, pets, and property at least 25 feet from the
tiller + cultivator while it is in operation. Stop the tiller +
cultivator if people or pets enter the discharge area.
• Always observe the surface conditions in order to avoid
slipping, falling, and unexpected objects.
Preparation
• Always inspect the area where the tiller + cultivator is to
be used. Remove all objects (i.e. stones, sticks, wires, and
other foreign materials) that could be thrown by the blades
or cause the operator to trip.
• Thrown objects can cause serious injury to the eyes and
exposed body. Always wear safety glasses or eye shields
during operation and while making an adjustment or repair.
• Always operate the tiller + cultivator wearing adequate
garments. Do not wear jewelry or other loose clothing,
which could become entangled in moving parts. Wear
non-slip footwear to ensure proper footing.
• Observe any noise-prevention regulations and laws.
• Inspect the tiller + cultivator for worn, missing, or damaged
parts and safety labels. See maintenance section for
detailed instructions.
Operation
• Do not operate the machine while under the inuence of
alcohol or drugs.
• Keep all safety devices in place and in proper working
order. Do not operate with missing or damaged
components.
• Ensure the controls (start/stop) function properly
before cultivating.
• Hold onto the tiller + cultivator with both hands during
operation. Ensure the grips are dry.
• Contact with rotating parts can amputate hands and feet.
Keep hands and feet away from all rotating parts.
• Only operate the tiller + cultivator when there is good
visibility or light and dry conditions. Always watch your
footing and keep a rm hold on the grips. Walk; don't run!
• Do not operate the tiller + cultivator on slippery surfaces.
Check your footing during use.
• Exercise caution when changing direction and operating
the tool on slopes. Always keep feet and legs a safe
distance away from the machine. Look for hidden obstacles
or hazards.
• Do not overload machine capacity by attempting to
cultivate too deeply. It will cause excessive resistance.
• Stop the tiller + cultivator and remove the batteries before
leaving the operating position (behind the handles) to adjust
or inspect the unit. Wait until the blades have come to a
complete stop.
• If the tiller + cultivator should start to vibrate abnormally,
stop the machine and inspect thoroughly for damage.
• Turn the machine OFF when moving to a new work area.
Allow the blades to completely stop rotating before
transporting the unit.
• Always use proper care and good judgment when you
are confronted with a situation that is not covered in
this manual. If you are unsure of what to do, contact
your authorized Snow Joe®+ Sun Joe®dealer or call
the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
• Do not use in rain or wet conditions.
• Do not grasp the exposed cutting blades or cutting edges
when picking up or holding the appliance.
Stopping Work
• Always turn the tiller + cultivator OFF and remove the
batteries when stopping work or when changing work
areas. Never leave the machine running when unattended.
• The blades will continue to rotate for a short period after
turning OFF the tiller + cultivator. Wait until the blades
have completely stopped before lifting the machine or
conducting inspection and maintenance.

3
• The motor housing remains hot for a short period after
the machine is turned OFF. Allow the motor housing to
cool completely before touching or storing near
combustible material.
Maintenance + Storage
• Maintain or replace safety and instruction labels.
• Disengage all controls, stop the engine, and wait until the
blades come to a complete stop before cleaning, repairing,
or inspecting the tiller + cultivator.
• Regularly check the following:
i) Blades are clear and can rotate freely – Accumulation
of debris around the blades could impair performance
or damage the motor. Inspect and clean the area around
the blades before every use.
ii) Safety devices are operating properly – Do not
tamper with or adjust safety devices.
iii) Bolts and screws are properly tightened – Visually
inspect the machine for any damage and ensure that
the tiller + cultivator is in safe working condition.
iv) Use only identical replacement parts – Always replace
damaged parts with original equipment manufacturer’s
(OEM) parts only. Replacement parts that do not meet
the original equipment specications may lead to
improper performance and compromise safety.
Electric Safety
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
1. Prevent unintentional starting. Ensure the switch is in the
o-position before connecting with battery packs, picking
up or carrying the appliance. Carrying the appliance with
your nger on the switch or energizing appliance that have
the switch on invites accidents.
2. Remove the battery packs from the appliance before
making any adjustments, changing accessories, or storing
appliance. Such preventive safety measures reduce the
risk of starting the appliance accidentally.
3. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
4. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
5. When battery packs are not in use, keep them away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
7. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
8. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
9. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 265°F (130°C) may cause explosion.
10. Follow all charging instructions and do not charge the
battery packs or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the batteries and increase the risk of re.
11. Have servicing performed by a qualied repair person
using only identical replacement parts. This will ensure
that the safety of the product is maintained.
12. Do not modify or attempt to repair the appliance or the
battery packs (as applicable) except as indicated in the
instructions for use and care.
Battery + Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery packs can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement
batteries; other batteries may damage the cordless tiller +
cultivator and cause it to malfunction, which can lead to
serious personal injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.

4
Do not modify or attempt to repair the appliance or the battery
packs except as indicated in the instructions for use and care.
Have your battery packs serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the iON+
24V lithium-ion battery packs only in the designated iON+ 24V
lithium-ion charger. Other types of chargers present risk of re,
personal injury and damage. Do not wire the battery packs to
a power supply plug or car cigarette lighter. Such misuse will
permanently disable or damage the battery packs.
• Avoid dangerous environments – Do not charge the
battery packs in rain, snow or in damp or wet locations.
Do not use the battery packs or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery packs, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the battery outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger 24VCHRG-DPC is rated for 120 volt AC
only – The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged charger.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery
packs may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery packs
are burned.
• Do not crush, drop or damage battery packs – Do not
use the battery packs or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the batteries or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery packs and charger in a cool, dry
place – Do not store the battery packs or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the batteries
1. The battery packs supplied with your cordless tiller +
cultivator are only partially charged. The battery packs
have to be charged completely before you use the tool for
the rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery packs frequently.
3. Store the battery packs in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery packs must be replaced at the latest
when their capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your tiller + cultivator,
and therefore pose a safety risk.
5. Do not throw battery packs into an open re as this poses
a risk of explosion.
6. Do not ignite the battery packs or expose them to re.

7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the batteries fall noticeably
or the electronic protection system triggers. Place the
battery packs in storage only after they have been fully
charged.
8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery packs.
11. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery packs and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery packs will
become warm. Allow the battery packs to cool to room
temperature before inserting them into the charger to
recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent connection of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries inside the charger
for days on end.
8. Never use or charge battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery packs (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery packs will lead to premature aging
of the battery cells.
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery packs in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery packs, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery packs from freezing.
Battery packs that were stored below 32°F (0°C) for more
than 60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
5

Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates
a precaution, a warning, or
a danger.
WARNING! Do not expose the unit
to rain or wet conditions.
WARNING! Rotating parts may
cause serious injury. Make sure the
blades come to a complete stop
before transporting the machine
or before inspecting, cleaning, or
conducting any other maintenance.
Wear eye protection, breathing
protection, and ear protection
(i.e. safety goggles, dust masks, and
ear defenders).
Inspect the work area prior to
use and remove all objects that
could be thrown by the appliance. If
a hidden object is discovered while
working, stop the engine and remove
the object.
Work across slopes; never work up
and down such surfaces.
Symbols SymbolsDescriptions Descriptions
Beware of foreign objects
that could be thrown from the
appliance. Keep bystanders a
safe distance away from the
work area.
The rotating part will continuously
run for several seconds after you
turn o the machine.
STOP
Wear safety footwear at all times to
provide protection against objects
that may accidentally fall on feet.
Wear safety gloves during use to
protect hands.
Indoor use only. Only use battery
charger indoors.
6

7
Know Your Cordless Tiller + Cultivator
Read the owner’s manual and safety rules carefully before operating your cordless tiller + cultivator. Compare the illustration
below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
Technical Data
Motor .............................................................. 500 W Brushless
Battery Voltage Max* ................................... 48V D.C. (2 x 24V)
Battery Capacity ..................................................... 2.0 Ah each
Battery Runtime Max ...................................................... 13 min
(excavates up to 270 sq ft of 4 in. dirt)
Charger Input .............................................................. 120V AC,
60 Hz, 160 W
Charger Output ....................................... 26V DC, 2.2 A (2 port)
Charge Time Max ........................................................... 55 min
Cultivating Width Max ......................................... 14 in. (36 cm)
Cultivating Depth Max ........................................... 7 in. (18 cm)
Blade .................................... 4 steel 7 in. (18 cm) tilling blades
No Load Speed ........................................................... 180 rpm
Height Adjustment ................................................... 3 positions
Weight (tiller + cultivator alone) ..................... 23.4 lbs (10.6 kg)
Weight (with batteries installed) ..................... 26.7 lbs (12.1 kg)
1. Safety lock button
2. ON/OFF switch
3. Right upper handle
4. Left upper handle
5. Upper handle frame
6. Cable clip (2)
7. Middle handle frame
8. Middle handle knob + bolt (2)
9. Lower handle frame
10. Lower handle knob + bolt (2)
11. Motor housing
12. Battery compartment cover
13. Battery compartment
14. Tiller blades
15. Wheel (2)
16. Wheel adjustment knob
17. Battery indicator
18. Push button for battery indicator
19. Push lock button
20. iON+ 24V lithium-ion battery
(24VBAT-LTE) featuring exclusive
EcoSharp®technology (2)
21. iON+ 24V lithium-ion dual-port charger
(24VCHRG-DPC)
22. Charger plug
1
2
3
5
6
7
8
9
101112
13
14
15
16
4
17 18 19 20 21 22
*Generates 48V max with two 24V lithium-ion batteries. Initial no-load voltage, per fully charged battery, peaks at 24V. Nominal voltage under typical load is 21.6V.

8
Unpacking
Carton Contents
• Cordless tiller + cultivator with lower handle frame
• Middle handle frame
• Left upper handle
• Right upper handle
• Upper Handle frame
• Handle knobs + bolts (4 sets)
• Cable clips (2)
• iON+ 24V lithium-ion batteries (2)
• iON+ 24V lithium-ion dual-port battery charger
• Manuals with registration card
1. Carefully remove the cordless tiller + cultivator and check
to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
tiller + cultivator. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils
or small parts. These items can be swallowed and pose a
suocation risk!
Battery Pack Operation
The equipment is powered by two lithium-ion batteries. The
battery packs are completely sealed and maintenance free.
mWARNING! The cordless tiller + cultivator can only be
powered by both of the batteries together. One battery cannot
provide sucient power to the tool. Make sure to use two
batteries of the same voltage and the same capacity. Using the
tool with batteries of dierent capacity will cause damage to
the batteries.
mWARNING! Before rst use, the batteries require 55 min
charge time to be fully charged. When the batteries are at low
capacity, recharge for 55 min again before resuming operation.
Battery Charge Level Indicator
The battery packs are equipped with a push button for
checking the charge level. Simply press the push button to
read o the battery charge level from the LEDs of the battery
indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, connect the battery to the charger and charge
as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only iON+ 24V lithium-ion battery
packs with their compatible iON+ 24V lithium-ion charger.
Other types of batteries may cause personal injury
and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT-LTE
Lithium-Ion Batteries
NOTE: The iON+ 24VBAT-LTE lithium-ion battery packs do
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery packs before placing them into the charger.
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

9
• Use the battery charge indicator lights to determine when to
charge your iON+ 24VBAT-LTE lithium-ion battery packs.
• You can "top-o" your battery packs' charge before starting
a big job or after a long day of use.
Charging the Batteries
1. Open the battery compartment cover to expose the
battery packs inside. Press the push lock buttons on the
batteries to pull the battery packs out of the equipment
(Fig. 1).
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, insert the
charger's plug into the electrical wall outlet. When you
plug in the charger, two green lights will illuminate and
stay green (Fig. 2).
3. Place the battery packs into the charger by sliding the
packs to lock them into position. When you insert the
batteries into the charger, the two green lights will go
o, and the red lights will illuminate to indicate that the
batteries are charging (Fig. 3).
4. When the charger lights turn green, the batteries are fully
charged (Fig. 3).
NOTE: A fully discharged pack with an internal
temperature in the normal range will fully charge in
55 min (between 32ºF/0ºC and 113ºF/45ºC).
5. If the light indicators do not come on at all, check that
the battery packs are fully seated into the bay. Remove
the battery packs and reinsert. If the problem persists,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
6. When charging is complete, remove the batteries from the
charger by pressing the push lock buttons and sliding the
batteries backward to unlock them from the charger
(Fig. 4).
mCAUTION! FIRE HAZARD. When remove the batteries
from the charger, be sure to unplug the charger from the outlet
rst, then remove the batteries from the charger.
mWARNING! This charger does not automatically turn
o when the batteries are fully charged. Please take care not
to leave the batteries in the charger. Switch o or unplug the
charger at the mains when charging is complete.
Fig. 1
Push lock
button
Battery
compartment
cover
Fig. 2
Charger
green
Power on
Fig. 3 Battery packs
red
Charging
green
Fully
Charged
Fig. 4
Push lock
button

10
7. Timely recharging of the batteries will help prolong the
batteries' life. You must recharge the battery packswhen
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery packs to become
fully discharged as this will cause irreversible damage to
the batteries.
Charging a Hot or Cold Battery Pack
The green indicator lights on the charger base indicates that
the battery packs' temperatures are outside the charging
range. Once the packs are within the acceptable range, normal
charging will take place and the red light will be continuous.
Hot or cold battery packs may take longer to charge.
Assembly
Upper Handles Assembly
1. Separate the upper handle frame by removing the 4
screws. Retain the screws (Fig. 5).
2. Fit the left upper handle and the right upper handle in
the handle grooves of the upper handle frame rear piece.
Make sure the holes are aligned (Fig. 6).
3. Put the handle frame front piece in place, inserting the 4
pegs into the holes on the handle frame rear piece (Fig. 7).
4. Join the assembly with the original 4 screws, as shown
(Fig. 8).
Connect Handle Frames
1. Connect the upper handle frame assembly to the middle
handle frame by 2 sets of handle knobs + bolts, as shown
(Fig. 9).
Fig. 5
Upper handle
frame rear
piece
Upper handle
frame front
piece
Fig. 6
Upper handle
frame rear
piece
Left upper
handle
Right upper
handle
Align the holes
Handle frame
front piece
Fig. 7
Fig. 8
Fig. 9
Handle knob
+ bolt
Middle
handle frame

11
2. Connect the upper handle frame + middle handle frame
to the lower handle frame by the other 2 sets of handle
knobs + bolts, as shown (Fig. 10).
NOTE: Make sure that the handle knobs are placed inside
the handle frame. Otherwise they will aect the wheel
adjustment system.
3. Clip on the cable clips to secure the cable.
Operation
Intended Use
The 24V-X2-TLR14 cordless tiller + cultivator is designed for
small gardens and ower beds, this cordless tiller + cultivator
eectively loosens and turns over new soil. It may also be
used to mix coarse soil with fertilizer, peat, and compost. This
product may not be used to till extremely dry or wet soil.
The use of this product in rain or wet conditions is prohibited.
For safety reasons, it is essential to read the entire instruction
manual before rst use and to observe all the instructions
contained within this manual.
This product is intended for private domestic use only. It is not
intended for any commercial trade use. It must not be used for
any purposes other than those described.
Wheel Adjustment
mWARNING! Always switch the product o and remove
the batteries before making any adjustments.
1. The wheels can be adjusted to 3 dierent positions for
better cultivating results (Fig. 11).
2. To adjust the wheel position, push the wheel adjustment
knob while moving it to the slot for desired position; let go
of the knob and make sure it locks into position (Fig. 12).
Starting the Machine
mWARNING! Rotating blades may cause serious injury.
The blades will continue to turn for a few seconds after the
tool has been switched OFF. Do not touch the rotating blades.
Contact with hot components (i.e. motor housing, gear box,
etc.) on the machine may cause burns. Allow the machine to
cool before handling.
1. Open the battery compartment cover and slide both
batteries in until they click to lock it into position, then
close the battery compartment cover (Fig. 13).
Fig. 10
Handle knob
+ bolt
Lower
handle frame
Fig. 11
Transport
position
Work
position 01
Work
position 02
Fig. 12
Wheel
adjustment knob
Work
position 02
Work
position 01
Transport
position
Fig. 13
Battery
compartment
cover
Push in

12
2. To turn the tool ON, press and hold the safety lock button
while squeezing the ON/OFF switch. Once the tool is
running, release the safety lock button (Fig. 14).
3. To switch OFF, release the ON/OFF switch (Fig. 14).
Operating Tips
• Before each use, check the product, the batteries, and any
other accessories for damage. Do not use the product if it is
damaged or shows wear.
• Double check that the accessories and attachments are
properly tted.
• Always hold the product by its handles. Keep the handles
dry to ensure a secure grip.
• Ensure that the air vents are always unobstructed and clear.
Clean them if necessary with a soft brush. Blocked air vents
may lead to overheating and damage the product.
• Switch the product o immediately if you are disturbed
while working by other people entering the working area.
Always let the product come to a complete stop before
averting your attention.
• Do not overwork yourself. Take regular breaks to ensure you
can concentrate on the task at hand and have full control
over the product.
mWARNING! In some countries, regulations dene
restrictions for use of such products, including the times and
days when operation is permissible. Ask your community for
detailed information and observe these regulations in order to
preserve a peaceful neighborhood and avoid violating any local
ordinances.
Tilling
• Make sure that the work area is clear of stones, sticks, wire,
or other objects that could damage the product or its motor.
• Do not till very wet soil because wet soil tends to stick to
the working tool, preventing proper blade rotation; it could
also cause you to slip and fall.
• Always maintain a rm grip on the product. For better
guidance, apply light pressure to the handles.
mWARNING! Do not place hands, feet, or any other part
of the body or clothing near the rotating blades or any other
moving part. The blades begin to rotate forward once the
trigger switch is depressed. The blades continue to rotate until
the trigger switch is released. Failure to avoid contact with the
rotating blades could cause serious personal injury.
• Do not try to till too deeply or force the product into soil that
is extremely hard or resistant.
• Walk the product through the soil at a normal pace and in
as straight a line as possible.
• Till in slightly overlapping rows. To till most eectively,
follow the pattern indicated in Fig. 15. Start by moving the
tiller + cultivator up and down in vertical lines, then work
horizontally from left to right. This will keep the rows even
and ensure that all the ground is tilled without missing
any spots.
• Pay special attention when changing direction. Apply
light pressure to the handle in order to lift the blades and
facilitate the turn. Turn the product around using the wheels
as a guide. Gradually release pressure on the handle and
move the blades back to the ground.
mWARNING! Stop the motor if the product strikes a
foreign object. Switch the product o, remove the batteries,
and let it cool completely. Inspect the product thoroughly for
damage and have any damage repaired before restarting.
Extensive vibration of the product during operation is an
indication of damage. Immediately stop the motor and
promptly inspect and repair the tool.
After Use
• Switch the product o, remove the batteries, and let it
cool completely.
• Check, clean, and store the product as described below.
Fig. 14
On/Oswitch
Safety lock switch
Fig. 15

13
Care + Maintenance
The Golden Rules for Care
mWARNING! Always switch the product o, remove
the batteries, and let the product cool completely before
inspecting, cleaning, or performing any other maintenance
task.
• Keep the product clean. Remove any debris after each use
and before storage.
• Regular and proper cleaning will help ensure safe use and
prolong the life of the product.
• Inspect the product before each use for worn and damaged
parts. If you nd broken and/or worn parts, do not use
the tool.
mWARNING! Only perform the repairs and maintenance
work described in this manual. Any other work must be
performed by a qualied technician.
General Cleaning
• Clean the product with a dry cloth. Use a brush for areas
that are hard to reach.
• Be sure to clean the air vents after every use with a cloth
and brush.
• Remove stubborn dirt with high pressure air (max. 3 bar).
NOTE: Do not use chemical, alkaline, abrasive, or other
aggressive detergents or disinfectants to clean this product as
such substances might damage the tool's surfaces.
• Check for worn or damaged parts. Replace worn parts as
necessary or contact the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563) for
repair before using the product again.
Cleaning the Underbody + Working Tool
mWARNING! Wear safety gloves when working on or
near the working tool. Use appropriate tools (e.g a wooden
stick) when necessary; never use your bare hands!
• Keep the underbody and blades clean and free of debris.
Use a brush or another implement to remove soil from the
working tool.
• All nuts and bolts must be checked periodically for tightness
before operation. After prolonged use, especially in sandy
soil conditions, the working tool will become worn and lose
some of its original shape. Tilling eciency will be reduced
and the working tool should be replaced.
• Have worn or damaged working parts replaced with new
ones of the same type by a qualied technician.
• To prolong the life span of the working tool and the product,
lubricate the blades after each use.
mWARNING! Unexpected blade movement may cause
personal injury. Before servicing, repairing, or inspecting the
unit, turn the motor OFF and remove the batteries. Wait for
the blades to completely stop rotating before conducting
inspection, cleaning, or maintenance.
Before and after each use, check the product and accessories
(or attachments) for wear and damage. When necessary, only
use identical replacement parts that are approved by the
manufacturer.
mWARNING! Contact with hot components (e.g. motor
housing, gear box, etc.) on the machine may cause burns.
Allow the machine to cool o before handling.
IMPORTANT!
• Wear protective gloves when cleaning or maintaining
the machine.
• Do not use cleaning uids or solvents or spray the
machine down with water (especially water under
pressure) when cleaning the machine.
NOTE: After each use, follow these steps to properly clean
the unit:
1. Remove soil, dirt, and foliage stuck in the blades, drive
shaft, tool surface, and vents with a brush or dry cloth.
2. Spray or rub biodegradable oil onto the blades.
3. Clean soiled grips with a damp cloth.
Always inspect the machine for damaged and worn parts after
each use. Check that safety features (i.e. labels, guards, etc.)
are in place. Check that nuts, bolts, and screws are tight.
Changing the Blades
NOTE: The machine is tted with four tilling blades that can
easily be changed in pairs. Both of the steel blade pairs can
be tted on the left or right, as required. Always change both
blade pairs at the same time to avoid imbalance and damage
to the machine.
To replace the blades, follow the steps below:
1. While standing on a at and stable surface, switch o the
unit and remove the batteries.
2. Remove the hex bolts and the self-locking nuts, then
remove the steel blades (Fig. 16).

14
3. Clean the drive shaft with biodegradable oil (Fig. 17).
4. Place the new blades onto the drive shaft so that the holes
on the axles line up with the holes on the drive shaft
(Fig. 17).
5. Insert the hex bolts through the holes and secure them
with the self-locking nuts (Fig. 16).
IMPORTANT: The blades must be set in the correct turning
direction. Note the way the old blades came o and replace
the new ones exactly the same way.
Transportation
• Switch the product o. Ensure that the wheels are set to the
transport position (see Fig. 11, pg. 11).
• Always carry the product by its transport handles.
• If you are transporting the tiller + cultivator in a vehicle,
brace it properly to protect it from heavy impact or
strong vibrations.
• Secure the product to prevent it from falling over
or slipping.
Repair
This product does not contain any parts that can be repaired
by the consumer. Contact an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563)
for assistance.
Storage
• Examine the cordless tiller + cultivator thoroughly for worn,
loose, or damaged parts. Should you need to repair or
replace a part, contact an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563)
for assistance.
• Remove the batteries from the cordless tiller + cultivator
before storing.
• Clean the product as described above.
• Store the product and its accessories in a dark, dry,
frost-free, and well-ventilated place.
• Always store the product in a place that is inaccessible
to children.
• The ideal storage temperature is between 50ºF (10°C) and
86ºF (30°C).
• We recommend using the original package for storage or
covering the product with a suitable cover or enclosure to
protect it against dust.
Battery+ChargerO-SeasonStorage
1. Do not expose your battery packs or charger to water,
rain or allow them to get wet. This could permanently
damage the charger and the battery pack. Do not use oil
or solvents to clean or lubricate your battery packs as the
plastic casing can become brittle and crack, causing a
serious risk of injury.
2. Store the battery packs and charger at room temperature
away from moisture. Do not store in damp locations where
corrosion of terminals may occur. As with other battery
pack types, permanent capacity loss can result if the pack
is stored for long periods of time at high temperatures
(over 120ºF/49ºC).
3. iON+ 24VBAT-LTE lithium-ion battery packs maintain
their charge during storage longer than other battery
pack types. As a general practice, it is best to unplug the
battery charger and remove the battery packs when they
are not in use. Recharge the battery packs every 6 months
to 60% capacity (2 lights on) during o-season storage to
maintain optimal battery performance.
Recycling + Disposal
The product comes in a package that protects it against
damage during shipping. Keep the package until you are
sure that all parts have been delivered and the product is
functioning properly. Recycle the package afterwards or keep it
for long-term storage.
Fig. 16
Hex bolts
Self-
locking
nut
Self-
locking
nut
Fig. 17
Drive shaft
Steel blades Steel blades

WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority
or local store for recycling regulations.
Battery Caution + Disposal
Always dispose of your battery packs according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service and Support
If your Snow Joe®24V-X2-TLR14 cordless tiller + cultivator
requires service or maintenance, please call the Snow Joe®+
Sun Joe®customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model and Serial Numbers
When contacting the company, reordering parts or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
2 4 V - X 2 - T L R 1 4
15
