A Division of Snow Joe®, LLC

OPERATOR’S MANUAL

Model 24V-PP350-CT Form No. SJ-24V-PP350-CT-880E-M

CORDLESS PORTABLE

POWER CLEANER – TOOL ONLY

24-VOLT MAX* | 350 PSI MAX†| 0.6 GPM MAX †

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

mWARNING! This indicates a hazardous situation, which,

if not avoided, could result in death or serious injury.

mCAUTION! This indicates a hazardous situation, which,

if not avoided, could result in minor or moderate injury.

mDANGER! This indicates a hazardous situation, which, if

not followed, will result in death or serious injury.

General Safety

mWARNING! This appliance is not intended for use

by children or by unassisted, unsupervised persons whose

physical, sensory or mental capabilities prevent them from

using it safely. Children should be supervised to ensure that

they do not play with the appliance.

Before starting up your machine, please check it carefully for

any defects. If you nd any, do not start up your machine.

Contact your authorized Snow Joe®+ Sun Joe®dealer or

call the Snow Joe®+ Sun Joe®customer service center at

1-866-SNOWJOE (1-866-766-9563).

mWARNING! When using the power cleaner, basic safety

precautions should always be followed to reduce the risk of

re, electric shock, and personal injury. These include:

• Know your product – Know how to stop the machine

quickly. Thoroughly familiarize yourself with the controls.

• Keep bystanders away – All visitors and pets should be

kept a safe distance away from the work area.

• Use the right product – Do not use this machine for any

job except that for which it is intended.

• Dress properly – Do not wear loose clothing or jewelry.

They can get caught in moving parts. Protective rubber

gloves and non-slip footwear are recommended when

working outdoors.

• mCAUTION! – Exercise caution to avoid slipping or falling.

Wear protective footwear that will protect your feet and

improve your footing on slippery surfaces.

• Stay alert – Watch what you are doing. Use common

sense. Do not operate the power cleaner when you are

tired, or under the inuence of alcohol or drugs.

• Do not overreach – Keep proper footing and balance at

all times.

• Avoid unintentional starting – Do not carry a machine with

power with your nger on the trigger. Make sure the switch

is o before inserting the battery.

• Remove the battery – Remove the battery from the power

cleaner when it is not in use, before servicing it, when

changing accessories, and when performing any other

maintenance task.

• Use safety glasses – Also use safety footwear, snug-tting

clothing, protective gloves, hearing and head protection.

• Check the water temperature – This power cleaner is not

meant to pump hot water. NEVER connect it to a hot water

supply as it will signicantly reduce the life of the pump.

• Store indoors – NEVER store the power cleaner outdoors

or where it could freeze. The pump could be seriously

damaged.

mWARNING! Do not use this appliance without reading

this instruction manual.

mWARNING! This appliance has been designed for

use with cleaning agents that are recommended by the

manufacturer. The use of other cleaning agents or chemicals

may adversely aect the safety of the appliance.

mWARNING! Do not use the appliance within range of

persons unless they are wearing protective clothing.

mWARNING! High-pressure jets can be dangerous if

subject to misuse. The jet must not be directed at persons,

pets, live electrical equipment, or the appliance itself.

• Do not direct the jet at yourself or others in order to clean

clothes or footwear.

• Risk of explosion – Do not spray ammable liquids.

• Keep children away – This cordless power cleaner must

not be used by children or untrained personnel. Close

supervision is necessary when a product is used near

children.

• To ensure appliance safety, use only original replacement

parts from the manufacturer or those approved by the

manufacturer.

mWARNING! During cleaning, maintenance or when

replacing parts, the machine must be disconnected from its

power source by removing the battery.

mWARNING! High-pressure hoses, ttings, and

couplings are important for the safe operation of the appliance.

Use only hoses, ttings, and couplings recommended by

the manufacturer.

mWARNING! Electrical Shock Hazard – Before starting

up your machine, please check it carefully for any defects.

If you nd any, do not start up your machine and contact

your distributor.

IMPORTANT: Do not connect the machine to water supply

which is turbid, muddy or corrosive. Not recommended for use

with salt water, immediately rinse with fresh water for proper

maintenance.

• Check for damaged parts – Do not use the appliance if

any important parts of the appliance are damaged.

• This cordless power cleaner must not be used at

temperatures below 32ºF (0°C).

• In the event of an accident or breakdown, switch o the

machine immediately. (If contact with detergent occurs,

rinse with an abundance of clean water.)

Electric Safety

mWARNING! Read all safety warnings and instructions.

Failure to follow the warnings and instructions may result in

electric shock, re and/or serious injury.

1. Prevent unintentional starting. Ensure the switch is

in the o-position before connecting with the battery

pack, picking up or carrying the appliance. Carrying the

appliance with your nger on the switch or energizing an

appliance that has the switch on invites accidents.

2. Remove the battery pack from the appliance before

making any adjustments, changing accessories, or storing

appliance. Such preventive safety measures reduce the

risk of starting the appliance accidentally.

3. Recharge only with the charger specied by the

manufacturer. A charger that is suitable for one type of

battery pack may create a risk of re when used with

another battery pack.

4. Use appliances only with specically designated battery

packs. Use of any other battery packs may create a risk of

injury and re.

5. When the battery pack is not in use, keep them away

from other metal objects, like paper clips, coins, keys,

nails, screws or other small metal objects, that can make

a connection from one terminal to another. Shorting the

battery terminals together may cause burns or a re.

6. Under abusive conditions, liquid may be ejected from

the battery; avoid contact. If contact accidentally occurs,

ush with water. If liquid contacts eyes, additionally seek

medical help. Liquid ejected from the battery may cause

irritation or burns.

7. Do not use a battery pack or appliance that is damaged

or modied. Damaged or modied batteries may exhibit

unpredictable behavior resulting in re, explosion or risk of

injury.

8. Do not expose a battery pack or appliance to re or

excessive temperature. Exposure to re or temperature

above 265°F (130°C) may cause explosion.

9. Follow all charging instructions and do not charge the

battery pack or appliance outside of the temperature

range specied in the instructions. Charging improperly

or at temperatures outside of the specied range may

damage the battery and increase the risk of re.

10. Have servicing performed by a qualied repair person

using only identical replacement parts. This will ensure

that the safety of the product is maintained.

11. Do not modify or attempt to repair the appliance or the

battery pack (as applicable) except as indicated in the

instructions for use and care.

Battery + Charger

Safety Instructions

NOTE: This unit is tool only. The battery and the charger are

not included. They must be purchased separately.

Model 24V-PP350-CT is compatible with the iON+ 24V System

batteries and chargers. See page 14 for more information.

We pay a great deal of attention to the design of every battery

pack to ensure that we supply you with batteries that are safe,

durable and have a high energy density. The battery cells have

a wide range of safety devices. Each individual cell is initially

formatted and its electrical characteristic curves are recorded.

This data is then used exclusively to be able to assemble the

best possible battery packs.

Despite all the safety precautions, caution must always be

exercised when handling the battery. The following points must

be obeyed at all times to ensure safe use. Safe use can only

be guaranteed if undamaged cells are used. Incorrect handling

of the battery pack can cause cell damage.

IMPORTANT! Analyses conrm that incorrect use and poor

care of high-performance batteries are the main factors

responsible for personal and/or product damage.

mWARNING! Use only approved replacement batteries;

other batteries may damage the cordless power cleaner and

cause it to malfunction, which can lead to serious personal

injury.

mWARNING! Do not use a battery pack or appliance that

is damaged or modied. Damaged or modied battery may

exhibit unpredictable behavior resulting in re, explosion or risk

of injury.

Do not modify or attempt to repair the appliance or the battery

pack except as indicated in the instructions for use and care.

Have your battery pack serviced by a qualied repair person

using only identical replacement parts. This will ensure that the

safety of the battery pack is maintained.

mCAUTION! To reduce the risk of injury, charge the 24V

iON+ lithium-ion battery pack only in the designated 24V iON+

lithium-ion charger. Other types of chargers present risk of re,

personal injury and damage. Do not wire the battery pack to

a power supply plug or car cigarette lighter. Such misuse will

permanently disable or damage the battery pack.

• Avoid dangerous environments – Do not charge the

battery pack in rain, snow or in damp or wet locations.

Do not use the battery pack or charger in the presence of

explosive atmospheres (gaseous fumes, dust or ammable

materials) because sparks may be generated when

connecting or disconnecting the battery pack, which could

lead to a re.

• Charge in a well-ventilated area – Do not block the

charger vents. Keep them clear to allow for proper

ventilation. Do not allow smoking or open ames near a

charging battery pack. Vented gases may explode.

NOTE: The safe temperature range for the battery is 41°F –

105ºF (5°C – 40.5°C). Do not charge the battery outside in

freezing weather; charge it at room temperature.

• Maintain charger cord – When unplugging the charger, pull

the plug, not the cord, from the receptacle to reduce the

risk of damage to the electrical plug and cord. Never carry

the charger by its cord or yank it by the cord to disconnect

it from the receptacle. Keep the cord away from heat, oil

and sharp edges. Make sure the cord will not be stepped

on, tripped over or subjected to damage or stress when the

charger is in use. Do not use the charger with a damaged

cord or plug. Replace a damaged charger immediately.

• Do not use an extension cord unless it is absolutely

necessary – Using the wrong, damaged or improperly

wired extension cord poses a risk of re and electric shock.

If an extension cord must be used, plug the charger into a

properly wired 16 gauge or larger extension cord with the

female plug matching the male plug on the charger. Make

sure that the extension cord is in good electrical condition.

• Use only recommended attachments – Use of an

attachment not recommended or sold by the battery

charger or battery pack manufacturer may result in risk of

re, electric shock or personal injury.

• Unplug charger when not in use – Make sure to

disconnect battery pack from unplugged charger.

mWARNING! To reduce the risk of electric shock,

always unplug the charger before performing any cleaning

or maintenance. Do not allow water to ow into the charger.

Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock

hazards.

• Do not burn or incinerate battery pack – Battery pack

may explode, causing personal injury or damage. Toxic

fumes and materials are created when the battery pack is

burned.

• Do not crush, drop or damage battery pack – Do not use

the battery pack or charger if they have sustained a sharp

blow, been dropped, run over or have been damaged in any

way (i.e. pierced with a nail, hit with a hammer, stepped on,

etc.).

• Do not disassemble – Incorrect reassembly may pose

a serious risk of electric shock, re or exposure to toxic

battery chemicals. If the battery or charger are damaged,

contact an authorized Snow Joe®+ Sun Joe®dealer or

call the Snow Joe®+ Sun Joe®customer service center at

1-866-SNOWJOE (1-866-766-9563) for assistance.

• Battery chemicals cause serious burns – Never let a

damaged battery pack contact the skin, eyes or mouth.

If a damaged battery pack leaks battery chemicals, use

rubber or neoprene gloves to safely dispose of it. If skin

is exposed to battery uids, wash the aected area with

soap and water and rinse with vinegar. If eyes are exposed

to battery chemicals, immediately ush with water for 20

minutes and seek medical attention. Remove and dispose

of contaminated clothing.

• Do not short circuit – A battery pack will short circuit if

a metal object makes a connection between the positive

and negative contacts on the battery pack. Do not place a

battery pack near anything that may cause a short circuit,

such as paper clips, coins, keys, screws, nails and other

metallic objects. A short-circuited battery pack poses a risk

of re and severe personal injury.

• Store your battery pack and charger in a cool, dry

place – Do not store the battery pack or charger where

temperatures may exceed 105ºF (40.5ºC), such as in direct

sunlight or inside a vehicle or metal building during the

summer.

Information about the battery

1. For optimum battery performance, avoid low discharge

cycles by charging the battery pack frequently.

2. Store the battery pack in a cool place, ideally at 77°F

(25°C) and charged to at least 40%.

3. Lithium-ion batteries are subject to a natural aging

process. The battery pack must be replaced at the latest

when their capacity falls to just 80% of its capacity when

new. Weakened cells in an aged battery pack are no

longer capable of meeting the high power requirements

needed for the proper operation of your power cleaner,

and therefore pose a safety risk.

4. Do not throw the battery pack into an open re as this

poses a risk of explosion.

5. Do not ignite the battery pack or expose it to re.

6. Do not exhaustively discharge the battery. Exhaustive

discharge will damage the battery cells. The most

common cause of exhaustive discharge is lengthy storage

or non-use of partially discharged battery. Stop working as

soon as the performance of the battery fall noticeably or

the electronic protection system triggers. Place the battery

pack in storage only after it has been fully charged.

7. Protect the battery and the tool from overloads. Overloads

will quickly result in overheating and cell damage inside

the battery housing even if this overheating is not

apparent externally.

8. Avoid damage and shocks. Immediately replace the

battery that has been dropped from a height of more

than one meter or has been exposed to violent shocks,

even if the housing of the battery pack appears to be

undamaged. The battery cells inside the battery may have

suered serious damage. In such instances, please read

the waste disposal information for proper battery disposal.

9. If the battery pack suers overloading and overheating,

the integrated protective cuto will switch o the

equipment for safety reasons.

IMPORTANT! Do not press the ON/OFF switch any more

if the protective cut-o has been activated. This may

damage the battery pack.

10. Use only original battery pack. The use of other batteries

poses a re risk and may result in injuries or an explosion.

Information about the charger and the

charging process

1. Please check the data marked on the rating plate of the

battery charger. Be sure to connect the battery charger

to a power supply with the voltage marked on the rating

plate. Never connect it to a dierent mains voltage.

2. Protect the battery charger and its cord from damage.

Keep the charger and its cord away from heat, oil and

sharp edges. Have damaged cords repaired without delay

by a qualied technician at an authorized Snow Joe®+

Sun Joe®dealer or call the Snow Joe®+ Sun Joe®

customer service center at 1-866-SNOWJOE

(1-866-766-9563).

3. Electrical plugs must match the outlet. Never modify

the plug in any way. Do not use any adapter plugs with

grounded appliances. Unmodied plugs and matching

outlets will reduce the risk of electric shock.

4. Keep the battery charger, battery pack and the cordless

tool out of the reach of children.

5. Do not use the supplied battery charger to charge other

cordless tools.

6. During periods of heavy use, the battery pack will become

warm. Allow the battery pack to cool to room temperature

before recharging.

7. Do not overcharge the battery. Do not exceed the

maximum charging times. These charging times only apply

to discharged batteries. Frequent connection of a charged

or partially charged battery pack will result in overcharging

and cell damage. Do not leave the battery connected with

the charger for days on end.

8. Never use or charge battery if you suspect that it has

been more than 12 months since the last time they were

charged. There is a high probability that the battery pack

has already suered dangerous damage (exhaustive

discharge).

9. Charging the battery at a temperature below 41°F (5°C)

will cause chemical damage to the cells and may cause a

re.

10. Do not use batteries that have been exposed to heat

during the charging process, as the battery cells may have

suered dangerous damage.

11. Do not use the battery if it suered curvature or

deformation during the charging process or exhibit other

atypical symptoms (gassing, hissing, cracking, etc.).

12. Never fully discharge the battery pack (maximum

recommended depth of discharge is 80%). A complete

discharge of the battery pack will lead to premature aging

of the battery cells.

Protectionfromenvironmentalinuences

1. Wear suitable work clothes. Wear safety goggles.

2. Protect your cordless tool and the battery charger

from moisture and rain – Moisture and rain can cause

dangerous cell damage.

3. Do not use the cordless tool or the battery charger near

vapors and ammable liquids.

4. Use the battery charger and cordless tools only in dry

conditions and at an ambient temperature of 41ºF – 105°F

(5°C – 40.5°C).

5. Do not keep the battery charger in places where the

temperature is liable to reach over 105°F (40.5°C). In

particular, do not leave the battery charger in a car that is

parked in the sunshine.

6. Protect batteries from overheating. Overloads,

overcharging and exposure to direct sunlight will result

in overheating and cell damage. Never charge or work

with batteries that have been overheated – replace them

immediately, if possible.

7. Store the charger and your cordless tool only in dry

locations with an ambient temperature of 41ºF – 105°F

(5°C – 40.5°C). Store your lithium-ion battery packs in a

cool, dry place at a temperature of 77°F (25°C). Protect

the battery pack, charger and cordless tool from humidity

and direct sunlight. Only place fully charged batteries in

storage (charged to at least 40%).

8. Prevent the lithium-ion battery pack from freezing. Battery

packs that were stored below 32°F (0°C) for more than 60

minutes must be discarded.

9. When handling the battery, be wary of electrostatic

charge. Electrostatic discharges can damage the

electronic protection system and the battery cells. Avoid

electrostatic charging and never touch the battery poles.

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all

instructions on the machine before attempting to assemble and operate.

To reduce the risk of injury, user

must keep all bystanders at least

49 ft (15 m) away.

READ THE OPERATOR'S

MANUAL(S) – Read, understand,

and follow all instructions in the

user manual(s) before attempting

to assemble and operate.

SAFETY ALERT – Indicates a

precaution, a warning, or a danger.

WEAR EYE AND HEARING

PROTECTION – For protection

against injury, wear ear defenders

and safety goggles.

WARNING! Do not expose the unit

to rain or wet conditions. Keep dry.

Machine not suitable for connection

to the potable water mains.

Symbols SymbolsDescriptions Descriptions

Wear non-slip footwear that will

protect your feet and improve your

footing on slippery surfaces.

Wear safety gloves during

use to protect hands.

Store indoors. Never store the

power cleaner outdoors.

If the pump freezes, permanent

damage may result.

Indoor use only. Only use battery

charger indoors.

Know Your Cordless Portable Power Cleaner

Read the owner’s manual and safety instructions carefully before operating the cordless portable power cleaner. Compare the

illustration below to the cordless portable power cleaner in order to familiarize yourself with the location of the various controls

and adjustments. Save this manual for future reference.

1. Cordless power cleaner

2. Extension wand

3. Spray wand

4. Multi-spray nozzle

5. Hose lter

6. Floater

7. Siphon hose

1234

5678

9 10

8. Quick connector

9. Siphon hose adapter

10. Safety lock button

11. On/O trigger

12. Battery compartment

13. Garden hose adapter

14. Needle clean-out tool

SOLD SEPARATELY Battery + Charger options available at sunjoe.com

24VBAT

24VBAT-LTE 24VBAT-LT 24VBAT-XR 24VCHRG-QC 24VCHRG-DPC

Technical Data

Battery Voltage*........................................................

24 V D.C.

Battery Capacity

.............................................

See page 14 for
