sunjoe 24V-PSC-CT User manual

© 2021 by Snow Joe®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
A Division of Snow Joe®, LLC
OPERATOR’S MANUAL
Model 24V-PSC-CT Form No. SJ-24V-PSC-CT-880E-M
RCORDLESS PATIO CLEANER
– TOOL ONLY
24V MAX* | 12 INCH
EN
1
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which, if
not followed, will result in death or serious injury.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory or mental capabilities prevent them from
using it safely. Children should be supervised to ensure that
they do not play with the appliance.
Before starting up your machine, please check it carefully for
any defects. If you nd any, do not start up your machine.
Contact your authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! When using the patio cleaner, basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury. These include:
• Avoid dangerous environments.
• Don't use in rain.
• Don't force appliance – It will do the job better and with
less likelihood of a risk of injury at the rate for which it was
designed.
• Store idle appliances indoors – When not in use,
appliances should be stored indoors in dry, and high or
locked-up place out of reach of children.
• Know your product – Know how to stop the machine
quickly. Thoroughly familiarize yourself with the controls.
• Keep bystanders away – All visitors and pets should be
kept a safe distance away from the work area.
• Use the right product – Do not use this machine for any
job except that for which it is intended.
• Dress properly – Do not wear loose clothing or jewelry.
They can get caught in moving parts. Protective rubber
gloves and non-slip footwear are recommended when
working outdoors.
• mCAUTION! – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
• Stay alert – Watch what you are doing. Use common
sense. Do not operate the patio cleaner when you are tired,
or under the inuence of alcohol or drugs.
• Do not overreach – Keep proper footing and balance at
all times.
• Avoid unintentional starting – Do not carry a machine with
power with your nger on the trigger. Make sure the switch
is o before inserting the battery.
• Remove the battery – Remove the battery from the patio
cleaner when it is not in use, before servicing it, when
changing accessories, and when performing any other
maintenance task.
• Use safety glasses – Also use safety footwear, snug-tting
clothing, protective gloves, hearing and head protection.
• Check the water temperature – This power cleaner is
not meant to pump hot water. NEVER connect it to water
supply that with temperature exceed 95°F (35℃).
mWARNING! Do not use this appliance without reading
this instruction manual.
mWARNING! Do not use the appliance within range of
persons unless they are wearing protective clothing.
mWARNING! The jet must not be directed at persons,
pets, or live electrical equipment.
• Do not direct the jet at yourself or others in order to clean
clothes or footwear.
• Risk of explosion – Do not spray ammable liquids.
• Keep children away – This cordless patio cleaner must
not be used by children or untrained personnel. Close
supervision is necessary when a product is used near
children.
• To ensure appliance safety, use only original replacement
parts from the manufacturer or those approved by the
manufacturer.

2
mWARNING! During cleaning, maintenance or when
replacing parts, the machine must be disconnected from its
power source by removing the battery.
mWARNING! Hoses, ttings, and couplings are important
for the safe operation of the appliance. Use only hoses,
ttings, and couplings recommended by the manufacturer.
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
If you nd any, do not start up your machine and contact
your distributor.
IMPORTANT: Do not connect the machine to water supply
which is turbid, muddy or corrosive. Not recommended for use
with salt water, immediately rinse with fresh water for proper
maintenance.
• Check for damaged parts – Before further use of the
appliance, a guard or other part that is damaged should be
carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other condition that may aect its
operation. A guard or other part that is damaged should
be properly repaired or replaced by an authorized service
center unless indicated elsewhere in this manual.
Additional Safety Instructions
Safety Instructions for Patio Cleaners
• Operate the device only with untreated, clean fresh water.
The device must not under any circumstances be operated
with explosive, corrosive or inammable substances.
• Never fully immerse the device in liquids.
• Only operate the device outdoors.
• Do not use the device on surfaces where water is already
present.
• Ensure that the surface to be cleaned is free of sand, stones
or loose elements before starting work. These can be
ung away during cleaning or damage the surface and the
device.
• Do not pull on the connected hose.
• Only switch the device on when the brushes are on the
oor.
• Be aware of the recoil of the device during operation. The
device pushes toward the operator when switched on. Hold
the device securely and maintain a solid and safe footing.
• Do not lift the device o the oor when switched on.
• All live parts in the work area must be protected against
spray water.
• Do not operate the device in the vicinity of any devices that
are connected to electrical power.
• Protect the device from frost and excessive heat. Only
operate and store the device between permitted ambient
temperature range of 41°F (5°C) to 104°F (40°C).
Electric Safety
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
1. Prevent unintentional starting. Ensure the switch is
in the o-position before connecting with the battery
pack, picking up or carrying the appliance. Carrying the
appliance with your nger on the switch or energizing an
appliance that has the switch on invites accidents.
2. Remove the battery pack from the appliance before
making any adjustments, changing accessories, or storing
appliance. Such preventive safety measures reduce the
risk of starting the appliance accidentally.
3. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
4. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
5. When the battery pack is not in use, keep them away
from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make
a connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
6. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
7. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
8. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 265°F (130°C) may cause explosion.
9. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
10. Have servicing performed by a qualied repair person
using only identical replacement parts. This will ensure
that the safety of the product is maintained.
11. Do not modify or attempt to repair the appliance or the
battery pack except as indicated in the instructions for
use and care.

3
Battery + Charger
Safety Instructions
NOTE: This unit is tool only. The battery and the charger are
not included. They must be purchased separately.
Model 24V-PSC-CT is compatible with the iON+ 24V System
batteries and chargers. See page 17 for more information.
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling the battery. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the cordless patio cleaner and
cause it to malfunction, which can lead to serious personal
injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied battery may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the 24V
iON+ lithium-ion battery pack only in the designated 24V iON+
lithium-ion charger. Other types of chargers present risk of re,
personal injury and damage. Do not wire the battery pack to
a power supply plug or car cigarette lighter. Such misuse will
permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when
connecting or disconnecting the battery pack, which could
lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the battery outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to
disconnect battery pack from unplugged charger.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery pack – Battery pack
may explode, causing personal injury or damage. Toxic
fumes and materials are created when the battery pack is
burned.
• Do not crush, drop or damage battery pack – Do not use
the battery pack or charger if they have sustained a sharp
blow, been dropped, run over or have been damaged in any
way (i.e. pierced with a nail, hit with a hammer, stepped on,
etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.

4
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
2. Store the battery pack in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
3. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when their capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your patio cleaner,
and therefore pose a safety risk.
4. Do not throw the battery pack into an open re as this
poses a risk of explosion.
5. Do not ignite the battery pack or expose it to re.
6. Do not exhaustively discharge the battery. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged battery. Stop working as
soon as the performance of the battery fall noticeably or
the electronic protection system triggers. Place the battery
pack in storage only after it has been fully charged.
7. Protect the battery and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not
apparent externally.
8. Avoid damage and shocks. Immediately replace the
battery that has been dropped from a height of more
than one meter or has been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
9. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
10. Use only original battery pack. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack and the cordless
tool out of the reach of children.
5. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before recharging.
6. Do not overcharge the battery. Do not exceed the
maximum charging times. These charging times only apply
to discharged batteries. Frequent connection of a charged
or partially charged battery pack will result in overcharging
and cell damage. Do not leave the battery connected with
the charger for days on end.
7. Never use or charge battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
8. Charging the battery at a temperature below 41°F (5°C)
will cause chemical damage to the cells and may cause a
re.
9. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
10. Do not use the battery if it suered curvature or
deformation during the charging process or exhibit other
atypical symptoms (gassing, hissing, cracking, etc.).
11. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.

5
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger
from moisture and rain – Moisture and rain can cause
dangerous cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery packs in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
9. When handling the battery, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.

6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
To reduce the risk of injury, user
must keep all bystanders at least
49 ft (15 m) away.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
WARNING! Do not expose the unit
to rain or wet conditions. Keep dry.
Symbols SymbolsDescriptions Descriptions
Store indoors. Never store the
patio cleaner outdoors. If the pump
freezes, permanent damage may
result.
Machine not suitable for connection
to the potable water mains.
Wear non-slip footwear that will
protect your feet and improve your
footing on slippery surfaces.
Wear safety gloves during
use to protect hands.
Indoor use only. Only use battery charger indoors.
DANGER! Improper hose
connections and/or leaks can result
in a slip and fall hazard.

7
Know Your Cordless Patio Cleaner
Read the owner’s manual and safety instructions carefully before operating the cordless patio cleaner. Compare the illustration
below to the cordless patio cleaner in order to familiarize yourself with the location of the various controls and adjustments. Save
this manual for future reference.
1. Water ow regulation valve
2. Speed control button
3. Direction control button
4. Auxiliary handle
5. Auxiliary handle knob
6. Upper pole
7. Pole knob
8. Lower pole
9. Wheel frame knob
10. Housing
11. Spray wand (2)
12. Nozzle (2)
13. Rotating brush (2)
14. Brush fastener (2)
15. Wheel (2)
16. Garden hose adapter
17. Wheel frame
18. Battery compartment
19. Garden hose supporter
(with Velcro band)
20. Water inlet adapter
21. On/O switch
22. Safety lock button
1
2
34
5
6
78
9
10
11
12
13
14 15
16
17
18 19 20
21
22
24VBAT-LT
24VBAT-XR
24VCHRG-QC
24VCHRG-DPC
24VBAT
24VBAT-LTE
SOLD SEPARATELY
Battery + Charger options
available at sunjoe.com

8
Technical Data
Motor .................................................................... 500 W Brush
Battery Voltage* .......................................................... 24V D.C.
Cleaning Width Max. .................................... 12 inch (30.5 cm)
Max Water Inlet Pressure ............................................... 1 MPa
Water Flow Control ...................................... 0 GPM – 0.7 GPM
Brush Rotation Speed Control ................. 800 rpm | 1000 rpm
Brush Size (Each) ......................................... � 4 inch x 5.5 inch
(� 10 cm x 14 cm)
Net Weight ......................................................... 12 lbs (5.5 kg)
* Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless patio cleaner with poles
• Pole knob + bolt
• Garden hose adapter
• Manual with registration card
1. Carefully remove the patio cleaner and check to see that
all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless patio
cleaner. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suocation risk!
mWARNING! Do not insert the battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, connect to the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
In order to operate this cordless patio cleaner you will need
a iON+ 24V System battery and charger. See page 17 for
battery and charger options and specications, or for more
information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

9
Charger Operation
mWARNING! Charge only 24V iON+ lithium-ion battery
pack with its compatible 24V iON+ lithium-ion charger. Other
types of batteries may cause personal injury and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24V Lithium-
iON Battery
NOTE: The iON+ 24V lithium-iON battery pack does not
develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before inserting the charger plug.
• Use the battery indicator lights to determine when to charge
your iON+ 24V lithium-iON battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Push the push lock buttons on the battery to pull the
battery pack out from the battery compartment (Fig. 1).
2. Depending on your Snow Joe®+ Sun Joe®charger
model, how to recharge your lithium-ion battery will
vary. You may either insert your 24-volt battery into the
24VCHRG-QC Quick Charger (sold separately) or the
24VCHRG-DPC Dual Port Charger (sold separately)
(Figs. 2 – 3).
3. The battery indicator LEDs will illuminate one by one
during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
4. The 24VCHRG-QC Quick Charger (sold separately) and
the 24VCHRG-DPC Dual Port Charger (sold separately)
are also equipped with additional charging indicating
lights which will indicate the charging status (Figs. 2 – 3).
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery.
mWARNING! This charger does not automatically
turnowhenthebatteryisfullycharged.Please take care
not to leave the battery plugged into the charger. Switch
oorunplugthechargeratthemainswhenchargingis
complete.
In order to operate this cordless patio cleaner you will need
a iON+ 24V System battery and charger. See page 17 for
battery and charger options and specications, or for more
information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Fig. 1
Push lock button
Fig. 2 Battery pack
24VCHRG-QC
quick charger
(Sold separately)
red
Charging
green
Fully
Charged
Fig. 3 Battery pack
24VCHRG-DPC
dual port charger
(Sold separately)
red
Charging
green
Fully
Charged

10
5. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
6. When charging is complete, remove the battery from the
charger by pulling the push lock buttons and sliding the
battery backward to unlock it from the charger.
Assembly
mWARNING! To avoid serious personal injury, read and
understand all safety instructions provided.
mWARNING! Do not insert battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
mWARNING! Before performing any maintenance,
make sure battery is removed. Failure to heed this warning
could result in serious personal injury.
Adjust the Wheel Frame
NOTE: The patio cleaner comes with the wheel frame in
storage position. Follow the instructions below to set the wheel
frame in operation position.
1. Loosen the wheel frame knob, and rotate the wheel frame
assembly to the working position. Rotate the wheel frame
knob to lock the assembly (Fig. 4).
Pole Assembly
1. Slide the upper pole into the lower pole assembly. Align
the screw holes (Fig. 5).
2. Insert the bolt from the back of the pole through the
aligned holes in the poles and secure the front end with
the knob (Fig. 5).
NOTE: You may have to carefully move the wiring inside
the tube to one side if it blocks the path of the bolt.
3. Loosen the auxiliary handle knob and set the auxiliary
handle in a comfortable working position. Lock the
auxiliary handle knob securely (Fig. 6).
NOTE: The auxiliary handle can be set to 7 angles in 30º
increments. Select the optimal position based on the
project's need.
Connect to Water Source
The patio cleaner can be connected with spigot by a regular
garden hose with the included garden hose adapter. Follow the
instruction below for a secure connection.
mWARNING! The patio cleaner must only be used with
clean water; use of unltered water containing corrosive
chemicals will damage the patio cleaner.
mWARNING! The intake water temperature must not
exceed 95ºF/35ºC.
Fig. 4
Wheel frame assembly
Wheel frame knob
Fig. 5
Upper pole
Lower pole
Pole knob
Bolt
Fig. 6
Auxiliary
handle
Auxiliary
handle knob

11
1. Before connecting to water source, make sure the water
ow regulation valve is set to the minimum setting
(Fig. 7).
2. First, connect the patio cleaner with the provided garden
hose adapter. Pull down the collar of the garden hose
adapter and t it onto the water inlet adapter. Release
the collar to lock the adapter in place. Then connect the
garden hose to the garden hose adapter. Twist tightly to
secure (Fig. 8). Rest the garden hose on the garden hose
supporter, and use the Velcro band attached to the hose
supporter to x the garden hose in place (Fig. 9).
3. Attach the other end of the garden hose to water supply
(Fig. 10).
mWARNING! Keep hose away from sharp objects.
Bursting hoses may cause injury. Examine hoses regularly and
replace if damaged. Do not attempt to mend a damaged hose.
mWARNING! Water that has owed through back ow
preventers is considered to be non-potable.
Operation
Control Panel (Fig. 11)
1. Direction control – Use the direction control button and
indicators to set the appliance to move forwards or move
backwards. The appliance is default set in forward mode.
Fig. 7
Waterow
regulation valve
Fig. 8
Water inlet
adapter
Garden hose adapter
Garden hose
Fig. 9
Garden hose
supporter
Velcro band
Fig. 10
Connect to water supply
Garden hose
Fig. 11
Direction
control
button
Direction
control
indicators
Speed
control
indicators
Error
Indicator
Brush
speed
control
button

12
Press the button, the backward indicator will light and
the unit will move backward. Press the button again, the
forward indicator will light and the unit will move forward.
2. Brush speed control – The brush rotation speed can
be set in 2 settings: slow mode of 800 rpm (for smooth
surfaces) and fast mode of 1000 rpm (for rough surfaces).
The appliance is default set in fast mode. Press the speed
control button, the slow mode indicator will light and the
appliance will run in slow mode. Press the speed control
button again to change to fast speed.
3. Error indicator – The error indicator will ash in red to
indicate overcurrent, and the appliance will automatically
shut down.
Starting the Cleaner
1. Make sure the patio cleaner is connected with a
proper water source. Slide the battery into the battery
compartment until it clicks and locks into position
(Fig. 12).
2. Turn the water supply tap on completely.
3. Determine the direction you want to clean and adjust the
spray wands accordingly. Rotate the spray wands to the
back of the machine to clean the rear area. Rotate the spray
wand to the front of the machine to clean the front area.
Rest the spray wands in the slots located on the front and
the back of the machine (Fig. 13).
4. Make sure the water ow regulation valve is set to the
minimum ow position (front), press the safety lock button,
and squeeze the On/O switch. When the appliance is
running, release the safety lock button (Fig. 14).
5. Use the control panel to set the appliance in desired
direction and brush speed. If the rear area needs to be
cleaned, set the appliance in backward mode (Fig. 15).
If the front area need to be cleaned, set the appliance in
forward mode (Fig. 16) Make sure the spray wands are
placed in the corresponding position.
Fig. 12
Battery pack
Fig. 13
Spray
wands
Front slot Back slot
Fig. 14
Safety lock button
On/Oswitch
Fig. 15
CLEAN THE REAR AREA
Backward
mode
Spray wands

13
6. Open the water ow regulation valve and set the water to
a suitable ow for the task. Adjust the water ow during
operation as needed. Push the valve forward to reduce
the water ow, and pull the valve backward to increase the
water ow (Fig. 17).
Basic Cleaning Procedure
The device is intended for removal of dirt and grime from
outdoor surfaces. The device is suitable for wooden, stone or
composite material (WPC) surfaces. Do not use the device for
cleaning planted areas such as a lawn or ower bed.
1. Before cleaning, remove all the loose elements from the
surface.
2. Before starting, position the unit and make sure the
brushes are evenly placed on the surface to be cleaned
(Fig. 18).
3. Start the appliance and adjust the water ow as needed.
Guide the brushes over the surface with light pressure.
4. If you need to change brush speed or cleaning direction
during operation, make sure to close the water ow
completely by pushing the water ow regulation valve
forward before making the change.
NOTE: Once the appliance is shut o and the battery is
removed, it will return to the default setting of fast brush
speed and forward direction.
5. When cleaning delicate surfaces such as wood, it's
recommended to test the device on an inconspicuous
area. During cleaning, do not allow the appliance to
remain in one area for an extended time. Keep it moving.
NOTE: Always clean wooden surfaces in the direction of
the grain. Always clean along the oorboards or wooden
elements and down the slope.
NOTE: If the wood has previously been pre-treated, the
pre-treatment may be removed and cause an uneven
eect.
6. The rotating brush is equipped with side bristle on one
side, which is used for cleaning the bottom of walls and
steps. Walk slowly along the wall and guide the side
bristle to brush the area to be cleaned (Fig. 19).
Shutting Down
1. Push the water ow regulation valve forward to stop the
water ow. Release the trigger. Remove the battery.
2. Turn o the water source. Disconnect the garden hose
connection on the patio cleaner.
Fig. 16
CLEAN THE FRONT AREA
Spray wands
Forward
mode
Fig. 17
Waterow
regulation
valve
Reduce
Increase
Fig. 18
Fig. 19
WALL
Side
bristle

14
3. Before storage, drain the remaining water from the
appliance. Turn the water ow regulation valve to open the
water ow completely, stand the device upright for a while.
The remaining water will drain from the nozzles.
NOTE: An incompletely drained appliance can be
damaged by frost.
mWARNING! Do not knock the housing on the ground to
drain the remaining water.
Storage
mCAUTION! Always store your patio cleaner in a
frost-free location where the temperature will not fall below
32ºF (0ºC). FREEZE DAMAGE IS NOT COVERED BY THE
WARRANTY.
• Store the patio cleaner indoors in a dry, covered area
where it is not subject to adverse weather conditions.
• Always empty water from all hoses, attachments and unit,
before storing.
Maintenance
To order genuine replacement parts or accessories for the
Sun Joe®24V-PSC-CT cordless patio cleaner, please visit
sunjoe.com or contact the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
mCAUTION! Before working on the patio cleaner, remove
the battery from the compartment.
Cleaning
mWARNING! To avoid serious personal injury, always turn
the unit o and remove the battery before cleaning or servicing.
1. Use a wet cloth to clean the outside of the unit. Do not
use strong detergents, household cleaners that contain
aromatic oils (e.g. pine and lemon) or harsh solvents such
as kerosene as these substances can damage the plastic
housing or the handles. Do not use a hose or pressure
washer to clean the appliance.
2. Remove the soiling, debris or sand/stone from the brush.
If necessary, remove the brushes and clean them under
running water. See instruction in Cleaning/Replacing the
Brushes on page 14 for how to disassemble the brushes.
Clean the Water Inlet Filter
To ensure good performance, check and clean the water inlet
lter on the end of the water inlet adapter.
1. Turn the water inlet adapter counterclockwise and remove
it from the water inlet (Fig. 20).
2. Insert a plier into the smaller end of the adapter to take out
the water inlet lter, as shown (Fig. 21).
3. Rinse all components with warm water, including the water
inlet lter, the water inlet adapter, and the garden hose
adapter to prevent any foreign matter from clogging the
appliance.
Cleaning/Replacing the Brushes
IMPORTANT: Only use original replacement parts specied for
this appliance. The use of parts that do not meet the original
equipment specications may lead to improper performance of
the patio cleaner, may compromise operator safety.
1. Turn o the appliance and remove the battery from the
battery compartment.
2. Turn the appliance sideway so the brush fastener is facing
up. Turn the brush fastener counterclockwise to unlock the
brush (Fig. 22).
Fig. 20 Water inlet adapter
Fig. 21
Water inlet
adapter
Water inlet
lter
Fig. 22 Brush fastener
Rotating brush

15
3. Remove both the brush and the brush fastener (Fig. 23).
4. Repeat the above steps to remove the brush and the
brush fastener on the other side.
5. Clean the brushes and the brush fasteners under running
water. If the brushes are worn out, replace with a new set
of brushes.
NOTE: One brush set contains 2 rotating brushes, which
looks dierent. One of the rotating brushes is equipped
with side bristles to clean walls or other vertical surface
(Fig. 24). The rotating brush with side bristles can be
assembled at either left side or right side as needed.
NOTE: When replacing the brushes, pay attention to the
direction of the brush. The tapered end should always
facing outside and be connected with the fastener
(Fig. 25).
Disposal
Recycling the Cleaner
• Do not dispose of appliances as unsorted municipal
waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater and
get into the food chain, damaging your health and well-
being.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Recycling + Disposal
The product comes in a package that protects it against
damage during shipping. Keep the package until you are
sure that all parts have been delivered and the product is
functioning properly. Recycle the package afterwards or keep
it for long-term storage.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes
and materials are emitted into the surrounding atmosphere.
Fig. 23 Brush fastener
Rotating brush
Brush shaft
Fig. 24
Brush set
Side bristle
Fig. 25
Straight end | connect to shaft
Tapered end | connect to fastener

16
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service + Support
If your Sun Joe®24V-PSC-CT cordless patio cleaner requires
service or maintenance, please call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE (1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
2 4 V - P S C - C T
Model #:
Serial #:

17
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe®+ Sun Joe®replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless patio cleaner. Contact Snow Joe®+
Sun Joe®if you are unsure whether it is safe to use a particular replacement part or accessory with your patio cleaner. The use of
any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
24V iON+ Lithium-Ion Battery Quick Charger 24VCHRG-QC
ModelAccessories Item
1
2
3
4
5
24V iON+ 2.0 Ah Lithium-Ion Battery
Battery Runtime Max –
HIgh speed: 10 min | Low speed: 15 min (Continuous cleaning)
24VBAT-LTE
24V iON+ 2.5 Ah Lithium-Ion Battery
Battery Runtime Max –
High speed: 12 min | Low speed: 20 min (Continuous cleaning)
24VBAT-LT
24V iON+ 4.0 Ah Lithium-Ion Battery
Battery Runtime Max –
High speed: 20 min | Low speed: 30 min (Continuous cleaning)
24VBAT
24V iON+ 5.0 Ah Lithium-Ion Battery
Battery Runtime Max –
High speed: 25 min | Low speed: 40 min (Continuous cleaning)
24VBAT-XR
6
24V iON+ Lithium-Ion Dual-Port Battery Charger 24VCHRG-DPC
7
Replacement brush set 24V-PSC-BRUSH
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe®+ Sun Joe®to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).

18 R4_01282020
SNOW JOE®+ SUN JOE®CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®, or Aqua Joe®product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
EN

19

20
