SunnCamp Swift 325 Air User manual

Thank you for purchasing your Awning from SunnCamp. Please read and follow these instructions carefully.
If there is anything you do not understand, please contact your supply retailer for advice.
Awning Flysheet
1
Storm Mate
Straps 2
Flysheet Repair
Kit 1
Air Inflator Pump
1
Draught Skirt
1
Awning Peg Bag
1
Awning Carry Bag
1
Air Roof Bar (Swift
325 air only) 1
Our Warranty necessitates that you unpack and erect this product prior to your first use to ensure that all components are enclosed and in
good condition. Please see our Warranty section for full details of our Warranty conditions. If you find a component missing or a fault, please
contact your SunnCamp stockist for advice.
SITE SELECTION
Select ground that is flat, smooth and dry.
Endeavour to locate the awning entrance away
from direct wind. DO NOT erect on rough
ground where sharp rocks etc may cause
damage to your product.
INFLATABLE TUBES
Your awning comprises of inflatable bladders
retained within a reinforced zipped oxford
polyester retaining sleeve to support the
awning’s flysheet. The inflatable tubes require a
maximum of 5psi pressure to provide rigid
support. DO NOT OVER INFLATE AS THIS
WILL CAUSE THE INFLATABLE BLADDER TO
RUPTURE.
The air valves on the tubes are attached with
retaining straps but are not pre-fitted and will
need to be screwed into place before inflation.
Carefully screw the valve’s body on ensuring
that you do not cross the valve’s thread. Do not
over tighten but ensure sufficiently tight to
produce a good seal. Should you require spare
valves, these are available to purchase from
your SunnCamp stockist.
AIR INFLATOR PUMP
The awning is supplied with a manual air pump
specifically designed for use with the awning’s
air valves. You must not use any other type of
pump (including 12v tyre inflators or air
compressors). Before using the pump it will
require assembling. Follow the instructions on
the front of the pump. Please note that your
pump is fitted with a dump valve and it is
essential you use this to avoid over inflation.
AWNING
Lay the awning flysheet out on the selected
ground area with the entrance correctly
positioned. Slide the beaded rear edge of the
awning in the caravan’s awning channel.
Secure the awning to the ground by the corner
tags using the awning pegs. The inflatable
tube(s) is fitted with a single inflation valve
which is at ground level. Remove the valve cap
(turn anti-clockwise). The valve cap should be
attached to the valve body by a plastic tab, if
not, make sure you keep the cap safe ready to
replace once inflation is complete. Insert the
nozzle of the hose into the valve using firm
pressure. Operate the pump, making necessary
adjustments to the awning flysheet as the tube
inflates. It may be necessary to lift the tube(s) to
help position the tube(s) during the last stages
of inflation. Once you reach a pressure of 5psi,
stop pumping. Carefully disconnect the pump
nozzle and replace the valve cap where
applicable. Repeat this process for all the
inflatable tubes. DO NOT OVER INFLATE AS
THIS MAY CAUSE THE TUBE TO EXPLODE.
PLEASE READ THE SECTION ON AIR
PRESSURE MAINTENANCE. Bring the awning
to an upright position before pegging out the
storm straps. These may need to be re-pegged
later.
STORM MATE STRAPS
Attach the storm mate straps supplied to the
storm mate clips. The storm mate straps are
designed and supplied to help secure the
awning in windy conditions but are not to be
relied upon as an anchor in severe adverse
weather conditions.
ENTRANCE
Ensure that all entrances to the awning are
closed with zips fully secured. Failure to do this
will result in your awning being out of alignment
when fitting the awning pegs.
AWNING PEGS
Peg the awning’s remaining pegging points to
the ground. The rear two corner pegging points
should be pegged first followed by the front two
corner pegging points to obtain the correct
shape. Peg all remaining pegging points
remembering to cross any zip door opening
points. Pegs should be inserted into the ground
at a 45 degree angle away from the awning.
Hammer the pegs into the ground with a
suitable mallet. DO NOT PRESS PEGS INTO
THE GROUND WITH YOUR FOOT AS THIS
MAY BEND THE PEGS.For extraction of pegs
use a tent peg extractor. To allow easy hooking
and unhooking of pegging points at entrances
to your awning (for opening and closing doors)
leave the pegs used at the entrances slightly
raised.
GUY ROPES
Secure each guy rope by positioning with a peg
at a suitable distance from the awning. When
pegged, tighten each guy rope using the guy
rope’s slider equally to bring the awning to its
natural shape. DO NOT OVER TIGHTEN THE
GUY ROPES. GUY ROPES ARE A TRIP
HAZARD ESPECIALLY IN THE DARK.
ADJUSTABLE REAR WEATHER PAD
POLES
These are an optional extra and can be
purchased from your SunnCamp stockist.
Please quote product code DT0052. Rear
supports pad poles should be located into the
pockets at the top back corner of the awning
canvas. The awning’s weather seal pads should
be positioned in between the caravan’s wall and
the support poles. Both rear support poles
should be extended and the mini quick lock
brackets locked to hold the poles under tension.
FRONT ENTRANCE/SIDE
ENTRANCES/WINDOWS
The front entrance of your awning can be rolled
out of the way or it can be raised to create a
porch. Should you wish to create a porch, a
porch pole set is available to purchase from
your SunnCamp stockist. When you close the
doors on your awning check carefully that the
zip covers are fully secured into place by
ensuring the velcro tabs are aligned. Ensure the
awning’s skirt is also correctly positioned and
secured by awning pegs. Failure to do this may
result in water ingress.
SIDE DOORS
The awning’s two side doors have a secondary
mesh panel allowing the door to be fully open to
provide ventilation whilst keeping insects out.
Both the solid outer door and the inner mesh
door can independently be rolled to the side

and secured with toggle and loop fixings. When
closing any of the doors ensure that the zips are
fully secured and the protective flap is in place
and secured by the velcro tabes to prevent
water ingress. When not in use doors should
also be fully pegged.
AIR ROOF BAR (325 Air only)
Inflate the roof bar and position in the centre of
the awning by matching the roof bar velcro ends
to the velcro sewn in panels in your awning.
WEATHER SKIRT
Ensure the awning’s skirt is also correctly
positioned and secured by awning pegs. Failure
to do this may result in water ingress.
SAFETY
The awning fabric use by SunnCamp is fire
retardant to British Standard and whilst fire
retardant it is not fire proof and therefore you
must not smoke or use a naked flame in or near
the awning. This includes traditional ‘camp
fires’. Guy ropes/awning pegs should be
marked so they are not a trip hazard.
SAFETY WARNING: BBQ’S/GAS
APPLIANCES
Your awning has a sewn in label warning
against CARBON MONOXIDE POISONING.
Please be aware of carbon monoxide poisoning
and do not under any circumstances use or
leave a used BBQ (even if you think it is still not
burning) in your awning or tent.
CLEANING, STORING & REPAIRS
Cleaning: The inside and the outside of your
awning should only be cleaned using fresh
clean water and a damp cloth. Do not use
detergents or chemical cleaners.
Storing: Your awning is best stored packed in
its original carry bag (spare bags are available
to purchase through your SunnCamp stockist).
Please note however that if the awning is taken
down when wet, you must thoroughly dry the
awning as soon as possible prior to storing.
After a wet take down, re-erect your awning as
soon as possible to allow the flysheet, guy
ropes etc to fully dry naturally before storing
away. If stored when the flysheet and/or guy
ropes are wet, the awning will suffer from
mildew and will become unusable. Please note
that damage caused by incorrect storage is not
covered by the manufacturer’s warranty.
The air valve’s body must always be left
unscrewed from the tubes when packing away
your awning. Please refer to the section headed
‘VALVES’. Replacement valves are available to
purchase from your SunnCamp stockist.
Repairs: Repairs to your awning should only be
made by the manufacturer’s recommended
agents. Repairs made by an unauthorised third
party will make the manufacturer’s warranty
void.
STORM AND WEATHER SUITABILITY
This awning is designed for light use in normal
weather conditions. It is not suitable for storms,
gales and sub zero or tropical conditions.
UV DETERIORATION
Prolonged exposure to sunlight can weaken the
fabric of the awning. To avoid the risk of UV
deterioration, site the awning in a shaded area
where it will be protected from exposure to
strong sunlight.
MOISTURE
Moisture collecting on the inside of your
awning’s fabric is condensation caused by the
occupier(s). IT IS NOT A SIGN OF LEAKAGE.
Please note condensation and damage caused
by condensation is not covered by the
manufacturer’s warranty.
SEAMS
Your awning has all of its main seams hot air
taped to help prevent leakage. The remaining
seams should be treated with a seam sealant to
maximize the awnings weatherproofing. Seam
sealant is available to purchase from your
SunnCamp stockist.
VALVES
Please note that the valves used on this product
rely on a good air seal which can fail if left
under compression whilst in storage. To reduce
the chance of valve malfunction, the valves
should be fully unscrewed when the product is
in storage. Replacement valves are available to
purchase from your SunnCamp stockist.
INFLATABLE BLADDERS
Please note that an emergency repair patch is
enclosed with your tent/awning for emergency
repairs to small holes. If you over inflate your
bladder, it may explode and this will not be
repairable. Spare bladders with full instructions
are available to purchase from your SunnCamp
stockist.
DISMANTLING
To deflate the tubes, turn the valve’s air release
collar anti clockwise to allow the air to escape.
The release collar will remain attached by a
plastic tab. Please note that un-pegging can be
carried out before, during or after deflation.
When you have fully un-pegged the awning,
slide the beading from the caravan’s awning
channel. The awning should be carefully rolled
prior to placing it back in the carry bag.
DO NOT refit the valve before storing. Please
refer to the section ‘storing’ for more
information.
AIR PRESSURE MAINTENANCE
Changing atmospheric conditions can make air
tubes appear to lose or gain pressure. This is
commonly caused by a rising or lowering in
ambient temperature. Should this occur, the
tube will simply require either a top up or
release of excess pressure. It should not be
considered a sign of leakage or puncture.
IF THE TEMPERATURE DROPS AND YOUR
AWNING HAS LOST PRESSURE, PLEASE BE
AWARE THAT WHEN THE TEMPERATURE
RISES AGAIN THE PRESSURE IN THE
TUBES WILL INCREASE. IF NOT
MONITORED THIS MAY CAUSE YOUR
BLADDER TO RUPTURE WHICH IS NOT
COVERED UNDER WARRANTY.
Where a leak is suspected, you should firstly
inspect the valve to ensure that no parts are
cross threaded and that the air seals are in
good condition and tight. Removing the valve
then re-fitting and re-inflating may help. If you
discover that a valve is damaged or faulty or a
bladder has developed a leak, spares are
available to purchase from your SunnCamp
stockist.
WARRANTY
Please refer to the separate warranty sheet that
is enclosed with your Tent/Awning.

MANUFACTURERS WARRANTY
YournewSunnCampinflatabletent/awningiscoveredbytheManufacturer’sWarrantyagainstanymanufacturingdefectforatwelve
monthperiodfromthedateofpurchase.DuringthisperiodtheCompanyundertakestoreplaceorrepair,freeofcharge,anydefect
whichtheCompanyconsiderstobeduetofaultyworkmanshipormaterial.Pleaseensureyouretainyourreceiptandproofofpurchase
forthisproduct.

Pleasenoteyourtent/awningisintendedforuseasaninflatablestructureforcamping/caravanning.Itisnotatoyandmustnotbe
treatedassuch.Youmustnotjump/bounce/launchyourselfontooroffanyairtubesandyoumustnottwist/bend/wrenchorhandle
anyairtubeinanyaggressivewaywhichwillinevitablycausedamage.Productsarenotcoveredunderwarrantyforanydamagetothe
airtubesdeemedtobecausedbysuchmisuse.

InadditionthefollowingareNOTCOVEREDbytheManufacturer’sWarranty:‐

•OverinflationoftheTPUtubeswhichcausesdamage
•Generalwearandtear
•Defectsarisingfromneglect,misuseorunauthorisedmodifications,additionsorrepairs
•Damagecausedbystorms,windsorotherinclementweatherconditions
•Damagecausedbyabuse,misuse,droppingorothersimilardamagecausedby,orasaresultof,failuretofollowstorageor
erectioninstructions
•Moistureappearingontheinsideoftheflysheet‐thisiscausedbycondensationandisnotaleak
•Leakagethroughtheseamsofthetent/awningduetoexcessiveabrasionanddamagetothesealanttape
•Seamscomingapartasaresultofovertensioning
•Brokenordamagedzipscausedbyundueforce,jammingorincorrectpegging
•Brokenbucklesiftheyhavebeensubjectedtoundueforce
•Damagedcarrybagifduetobeingoverloaded,incorrectpackingorgeneralmisuse
•Inflatablebladderdamageduetowearandtear.Thebladderisaperishablecomponentandisregardedas‘Fairwearandtear’.
Bladdersareeasilyreplaceableandreadilyavailabletopurchasefromyourretailer.
•Damagecausedbyincorrectpitchingordismantling
•Anydamagesustainedduetocookinginsidethetent/awning
•DamagecausedbyUVdegradation
•Productsusedonpermanentsites,displaysorcommercialusebyrentalcompanies
•TransportationorshipmentcoststoandfromtheManufacturerortheirrecognisedagentsforrepairorassessment
againstaWarrantyclaim.

THISDOESNOTAFFECTYOURSTATUTORYRIGHTS

TheManufacturerand/ortheirrecognisedagents,directors,employeesorinsurerswillnotbeliableforconsequentialorother
damages,lossesorexpensesinconnectionwithorbyreasonoftheinabilitytousetheproductforanypurpose.

NOTE:Anyclaim(s)arisingduetomissingpartsorfaultygoodsMUSTbemadebeforeuse.TheManufacturerwillnotbe
responsibleforanyclaimsregardingmissingpartsorfaultyitemswheretheproducthasnotbeencheckedbytheuserpriortouse.

Intheeventofaproductbeingreturnedforassessment,itmustbesentinacompletelydryandcleancondition.Failuretodothis
mayaffectyourwarranty.Failuretodothiswillalsodeemtheproductunfitforinspection.

Sunnflair Ltd, The Coach House, Goodwood Avenue, Brentwood, Essex, CM13 1QD
Tel: [phone] | www.sunncamp.co.uk | Fax: [phone]
