Sunricher Universal Series User manual

1/R/
ww
LED
RF Receiver
Learning Key
Repeater Signal
Recei ve r Rep ea ter
2/G/
cw
3/B/
ww
4/W/
cw
Universal series RF Receiver 09.009PD.04013
Learning Key:
Pairing with RF remote
Function introduction
Important: Read All Instructions Prior to Installation
12-36V DC power input
Common Anode output(+)
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Product Data
Safety & Warnings
Input
Voltage Remarks
Output
Current
12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
Power
12-36VDC Constant current
4x(4.2-12.6)W
4x350mA
12-36VDC Constant current
4x(8.4-25.2)W4x700mA
No.
1
2
3
Waterproof grade: IP20
Radio Frequency : 869.5/916.5/434mhz
Size(LxWxH)
166x53.4x23mm
166x53.4x23mm
166x53.4x23mm
CH 1:R-/WW- output
CH 2:G-/CW- output
CH 3:B-/WW- output
CH 4:W-/CW- output
Receiver / Repeater
Repeater signal input/output
Operation
Do wiring according to connection diagram.
Pair to RF sender with learning key:
1. Connect and wire up the RF receiver correctly, power on.
2. Click on/off button of the remote/panel to turn on it  Click “Learning” key on the receiver  Click a zone
number (ignore this step if the remote/panel has only 1 zone)  Touch the color wheel/slider (click any button
except on/off and zone buttons if the remote has no color wheel/slider)  LED lights connected with the
receiver will blink to indicate successful pairing to the selected zone
Note: one receiver can be paired with max 8 remote controls.
Pairing to RF sender without learning key (Applicable to RF senders with color wheel):
1. Pairing to RF remotes which have color wheel (including single color, CCT and RGBW): power off and power
on the receiver  turn on the remote, then click a zone number twice and press and hold it continuously and
quickly within 10 seconds  LED light connected with the receiver will flash to indicate successful pairing to
the selected zone.
2. Pairing to multi-zone RF touch panels which have color wheel (including single color, CCT and RGBW):
power off and power on the receiver  turn on the panel, then click a zone number three times and press and
hold it continuously and quickly within 10 seconds  LED light connected with the receiver will flash to indicate
successful pairing to the selected zone.
Note: RF remotes without color wheel, single zone RF touch panels with color wheel, and RF touch
panels without color wheel do not have this function.
Pairing to RF sender without learning key (Applicable to all compatible RF senders):
Re-power on the receiver three times continuously to set it into pairing status  Within 15 seconds, click on/off
button of the remote/panel to turn on it  Click a zone number (ignore this step if the remote/panel has only 1
zone)  Touch the color wheel/slider (click any button except on/off and zone buttons if the remote has no color
wheel/slider)  LED lights connected with the receiver will blink to indicate successful pairing to the selected
zone
Delete pairing with learning key:
1. Wire up the RF receiver correctly, power on.
2. Press and hold down the “ Learning Key” button on receiver for over 3 seconds until the connected led light
on receiver flickers twice, which means well deleted.
How to stop running mode of single color LED light caused by RGBW sender interference:
1. When pairing single color LED light to a single color remote, it might be interfered and paired by nearby
RGBW senders, which might control the single color light into running mode. The running mode can not be
stopped by the paired single color remote or by delete pairing.
2. Then we need a remote or wall panel that has color wheel, and pair the remote or wall panel to the receiver
via above mentioned pairing method “Pairing to RF sender without learning key (Applicable to RF senders with
color wheel)”, then touch the color wheel to stop the running mode.
3. Then delete pairing and pair the receiver to the single color remote again, it can be controlled by the remote
again.
Receiver/Repeater setting jumper:
One receiver can connect multiple repeaters to realize perfect sync the sync distance can be over 100m no volt
drop.
Built-in 10 color changing modes are as follows:
Mode 1: Any two colors of RGB mix fade-in & fade-out
Mode 2: RGB three colors mix fade-in & fade-out
Mode 3: RGB three colors mix fade-out & fade-in
Mode 4: RGB flash
Mode 5: RGB three colors fade-in & fade-out successively
Mode 6: RGB three colors fade-in successively
Mode 7: RGB three colors fade-out successively
Mode 8: RGB three colors jump changing successively
Mode 9: R&B two colors mix fade (R in B out), then G fade-in, then R&B mix fade (R out B in), then G fade-out
Mode 10: B fade-out, then G&B mix fade (G out B in), then R&G mix fade (R out G in), then R fade-in

If you use multiple receivers, you have two choices:
Option 1: have all the receivers in the same zone, like zone 1
Zone 1
Option 2: have each receiver in a different zone, like zone 1, 2, 3 or 4
Zone 1 Zone 2 Zone 3
RF remote
RF remote
1/R/
ww
LED
RF Rece iv er
Learn ing Key
Repea ter Sig nal
Receiver Repeater
2/G/
cw
3/B/
ww
4/W/
cw
1/R/
ww
LED
RF Rece iv er
Learn ing Key
Repea ter Sig nal
Receiver Repeater
2/G/
cw
3/B/
ww
4/W/
cw
1/R/
ww
LED
RF Rece iv er
Learn ing Key
Repea ter Sig nal
Receiver Repeater
2/G/
cw
3/B/
ww
4/W/
cw
1/R/
ww
LED
RF Rece iv er
Learn ing Key
Repea ter Sig nal
Receiver Repeater
2/G/
cw
3/B/
ww
4/W/
cw
1/R/
ww
LED
RF Rece iv er
Learn ing Key
Repea ter Sig nal
Receiver Repeater
2/G/
cw
3/B/
ww
4/W/
cw
Wiring Diagram
L
N
GV+
V-
OUTPUT
INPUT
AC Power
50/60Hz
12V/24V/36V
CV PSU
If Con ne ct w ith RGBW LED St ri p
V+ V+
R- R-
G- G-
B- B-
W- W-
V+ V+
1- V-
2- V-
3- V-
4- V-
If Con ne ct w ith Single Co lo r LE D Strip
V+ V+
WW WW
CW CW
WW WW
CW CW
If Con ne ct w ith Dual Colo r LE D St rip
With single color lighting
L
N
GV+
V-
OUTPUT
INPUT
AC Power
50/60Hz
12V/24V/36V
CV PSU
With dual color lighting
L
N
GV+
V-
OUTPUT
INPUT
AC Power
50/60Hz
12V/24V/36V
CV PSU
If Con ne ct w ith RGBW LED St ri p
V+ V+
R- R-
G- G-
B- B-
W- W-
If Con ne ct w ith RGBW LED St ri p
V+ V+
R- R-
G- G-
B- B-
W- W-
Repeater
Repeater
Receiver 1 /R/
ww
LED
RF Receiver
Lea rni ng Key
Rep eater S ignal
Rece ive r Repe ater
2/G /
cw
3/B /
ww
4/W /
cw
1/R /
ww
LED
RF Receiver
Lea rni ng Key
Rep eater S ignal
Rece ive r Repe ater
2/G /
cw
3/B /
ww
4/W /
cw
1/R /
ww
LED
RF Receiver
Lea rni ng Key
Rep eater S ignal
Rece ive r Repe ater
2/G /
cw
3/B /
ww
4/W /
cw
1/R /
ww
LED
RF Receiver
Lea rni ng Key
Rep eater S ignal
Rece ive r Repe ater
2/G /
cw
3/B /
ww
4/W /
cw
1/R /
ww
LED
RF Receiver
Lea rni ng Key
Rep eater S ignal
Rece ive r Repe ater
2/G /
cw
3/B /
ww
4/W /
cw
