Sunroad SR204 User manual

Digital Fishing Barometer
User Manual

Thank you for your purchase of Sunroad SR204 Digital Fishing Barometer.
Design Strategy:
It has been known that barometric pressure is one of the most important factor to
influence fishing. When barometric pressure is higher, DO in the water will be
higher, Fish will be active and has a good appetite. On the contrary, fish will be
dispirited and has a bad appetite. If we know the trend of barometric pressure, it
can greatly increase the chance of successful fishing.
Functions:
◆ Smart tracking barometric pressure for 6 fishing places
◆ Smart remind suitable fishing time
◆ 24 hours barometric pressure trend chart
◆ Adopt super-accuracy barometric sensor from Swiss
◆ 3 days air pressure & temperature record
◆ Incorporates altimeter, barometer, temperature, weather forecast, countdown
timer, time & date functions etc.
◆ IPX 4 waterproof
Digital Fishing barometer
1

Specifications:
Barometer：
Range from 300hpa to 1100hpa
Hpa and Inhg unit switch available
Resolution of 0.1hpa
Thermometer：
Range from -10℃ to +60℃
℃ and ℉ unit switch available
Resolution of 0.1 degree
Data records：6 sets data for fishing places including pressure, time, water depth
countdown timer: Range from 0 to 59:59:59.
Weather forecast:
4 weather status indicating, sunny - partly cloudy - cloudy - rainy.
The weather forecast for next 12 to 24 hours
Time：12h and 24h format switch available,
Date：Month/day format or day/month can interchangeable
Three days history data record: Record three days maximum (minimum)
pressure, maximum (minimum) temperature, provide the basis for fishing.
Low battery alert: Voice remind every 5 minutes when battery is low power.
Battery life：about 12 months.
Spare parts: manual*1 Carabiner: 1pcs Battery:1pcs
2

1. Start
Installing the Battery
Rotate the back cover counter clockwise, gripping the unit with both hands,
using your index fingers and thumbs. Rotate until it stops, then gently pry off the
back cover with your fingers, exposing the battery compartment.
Note: you may have to squeeze on the outer ring (not the display) and apply
force in the clockwise and counterclockwise direction repeatedly (work back and
forth) to free the back cover after extended use, due to sweat and other debris.
Make sure your fingers are dry.
Insert the CR2032 battery (+ side up), and close the back
cover, insuring the gasket is firmly seated in the housing
trace, as shown in Figure 1.
To remove the battery, use a small pen or paperclip to
pry the battery out of the battery compartment.
To close the back cover, rotate the back cover clockwise
until the back cover is completely closed. The display
should be powered up in the time and date mode,
and ready for use.
3
Figure 1

4
2. Operating instructions
2.1 Default mode - time mode
● LCD display：weather forecast, temperature, time, date, local air pressure,
pressure trend arrow, pressure trend chart, fish icon(if pressure is not fit for
fishing, this icon will not display on screen ) etc. Please refer figure 2.
● Pressure trend chart shows air pressure change in passed 24hours, X-axis is
time, Y-axis is air pressure (every division means 2hpa )
● Pressure trend arrow forecast pressure
change in future 12 hours.
● If current pressure is higher than fishing
pressure, the fishing icon will
display on screen. If not, the
fishing icon will disappear.
● Before first using, please set up
initial data such as time, date,
temperature unit, air pressure unit,
altitude unit and sea level altitude
etc. Detail setting method, please
refer item 2.2 (Setting mode) .
Figure 2

2.2 Setting mode
● Under time mode, long press SET 5 second to enter setting mode, weather
icon will be flashed. Press MODE to switch setting items; Press SET to detail
item. Long press SET again to save and exit setting mode.
In setting mode, if there is no operation in 30 seconds, it will save and exit
setting mode automatically.
● Steps: Time mode(Long press SET 5second ) weather forecast(press
MODE) temperature unit(℃/℉0(press MODE) 12H/24H(press MODE)
hour(press MODE) minute(press MODE) month(press MODE)
date(press MODE) pressure unit(hpa/inHg)(press MODE) altitude unit
(m/ft)(press MODE) Suitable fishing pressure(thousand hundred ten one)
(Long press SET) Saving and exit to default mode ( time mode ) .
5
→
→ →
→ → → →
→
→
→
→

6
2.3 Suitable fishing pressure setting
● The default suitable fishing pressure of this unit is 1002hpa. When current
air pressure is higher than it, fishing icon will display on screen.
Altitude (M) Fishing pressure
(hpa) Altitude (M) Fishing pressure (hpa) Altitude (M) Fishing pressure (hpa)
50 1002 1000 889 2100 759
100 996 1500 830 2200 747
200 984 1300 854 2300 735
300 972 1400 842 2400 723
400 960 1500 830 2500 711
500 948 1600 818 2600 699
600 937 1700 806 2700 687
700 925 1800 795 2800 676
800 913 1900 783 2900 664
900 901 2000 771 3000 652
Sheet of fishing pressure for different altitude (Only for reference)
● Different region, different sea level altitude, the fishing pressure will be
different also. Please set suitable fishing pressure base on your local altitude.
● Detail setting method, please refer item 2.2.
.

Figure 3
7
● Under time mode, press button MODE to enter
countdown timer mode.
● LCD display weather forecast, temperature，
countdown timer, suitable fishing icon.
Please refer figure 3.
● Turn on/off countdown
:
: press SET button to turn on/off
countdown. When times up, it will remind by sound
in 30 seconds.
2.4 Countdown timer mode
Countdown timer setting
● Under countdown mode, long press button SET
3 seconds to open backlight; long press it 6
seconds to enter countdown setting mode.
Please refer figure 4.
● Press button MODE to switch setting items. Press
button SET to set digit. Long press SET to save
setting and exit to countdown mode.
Figure 4

2.5 Altimeter mode
● Under time mode, press MODE two times
to enter altitude mode.
● LCD display: weather forecast,
temperature, sea level altitude,
climb altitude.Please refer figure 5.
● Climb altitude: Long press MODE to clear
climb altitude to zero and start to measure.
8
Figure 5
● The altimeter is measured base on air pressure
which changes at any time. Altimeter will take this
change as a vertical movement. Normally there will
be around 20 m changes per day.
● So it’s neccessary to calibrate the altitude
after we know accuracy sea level altitude.
● Under altitude mode,long press SET 6
seconds to enter sea level altitude calibration,
please refer figure 6.
● Press MODE to switch digit. press SET setting
number. Long press SET to save setting and exit to
altimeter mode.
Sea level altitude setting
Figure 6
Sea level
altitude
Climb
altitude

2.6 3days history record mode
●Under countdown timer mode, press MODE three seconds to enter 3days history
record mode “HISTORY” will display on screen.
● LCD display: weather forecast, highest (lowest) temperature, date, highest
(lowest) air pressure, pressure trend chart. Please refer figure 7.
● Press MODE to browse three days record in turn. Press SET to browse the
highest (lowest) temperature and highest (lowest) air pressure for each day.
PS: 3days history record is applying in very
cold weather condition such as winter or
autumn. if temperature difference in 3 days
is changing smaller and smaller, or if the
lowest temperature in 3 days is becoming
higher and higher, it should be fit for fishing
in future few days. Under 3days history
record mode, there is maximum and minimum
temperature for each day. It can help us to
know whether it fit for fishing or not.
9
Figure 7

2.7 Pressure of fishing places
● Under time mode, press SET to enter pressure of fishing places mode.
● LCD display: fishing water depth, time, initial record air pressure, fishing
place code, fishing icon. Please refer figure 6.
● Press MODE to switch among different fishing places code
10
Figure 8

2.7.1 Record initial air pressure for fishing place
Before tracking air pressure for fishing places, at first time when arriving the
fishing place (such as one lake, one river etc.), we should record an initial air
pressure. There are two methods to record initial air pressure as below,
1. Method , under time mode, long press MODE to collect current air pressure
(air pressure will flash on screen), press SET to enter fishing place mode, Press
MODE to select fishing place code. Press SET to save and exit.
11
Press SET
to save and exit Press MODE to select
code of fishing place
Long press MODE,
then press SET

2. 7.2 Pressure tracking for fishing place
● Step 1 Link fishing place
At fishing place, recording the initial air pressure base on method of item 2.6.1.
When coming back usual staying place (such as home or company), please long
press MODE to link fishing place under time mode.
● Step 2 Checking current air pressure of fishing place when we are staying at
usual place (such as home or company), steps are as below,
1. Under time mode, press SET two times to enter pressure tracking mode.
2. Press MODE to switch fishing place code.
12
Initial pressure mode Pressure tracking mode
Press SET

13
2.8 Low Battery Indicator
Unit will be alarm every 5 seconds when battery is low power.
Remark: Please change battery when low power supply. Otherwise it can not
measure pressure accuracy or bring other problems.
2.9 How to know fishing time is coming?
1) Checking fish icon whether display on screen or not. If fishing icon is
displayed on screen, it fits for fishing.
2) Normally pressure range from 1002 hpa ( 29.58inHg ) to 1005.4hpa
(29.67inHg), it is suitable for fishing. Range from 1006hpa (29.70inHg) to
1028hpa(30.35inHg), it is perfect for fishing. For other pressure, it is not
suitable for fishing.
3) Checking pressure trend arrow, if the arrow is increasing, it will be great time
for fishing.
4) During Winter or Autumn, if temperature difference in 3 days is changing
smaller and smaller, or if the lowest temperature in 3 days is becoming higher
and higher, it should be fit for fishing in future few days.
Attentions：
1. This unit is not designed for professional or special purpose.
2. The unit is water proof but not for diving. Don’t submerse in water.
3. Do not operate outside of the specific temperature range（-10º to 60℃)
