Sunshine Technology C53 User manual

C53 4.3-inch
Back-Up Camera
Quick Start Guide

Contents
SAFETY PRECAUTIONS -----------------------------------2
BACK-UP CAMERA SAFETY -------------------------------2
INTRODUCTION ----------------------------------------3
FEATURES ---------------------------------------------4
WHAT’S IN THE BOX -------------------------------------4
INSTALLATION -----------------------------------------5
OVERVIEW --------------------------------------------10
SETTINGS ---------------------------------------------11
SPECIFICATIONS ---------------------------------------13
SAFETY PRECAUTIONS
WARNING
This product contains a chemical known to the State of California to cause
cancer or birth defects or other reproductive harm.
This safety alert symbol indicates that a potential personal injury hazard is
present. The symbol is usually used with a signal word (e.g., WARNING) Which
designates the degree or level of hazard seriousness.
The signal word WARNING indicates a hazardous situation which, if not
avoided, would result in death or serious injury.
The signal word NOTICE indicates a situation which can cause damage to the
product, other personal property and/or to the environment, or cause the
product to operate improperly.
The combination of the safety alert symbol and signal word is used in safety
messages throughout this manual and on safety labels on this product.
WARNING
All safety messages that follow have WARNING level hazards. Failure to
comply could result in death or serious injury.
Back-Up Camera Safety
Please check with your local and state authorities to confirm what is legal
regarding the mounting of the Back-Up Camera to your vehicle. It is the
responsibility of the vehicle owner to understand state and municipal
12

Quick Start Guide
What’ s in the Box
,
Monitor X 1
regulations and ensure compliance.
When installing the Back-Up Camera, the vehicle must be turned off with the
vehicle in park and the park brake applied.
Do not attempt to install the Back-Up Camera while the engine is operating.
Do not modify the wiring in any way.
Only install the Back-Up Camera to a 12-volt vehicle wiring, have the Back-
Up Camera professionally installed.
This device as well as other wireless devices may be subject to interference.
Interference may be caused by cellphones, Bluetooth headsets, Wi-Fi routers,
power lines and other various electrical equipment.
Keep all power cords and wires away from the vehicle’s mechanical
controls.
Do not mount the monitor where it will interfere with your view of the road.
Do not adjust monitor settings while operating the vehicle.
Do not install the Back-Up Camera to the front of your vehicle.
Do not use in a vehicle which sounds an alarm or horn when driving in
reverse.
Do not paint or spray the camera.
The Back-Up Camera displays images behind the vehicle, and is used when
backing up a vehicle. When the vehicle is driven in reverse, the camera is
activated, which sends a signal to the transmitter. The transmitter sends a
video signal to the monitor, which then display what the camera is capturing.
Car Charger
with Power Cable X 1
INTRODUCTION
FEATURES
Color monitor display image gotten from the rear of the vehicle.
Wireless monitor can be mounted to windshield or dash for easy visibility
Adjustable vertical camera angle
Infrared LED lights for nighttime vision
Weatherproof camera With 100°viewing angle.
Parking Asist activates automatically when car is shifted to reverse
Back-Up Camera
with Cable X 1 Extended Cable with Transmitter X 1
34

Installation
Some states or local governments may have regulations or laws that
restrict the use of anything that might impair the clear view of a license
plate. Check local laws for compliance.
For the Back-Up Camera to be properly installed, It must be wired into the
vehicle’s taillight harness. If you are not comfortable or knowledgeable
with 12-Volt or 24-Volt DC wiring, have the system professionally installed.
These instructions are only meant as a general guide due to the number of
different makes and models of vehicles. For vehicle-specific questions,
contact your vehicle’s manufacturer.
(1).Remove the screws that hold
the license plate to the vehicle
and install the Back-Up camera as
the picture shown. The side with
2 screws should face down to the
ground.
The camera should be mounted to a horizontal position relative to the
ground.
(2).Lose the screws on the camera’s bottom, so as to pitch the camera to a
desired angle.
(3).Install the license plate screws to secure the camera to the vehicle.
(4).There’s a notch on the mount of the Back-Up Camera. When you mount
the Back-Up Camera on the vehicle, please run the cable through the notch.
(5).Connect two 4 pin cables and the two arrow on its connector should point
at each other.
(6).Make sure the vehicle engine is off before you check the vehicle wires and
splice the camera wires into the reverse light’s.
(7).Determine which are the positive (+) and negative (-) wires for the reverse
lights on the vehicle. You can use either the right-or-left-side reverse light
wires. For help locating the vehicle’s reverse light circuit, contact your
vehicle’s manufacturer for vehicle-specific wiring diagrams.
NOTICE
NOTICE
NOTICE
NOTICE
56

1
23
6
5
2
4
+
7
1. Positive (+) Wire from Reverse light
2. Wire Connector
3. Reverse light
4. Negative wire (-) from Reverse Light
5. Negative (-) Camera Power Wire (Black)
6. Positive Camera Power Wire (Red)
7. Back-Up Camera
(8).Remove the vehicle’s negative (-) battery cable.
(9).Once the proper wires for the reverse lights have been determined, the
camera wires must be spliced into the vehicle wires. To wire the camera, you
must be knowledgeable in 12-volt or 24-volt DC electrical practices.
(10).The red positive (+) wire from the camera splice into the positive (+) wire
from the reverse lights and the black negative (-) wire from the camera splices
into the negative (-) wire from the reverse lights.
(11).Using the electrical tape to fix the wire you are splicing into the vehicle.
(12).Run the Back-Up Camera’s cables as the picture shown below.
(13).Remove the protector coverage on the adhesive mount of the monitor and
mount the monitor on a proper position that will not interfere with a driver’s
view of the road.
78

(14).The monitor can be adjusted to a desired angle.
(15).Connect the monitor’s power cables and insert the car charger into the
cigarette lighter’s socket.
(16).When you reverse your vehicle, it will activate the monitor automatically
and offer a rear view for parking as assist.
NOTE: The monitor will remined off until the reverse light is triggered.
①
②
③
① Up ② Menu ③ Down
Overview
910
4.3in

Language Setting
The language by default is English. Press the menu button 6 times then the
language setting will pop up. Press Up or Down button to select a preferred
language.
Settings
△English
△Turkish
△Polish
△Japanese
△Chinese
△Russian
Brightness
Contrast
Staturation
△Portuguese
△Spanish
△Italian
△French
△German
Press the“ Up”button to increase the value and press“ down”button to
decrease the value.
Press the“ Up”button to increase the value and press“ down”button to
decrease the value.
Press the“ Up”button to increase the value and press“ down”button to
decrease the value.
Tint
Press the“ Up”button to increase the value and press“ down”button to
decrease the value.
Mode
11 12
√
To select a screen ratio, 16:9.

Specifications
Screen Size 4.3in
Resolution
TV Mode
Operating Temp.
Input voltage
Transmitter
Transmission Range
Operating Temp of Back-Up Camera
640*480
-10°C-65°C
DC 12V
2.4GHz
10m
14℉-158℉
NTSC/PAL
13 14
Transmitter Operating Temp 14℉-131℉
110°
Back-Up Camera Horizontal
Viewing Angle
