Amtel 3088 User manual

1
Amtel –3088
Operating Instructions
Wireless Car Theater System (WCTS)
Model: 3088
Please read these instructions completely before operating this unit.
Actual VCP/VCR unit may
be different from picture.

2
Caution ATTENTION
The Owner’s Manual contains important
RISK OF ELECTRIC SHOCK Operating and maintenance instructions
DO NOT OPEN For your safety, it is necessary to refer to
The manual.
CAUTION: TO REDUCE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK) DANGEROUS VOLTAGE
NO USER SERVICEABLE PARTS INSIDE. Uninsulated Dangerous Voltage, that may
REFER SERVICING TO QUALIFIED SERVICE Give off sufficient magnitude to constitute a
PERSONNEL. Risk of electric shock, is present within the
cabinet of this VCP unit.
WARNING: To reduce the risk of fire or electric shock, do not
Expose this screen and VCP to rain or moisture.
This product operates under provision of Part 15 of the FCC Rules.
Modifications to this product not specifically authorized by Amtel
may void the user’s authority to operate this device.

3
CUSTOMER
Your new Amtel-3088 WCTS utilizes
the latest state of the art solid-state circuit
to provide years of reliable, trouble-free
service. However, for best performance it
must be properly installed and operated.
We urge you to read this instruction
manual thoroughly before operating this
unit. This manual is a valuable part of your
new WCTS. After the unit is installed and
operating properly, store the manual in a
safe place.
Customer’s Record
The serial number of this product is found
on its Back cover. You should note the
serial number of this unit in the space
provided as a permanent record of your
purchase and for identification in the event
of theft or loss.
Model Number:
Serial Number:
This Wireless Car Theater System is
designed in accordance with North
America Standards and cannot be used
in countries that have different
broadcasting systems.
CAUTION: remove AC Adapter from the
cigarette lighter when unit will not be in
use for a prolonged period.
WARNING: To prevent damage by hazards
such as fire or shock do not expose this
unit to rain or moisture.
Please read the IMPORTANT SAFETY
INSTRUCTIONS

4
INDEX
•Important Safety Instructions . . . . . . . . . . . . .5
•Controls, Functions and Adjustments . . . . . . .6
•Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . 7
•Operating Instructions . . . . . . . . . . . . . . . . . . 8
•Maintenance . . . . . . .. .. . . . . . . . . . . . . . . . . .9
•Troubleshooting Chart . . . . . . . . . . . . . . . . . . 10

5
IMPORTANT SAFETY INSTRUCTIONS
1. Save these instructions for later use.
2. Unplug the WCTS from the car
cigarette lighter before cleaning. Use a
damp cloth for cleaning.
3. Use only attachments recommended
by Amtel.
4. Do not use this WCTS near water, I.E.;
near a bathtub, sink, laundry tub, in
a wet basement, or near a swimming
pool, ect.
5. Do not place this WCTS on an
unstable surface, stand or table.
WCTS may fall, causing serious
damage to the WCTS.
6. Slots and openings in the cabinet at
the back or bottom are provided for
ventilation and to protect the WCTS
from overheating. These openings
must not be blocked or covered. This
WCTS should never be placed near or
over a radiator or heater. This WCTS
should not be placed in a built-in
installation such as a bookcase unless
proper ventilation is provided.
7. This WCTS should be operated only
from the type of power source
recommended by Amtel
8. Do not allow anything to rest on the
power cord when connected to the car
cigarette lighter. Do not place the
WCTS where individuals may step on
the cord. Stepping on the cord may
result in damage to the cord.
9. Follow all warning and instructions
marked on the WCTS.
10. Never push objects of any kind into
this WCTS through cabinet slots as
they may touch dangerous voltage
points or short out parts that could
results in fire or electric shock. Never
spill liquid of any kind on the WCTS.
11. Do not attempt to service the WCTS
yourself. Opening or removing covers
may expose you to dangerous voltage
or other hazards. Refer all servicing to
qualified service personnel.
12. Unplug this WCTS from the car
cigarette lighter or battery pack and
refer to qualified service personnel
under the following conditions.
a. When the power supply plug is
damaged or frayed.
b. If liquid has been spilled into
the WCTS.
c. If the WCTS does not operate
normally by following the
operating instructions.
d. If the WCTS had been dropped
and the unit does not work or
the casing has been damaged.
13. When replacement parts are required,
be sure the service technician has
issued replacement parts specified by
the manufacturer that have the same
characteristics as the original part.
UNAUTHORIZED substitutions may
result in fire, electric shock, or other
hazards.
14. All warranty becomes void if any of the
system’s units is dropped or
mechanically abused.

6
CONTROLS, FUNCTIONS AND ADJUSTMENTS
1. Low Battery Indicator Light
2. Power On/Off Switch
3. DC 12V Power Input Jack
4. Video Input Jack
5. Audio Input Jack
6. Contrast Control
7. Brightness Control
8. Volume Control
9. Headphone Jack
10. Headphone Jack
1. Power On/ Off Switch –Slide switch down to turn power ON and up to turn power OFF.
2. Volume Control –Turn the control to desired listening level.
3. Contrast Control –Adjust this control to desired contrast level.
4. Brightness Control –Adjust this control to change overall brightness of the picture.
5. DC 12V Input jack –When you want to use your unit in a car or recreational vehicle,
connect the DC plug from the CAR CORD into the DC 12V input jack and the other end
into the car cigarette lighter of your vehicle.
1
2
3
4
5
6
7
8
9
10

7
POWER SUPPLY
Battery Operation of the LCD Monitor Unit
1. The unit will run for approximately 2-3 hours when fully charged and battery is new.
2. To charge the unit use a 12V car cigarette adapter cord.
3. You can also charge while using the unit, it will take about 3-4 hours to fully charge
the battery. When the unit is being used, it will be about one hour longer than when
the unit is off.
4. Remove plug from cigarette light receptacle when not in use.
Notes:
1. This product is designed to operate on 12V car voltage system.
2. When the battery power is low, the picture will become dimmer.
3. The battery operating time and efficiency decrease at extreme low and extreme high
temperatures (unit is not designed to be operated below 32°F and above 115°F).
CAUTION
Only use the adapters included with this unit or those approved by Amtel. An incorrect
adapter may damage your unit and void our applicable warranty. An incorrect AC/DC
adapter will lengthen the charging time or damage the unit if the voltage is too high.

8
OPERATING PROCEDURES
WCTS OPERATION
1. Remove unit from box.
2. Secure the LCD monitor to the car headrest with straps, secure tightly.
3. Place the VCP on a solid base so that it will not tip over or fall.
4. Slide the Power On/Off Switch to the “ON” position to turn the power ON for the LCD
monitor.
5. Press the Power On/Off button on the VCP to turn the power ON for the VCP.
6. Insert tape into VCP.
7. Press the play button to start the tape.
8. Adjust the volume for proper level of comfort.
9. To turn the WCTS off, press stop on the VCP.
10. Press eject to remove videotape.
11. Press the Power button on the VCP to Shut the VCP off. **
12. Slide the Power button to the Off position to shut off the LCD Monitor.
** To avoid a stuck tape, always eject tape first before unplugging the VCP unit.
Other Controls:
Volume, Brightness, and Contrast. Refer to page 6.
Note:
1. Because of the radio transmission, this unit is subject to noise interferences. This can
occur when this unit is moved around or an object moves between the VCP and the LCD
monitor. When the VCP and the LCD unit are fixed relative to each other, the signal
quality will be the best. **
2. When the battery LED flashes on the LCD display it is time to charge the LCD battery.
Just plug the 12V Car adapter to the LCD display to start the charging process. It takes
about 2-3 hours to charge the battery depending on the battery condition.
3. The LCD display may be charged while being used. The charging time will then be 3-4
hours.
4. Make sure the LCD display’s power is OFF before storing it away.
5. There are two headphone jacks A and B, one jack cuts off the speaker sound completely.
**Sometimes when an interference noise occurs, ask the viewer to move his body just
slightly left or right a couple of inches. This will eliminate the problem.

9
MAINTENANCE
We offer the following suggestions so you will enjoy this product for many years to come.
Do not store in hot areas. High temperatures
can shorten the life of electronic devices,
damage batteries, and can even distort or
melt certain plastics.
Do not drop your product. This will likely
result in failure to operate. Circuit boards
can crack and the cases may not survive the
impact. Handling your product roughly will
shorten its useful life.
Do not use or store in areas with a high level
of dirt or dust. The electronic parts may be
contaminated or will wear prematurely.
Do not use harsh chemicals or strong
cleaning solvents to clean the unit. All that
you need to use is a slightly moist, never wet
cloth.

10
TROUBLESHOOTING CHART
If your WCTS set fails to operate properly, check the following points before seeking service.
Problems Possible Cause and Solution
Sound OK, no picture Contrast and/or Brightness control may need adjustment.
Blurry picture LCD’s internal battery low.
No sound, no picture Check LCD’s power switch, Check VCP’s power switch. Or the LCD’s
internal battery needs to be recharged.
Picture OK, No Sound Volume control may be at minimum position.
Car Battery Operation Check the connections at both ends of car cord. Make sure lighter plug is
plugged in.
NO Power Car adapter cord not plugged in or correctly connected. Battery in LCD
display may need to be charged.
