1080P红外夜视MINI DV 使用说明书
MQ8
提示：
1. 当电池电量不足时, 低电提示，红蓝灯快闪5秒自动保存文件关机。
2. 无卡开机，红蓝灯同时闪3秒自动关机。
3. 有卡开机蓝灯长亮待机，没进入任何工作模式30秒自动关机。
4. 长期不实用，本机电池会有UA级漏电，建议把电池取出保管本机。
1. 开关机按键 2. 模式按键 3. 940/红外夜视灯 4. 咪头 5. 高清摄像头
6. 吊绳口 7.红蓝 LED灯显示口 8. TF卡口 9. 碱性电池扣 10. 后盖
720P录像不闪灯：
点按开机按键2秒左右开机，开机蓝灯长亮待机，再点击开关机1次，蓝灯闪3下灭
为1280X720P录像（声画同步），录像过程灯不提示，10分钟一段自动分段保存连续录
像，循环覆盖，再点按开关按键一次为停止录像，回到蓝灯常亮待机模式。
1080P录像不闪灯：
开机蓝灯长亮待机模式，长按开关机按键3秒左右红灯长亮蓝灯闪3下灭为
1920X1080P录像（声画同步），录像过程中灯不提示，5分钟一段自动分段保存连续录
像，循环覆盖，再点按开关机一次停止录像，回到蓝灯长亮待机模式。
拍照1200万：
开机蓝灯待机模式下点按模式按键1次蓝灯长亮红灯闪一次为拍照一张1200万像素
（4032X3024）自动保存。拍完1张后回到蓝灯长亮模式待机。
红外灯开启关闭：
开启红外灯：开机蓝灯长亮待机模式下，长按模式按键3秒左右蓝灯长亮红灯闪3下
灭，红外灯开启，此时可以再按开机按键1次夜视灯开启录像。
关闭红外灯：在停止录像蓝灯待机模式下，关闭红外夜视灯，按住模式按键4秒左
右，蓝灯长亮红灯闪4下灭为关闭红外夜视灯，关机电池取出，全部恢复默认。
格式化T卡：
开机蓝灯待机模式下点按2次开机按键红蓝灯双闪数秒后停止为TF卡格式化TF卡内容
清空。
复位：机子出现死机，按键无效，无法正常使用，请重新插拔电池一次。
关机：长按6秒左右红蓝灯全灭为关机。
时间水印：
写入视频时间水印，插入TF卡录像后在TF卡更目录下会自动生成一个TXT文件名称
如下：time.txt 点击打开会出现时间水印格式如下：2018/08/08 00:00:00 N （解释：
2018年08月08日00分00秒）N代表无时间水印，Y代表有时间水印：自行修改自己需要
的时间年月日时分秒后把最尾的N改成Y。
参考样式：2018/08/08 00:00:00 Y (把尾改成Y代表视频有时间水印)
2018/08/08 00:00:00 N (把尾改成N代表视频无时间水印)
视频格式 AVI
视频编码 M-JPEG
视频分辨率 1920X1080P 1280X720P
视频帧率 30 fps
播放软件 操作系统自带或主流影音播放软件
图片格式 JPG
影像比例 4:3
支持系统 Windows me/2000/xp/2003/vista; Mac os; Linux
工作时间 约150分钟左右约2.5小时
存储支持 TF 卡
电池类型 7号AAA/1.5V碱性电池
相关参数：
项 目 相 关 参 数
注意事项：
使用场合：敬请严格遵守国家相关法律，不得将此产品用于任何非法用途，否则后果自负。
工作温度：请在自然温度下使用，请勿在人体不能适应的温度下工作。
工作湿度：请在人类适宜生活的环境湿度下使用，请勿将产品置于潮湿的工作环境，产品不具备防水功能，敬请
避免使本产品淋水或暴露在雨水中。
拍摄照度：请在有充足光源的环境下使用，请勿将摄像头直接对着太阳等超强光源，以免光学器件受损。
保洁要求：请勿在粉尘密度过大的环境下使用，以免镜头以及其它部件沾染粉尘，影响摄像效果。
废弃处理：请注意环保，勿随意丢弃本产品。禁止把本产品投掷于火中，以免发生爆炸。
特点：
2节7号AAA/1.5V碱性电池，方便携带随时替换电池无
需担心充电，环保，故障率低。视频格式为1920X1080P &
1280X720P，最大支持64GB TF卡。
● 高品质图像高清 1080P DV DC
● 6颗高功率940夜视灯（肉眼看不见）
● 视频格式为：1920X1080 1280X720P
● 拍照模式为：12M（4032X3024）
● 最大可支持64G的T-flash卡(如果需要使用64G请用本机格式化64G的TF卡一
次才能使用，个别品牌的64G因兼容性问题导致无法使用）
● 2节AAA/1.5V碱性电池可以连续摄像150分钟左右（约2.5小时）

1 2
3 5
46 78
9
10
720P video without ashing:
Press ON/OFF for 2 seconds to turn on the DV. Blue light is on, this means the device is standby;
press once ON/OFF again, blue light gives 3 ashes and is off, this is 1280X720P video (synchronized
sound); no light during the video taking; 10-minute automatic segmentation and saving of continuous
video, cyclic covering; press once ON/OFF again to stop video taking and back to standby mode (blue
light is on).
1080P video without ashing:
Turn it on to enter standby mode (blue light is on); long-press ON/OFF for 3 seconds, red light is on
while blue light gives 3 ashes and is off, this is 1920X1080P (synchronized sound); no light during the
video taking; 5-minute automatic segmentation and saving of continuous video, cyclic covering; press
once ON/OFF again to stop video taking and back to standby mode (blue light is on).
Shoot at 12 mega pixels:
Turn it on to enter standby mode (blue light is on), press MODE once, blue light is on while red light
gives a ash, this means a picture of 12 mega pixels (4032X3024) has been shot and automatically
saved; then the device goes back to standby mode (blue light is on).
IR LED on/off:
IR LED on: In standby mode (blue light is on), long-press MODE for 3 seconds, blue light is on while
red light gives 3 ashes and is off, IR LED is on, now we may press ON/OFF once, night vision is on and
video starts.
IR LED off: In standby mode and video is stopped, turn off IR LED; long-press MODE for 4 seconds,
blue light is on while red light give 4 ashes and is off, this means IR LED is turned off. Turn the device off,
remove the batteries, and all are restored to default state.
Format T card:
In starting up and blue light standby mode, press ON/OFF 2 times, red and blue lights both ash for a
few seconds then stop, this means TF card is formatted, and all data in TF card are cleared.
Reset: If the device crashes, no button works, please remove and reposition the batteries.
Turn off: Long-press for 6 seconds to turn off the device (both red and blue lights are off).
Time watermark:
Write in video time watermark, insert TF card and record video, a TXT le named “time.txt” will be
created automatically under the root directory of TF card; Click to open the le, the time watermark format
will appear as follows 2018/08/08 00:00:00 N (yyyy/mm/dd hh:mm:ss) N means no time watermark, Y
means showing time watermark: After setting the yyyy/mm/dd hh:mm:ss, change N to Y.
Reference patterns:
2018/08/08 00:00:00 Y (The sufx Y means the video shows time watermark)
2018/08/08 00:00:00 N (The sufx N means the video shows no time watermark)
PRECAUTIONS:
Usage occasion: Please strictly abide by the applicable laws of the country; not use this product for any illegal
purposes; otherwise you will be responsible for the consequences.
Operating temperature: Please use at natural temperature; do not operate the device at temperatures that human
body cannot adapt to.
Operating humidity: Please use the product in the humidity suitable for living of human beings. Do not put the product
in a damp working environment. The product is not waterproof. Please avoid exposing it to rain.
Shooting illumination: Please use it in an environment with sufcient light source. Do not point the camera directly at
a strong light source such as the sun to avoid damage to the optical device.
Requirements on cleanliness: Do not use it in an environment with excessive dust, so as to prevent the lens and
other components from being contaminated with dust and affecting the effect.
Disposal considerations: Please protect our environment; do not discard this product at will. To avoid danger, it is
forbidden to throw this product into the re.
1. ON/OFF 2. MODE 3. 940/IR night vision light 4. Mic 5. HD camera 6. Strap holder
7. Red and blue LED lights display 8. TF card slot 9. Alkaline battery clip 10. Back cover
Notes:
1: When the battery is low, red and blue lights quick-ash for 5 seconds, le will be automatically
saved, and then the device is powered off.
2: If the device is powered on but there is no card, red and blue lights ash for 3 seconds, and the
then the device is powered off automatically.
3: If there is card and the device is powered on, blue light is on, the device is standby; it is
powered off automatically if no working mode is started in 30 seconds.
4: If left idle for a long time, the device battery can have uA level leakage. It is suggested that
batteries should be taken out to protect the device.
1080P Infrared Night Vision
MINI DV USER MANUAL
MQ8
Features:
2 AAA/1.5V alkaline batteries, easy to carry and you can
change battery at any time; no need to worry about charging; it
is environmentally friendly and has low failure rate. The video
format is 1920X1080P&1280X720P, supporting max. 64GB TF
card.
● High quality image HD 1080P DV DC
● 6 high power 940 night vision lights (invisible to the naked eye)
● Video format: 1920X1080 1280X720P
● Photo mode: 12M (4032X3024)
● Support up to 64G T-ash card (If 64G is needed, use this device to format
64G TF card once before use; certain brands do not support 64G due to
incompatibility)
● 2 AAA/1.5V alkaline batteries can ensure continuous shooting for about 150
minutes (2.5 hours)
Video format AVI
Video coding M-JPEG
Video resolution 1920X1080P 1280 X720P
Frame rate 30 fps
Player software operating system or bring the mainstream video player software
Picture format JPG
Imaging scale 4:3
Support system Windows me/2000/xp/2003/vista; Mac os; Linux
Working time About 150 minutes (about 2.5 hours)
Storage support TF card
Battery type AAA/1.5V alkaline battery
Related parameters:
Item Relevant parameter
