SWF EMBROIDERY MACHINE
How to Change Version
board
Configure machine
1. Version Change
keys to move the cursor to 'PROGRAM' under INS ALL and
press F7 SELEC to enter the screen in [Picture 5].
Install program and data -
[Picture 3] when SWF logo image as in [Picture 2] appears.
urn ON the machine -
Insert FDD or USB -
1
2
3
Select S AR key -
4
5 Update thread sensing -
6
-
-
-
settings
1) urn ON the machine and press left and right frame move key
2) At the screen shown in [Picture 4], use F1 ↑ and F2 ↓ arrow
[T] OPERATION BOX
A. Content
SWB E 08
Order Tools Required
B. Order
C. Details
JIG /
Instruments
No.
CD CODE No:
Picture 1
Picture 2
Picture 3
4
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
4) At the screen shown in [Picture 4], use F1 ↑ and F2 ↓ arrow
keys to move the cursor to 'PROGRAM' under INS ALL and
press F7 SELEC to enter the screen in [Picture 6].
5) Data file Installation:
program and data are installed using FDD or USB memory stick.
Selecting HREAD under INS ALL in [Picture 4] creates the
same screen.
When you use a diskette, insert the diskette to FDD and press F1
FDD key. When you use a USB memory stick, connect it
press F1 GO key. o cancel, press F3 CANCEL.
to USB POR and press F2 USB. o cancel, press F3 CANCEL.
7) If you want to upgrade the program of thread sensing board,
When you use a diskette, insert the diskette to FDD and press F1
FDD key. When you use a USB memory stick, connect it
3) Program Installation:
6) [Picture 7] is a screen that is automatically created when
to USB POR and press F2 USB. o cancel, press F3 CANCEL.
*Reference: USB memory stick Format ype
File system of USB memory stick must be FA 16
to be loadable. If it is formatted as FA 32, the
USB cannot be used.
Picture 5
Picture 6
Picture 7
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
CON ROL MODULE -> JUMP MAI_MO OR QAMP_X, QAMP_Y
Check below;
shown in [Picture 9] and you can confirm the setting.
8) Lastly, check the machine information at the initial embroidery
screen.
8) [Picture 8] shows machine settings.
Selecting MEMORY [PARA SE ] in [Picture 4] generates the
same screen.
[Picture 8-1~11].
After configuring all items, press F7 NEX to enter the screen
Use F1 ▲, F2 ▼ keys to move to each item. Press
F7 SELEC to generate function screens such as
8
Picture 9
Picture 8 1 Head No. Set Picture 8 2 Color No. Set
Picture 8 3 Setting Trim Type
Picture 8 4 Setting Y Frame
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
Picture 8 5 Setting X Frame
Size
Picture 8 6 Setting alternative function
Picture 8 7 Setting Wheel
Picture 8 9 Setting Basic Value in X Satin Picture 8 10 Setting Basic Value in Y
Satin
Picture 8 10 Setting Cording
Picture 8 8 Setting Sequin
