SunStar 332 Instruction Manual

WARNING
Shock hazard.
Be sure AC power is not connected
before performing this procedure.
2Place the Body Fan Mounting
Bracket behind the Body Fan
Bracket and secure with the
(2) 1/4-20 x 1/2” screws.
In this kit you should find the following parts:
Locate the Body Fan Endcap packaged with the Bench.
It can be identified by the slots for the body fan.
pg. 1 26795-01A
1Slip the Body Fan into the Body Fan
Endcap, as shown. Be sure to insert
the wire connector into the rectangular
hole and route the wire in the groove
in the Body Fan Bracket.
Installing the Body Fan on a SUNSTAR 332 and 432
You will need a #2 Phillips screwdriver to perform this procedure.
(4) - #10 x 1/2” Phillips pan head
sheet metal screws
(2) - 1/4-20 x 1/2” Phillips pan head
machine screws with lock washer
Body Fan
Mounting Bracket
Body Fan

4Working from the inside of the bench,
fasten the Body Fan Mounting
Bracket to the metal endcap with the
(4) #10 x 1/2” screws.
5Close the bench acrylic.
1” SCREW
1” SCREW
1/2” SCREW
3Connect the Body Fan power cord to the
cord coming out of the end of the bench.
Using two #10 x 1/2” screws in the middle
holes and two #10 x 1” screws in the outer
holes (supplied in the main hardware kit)
attach the endcap to the bench. Start all
four screws in their holes before tightening.
Tighten the screws.
pg. 2 26795-01A
