SunVote E100 Owner's manual

Website: www.sunvote.com.cn Tech-Support Tel: [phone]-8024
Version V1.0 Date: 2021-04-25 E-mail: [email protected]
SunVote E100 Quick User Manual
LED Indicator Light Status
⚫Connection status light blinks slowly (once/s) in blue: connect with computer successfully
⚫Connection status light blinks quickly (many times/s) in blue: connect with software successfully.
⚫Data status light flashes: base station has received keypad’s data successfully.
⚫Connection status light and data status light flash alternately: the base station enters the program
upgrade state.
Connection type
Connect via USB port, plug and play under Windows. Accessary of 1.5M USB extending cable can be used.
Management
Base station ID
❖Get & Set ID
⚫Use Tool Kit to get base station ID.
⚫Use Tool Kit to set base station ID. In the same system with multiple base stations, each base station
should have a unique ID. In different systems with multiple base stations, the same ID would not
interfere each other.
⚫Base station ID will be saved until next modification.
❖Get & Set channel
⚫Use Tool kit to get and set base station ID and channel.
⚫Once set, base station ID and channel will be saved until next modification.
⚫When base station channel is changed, all the matched keypads will automatically
change to its new channel, no need to change on keypads one by one.
Matching
Support 3 Matching modes: Match Mode (Quick Match Mode), Free Mode and Auto Mode.
❖Match mode
How to use: Match the keypads to a certain base station before use. The pre-matched keypads
will connect to that base station automatically after power on.
When to use: Multiple conferences in one place and need to avoid interference from each other.
Keypads can only communicate with the matched base station. It cannot communicate with other
base station in other conferences.
❖Free mode
How to use: When the base station is on and in free mode, input a channel number on keypad to
make it connecting to that base station.
When to use: Multiple conferences in one place and need to avoid interference from each other.
Keypads are allowed to move around and it can select a specified base station to communicate
with.
❖Auto mode
How to use: Keypads connect with an auto mode base station automatically after turning on.
When to use: Mostly for rentals. Rental companies could distribute different sets to different
places quickly without too many configurations. Usually only one conference in one place, as in
auto mode, different systems will have interference to each other.
Note: When using the auto mode, ensure that no other base stations are used at the same time
within the effective communication distance (100 meters), otherwise it may cause interference
to other devices.
How to switch matching modes?
Open Tool Kit and connect the base station, select the mode you want. Once set, base station will
save the mode until next modification.

Website: www.sunvote.com.cn Tech-Support Tel: [phone]-8024
Version V1.0 Date: 2021-04-25 E-mail: [email protected]
Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
