MultiModem®
Wireless EDGE, GPRS, CDMA Modems
with Ethernet Interface
Quick Start Guide

Copyright and Technical Support
2 Multi-Tech Systems, Inc. Quick Start Guide
Cabling Guide
MultiModem®Wireless Modem with Ethernet Interface
MTCBA-E-EN, MTCBA-G-EN-Fx, MTCBA-C-EN-Nx
82010074L, Revision E
Copyright © 2005-8 by Multi-Tech Systems, Inc.
This publication may not be reproduced, in whole or in part, without prior
expressed written permission from Multi-Tech Systems, Inc. All rights
reserved. Multi-Tech Systems, Inc. makes no representations or warranty with
respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose.
Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this
publication and to make changes from time to time in the content hereof
without obligation of Multi-Tech Systems, Inc. to notify any person or
organization of such revisions or changes. Check Multi-Tech’s Web site for
current versions of our product documentation.
Record of Revisions
Revision Date Description
D 11/16/07 Updated Hazardous Warnings statements. The
Wireless Activation section now sends the user
to the Wireless Activation Notices for directions
on activating a wireless account. Add AT
Command for changing quad-band frequency.
E 03/07/08 Updated for software version 1.19.
Trademarks
Trademarks and registered trademarks of Multi-Tech Systems, Inc. include
MultiModem, the Multi-Tech logo, and Multi-Tech. All products or technologies
are the trademarks or registered trademarks of their respective holders.
Technical Support
Country By Email By Phone
Europe, Middle East, Africa: [email protected] +(44) 118 959 7774
U.S., Canada, all others: [email protected] 800 972-2439 or
763-717-5863
World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112
763-785-3500 or 800-328-9717
Fax [phone]
Internet Address: http://www.multitech.com

MultiModem Wireless Modem with Ethernet Interface
Multi-Tech Systems, Inc. Quick Start Guide 3
Introduction
The purpose of this guide is to cover safety concepts, the basic
connections, and general setup of the Multi-Tech wireless
MultiModem with Ethernet interface. For detailed information see the
User Guide which is available on the MultiModem CD accompanying
your wireless product and on the Multi-Tech Web site.
Check Multi-Tech’s Web site for current versions of our product
documentation.
Safety
Ethernet Ports Caution
The Ethernet ports are not designed to be connected to a Public
Telecommunication Network.
Handling Precautions
All devices must be handled with certain precautions to avoid
damage due to the accumulation of static charge. Although input
protection circuitry has been incorporated into the devices to
minimize the effect of this static build up, proper precautions
should be taken to avoid exposure to electrostatic discharge
during handling and mounting.
Caution: Maintain a separation distance of at least 20 cm (8
inches) between the transmitter’s antenna and the body of
the user or nearby persons. The modem is not designed for,
nor intended to be, used in applications within 20 cm (8
inches) of the body of the user.
Safety Instructions for Hazardous Locations
Installation Instructions
1. The modems are open devices intended for installation in
an ultimate enclosure suitable for the intended application.
2. THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I,
DIVISION 2, GROUPS A, B, C, AND D OR NON-
HAZARDOUS LOCATIONS ONLY.

MultiModem Wireless Modem with Ethernet Interface
4 Multi-Tech Systems, Inc. Quick Start Guide
3. “WARNING – Explosion Hazard – Substitution of
Components may Impair Suitability for Class I, Division 2”.
4. “WARNING – Explosion Hazard – Do not Disconnect
Equipment Unless Power has been switched off or the
area is known to be Non-hazardous”.
5. “WARNING – Explosion Hazard – Do not replace fuse
unless power has been switched off or the area is known
to be non-hazardous”
6. “WARNING – Do not install or remove SIM card unless
power has been switched off or the area is known to be
non-hazardous”.
Vehicle Safety
•Do not use your Wireless MultiModem while driving, unless
equipped with a correctly installed vehicle kit allowing ‘Hands-
Free’ Operation.
•Respect national regulations on the use of cellular telephones
in vehicles. Road safety always comes first.
•If incorrectly installed in a vehicle, the operation of Wireless
MultiModem telephone could interfere with the correct
functioning of vehicle electronics. To avoid such problems, be
sure that qualified personnel have performed the installation.
Verification of the protection of vehicle electronics should be
part of the installation.
•The use of an alert device to operate a vehicle’s lights or horn
on public roads is not permitted.

MultiModem Wireless Modem with Ethernet Interface
Multi-Tech Systems, Inc. Quick Start Guide 5
Ship Kit Contents
Unbundled Package
Modem with Not Accessories Bundled Package Modem with Accessories
1 modem
1 fused DC power cable
4 rubber feet for flat
surface mounting
1 Quick Start Guide
1 MultiModem CD
Note: You must supply
an antenna.
1 modem
1 power supply cable
(varies)
4 rubber feet for flat
surface mounting
1 antenna
1 Quick Start Guide
1 MultiModem CD
Note: See the User Guide for antenna specifications.
Set Up Your Wireless Modem
Obtain a Wireless Account
Please see the wireless account Activation Notices located
on the MultiModem CD. Choose the one for your wireless
network provider and follow the directions to activate your
account.
Phone Numbers for the Wireless Modem
Every wireless modem will have its own unique phone number.
The phone number may simply be given to you by your
wireless service provider. For GPRS and EDGE, it may also be
on the SIM card. Wireless provider implementations may vary.

MultiModem Wireless Modem with Ethernet Interface
6 Multi-Tech Systems, Inc. Quick Start Guide
Connect the Antenna, Ethernet, and
Power
•Antenna. Connect a suitable antenna to SMA connector. An
antenna is supplied with the bundled package ship kit. If you
purchase a single unit, you must supply your own antenna.
See the User Guide for antenna/RF specifications.
•Ethernet. Using an RJ-45 Ethernet cable, connect the
10/100 jack to an internal network switch or hub.
•Power. Plug one end of the power cord into the device and
the other end onto a live power outlet.
Notes
•The PWR LED. The PWR LED on the front panel lights up
after power-up. LEDs are defined in the User Guide.
•Reset Button. Pressing and holding the Reset button for 5
seconds will restore all factory default settings.
Back Panel View
Antenna Power Supply Cable
Ethernet Cable
This part of the
power supply cable
varies by the region
of the world to which
the product is
shipped: NAM / EU /
GB / IE

MultiModem Wireless Modem with Ethernet Interface
Multi-Tech Systems, Inc. Quick Start Guide 7
Fused DC Power Connection
•Connect the fused DC power
cable to the DC power source on
the vehicle or machine in which
you are mounting the modem. Be
sure the GND connection is
correct.
•Connect red wire to + (positive)
and black wire to – (negative).
Note: For automotive application:
according to the type of
application, you can use
permanent “+” or key-switched
“+”. Connect the power supply to
its source (for example, in a
mobile situation, to the vehicle’s
DC fuse/terminal block).
Warning: Over-voltage protection
is provided on the device. To
ensure complete protection, you
may want to add additional
filtering to the DC input.
Set Your PC’s TCP/IP Address for
Ethernet Functionality
After the wireless account is established and the device is
properly connected, set up the TCP/IP address on your PC, if
not previously set.
1. Open the PC's Control Panel.
2. Select Networks or Network Connections.
3. Under Protocols, select TCP/IP.
4. Under Properties, choose one of the following:

MultiModem Wireless Modem with Ethernet Interface
8 Multi-Tech Systems, Inc. Quick Start Guide
∗Check Obtain IP Address Automatically and Obtain
DNS Server Address Automatically. If you check
these, then the DHCP function obtains the IP Address
automatically from the Ethernet wireless modem, or
∗Check Use the Following IP Address and Use the
Following DNS Server Address. If you check these,
then enter the following addresses:
IP Address: 192.168.2.2
Subnet Mask: 255.255.255.0
Gateway: 192.168.2.1
Specify a DNS Server. For example, 205.171.3.65
Using AT Commands
Prerequisite Steps
In order to communicate directly with the internal cellular
module with AT commands, you first must disable PPP by
logging into the Web Management software:
1. From the workstation, open a Web browser.
Type the default Gateway Address: http://192.168.2.1
2. Login
After entering the Address, the Login screen displays.
•Type the default User name: admin (all lower-case).
•Type the default password: admin (all lower-case).
Note: User name and Password are case-sensitive
(both must be typed in lower-case). A password can
be up to 12 characters. If Windows displays the
AutoComplete screen, you may want to click No to
tell the Windows OS not to remember the password;
this helps maintain PC security.
•Click the Login button. The Web Management Home
screen displays.
3. Go to the Wizard Setup Screen
•On the Wizard Setup screen under PPP
Configuration, disable PPP.
•Click the Submit button and then Save & Restart.

MultiModem Wireless Modem with Ethernet Interface
Multi-Tech Systems, Inc. Quick Start Guide 9
4. Open the Command Window and Access Modem
Mode
You must be in modem mode in order to enter AT
Commands.
•From the workstation, open the command window by
clicking the Start button and selecting Run.
•Type CMD to open the command window. Click OK.
•When the command window opens, type: Telnet
192.168.2.1 5000
Note: 5000 is the port number.
•At Login, enter the user name admin.
•At Password, enter the password admin. Once
logged in, you can use AT commands to
communicate with the cellular module.
For CDMA, you will have to enter some AT Commands
to complete your activation steps. See the Customer
Activation Notices included in your ship kit.
For GPRS, you will have to use AT Commands to
change the quad-band frequency.
For CDMA, EDGE, and GPRS, you can use AT
commands to verify signal strength, check network
registration and roaming status, etc. See the AT
Command guides available on the CD in your ship kit
for other functionality you can view and set.
AT Command for Changing the GPRS
Quad-Band Frequency
For the GPRS Quad-Band product, the default setting may be either
850/1900MHz dual-band mode or 900/1800MHz depending upon
the model you ordered. If for any reason you want to change the
band, you can accomplish this by using the +WMBS command.
Steps for Changing the GPRS Band for Ethernet Models
Using the command window (see steps above), you can enter the
AT Command for changing the GPRS Band.

MultiModem Wireless Modem with Ethernet Interface
10 Multi-Tech Systems, Inc. Quick Start Guide
Type AT+WMBS=<Band>,<Param>. Press Enter.
For <Band>, enter the option you desire:
4= Dual-band mode 850/1900MHz
5= Dual-band mode 900/1800MHz
For <Param>, enter the option you desire:
0= The modem will have to be reset to start on the
specified band(s). This is the default.
1= The modem restarts immediately on the
specified band(s).
Example: AT+WMBS=4,0. Press Enter.
Exiting Modem Mode
1. After the last AT Command is entered, press:
CTRL + ] (the right bracket).
2. The following prompt displays:
telnet>
Type quit and press Enter.
3. Then the following prompt displays:
c:>
Type exit and press Enter.
