SUPA PEG FRONTIER Manual

SET UP
INSTRUCTIONS
www.supapeg.com.au

FIRE PIT SET UP
INCLUDES:
01
Find panel “A”, there is an
arrow on the bottom of the
panel. Following the arrow
direction, connect panel “A”
with first middle panel “B”.
Check contents and
separate for set up.
A BCD E
F
H
G
BASE PLATE
BBQ RAILS LOCKING BASE PLATE
RETAINING PIN1 X START PANEL 1 X END PANEL 1 X CARRY BAG 6 X MIDDLE PANELS
02
[phone] [e-mail] 14 BINARY STREET, YATALA - QLD

FIRE PIT SET UP
Go through in a anti
clockwise position
connecting all middle panels.
03
Connect last panel “C”and go
around checking if all panels
are propriely connected and
aligned at same level.
04
Find a litle arrow on the
locking base plate “G” and
by holding it with your
fingers, connect arrow with
arrow (the arrow in the
locking base plate “G” and
the arrow at the bottom of
your first panel “A”).
05
[phone] [e-mail] 14 BINARY STREET, YATALA - QLD

FIRE PIT SET UP
Holding the bottom of
start panel “A”, go
through connecting the
base to all panels.
06
Hold the retaining pin
“D” on the little tab at
the top and slide down
to lock it all in place.
08
09
Connect start panel
“A” to end panel “C”.
This unit is mainly used as a Fire
Pit, but you can easily use it for
cooking by simply placing the BBQ
rails “H” in place and add your
favourite pot, pan or grill plate.
07
