Sunjoy A301016500 User manual

1/ 8
Country of Origin: China Production Number: XXXXXXXXXX
ASSEMBLY INSTRUCTION
Item No.: A301016500


WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
1-(866)-578-6569
[email protected]

2/ 8
Country of Origin: China Production Number: XXXXXXXXXX
Warning! Pleasereadandunderstandthisentiremanualbeforeattemptingto
assembleoroperatethisproduct.
Caution!Somepartsmaycontainsharpedges.Pleasewearprotectiveglovesduring
Caution！
Properplacementofyourfirebowlisessential.
Keepchildrenawayduringassembly.
Thisproductcontainssmallpartswhichcanbeswallowedbychildren.
Keepfingersawayfromtheplaceswheretheycanbepinchedortrapped.
Pleasewearprotectiveglovesduringassembly.
Donotattempttoassemblethefirebowlifanypartsaremissing.









•Thisfireplaceisintendedforoutdooruseonly.NEVERLEAVEAFIREUNATTENDED.
•DONOTusethefireplacetocookfood.Thefireplaceisnotdesignedforgrillingfood.
•DONOTallowchildrenorpetsnearthefireplacewithoutsupervision.
•DONOTtouchthesurfaceofthefireplacewhileinuseasitmaycauseburns.
•NEVERburninvehicles,tentsorindoors.CARBONMONOXIDEHAZARD.
•Useapokerand/orheat‐resistantglovestoopen/closethemeshcoverwhileinuse.
•DONOTusewatertoextinguishasthisisdangerousandcancausedamage.
•Burnonlyuntreatedwoodlogsinthisfirebowl.
•DONOTusegasolineorkerosenetostartthefireinthisfirebowl.
•DONOTusethisfireplaceonawooddeck,longordrygrass,leaves,oracombustiblesurface.
•DONOTattempttomovethefireplacewhileitishotorinuse.
•Placethefireplacenocloserthan8ft.fromwallsorcombustiblesduringuse.
•Adequatefireextinguishingmaterialshouldbereadilyavailable.
•Thepokerhandlemaybecomehotduringandafteruse.
•Checklocalfireregulationsandmunicipalby‐lawsforinformationregardingthesafeuseof
thisfirepit.









Placeallpartsfromtheboxinaclearedareaandpositionthemonthefloorinfrontofyou.Remove
allpackingmaterialsandplacethembackintothebox.Donotdisposeofthepackingmaterialsuntil
assemblyiscompleted.Readeachstepcarefullybeforebeginninganyassemblyandmakesureyou
understandeachstep.





Important Safety Instructions

3/ 8
Country of Origin: China Production Number: XXXXXXXXXX








Exploded Drawing

4/ 8
Country of Origin: China Production Number: XXXXXXXXXX











Label Part Number Description Qty Part Image
A
P005100124
Screen Handle 1
B
P002600042
Mesh Screen 1
C
P002500100
Fire Bowl 1
D
P005400297
Leg 4
E
P002700035
Poker 1
F
P005000416
Support tube 4
Label Part Number Description Qty Part Image
AA R990020765 Bolt M6*50 4
BB H010110039 Bolt M6*20 4
CC H040020004 Nut M6 1
DD H090010017 Wrench M6 1
Parts List
Hardware Pack

5/ 8
Country of Origin: China Production Number: XXXXXXXXXX







Assembly Step 1
1x 4x
4x
4x
4x

6/ 8
Country of Origin: China Production Number: XXXXXXXXXX

1x
1x
1x
Assembly Step 2

7/ 8
Country of Origin: China Production Number: XXXXXXXXXX






1x
Assembly Step 3

8/ 8
Country of Origin: China Production Number: XXXXXXXXXX
Lighting
•Makesurethereisonlyasmallamountofashinthebottomofthebowl.
•Placealayerofdryseasonedhardwoodthatcoversnomorethan3/4ofthebowl.
•Useamatchtolightkindlingorfirestarter.
• Usethepokerthatisprovidedtooperate.Pleasewearheat‐resistantglovesduringuse. 

Extinguishing
•Allowfiretoburnitselfout.
• DONOTusewatertoextinguishasthisisdangerousandcandamagethisfireplace. 

Cleaning
•Thisfireplaceshouldbecleanedonaregularbasistopromotesaferexperienceandlongproductlife.
•DONOTattempttocleanthisfireplaceuntilthefireisCOMPLETELYoutandcooltotouch.
• DONOTuseovencleanerorabrasivecleanerasthiswilldamagethefirebowl. 

Storage
•DONOTmoveorstorethisfireplaceuntilthefireisCOMPLETELYoutandcooltotouch.
•Storethefireplaceinadrylocationtomaximizeproductlife.
•Storeassembledfireplaceinalocationawayfromchildrenandpets.




Thislimitedwarrantyisextendedtotheoriginalpurchaserandappliestodefectsinmaterialand
workmanshipofyouritemprovidedtheitemismaintainedwithcareandusedonlyforpersonal,
residentialpurposes.ThemanufacturerSunjoyGroupwarrantsthisitemisfreeofdefectsinmaterial
andworkmanshipforaperiodof6months.Ifanydefectisfound,pleasecallourSunjoyGroup
customerservicedepartmentat1‐866‐578‐6569oremailat[email protected]for
help.ThemanufacturerSunjoyGroupwillnotcovertransportationordeliverycostsorcompensate
theindividualoranyoutsidepartyforassemblingordisassemblingtheproduct.
Caution!
Checkallscrewsandnutsperiodicallyfortightness,fasteningthemagainasrequired.
LIMITED WARRANTY
Cleanin
g
and Maintenance
