SupaScoota SPARTAN User manual

Motorized vehicle
SUMO
SPARTAN
User Manual
You must read this manual before using your SPARTAN
MDSS GmbH
Schiffgraben 41
30175 Hannover, Germany
Distributor:
P/N: 9034595 Rev. 01/20

Table of contents
SAVE THIS MANUAL FOR FUTURE REFERENCE.
- 1 -
INTENDED USE
 Intended use of device
As a motorized portable electric vehicle for indoor or outside use by
persons with medical conditions require assistance.
 Device description
A battery operated lightweight portable mobility device designed for
personal travel indoors and limited outdoor use
It is used in a sitting position and operated by a hand controlled
throttle located on the handle bars. Brake is automatically controlled
when releasing the throttle by the electronic controller and magnetic
motor brake.
The product is supplied ready to use with a battery and charger and
it can be disassembled and folded for transport.
 Technological characteristics
Unique one piece folded frame available in several models to suit
different users and applications. The compact design and minimal
component weight are of significant benefit to the elderly who are
independent and have a need to transport the scooter in their motor
vehicle. The electronically controlled speed reduction system which
operates when turning is a valuable safety features for elderly
users.
- 2 -
Contents Pages
Intended use- - - - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - -2
Safety Symbols, Words and Labels- - - - - - - - - - - - - - - - - - -3
Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - -4
Electromagnetic Interference - - - - - - - - - - - - - - - - - - - - - - -8
Assemble the Seat - - - - - -- - - - - - - - - - - - - - - - - - - - - - 11
Foldable Seat Frame - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11
To Open the Spartan - - - - - - - - - - - - - - - - - - - - - - - - -13
Anti-Tip Wheel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -18
Drive Wheel Release Mechanism - - - - - -- - - - - - - - - - - - - 19
Cruise Control, Lights and Switches - - -- - - - - - - - - - - - - - -20
Auto Switch Off Electronic System - - - - - - - - - - - - - - - - - - -22
Electronic Stability Control (ESC) - - - - - - - - - - - - - - - - - - -23
Swivel Seat (Optional) - - - - - - - - - - - - - - - - - - - - - -24
Spare Battery Tray (Optional) - - - - - - - - - - - - - - - - - - - - - -24
Spare Lithium Battery (Optional) - - - - - - - - - - - - - - - - - - - -25
Switch the Battery Type - - - - - - - - - - - - - - - - - - -26
Front Wheel Removal (Optional) - - - - - - - - - - - - - - - - - - - -26
How To Clean the Scooter - - - - - - - - - - - - - - - - - - - - - - - -27
Precaution - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 28
Fold the Spartan - - - - - - - - - - - - - - - - - - - - - - - - - - -28
Charge Battery - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 32
Battery Charger - - - - - - - - - - - - - - - - - - - - - - - - - - - 34
Battery Care & Maintenance - - - - - - - - - - - - - - - - - - - - - - 35
SLA Battery Wiring Diagram- - - - - - - - - - - - - - - - - - - - - - - 36
Specifications- - - - - - - - - - - - - - - - - - - - - -- - - - - - - - - - - 37
SupaScoota Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - 38
Purchaser information - - - - - - - - - - - - - - - - - - - - - - - - - - 39
Manufacturer: EUROGREEN INTERNATIONAL INC.
No.48, Ln.220, Sec.1, Fuzun Rd, Yuanlin Township,
Changhua County, 51055, TAIWAN

SAFETY SYMBOLS, WORDS AND LABELS
What You Need to Know About Safety Instructions
Warning and Important Safety Instructions appeared in this manual
are not meant to cover all possible conditions and situations that
may occur. Common sense, caution and care must be exercised
when operating or cleaning your SUMO.
Always contact your dealer, distributor, service agent or
manufacturer about problems or conditions you do not understand.
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
Radio wave sources may affect motorized
vehicle.
- 3 -
SAFETY INSTRUCTIONS
●Please read this manual before using your SUMO.
●Check the frame lock and all clamps before using your SUMO.
●Do not turn your Scooter “On” before you are seated and ready to go.
●Practice riding in an open area free of vehicles, pedestrians and
obstacles before using your SUMO near other people. It is also
recommended that someone accompanies you during practice.
●The SUMO was designed for hard and flat surfaces. It should not
be used on steep slopes or loose surfaces
●Reduce speed when turning.
●Take extreme care when driving in wet conditions.
●For your safety, it is recommended that you wear a helmet.
●Do not operate the Forward/Reverse switch when moving. This
could damage your SUMO.
●Do not use the SUMO on slopes over 6 degrees.
●Do not drive on slopes when the yellow battery light is on.
Also, you should recharge your battery as soon as possible.
If the red battery light comes on or is flashing, you should stop
using immediately and recharge the battery, or fit a spare battery
if you have one.
●Always switch the power “Off” before leaving your scooter or while
it is unattended. You can also disconnect the battery plug
before leaving your scooter.
●Do not put your fingers on the Speed Lever before you turn the
key switch “On”. This could cause the SUMO to move
without warning.
●Your key switch must be in the “Off” position before connecting
the battery lead.
- 4 -

A. ENVIRONMENTAL CONDITIONS WARNING: The scooter is not
designed for use in a heavy rain storm, or in snowy or icy
conditions.
i. Contact with water or excessive moisture can cause an
electrical malfunction. The frame, motors and other scooter
parts are not water-tight and may rust or corrode from the
inside.
To avoid a scooter failure:
●Minimize exposure of your scooter to a rain storm or very wet
conditions.
●Never take your scooter into a shower, tub, pool or sauna.
●Do not use your scooter in fresh or salt water (such as at the
edge of a stream, lake or ocean).
●Make sure all electrical connections are secure.
ii. Proceed slowly and use extra care if you must operate your
scooter on a wet or slick surface.
●Do so only if you are sure it is safe.
●Stop if one or both main wheels lose traction. If this occurs,
you may lose control of your scooter or fall.
●Never operate your scooter on a slope or ramp if there is
snow, ice, water or oil film present.
iii. When not in use, keep your scooter in a clean, dry place.
B. TERRAIN
i. This scooter is designed for use on firm, even surfaces such
as concrete, asphalt and indoor flooring.
ii. Do not operate your scooter in sand, loose soil or over rough
terrain. Doing so may damage wheels, bearings, axles or
motors, or loosen fasteners.
C. STREET USE WARNING: In most states, scooters are not legal
for use on public roads. Be alert to the danger of motor vehicles
on roads or in parking lots.
i. At night, or when it is hard to see, use reflective tape on your
scooter and clothing.
ii. It may be hard for drivers to see you. Make eye contact with
drivers before you proceed. When in doubt, yield until you are
sure it is safe. - 5 -
D. MOTOR VEHICLE SAFETY
i. Never sit in this scooter while in a moving vehicle. In an accident
or sudden stop you may be thrown from the scooter.
ii. Always move to an approved vehicle seat. You must be secured
with proper motor vehicle restraints.
iii. Never transport this scooter in the front seat of a vehicle. It may
shift and interfere with the driver.
iv. Always secure this scooter so that it cannot roll or shift.
E. TRANSFERS WARNING: It is dangerous to transfer on your own.
It requires good balance and agility. Be aware that there is a point
during every transfer when the seat is not below you.
To avoid a fall:
i. Always turn off power before you transfer to or from your scooter.
If you fail to do so you may touch the throttle control lever and
cause your scooter to move when you do not expect it.
ii. Make sure scooter is turned “Off”. This keeps the scooter from
moving when you transfer.
iii. Move your scooter as close as you can to the seat you are
transferring to.
iv. Transfer as far back onto the seat surface as you can. This will
reduce the risk that you will miss the seat or fall.
F. REACHING OR LEANING WARNING: Reaching or leaning affects
the center of balance of your scooter. If done improperly, a fall or
tip-over is likely. When in doubt, ask for help or use a scooter to
extend your reach.
To reduce the risk of injury and/or damage to the scooter:
i. Never reach or lean if you must shift your weight sideways or rise
up off the seat.
ii. Never reach or lean if you must move forward in your seat to do
so. Always keep your buttocks in contact with the backrest.
iii. Never try to pick up an object from the floor by reaching down
between your knees.
iv. Never reach or lean over the top of the seat back. This may
damage the backrest and cause you to fall.
If you must reach or lean; do so at your own risk.
Remember to: - 6 -

i. Move your scooter as close as you can to the object you wish to
reach.
ii. Turn off all power to your scooter. If you fail to do so, you may
touch the throttle control lever and cause your scooter to move
when you do not expect it.
G. DRIVING IN REVERSE WARNING: Use extra care when you drive
your scooter in reverse. You may lose control or fall if one of the
rear wheels hits an object.
i. Operate your scooter slowly and at an even speed.
ii. Stop often and check to make sure your path is clear of
obstacles.
H. WEIGHT LIMIT
i. Never exceed the weight limit of the scooter.
ii. The scooter is not designed for weight training and is unsafe for
use as a seat while weight training. Weight training from the
scooter substantially changes the stability of the scooter and
may cause tipping.
iii. Exceeding the weight limit is likely to damage the seat, frame or
fasteners and may cause severe injury to you or others from
scooter failure.
I. STAIRWAYS AND ESCALATORS WARNING:
The scooter is not designed to travel up or down stairs or
escalators. Always use an elevator. DO NOT use an escalator to
move the scooter between floors. Serious bodily injury may occur.
DO NOT attempt to move an occupied scooter between floors
using a stairway.
- 7 -
ELECTROMAGNETIC INTERFERENCE
It is very important that you read
this information regarding the possible effects of
Electromagnetic Interference on your SUMO.
This motorized scooter has an immunity of 20 V/m which should protect it
from Electromagnetic Interference (EMI) from Radio Wave Sources. These
EM waves are invisible and their strength increases as one approaches the
source. All electrical conductors act as antennas to the EM signals and to
varying degrees, all power wheelchairs and scooters are susceptible to
electromagnetic interference (EMI). This interference could result in
abnormal, unintentional movement and/or erratic control of the vehicle.
Motorized scooters may be susceptible to electromagnetic interference
(EMI), which is interfering electromagnetic energy (EM) emitted from
sources such a radio stations, TV stations, amateur radio (HAM)
transmitters, two-way radios, and cellular phones. The interference (from
radio wave sources) can cause the motorized scooter to release its brakes,
move by itself, or move in unintended directions. It can also permanently
damage the motorized scooter control system. The intensity of the
interfering EM energy can be measured in volts per meter (V/m). Each
motorized scooter can resist EMI up to certain intensity. This is called its
“immunity level.” The higher the immunity level, the greater the protection.
At this time, current technology is capable of achieving at least a 20 V/m
immunity level, which would provide useful protection from the more
common sources of radiated EMI.
Because EM energy rapidly becomes more intense as one moves closer to
the transmitting antenna (source), the EM fields from hand-held radio wave
sources (transceivers) are of special concern. It is possible to
unintentionally bring high levels of EM energy very close to the motorized
scooter control system while using these devices. Therefore, the warnings
listed below are recommended to prevent possible interference with the
control system of the motorized scooter, which should reduce the chance
of unintended brake release or motorized scooter movement that could
result in serious injury.
- 8 –

Do not operate hand-held personal
communication devices such as citizens band (CB) radios, or turn ON
personal communication devices and cellular phones while the
motorized scooter is turned ON.
1) Be aware of nearby transmitters, such as radio or TV stations
and try to avoid coming close to them.
2) If unintended movement or brake release occurs, turn the
motorized scooter OFF as soon as it is safe.
3) Be aware that adding accessories or components, or
modifying the motorized scooter, may make it more
susceptible to EMI; and NOTE: There is no easy way to
evaluate their effect on the overall immunity of the motorized
scooter.
4) Report all incidents of unintended movement or brake release
to the distributor listed on the back of this manual, and Note
whether there is a radio wave source of EMI nearby.
TURN “OFF” YOUR SCOOTER AS SOON AS POSSIBLE WHEN
EXPERIENCING THE FOLLOWING:
‧ Unintended or uncontrollable movement.
‧ Unexpected brake release
- 9 –
●Important Information
1) 20 Volts per meter (V/m) is a generally achievable and useful
immunity level against interference from radio wave sources (as of
May 1994) (the higher the level, the greater the protection);
2) This product has an immunity level of following:
- 10 –

ASSEMBLE THE SEAT
Assemble the seat frame in the manner illustrated.
FOLDABLE SEAT FRAME - OPTIONAL
To open the seat frame
Pull out the knob “Z” in the
direction of the arrow and lift the
seat tube “C” up as illustrated.
Push the support lever in the
direction of the arrow until it
clicks into position “E”.
Warning: Pin “E” must be locked into
the position before using.
- 11 –
To fold the seat frame
Pull out the knob “Z” in the direction of the arrow
and push D downward as arrow illustrated
then push seat tube “C” downward to fold the seat frame.
The armrests on your Spartan are not designed to be load bearing.
DO NOT PUT EXCESSIVE WEIGHT ON THE ARMRESTS
- 12 –

TO OPEN THE SPARTAN
●Use one hand to hold the tiller handle (D) and use the other hand
to push the lock pin lever per the illustration and lift the handle.
Pull the tiller lock (C) and turn it clockwise. Continue lifting the
tiller until you hear the “click”, the locking into position.
Frame Assembly
Assembly and disassembly is best carried out by pulling the
locking pin C and allowing the tiller assembly to fold forward until
it rests on the ground.
- 13 -
●Pull the lock pin knob (V) and turn it to the “lock” position.
●Hold both frame sections horizontally by using the strap (T) with
one hand and the rear section with the other hand and slide both
together by inserting the tubes (U) into the corresponding holes in
the front frame.
●The pin will click when inserted correctly. You must check that
the pin has locked into position.
For SLA Battery
●Install the battery into the tray and fasten it securely.
- 14 -

For Lithium Battery
●Pull the knob (C) backward and have
2 block (A) Insert into slots (B) as
illustrated direction then push
battery module downward until you
hear click of locked into cam locker.
●You must check that the battery
module has locked into position.
●Reconnect plugs.
●Plug the main connector “T” into “M” on the frame.
●Plug in the battery connector “L1” into “L2” on the frame.
●The connectors are color matched. Don’t try to force it into the wrong
position.
- 15 -
●Fit the seat on to the frame and insert the seat frame tubes
into the corresponding holes on the main frame.
●Insert arm rest per the illustration.
●Tighten the screws
●Fit the front basket
- 16 –

●Inflate the tyres to the maximum of 40 PSI.
The partition board (PB) on your SUMO is not designed to load
bearing, have your feet always stay on the footrest (F) per indicated
above.
DO NOT PUT EXCESSIVE WEIGHT ON THE PARTITION BOARD.
IT IS IMPORTANT THAT YOU TAKE EXTRA CARE TO
PRACTICE IN AN OPEN SPACE AWAY FROM OBSTRUCTIONS.
- 17 –
ANTI-TIP WHEEL
Ensure that the anti-tip wheels are extended and locked in the
position “Q” when driving on sloping ground. (Per illustration below)
SPARTAN : To change the locking position, just pull the knob “Q”
and slide the tube to the preferred position. Position “Q” provides
the greatest stability.
Return the sliding tube to position “P” for transportation or
disassembly.
●Do not turn key switch “On” before you are seated ready to go.
●Always turn the key switch “Off” before getting off the scooter.
NOTE: Please be aware that should the scooter wheels meet an
obstruction, you will need to help it out manually. Attempting to
drive through an obstruction when the wheel is stuck could result
in damage - 18 -

DRIVE WHEEL RELEASE MECHANISM
●This scooter is equipped with drive wheel release
mechanism. Your SupaScoota can be moved
manually after the drive wheels are released.
Do not operate this device on slope.
To disengage the drive wheels
Pull the drive collar (part “A”) out and
turn it left or right, then release it.
To reconnect the drive wheels
Turn the drive collar (part “A”) until it reconnects with the wheel and
then move the scooter until the collar connects with the drive. (a
loud click)
- 19 -
CRUISE CONTROL, LIGHTS AND SWITCHES
LH throttle is available at optional
To lock the speed lever for transportation:
CAUTION ! : ONLY BE USED WHEN POWER is OFF.
Pull the lever as arrow direction “R” and
use the other hand to turn the
locker as arrow direction “Q”
●F : Forward and Reverse switch.
●S : Speed lever.
●K : Battery level indicator. (for lead-acid battery)
●H : Key switch
●J : Speed selection: F / full speed, S / reduced speed
●I : Disable button for ESC ●X: Disable ESC indicator
●W: Cruise activate & deactivate button ●Y: Cruise control indicator
●E : Clamp for height adjustment ●G: Handle bar angle adjustment
●Z : Battery green level gauge
Please note the display of the three green levels (Z) varies
from different scooter models, battery sizes as well as the
terrains conditions.
Do not place your fingers on the speed lever before you turn the key
switch “On”.
Do not operate speed selection switch “J” when scooter is moving.
Pull the speed lever “S” and accelerate slowly. Do not pull speed
lever “S” in rapid operation.
- 20 -

CRUISE CONTROL- OPTIONAL
When Cruise control is activated, the scooter automatically
maintains the stored speed.
To use cruise control:
You can operate cruise control at variable speed with pushing cruise
button “W” and the indicator “Y” will be light on.
To deactivate cruise control:
Briefly push cruise control button “W” or pull down the speed lever
“S” then release immediately.
●Use cruise control only if road and traffic conditions make it
appropriate to maintain a steady speed for prolonged period.
●Always pay attention to traffic conditions even when cruise control
is activated.
●Cruise control is only an aid designed to assist driving. You are
responsible for the scooter’s speed and for brake in good time.
Do not use cruise control:
●In traffic conditions which are not allowed you to drive at a
constant speed, e.g. heavy traffic, winding or bumpy roads,
where may cause an accident.
●On slippery roads, the drive wheels may lose their grip when
braking or accelerating which may cause the scooter to skid.
●When there is low visibility, e.g. due to fog, heavy rain or snow.
●Cruise control may be unable to maintain the stored speed on
uphill gradients. Hence, do not use cruise control when the slope
is of or over 4 degrees.
●Do not use cruise control when riding downhill..
- 21 -
If the scooter does not move after the re-set, one
of the follo ing indicator lights may be displayed:
The magnetic brake either turn off or
connectors are loose.
Batteries on scooter for recharging
with the key switch turn on.
Low voltage of batteries detected by
controller
Potentiometer broken down.
verload protection.
Battery needs recharging or
connection faulty - check grey color
connector.
Unusual current output.
AUTO SWITCH OFF ELECTRONIC SYSTEM
●The electronic system of this scooter is protected by a digital over
current cut-off system. If your SupaScoota stops, you will need to
turn the main key switch to the “Off” position, and then switch to
“On” position to reset the system.
●Possible causes of over current cut-out are battery not fully
charged or near the end of its life, or the slope is too steep for the
scooter. Do not continue to overload the system as this may
damage the controller.
●The electronic system of this scooter will switch itself “Off” after 3
minutes if the key switch is left in the “On” position when the
scooter is not in use. You will then need to turn the key switch to
the “Off” position, and then switch to “On” position to reset the
control system. - 22 –
Green light flashes quickly
Yellow & Red light ON
Green light
flashes slowly
Green, Red & Yellow lights ON
Red & Green light flash alternately
Red light ON
Yellow light flashes quickly

ELECTRONIC STABILITY CONTROL (ESC)
This is the most significant advancement in mobility scooter safety
ever designed and has dramatically reduced accidents due to
operator misuse. Turning corners at excessive speed has always
been one of the most common causes of accidents but with clever
engineering and sophisticated electronics we have all but eliminated
this problem. The speed of the SupaScoota is now electronically
governed in direct proportion to the rotation of the handle bars,
virtually eliminating any possibility of over speeding when turning.
With the handle bars at maximum rotation and the throttle at
maximum speed the scooter will turn at a very low speed with
complete safety. No other scooter can provide this level of safety.
Some situations may require maximum power to be used when
turning and we have allowed for this with a handlebar mounted push
button which will disable the ESC for 20 seconds if needed. (Push
button for one second)
Keep fingers and clothing
away from the Electronic
Stability Control sensor.
This vital piece of equipment
is very sensitive and could be
damaged, or could cause
damage, if tampered with.
Warning. If the ESC is disconnected
or faulty, the scooter will continue
to function normally but the speed
will not reduce when turning.
- 23 -
SWIVEL SEAT (OPTIONAL)
When removing the seat, do not lift the release handle as this could
cause the seat support frame to disconnect from the seat and fall.
To turn the seat, lift and hold
the release handle below the
seat (as shown). This will
allow the seat to turn.
SPARE BATTERY TRAY (OPTIONAL)
- 24 -

Assemble the battery tray as illustrated. Insert the screws and
tighten the nuts.
When using a lithium battery it is recommended that you place your
lithium battery on rear tray of the scooter and your SLA battery on
the front tray.
It is also recommended that you use the lithium battery and keep
the SLA battery in reserve.
SPARE LITHIUM BATTERY
Optional
Assemble the locker “E” to the
position “D” as illustrated.
●To have spare battery seated onto
spare tray, have 2 block (F) Insert
into slots (G) as illustrated direction
then push battery module downward.
●You must check that the battery module has locked into
position.
●To move the battery
just pull up and move away. - 25 –
SWITCH THE BATTERY TYPE
This scooter can be used either SLA or lithium battery. To meet the
right voltage to the battery gauge, it is allowed to set by following
step to select the different types of battery for going to use.
●Have the key switch at OFF position, keep pressing the ESC
button “I” and turning the key to switch on, then releasing ESC
button.
●Turn the FWD / REV switch “F” to select the battery type you are
going to use. (The led light of “K” must be at off position)
●Li = lithium battery, SA = lead-acid battery
IMPORTANT NOTE:
The stored program only meets the specification of manufacturer’s
battery.
Do not use any battery (include lithium) & Charger which are
NOT specified by manufacturer.
FRONT WHEEL REMOVAL
To reduce weight when lifting the scooter
The front wheels of the scooter can be quickly removed when it is in
the folded position by pushing the release pin “J” and pull front
wheels out as per the illustration. This will reduce the weight by
approximately 2 kg
Reassemble in the reverse order.
- 26 -

Double check that the shaft "K" is locked
in position before unfolding the frame and using the scooter.
If unstable felt during using, you must stop the scooter and check to
see if shaft “K” is loosen.
HOW TO CLEAN THE SCOOTER
Avoid power spray water washing of the scooter as this could cause
damage to the wire connectors and electronic system.
Completely dry off the scooter, if necessary use a dry cloth after
cleaning your scooter.
- 27 –
PRECAUTION
●When using your scooter for the first time you should practice at
slow speed in a flat open area free of obstacles, until you are
confident in turning, stopping, reversing and judging braking distance.
●This scooter is designed for the maximum rider weight of 200kgs.
●Always switch power off (Key switch to “Off” position) before
leaving your scooter.
●Do not store your scooter outside without adequate protection.
●Keep the shipping carton in dry place after unpacking your
SupaScoota in case it needs to be shipped for service.
●This appliance is not intended for use by persons (including
children) with insufficiency of physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given instructions concerning use of the appliance by
a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Your SupaScoota is extremely maneuverable but sharp turns must
only be done at very slow speed.
Do not operate the Forward/Reverse switch when scooter moving.
This could damage your SupaScoota.
FOLD THE SPARTAN
●Release screws and then remove the arm rests from scooter.
- 28 –

●Remove the front basket from scooter.
●Remove the seat.
For SLA Battery
●Unplug the battery
connector, undo the strap
and remove the SLA battery.
For Lithium Battery
●Unplug the battery connector, pull knob backward and pull up
the battery handle for removing lithium battery as illustrated.
- 29 -
●Press the lock tab of
connector and pull
out to disconnect the
connector as per
illustration.
Frame Disassembly
Disassembly is best carried out by pulling the locking pin C and
allowing the tiller assembly to fold as arrow direction until it rests on
the ground.
●Unplug all connectors.
●Pull the lock pin knob (V) and turn it to the “unlock” position, pull
lock pin (C) and lower the tiller until the frame rests on the ground.
●Hold the strap (T) with one hand and the rear section of the
scooter frame with the other hand and slide the 2 halves of the
frame apart.
- 30 -

●Use one hand to hold the handle, and use the other hand to pull
the lock pin knob (C) and turn it anticlockwise. Then fold the
handle down until you hear the “click” of the locking pin fitting into
position on the main frame.
- 31 -
CHARGE BATTERY
●When you get your new battery put it on charge for at least 24 hours.
●When recharging your battery, always charge for at least 12 hours
or until the light on the charger turns green. It is best to charge for
at least another hour after the light turns green.
●Never use the battery for any purpose other than to power your
scooter.
●The battery charger can become hot during charging so your
charger should be placed in a suitable place with good air flow
and away from children. To recharge the batteries,
follow the steps below:
●Place your Scooter close to
a standard electrical wall outlet.
●Turn the scooter key switch
to the “Off” position.
●Plug the charger power
cord (Round plug) into the
socket indicated on
scooter. (N)
●Plug the charger power plug
into a standard wall outlet.
●When charging is completed,
the yellow LED will turn to green.
●Disconnect the charger power cord from the wall outlet and the
plug from the scooter when the batteries are fully charged.
●NOTE: The battery connector L1 must be connected to L2 for
charging.
- 32 -

Or remove the battery from scooter, and use the connection
adaptor. (Optional accessory)
Do not place the battery on a concrete floor for charging. Raise the
battery off the concrete with wooden blocks or similar objects.
IMPORTANT NOTICE:
The battery terminal covers must be kept in place at all times to
avoid the possibility of something falling across the terminals and
causing a short circuit. This could damage the battery or even
cause it to explode.
To dispose of your battery, return it to your dealer or to a recycler.
Improper disposal of the battery could result in an explosion causing
injury and/or property damage.
Lithium battery & charger are optional accessories.
Do not use any battery (include lithium) which is NOT specified
by manufacturer.
- 33 -
Travel distance from battery indicator
& Cycles life
Items
Battery Type
Green light
Yellow
light
Red
light
Cycle
life
24V 15ah SLA Battery 6.5 Km
(4 miles) 2 Km (1.2 miles) 400
24V 15ah Lithium Battery 9 Km
(5.6 miles) 2.5 Km (1.6 mile) 1000
24V 12ah Lithium Battery 5 Km
(3.1 miles) 3.5 Km (2.2 miles) 800
Above are based on full charged battery with firm & even road
surfaces condition and can be varied from cycles by using which
may effected from duration reduced of riding distance per charge.
When the Yellow light is “On”, you will need to go for recharging the
battery and do not use scooter when Red light is ON.
BATTERY CHARGER
●Before charging, read the instructions. (included with charger)
●For indoor use only, do not expose to rain.
●Disconnect the mains power supply before making or breaking the
connections to the battery.
●This appliance is not intended for persons (including children) with
insufficiency of physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
instructions concerning use of the appliance by a person
responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
●This charger is not for recharging non-rechargeable batteries.
●Do not use for charging any batteries not specified by the
manufacturer.
- 34 -

BATTERY CARE & MAINTENANCE
Important notes to help prolong the life of the battery:
•Before the first use of your battery, put it on charge for 24 hours.
•Do not place the battery on a concrete floor for charging, have
the battery raised off the floor on wooden blocks or place the
battery on a shelf. (when you move the batteries out of scooter
for recharging)
•To fully charge the battery, choose a place where ambient
temperature is above 10 degrees Celsius.
•Always recharge your battery as soon as possible after use.
•When yellow light is “On” you should recharge your battery
as soon as possible.
•Never use the battery when the red light is “On”. You will
discharge the battery below its designated voltage and
damage it.
•Do not drop the battery.
•STORAGE:
If you know that you will not be using your battery in the near
future, disconnect the battery from the charger and store it in a
suitable dry place.
Recharge your battery before you use it or every 3 months
(No more than 3 months) if it is not used in that period.
•Always contact our service agent before you replace the
battery or the charger. Using an incompatible battery or
charger may damage the scooter and void your warranty.
NOTE: The battery gauge on the scooter does not give accurate
readings when using a lithium battery, unless reselect to meet the
right voltage. (P.25)
- 35 -
SLA BATTERY WIRING DIAGRAM
●SLA battery 15ah
2 x 12V 15ah
Lithium battery module
25.6V 15ah & 25.6V 12ah
This lithium battery module has individual user’s manual.
Read before use.
- 36 –

Specifications
Front Wheel Size 200mm (8”)
Rear Wheel Size Spartan: 200mm (8”)
Ground Clearance(tiller) 65mm (2.6”)
Length Spartan-1110mm (43.7”)
Width Spartan: 630mm (24.8”)
Front Frame Weight
Front Frame :13.5 kg (29.7 lbs)
Front Frame Without Front Wheel:11.3 kg (25 lbs)
Rear Frame Weight Spartan-12.2 kg(27 lbs)
Weight of Seat 10.6 kgs(23.3 lbs included seat frame & armrest)
Max Loading 200 kg (440 lbs) on level ground (Included spare
battery & luggage)
Turn Radius 1000mm (39.4”)
Motor Output 2 x 180 Watt
Transmission Worm Drive Gearbox
Reverse Forward / Reverse Switch
Brakes Dynamic Braking and Electromagnetic Brake
Braking Distance / time 1-1.5 meter (39-59”) / 0.6 - 0.7 second
Battery (SLA / Lithium)
SLA: 24V - 15 ah 9.2kg (20 lbs) Lithium:
24V 12ah or 15ah / 3.2 kg (7 lbs) or 3.7 kg (8.1 lbs)
Charger (SLA/Lithium) 24 volt 2 amp / 24V 2 amp
Max Speed SLA Battery Spartan: 6.2 kph (3.9 mph), 2
nd
speed 4.kph (2.5 mph)
Max Speed (UK) 3.9 mph
Slope Grade Ability 150 KG - 8 degree, 175 KG - 6 Degrees (max).
Travel Distance
Up to 9 km (5.6 miles) with standard SLA battery, / Up
to 12 Km (7.5 miles) or 9 km (5.6mile) with 24V 15ah
or 12ah lithium battery.
Arm Rests Distance between armrests 45cm - 57cm (18 -22.4")
- 37 -
SPARTAN Warranty
Your SupaScoota is fully guaranteed against faults arising due to
defects in manufacture or materials as follows
Frame: 2 years.
The height adjustable tiller and all other components except those
listed below: 1 year.
Subject to availability of parts, any such defects will be rectified,
either by repair or by unit replacement.
Warranty does not cover
Any damage due to improper use nor the replacement of parts
arising from normal wear and tear such as potentiometers, tyres,
arm rests and upholstery.
Claims due to a normal increase in operational noise level.
This warranty does not cover labour or service calls.
Batteries
Batteries are covered by a six month warranty from the original
manufacturer. Gradual deterioration due to being left in a
discharged state or being left in cold conditions for long periods is
not covered.
This section MUST BE READ and SIGNED by the purchaser and
stamped by the dealer
This warranty record must be kept by the purchaser and a copy
supplied with any claim
-38-
