UNITED DUE-1238 User manual

DUE-1238
DEHUMIDIFIER
USER MANUAL

1
SAFETY INFORMATION
1. Please read the manual carefully before the first time
using this product, and storage the unit in safe place
to avoid electricity leakage, flaming or person injure.
2. Do not put this product in the water or any other
liquids.
3. Stop using this appliance in below situations, or the
product might be damaged: power cord and wire is
broken, the unit is dropped or break down.
4. Please ask professional service agent to repair the
product. Improper repair might cause damage to
users.
5. Disconnect the appliance from power supply before
moving or cleaning the product, and also when the
product is not in used.
6. Please operate the product with specified electricity
voltage.
7. Please use this product only for household appliance
and follow the designed purpose.
8. Do not put any stuff on the product.
9. In order to avoid water leakage, please clean the
water tank before moving the product.
10.Do not incline the product, or leaking water may
damage the product.
11.This appliance can be used by children aged from 8
years and above and persons with reduced
physical,sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.

2
Cleaning and user maintenance shall not be made by
children without supervision.
12.Please keep the product from the wall or other
barriers in a minimum distance of 50 cm.
13.Please install the appliance following the country
wiring laws.
OPERATING INSTRUCTION
1. Power Button
2. Right panel
3. Front panel
4. Handle
5. Air inlet
6. Drain hole
7. Water tank

3
CONTROL PANEL DESCRIPTION
OPERATING INSTRUCTION
1. POWER
Press this key to turn “on” or “off”, and the relating indicating light may
follow the instruction to illuminate or extinguish. (While the unit is
defrosting, the indicating light may lights on and off in turn shortly.)
2. FAN SPEED
Press the key to choose high speed (HI) or low speed (LOW), and the
relating indicating light may follow the instruction to illuminate or
extinguish.
3. TIMER
a. Press the key to set time you need. (1 to 24 hours)
b. When setting timer in stand-by mode, the unit will be turned on
automatically; when setting timer in operating mode, the unit will be
turned off automatically.
c. If pressing the power key to turn off the unit before time finishes
counting down, the setting timer will be canceled.
d. While the timer is in used, the indicating light illuminates; if not, then
the indicating light extinguishes.
e. After set the timer 5 seconds, the display may switch back to
show the ambient humidity.(Press once again can show the
turning-off time.)

4
4. HUMIDITY SETTING
●Press the key to set the relative humidity you need. (From
continuous dehumidification [CO] to relative humidity 50%, 60%,
70%, 80%, comfort mode [AU], and back to continuous
dehumidification [CO]. The first time you electrify the unit, the unit is
set to be continuous dehumidification [CO].
●When ambient humidity is lower than setting humidity by 3%,
compressor will stop automatically, and return working until the
ambient humidity is higher than setting humidity by 3%.
COMFORT MODE [AU]
a. When ambient temperature is lower than 5℃, compressor will stop
working.
b. When ambient temperature is higher than 5℃and lower than 20℃,
the product will set the humidity to 60% automatically.
c. When ambient temperature is higher than 20℃and lower than
27℃, the product will set the humidity to 55% automatically.
d. When ambient temperature is higher than 27℃, the product will set
the humidity to 50% automatically.
WATER FULL
When the water tank is full, the indicating light will illuminate and the unit
will stop working until empty the water tank.
DEFROST
When the unit is defrosting, the indicating light will illuminate and the
compressor will stop working but the motor will keep operating.

5
WARNING
1. When operating the dehumidifier, please do not set the humidity higher
than ambient humidity.
2. When indicating light illuminates, please pour the water out of the tank
and put it back. Then the product will resume working.
3. When the product shut down, please wait at least 3 minutes before
restarting the unit to prevent damaging the compressor.
4. The applicable operating temperature range for this unit is 5-32℃.
5. If the dehumidifier can’t start (the indicating light does not illuminate) or
the dehumidifier shut down unreasonably, please make sure whether
the plug is connected firmly to power supply. If the plug and power
supply are in normal condition, please wait for 10 minutes before restart
the unit (because it takes 10 minutes to reposition). If the unit still does
not start after 10 minutes, please ask your local distributor service
station to repair.
6. When the dehumidifier is operating, it’s a normal situation that the
working compressor may cause some heat and bring the ambient
temperature up.
7. When the product is defrosting, the related indicating light will
illuminate.
8. The unit shows the ambient humidity when it’s operating. If the ambient
humidity is higher than RH95%, the display shows “HI”.

6
DRAINING INSTRUCTION
Draining water can storage in the water tank, or be continuous drained
by PVC tube. (The PVC tube is not included in the product.)
USAGE OF WATER TANK
When dehumidifying, the condensing water may be drained to water
tank. And the unit will stop working with
indicating light illuminates when the water tank is
full of water, please pour out the water that time.
1. Take out the water tank as Fig 01 and pour
out the water.
2. Put the water tank back.
3. Press power key to turn on the unit.
CONTINUOUS DRAINAGE
1. Before continuous draining water, please
take out the water tank and plug a draining
tube to draining hole (See Fig 02.) Then put
the water tank back.
2. Draining tube should place lower than the
draining hole to let water flow out.
FILTER REMOVAL
1. Take out the water tank before remove the filter.
2. Pulling out the filter with handles of
filter.
3. Wash the filter with cool water (cooler
than 40℃) every two weeks, and put
filter back after it air-dried naturally.
Fig 01
Fig 02

7
MAINTENANCE INSTRUCTION
1. The unit is not allowed to be placed on surface which is soft or not flat
to avoid the unit cause noise, vibration, and water or electricity
leakage when operating.
2. Never insert any slim rod or hard stuff into the unit to avoid the
damage of the unit.
3. Please disconnect the power cord to the power supply when you turn
off the unit or intend to stop using for long time.
4. In order to improve the performance of dehumidifier, please keep the
unit in open place away from barriers which may block the air.
5. Please wash the filter with cool water (cooler than 40℃) but not
gasoline or alcohol every two weeks, and put filter back after it
air-dried naturally.

8
SPECIFICATIONS
Model
Specification
PD12-ECE
Power Supply
220-240V~50Hz
Power Input(EN60335)
260W
Rated Current
1.2A
Weight
10.2Kg
Moisture Removal (30℃RH80%)
12 liters/day
Dimension(mm)
312Wx243D x417H
Applicable temperature
5℃-32℃
Water Tank Capacity
1.6L
(CE) N842/2006:
R134a is a kind of fluorinated greenhouse gases covered by
the Kyoto Protocol.
Its total global warming potential (GWP) is 1430.

9
NOTICEABOUT RECYCLING
Your product is designed and manufactured with high quality
materials and components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their
end-of-life, should be disposed of separately from your household waste.
Please dispose of this equipment at your local community waste
collection/ recycling centre.
In the European Union there are separate collection systems for used electrical and
electronic products. Please help us to conserve the environment we live in!
DECLARATION OF CONFORMITY
This product complies with the requirements of the directives
EMC Directive 04/108/EC
Low Voltage Directive 06/95/EC
RoHS2 Directive 11/65/EU
declare that this product is in compliance with the following norms:
EN55014-1:2006/A2:2011
EN55014-2:1997/A2:2008
EN61000-3-2:2014
EN61000-3-3:2013
EN60335-2-40:2003/A13:2012
EN60335-1:2012/A11:2014
EN62233:2008
