Super SAS 25-1/2H User manual

Please Read This Manual Carfully Before Operating.
SUPER GIANT ENTERPRISE CO., LTD.
E-mail:super@superpump.tw
Website:http://www.superpump.tw

1. Introduction
• Product Description…..........…….…........................2
• Application...........................…….……….........2
• Performance Graph.…….....……..……...........3
• Specications…............……..……...................3
• Exploded View...……….....…..…….............6, 7
2. Pre-Operation Inspection....…….......……......8
3. Operation Order….………....................……......8
4. Data Card
5. Product Warranty
Table of Contents

2
1.Introduction
• Product Description
(1) SAS-Series
(2) In/Outlet-Female Thread
25-1", 40- 1 - 1/2"
50-2", 65- 2 -1/2"
75-3"
(3) Pump Power
1/2:1/2HP
1:1HP 2:2HP
3:3HP 5:5HP
7:7.5HP 10:10HP
(4)H-High Head
(5) Seal Material
T - Teflon
Bellows /SSS
B - Teflon
Bellows /CCS
S - Non
Non
Teflon
Bellows/SSS
C - Teflon
Bellows/CCS
(6) Pump Material
6 - SUS316
Applications
1. Surface Treatment: Electroplating, Acid Bath, Degreasing.
2. Electronic Plant: CRT Manufacturing, Capacitors, Tungsten,Wire
,Battery Manufacturing, IC/PC Board Manufacturing.
3. Chemical Process: Chemical Plant, Laboratory, Test Facility, MSG/
Soy Sauce Manufacturing.
4. Water Treatment: Pure Water, Desalination, Wastewater.
5. Other: Food/Pharmaceutical Industry, Extract Diesel And Etc.
SAS - 40 2 H T - 6 N 5 2
(7) Elastomer
N - NBR
E-EPT
V - VITON
T- TEFLON
H-HV
(8) Frequency
5:50Hz
6:60Hz
(9) Pole
2-2P 4-4P

3
PERFORMANCE GRAPH
SPECIFICATIONS
※ 重量/性能以實物為準
Weight / Performance Is For Reference Only Actual Product May Vary
0 200100 500400300 800600 700 900 1000
20
10
30
25
5
15
1100 1200 1300
a
d
ef
g
h
j
k
I
0200100 500400300 800600 700 900 1000
20
10
30
35
25
5
15
12001100 1300 1400
A
CDF
E
H
J
I
GK
50Hz60Hz
25-1/2H 1" 1/2 2P a
25-1H 1" 1 2P c
40-1H 1-1/2" 1 2P d
40-2H 1-1/2" 2 2P e
50-3H 2" 3 2P f
50-5H 2" 5 2P g
65-5H 2-1/2" 5 2P h
65-7H 2-1/2" 7.5 2P i
75-7H 3" 7.5 2P j
75-10H 3" 10 2P k
19
26
26
30
45
50
55
66
68
75
A
C
D
E
F
G
H
I
J
K
11
18
14
24
25
32
23
32
31.5
34
12
15
16
20
21
32
20
28
26.5
34
130
185
305
430
400
540
900
950
1000
1280
145
220
320
380
460
540
980
1100
1260
1300

1.Introduction
• Product Description
(1) SAS-Series
(2) In/Outlet-Female Thread
25-1", 40- 1 - 1/2"
50-2", 65- 2 -1/2"
75-3"
(3) Pump Power
1/2:1/2HP
1:1HP 2:2HP
3:3HP 5:5HP
7:7.5HP 10:10HP
(4) L - Low Head
(5) Seal Material
T - Teflon
Bellows /SSS
B - Teflon
Bellows /CCS
S - Non Teflon
Bellows/SSS
C - NonTeflon
Bellows/CCS
(6) Pump Material
6 - SUS316
Applications
1. Surface Treatment: Electroplating, Acid Bath, Degreasing.
2. Electronic Plant: CRT Manufacturing, Capacitors, Tungsten,Wire
,Battery Manufacturing, IC/PC Board Manufacturing.
3. Chemical Process: Chemical Plant, Laboratory, Test Facility, MSG/
Soy Sauce Manufacturing.
4. Water Treatment: Pure Water, Desalination, Wastewater.
5. Other: Food/Pharmaceutical Industry, Extract Diesel And Etc.
SAS - 40 2 L T - 6 N 5 2
(7) Elastomer
N - NBR
E-EPT
V - VITON
T- TEFLON
H-HV
(8) Frequency
5:50Hz
6:60Hz
(9) Pole
2-2P 4-4P
4

5
PERFORMANCE GRAPH
5004003002001000 800600 700 900 1000
20
10
30
25
5
15
1100 12001300
ef
d
g
h
j
k
b
a
ci
5004003002001000 800600 700 900 1000
20
10
30
35
25
5
15
12001100 1300 1400
D
K
J
F
C
B
E
A
G
HI
SPECIFICATIONS
※ 重量/性能以實物為準
Weight / Performance Is For Reference Only Actual Product May Vary
50Hz60Hz
1" 1/2
1" 1
1-1/2" 1
1-1/2" 2
2" 3
2" 5
2-1/2" 5
2-1/2" 7-1/2 9
3" 7-1/2
3" 10
19
26
26
30
45
50
55
66
68
75
4P
2P
2P
2P
2P
2P
2P
2P
2P
2P
25-1/2L
25-1L
40-1L
40-2L
50-3L
50-5L
65-5L
65-7L
75-7L
75-10L
B
C
D
E
F
G
H
I
J
K
6
11
11
16
22
25
22
30
23
34
90
130
250
360
320
480
880
960
900
1400
b
c
d
e
f
g
h
i
j
k
5
11
11
14
17
26
21
20
21
26
110
180
300
300
400
530
900
00
1050
1200

6
No. Description No. Description
1 Motor 9-5 Bellows Packing
1A Oil Seal 9-6 Bellows Rear O-Ring
3 Connected Seat 10 Fixed-Seal
4 Rear-Cover O-Ring 10-1 Fixed-Seal O-Ring
6 Impeller 11 Inlet Flange Gasket
7 Water Filling Cap 12 Outlet Flange
8 Impeller Pin 13 Outlet Flange Gasket
9 Bellow-Seal Combination 14 Front Cover
9-1 Rotational-Seal 15 Inlet Flange
9-2 Bellow 19 Base
9-3 Bellow-Spring
9-4 Bellow Front O-Ring
Explored View - Teon Bellows SSic Seal
9
9-1
9-5
9-4
9-2
9-6
9-3
10-1
10
10-1
1
19
3
4
6
8
14
13
12
11
15
7

7
7
10
8
11
9
12
13
14
1
2
3
4
5
6
Explored View - Ceramic Fixed Seal + Carbon Rotational seal
No. Description No. Description
1 Motor 8 Impeller Pin
2 Base 9 Water Filling Cap
3 Connected Seat 10 Inlet Flange
4 Rear Cover O-Ring 11 Inlet Flange Gasket
5 Mechanical Seal 12 Outlet Flange
6 Bellow Spring 13 Outlet Flange Gasket
7 Impeller 14 Front Cover

8
2.Pre-Operation Inspection
(1) Check The Water/Solution Tank
Remove All The Foreign Object From The Water/Solution
Tank To Prevent Particles Or Objects Entering The Pump.
Make Sure There Is Enought Water/Solution In The Holding
Tank And Pump Inlet Should Be Fully Submerge To Prevent Air
Been Inhaled.
(2) Check The Motor Protection Device
Please Check The Voltage, Phase, Frequency And Motor
Nameplate,Avoid Using Temporary Power Operation,Because
Of The Instability Of Power Supply Often Damage The Motor.
3. Operation-Order
(1) Valve
Inlet Valve Should Be Fully Open and Outlet Valve Should Be
Fully Closed.
(2) Filling
Open Water Filling Plug And The Outlet,
Turn The Impeller While Injecting Water Into The Funnl
Untill Water Is Overflow. This Will Prevent Bubbles Been
Trap In The Impeller And Aect The Performance.
(3) Close The Outlet After Water Water Filling Plug
(4) Start
Make Sure The Motor Is Spinning At The Right Direction
As The Indicator Mark On The Pump. If Not, Direction Can Be
Change From The Motor Junction Box.

Date: Year Month day
Company Name
Address
Unit / Dept. TEL:
Name
Request a Catalog ( ) Sta to Negotiate ( ) Field Trials ( )
Other ( )
Industry Category
1. 口 Metal Products Factory 6. 口 Aluminum Anodizing Plant 11. 口 Dyed plant
2. 口 Metal Processing Plating 7. 口 Electronic PC Board Manufacturer 12. 口 Pharmaceutical Factory
3. 口 OEM Chemical Plating Plant 8. 口 Semiconductor Manufacturing 13. 口 Other
4. 口 Coating Equipment Factory 9. 口 Electronic Parts Factory
5. 口 OEM Coating Plant 10. 口 Tanneries
Consulted Model
Chemical
Solution
Name
Temperature Viscosity Approximately CPS
Impurity Y ( ) N ( ) PH
Operating
Condition
Capacity Approximately ( ) L/min Head ( ) M
Running time Hour Per Day
Environment
Installation Site Indoor ( ) Outdoor ( )
Usage Portable ( ) Fixed ( ) Other ( )
Liquid Temp. °C To °C
Use
Condition
Pump Inlet Liquid Level Above or Below The Pump Inlet Above( ) Below( )
Pipe Diameter
Phase Single Phase ( ) Three Phase ( )
Other
4. Data Card

ModelNumber:
Serial Number:
Thank You For Choosing SUPER.SUPER's Product Have Passed Strict Quality Control And
Fulll The Filtration Standard Under Proper Operation And Good Maintenance.
Please Store This Warranty Properly And Show It When Necessary.
1.SUPER Warrants The Included Hardware Product Against
Defects And Malfunctions.
• Warranty Period: 1 Year From Original Purchase Date.
2.SUPER Does Not Warrant Under The Following Conditions.
• The Damage Is Caused By Non-Permitted Repair, Improper Maintenance Or Operation.
• Damage that Is Caused By Natural Disasters. (Ex: Fire, Earthquake & Etc.)
• Normal wear and tear parts and accessories are not covered in the warranty.
For any question or help please contact our dealer or Super Giant Enterprise directly.
Address:No.7 Lane 404 Chung Cheng South Road, Yen Hang, Yung Kang, Tainan, Taiwan, R.O.C.
Website: http://superpump.tw http://superpump.cn
E-mail: [email protected]
Telephone:(06)2534546
Fax:(06)2534226
Super Giant EnterpriseCO.,LTD. Dealer or place of business
Year Month Day Year Month Day
Product Warranty

OCT. 2020
