Superior MULTI-OPEN SERIES User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTALLATION
INSTRUCTIONS
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow your gas suppliers
instructions.
• Ifyourgassuppliercannotbereached,callthe
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
POURVOTRESÉCURITÉ: Nepasentreposerniutiliser
d'essencenid'autrevapeursouliquidesinflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Netouchezàaucuninterrupteur. Nepasvousservir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installationetservicedoitêtreexécutéparunqualifié
installeur,agencedeserviceoulefournisseurdegaz.
This appliance may be installed in an aftermar-
ket permanently located, manufactured home
(USA only) or mobile home, where not prohib-
ited by local codes. This appliance is only for
use with the type of gas indicated on the rating
plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
DIRECT VENT
MULTI-OPEN SERIES
VENTED GAS FIREPLACE HEATERS - DIRECT VENT MODELS
P/N 700,001M REV. H 09/2005
WH Report No. J20006712
sledoMtlovilliMsledoMcinortcelE
NMC-TSDCNMC-LCDCNEC-TSDCNEC-LCDC
PMC-TSDCPMC-LCDCPEC-TSDCPEC-LCDC
NMC-FPDCNMC-RCDCNEC-FPDCNEC-RCDC
PMC-FPDCPMC-RCDCPEC-FPDCPEC-RCDC
MODELS
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LESINSTRUCTIONSDONNÉDANSCETTENOTICEPOUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
A French manual is available upon request. Order Form Number
700,001CF.
Ce manuel d’installation est disponible en francais, simplement
en faire la demande. Numéro de la pièce 700,001CF.

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 1
CDPF
CDST
Millivolt Models -
Millivolt models come standard with the
manually-modulated gas valve; flame ap-
pearance and heat output can be con-
trolled at the gas valve.
Input of millivolt models is shown in the
following table:
Electronic appliances are designed to operate
on natural or propane gas. An electronic inter-
mittent pilot ignition system provides safe,
efficient operation. External electrical power is
required to operate these units.
These appliances comply with National Safety
Standards and are tested and listed by War-
nock Hersey (Report No. J20006712) to ANSI
Z21.88-2000(inCanada,CSA-2.33-2000),and
CAN/CGA-2.17-M91 in both USA and Canada,
as vented gas fireplace heaters.
Bothmillivoltandelectronicversionsofthese
appliances are listed by Warnock Hersey for
installation in bedrooms and mobile homes.
Installation must conform to local codes. In the
absence of local codes, installation must com-
ply with the current National Fuel Gas Code,
ANSI Z223.1. (In Canada, the current CAN-1
B149 installation code.) Electrical wiring must
comply with the National Electrical Code ANSI/
NFPA 70 - (latest edition). (In Canada, the
current CSA C22-1 Canadian Electrical Code.)
TYPICAL INSTALLATION
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATIONANDLISTINGSOFTHISUNIT.
INTRODUCTION
These fireplaces are designed, tested and listed
foroperationandinstallationwith,andonlywith,
SecureVent™DirectVentSystemComponents,
SecureFlex™Flexible Vent Components manu-
facturedby SecurityChimneys Internationaland
Z-Flex™ Model GA Venting Systems, listed to
UL1777 and ULCS635 manufactured by Flex-
master Canada Limited. These approved vent
system components are labeled for identifica-
tion. DONOT use anyother manufacturer'svent
components with these appliances.
Themillivoltappliancesaredesignedtooperate
on either natural or propane gas. A millivolt gas
control valve with piezo ignition system pro-
vides safe, efficient operation. If any optional
accessories which require electrical power are
being installed, the electrical power must be
provided at the time of appliance installation.
GENERAL INFORMATION
Note: Installation and repair should be per-
formedby aqualified serviceperson.The appli-
ance should be inspected annually by a quali-
fied professional service technician. More fre-
quent inspections and cleanings may be re-
quired due to excessive lint from carpeting,
bedding material, etc. It is imperative that the
control compartment, burners and circulating
airpassagewaysoftheappliancebe keptclean.
S'assurerque lebrùleur etlecompartiment des
commandes sont propres. Voir les instruc-
tions d'installation et d'utilisation qui
accompagnent l'appareil.
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front, back and/or side viewing surfaces of
the appliance.
These appliances are designed to operate on
natural or propane gas only.
This installation manual will help you achieve a
safe, efficient and dependable installation for
your appliance and vent system. Please read
and understand these instructions be-
fore beginning your installation.
Packaging ........................................ page 2
Introduction ..................................... page 2
General Information......................... page 2
Location .......................................... page 3
Appliance and Vent Clearances....... page 4
Vent Termination Clearances ........... page 4
Typical Installation Sequence .......... page 5
Detailed Installation Steps ............... page 5
Step 1. Framing ............................. page 5
Fireplace Specifications ................... page 8
Step 2. Routing Gas Line ............... page 10
Step 3. Install the Venting System . page 10
Vertical Termination Systems .......... page 11
Vent Section Length Chart ............... page 11
Vertical Vent Tables and Figures...... page 14
Horizontal Termination System........ page 16
Horizontal Vent Tables and Figures . page 18
Venting Using Flexible Vent Pipe ..... page 21
Step 4. Field Wiring ....................... page 22
Step 5. Optional Blower Kit Wiring page 22
Step 6. Connecting Gas Line.......... page 23
Step 7. Installing Logs, Decorative Volcanic
Stone and Glowing Embers ........... page 23
Step 8. Checking Unit Operation ..... page 23
Step 9. Installing Glass
Enclosure Panels ........................... page 24
Step 10. Burner Adjustments ........... page 24
Step 11. Hood Installation ............... page 25
Finishing Requirements ................... page 25
Cold Climate Insulation.................... page 25
Installation Accessories ................... page 26
Gas Conversion Kits.................. page 28
TABLE OF CONTENTS
sledoMtlovilliM
enaporPdnalarutaN sledoMsaG
)H/UTB(etartupnI -yllaunaM detaludom
,NMC-FPDC,NMC-TSDC ,NMC-RCDC,NMC-LCDC ,PMC-FPDC,PMC-TSDC PMC-RCDC,PMC-LCDC
005,73OT000,03
PACKAGING
The assembled vented gas fireplace heater is
packaged with:
1 -onecartoned logsetlocated infireboxarea;
decorative volcanic stone and glowing em-
bers (rockwool) located inside the bottom
cabinet compartment.
2 -one envelope containing the literature
packagewhichconsistsofthehomeowner's
manual,installation instructions,warranty,
and 8 (CDST), 4 (CDPF, CDCR and CDCL)
nailing flanges; envelope is located on top
of the unit.
3 - one vent restrictor to be applied as shown on
page 10 ; restrictor is taped to the envelope.
4 - two hoods (CDST, CDCR, CDCL), or three
hoods(CDPF) taped to the topof the fireplace.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
*Eachmodelhastwoburners.Eachburnercontains
one of these orifices.
sledoMcinortcelE
enaporPdnalarutaN sledoMsaG )H/UTB(etartupnI etaRdexiF
,NEC-FPDC,NEC-TSDC ,NEC-RCDC,NEC-LCDC ,PEC-FPDC,PEC-TSDC PEC-RCDC,PEC-LCDC
005,73
ledoM .oN
*ezisecifirO noitavelE )sretem(teeF
.taN.porP
TSDC FPDC RCDC LCDC
44#55# 0054-0 )0731-0(
LOCATION
In selecting the location, the aesthetic and func-
tionaluseof theappliance areprimaryconcerns.
However, vent system routing to the outside
atmosphere and access to the fuel supply are
alsoimportant.Considerationshouldbegivento
traffic ways, furniture, draperies, etc., due to
high surface temperatures ( Figure 2 ). The loca-
tionshouldalso befreeofelectrical, plumbingor
other heating/air conditioning ducting.
Thesedirectventappliancesareuniquelysuited
for installations requiring a utility shelf posi-
tioneddirectlyabovethefireplace.Utilityshelves
like these are commonly used for locating tele-
vision sets and decorative plants.
To achieve the lowest possible shelf height, use
the alternative rear vent outlet. Do not insulate
the space between the appliance and the area
aboveit.See
Figure 3on page4 .Theminimum
height from the base of the appliance to the
undersideofcombustible materialsusedto con-
structautilityshelf inthisfashionis showninthe
table in Figure 3 on page 4 . The weight of the
utility shelf and anything placed upon it may not
be supported by the appliance in anyway.
Table 1
Test gage connections are provided on the
front of the millivolt gas control valve (iden-
tified IN for the inlet and OUT for the mani-
fold side). A ¹⁄₈" NPT test gage connection
is provided at the inlet and outlet side of
the electronic gas control valve.
Minimum inlet gas pressure to these appli-
ances is 5.0 inches water column (1.24 kPa)
for natural gas and 11.0 inches water column
(2.74 kPa) for propane for the purpose of input
adjustment.
Maximum inlet gas supply pressure to these appli-
ances is 10.5 inches water column (2.61 kPa) for
natural gas and 13.0 inches water column (3.23
kPa) for propane.
These appliances must be isolated from the
gas supply piping system (by closing their
individual manual shut-off valve) during any
pressure testing of the gas supply piping sys-
tem at test pressures equal to or less than ¹⁄₂
psig (3.5 kPa).
These appliances and their individual shut-off
valves must be disconnected from the gas
supplypiping system during any pressuretest-
ing of that system at pressures in excess of ¹⁄₂
psig (3.5 kPa).
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
Donotusetheseappliancesifanyparthasbeen
under water. Immediately call a qualified,
professional service technician to inspect the
appliance and to replace any parts of the con-
trol system and any gas control which have
been under water.
Ne pas se servir de cet appareil s'il a été
plongédans l'eau, complètement ou en
partie. Appeler un technicien qualifiépour
inspecter l'appareil et remplacer toute partie
du système de contrôle et toute commande
qui ont étéplongés dans l'eau.
Themillivoltappliancesaremanuallycontrolled
and feature a spark ignitor (piezo) that allows
theappliance'spilotgas tobelitwithout theuse
of matches or batteries. This system will still
function in the event of a power outage.
Installations at Altitudes of 0 to 4500 ft.-
Unitsaretested andapproved forelevations
of 0 to 4500 feet (0 to 1372 meters).
Installations at Altitudes above 4500 ft.-
For elevations above 4500 feet (1372
meters), install the unit according to the
regulations of the local authorities having
jurisdictionand,intheUSA,thelatestedition
ofthe NationalFuelGas Code(ANSI Z223.1)
or, in Canada, the latest edition of the
CAN1-B149.1 and .2 codes.
This appliance may be installed in an af-
termarket permanently located, manufac-
tured home (USA only) or mobile home,
where not prohibited by local codes. This
appliance is only for use with the type of
gas indicated on the rating plate. This ap-
pliance is not convertible for use with
other gases, unless a certified kit is used.
Cet appareil peut être installédans un maison
préfabriquée(É.-U.seulement)oumobile déjà
installée àdemeure si les réglements locaux
le permettent. Cet appareil doit être utilisé
uniquement avec les types de gaz indiqués
sur la plaque signalétique. Ne pas l'utiliser
avec d'autres gaz sauf si un kit de conversion
certifiéest installé.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
the flu with headaches, dizziness and/or
nausea. If you have these signs, obtain fresh
air immediately. Turn off the gas supply to
the appliance and have it serviced by a
qualified professional, as it may not be op-
erating correctly.
Electronic Models -
Electronic models have a fixed rate gas valve.
Input of electronic models is shown in the
following table:
All Models -
Maximum manifold pressure is 3.5 in. w.c.
(0.87 kPa) for natural gas and 10 in. w.c.
(2.49 kPa) for LP/Propane gas.
WARNING: FAILURE TO COMPLY WITH
THEINSTALLATIONANDOPERATINGIN-
STRUCTIONS PROVIDED IN THIS DOCU-
MENT WILL RESULT IN AN IMPROP-
ERLY INSTALLED AND OPERATING AP-
PLIANCE,VOIDINGITSWARRANTY. ANY
CHANGE TO THIS APPLIANCE AND/OR
ITSOPERATINGCONTROLS IS DANGER-
OUS. IMPROPERINSTALLATIONORUSE
OF THIS APPLIANCE CAN CAUSE SERI-
OUS INJURY OR DEATH FROM FIRE,
BURNS, EXPLOSION OR CARBON MON-
OXIDE POISONING.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OFHIGHSURFACETEMPERATURES.USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CARE-
FULLYSUPERVISEDWHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS
ON OR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LES MEUBLES, L'ESSENCE OU AUTRES
LIQUIDES ÀVAPEUR INFLAMMABLES
ÀCOTE DE L'APPAREIL.
Table 1 shows the units' gas orifice size for
theelevationsindicated.

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
hctiPfooR H)teef(
21/6ottalF0.1
21/7ot21/6revO52.1
21/8ot21/7revO5.1
21/9ot21/8revO0.2
21/01ot21/9revO5.2
21/11ot21/01revO52.3
21/21ot21/11revO0.4
KCAB )mm31(.ni2/1 srecaps)mm0(.ni0
SEDIS )mm31(.ni2/1 srecaps)mm0(.ni0
SRECAPSPOT)mm0(.ni0
ROOLF)mm0(.ni0
mottoBmorF ottinUfo gnilieC )mm6261(.ni46
TNEV*)mm4.52(.ni1
SECNARAELCECIVRES
GNIWEIV -SEDIS KCABTNORF( )EDISRO
)sretem9.0(.teeF3
12
X
Roof Pitch is X/12
2 FT
MIN.
2 FT MIN.
Lowest
Discharge
Opening
H*
*H = MINIMUM HEIGHT FROM ROOF TO
LOWEST DISCHARGE OPENING OF VENT
TERMINATION HEIGHTS FOR VENTS ABOVE
FLAT OR SLOPED ROOFS
Horizontal Overhang
Vertical
Wall
Vent
Termination
Storm Collar
Concentric
Vent Pipe
Flashing
1 inch (25.4 mm) Minimum
Clearance to Combustibles
Figure 4
Figure 2
APPLIANCE AND VENT CLEARANCES
The appliance is approved with zero clearance to
combustible materials on all sides (as detailed in
Table2) ,withthefollowingexception:Whenthe
unit is installed with one side flush with a wall,
the wall on the other side of the unit must not
extend beyond the front edge of the unit. In
addition,when theunit isinstalled in themiddle
of a room, the side walls surrounding the unit
must not extend beyond the front or rear edge
of the unit. See Figure 2 .
The appliance should be mounted on a fully
supported base extending the full width and
depth of the unit. The appliance may be located
on or near conventional construction materi-
als. However, if installed on combustible mate-
rials, such as carpeting, vinyl tile, etc., a metal
or wood barrier covering the entire bottom
surface must be used.
Figure 3
TYPICAL LOCATIONS
VERTICAL VENT
See-Through
(CDST)
Corner - Left
(CDCL)
Corner - Right
(CDCR)
Peninsula
(CDPF)
HORIZONTAL VENT
- REAR
See-Through
(CDST) -
one side flush
with a wall
HORIZONTAL VENT
- TOP
* Note: 3 in. (75 mm) above any horizontal/inclined
vent component.
Table 2
.oNledoM )mm(sehcnithgieHflehS
woblEeergeD09enOhtiw-tneVpoTkcaBehttuOthgiartS-tneVraeR
tneVeruceSxelFeruceStneVeruceSxelFeruceS
TSDC FPDC RCDC LCDC
2/135)9531(4/155)3041(8/114)5401(8/114)5401(
VENT TERMINATION CLEARANCES
These instructions should be used as a
guideline and do not supersede local codes
in any way. Install vent according to local
codes, these instructions, the current Na-
tional Fuel Gas Code (ANSI-Z223.1) in the
USA or the current standards of CAN/CGA-
B149.1 and -B149.2 in Canada.
Vertical Vent Termination Clearances
Terminate single vent caps relative to
building components according to
Figure 4.
Terminate multiple vent terminations accord-
ing to the installation codes listed above.
HorizontalVent Termination Clearances
See Figure 5 on page 5 for horizontal vent
termination clearances to any overhead com-
bustible projection less than or equal to 2 ¹⁄₂"
(64 mm) and greater than 2¹⁄₂" (64 mm). For
additional vent location restrictions refer to
Figure 8 on page 6 .
Shelf Above Fireplace
With Rear Venting
Do not insulate the
space between the
appliance and the
area above it.
Shelf Height
(see table)
Shelf Above Fireplace
With Top Venting
Do not insulate the
space between the
appliance and the
area above it.
Shelf Height
(see table)

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
3"
(76 mm)
12"
(305 mm)
Termination
Kit
Combustible Projection
greater than 2¹⁄₂ inches in length
Horizontal Vent Termination Clearances
Combustible Projection
2¹⁄₂ inches or less in length
18"
(457 mm)
Ventilated
Soffit
Unventilated
Soffit
Top Louver Panel
Unit Parts Identification
Control Compartment Access Panel
Figure 5 - Side Elevation View
Figure 6
Note - See Figure 39 on page 17 for the exterior
wall recess allowances of the square horizontal
termination.
TYPICAL INSTALLATION SEQUENCE
The typical sequence of installation follows,
however,eachinstallationisuniqueresultingin
variations to those described.
See the page numbers references in the follow-
ing steps for detailed procedures.
Step 1. (page 5) Construct the appliance
framing. Position the appliance within the
framing and secure with nailing brackets.
Step 2. (page 10) Route gas supply line to
appliance location.
Step 3. (page 10) Installtheventsystemand
exterior termination.
Step 4. (page 22) Field Wiring
A.Millivolt Appliances –The operating control
switch is factory installed.
B. Electronic Appliances –Connect 120 Vac
electrical power to the appliance receptacle.
Step 5. (page 22) Installblowerkit(optional
equipment).
Step 6. (page 23) Make connection to gas
supply.
Step 7. (page 23) Installthe logset,decora-
tive volcanic stone and glowing embers.
Step 8. (page 23) Checkout appliance op-
eration.
Step 9. (page 24) Install glass enclosure
panels.
Step 10. (page 24) Adjust burner primary air
shutter to achieve proper flame appearance.
Step 11. (page 25) Install the hoods.
Side Nailing Flanges
The fireplace should be secured to the framing
at the side(s) and/or rear of the unit using the
factory-provided nailing flanges. Install the
nailing flanges - 8 (CDST), 4 (CDPF, CDCL and
CDCR) - as shown in
Figure 7 using the
existing screws. Position the fireplace within
the framing. When required, the flanges may
be bent 90 degrees by hand or with the assis-
tance of a hammer. Use wood screws to
secure the nailing flanges to the framing. See
Table 2 on page 4 for clearances of framing
members to cabinet parts in the nailing flange
area. The nailing flange itself is exempt from
these clearances.
Floor Nailing Tabs
Secure the fireplace to the floor as shown in
Figure 7.
Turn tabs down and secure to the floor with
8d nails or other appropriate fasteners
on all sides of the unit which do not have
viewing glass panels.
CDST SHOWN
(CDPF - NO NAILING FLANGES
ON END WITH GLASS PANEL) CDCL SHOWN
(FOR CDCR VIEW, INTERCHANGE SIDES)
Remove these two screws and
use them when installing
the nailing flanges.
Nailing Flanges
Figure 7
DETAILED INSTALLATION STEPS
3 - Lift the pressure relief plates and remove
thecardboardfromunderneath eachofthem.
4- Openthecontrolcompartmentaccesspanel
byactuatingthespringloadedmagneticcatches
securingthepanel,gently depressingtheouter
top corners of the panel until the catches "pop"
the panel free, allowing it to swing out and
down to open.
5- Open the two latches (located under the
firebox floor) securing the glass enclosure
panel. Remove the panel by tilting it outward at
the bottom and lifting it up. Set the door aside
protecting it from inadvertent damage. See
Figure 57 on page 24.
The appliance is shipped with all gas controls
and components installed and pre-wired.
1 - Remove the shipping carton.
2- Removethe top louver panel (seeFigure6) .
Note: The CDST fireplace is installed in the
framing by cocking it at an angle, fitting the
collarsideinfirstandthentwistingandpushing
the other side in. To minimize the obstruction,
it is helpful to make sure the cap is removed
from the rear collar.
Iftheappliance istobeelevated abovefloorlevel,
asolidcontinuousplatformmustbeconstructed.
Headers may be in direct contact with the appli-
ance top spacers but must not be supported by
themornotchedtofitaroundthem. Allconstruc-
tionabovetheappliancemustbeselfsupporting,
DONOTuse the appliancefor structuralsupport.
All framing details must allow for a mini-
mum clearance to combustible framing
members as shown in Table 2 on page 4 .
Step 1. FRAMING
Frame these appliances as illustrated in
Figures 9 (CDST), 10 (CDPF), 11 (CDCL)
or 12 (CDCR).

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 8
EXTERIOR HORIZONTAL VENT TERMINATION CLEARANCE REQUIREMENTS
*noitallatsnInaidanaC**noitallatsnISU
,hcrop,adnarev,edargevobaecnaraelC=A .ynoclabro,kced *)mc03(sehcni21**)mc03(sehcni21
ebyamtahtroodrowodniwotecnaraelC=B .denepo secnailpparof)mc51(ni6 )mc03(ni21,)Wk3(hutB000,01< dna)Wk3(hutB000,01>secnailpparof )mc19(sehcni63,)Wk03(hutB000,001< *)Wk03(hutB000,001>secnailpparof secnailpparof)mc51(ni6 )mc32(ni9,)Wk3(hutB000,01< dna)Wk3(hutB000,01>secnailpparof )mc03(sehcni21,)Wk51(hutB000,05< **)Wk51(hutB000,05>secnailpparof
wodniwdesolcyltnenamrepotecnaraelC=C wodniwtneverpotmuminim)mm503("21 noitasnednoc wodniwtneverpotmuminim)mm922("9 noitasnednoc
tiffosdetalitnevotecnaraelclacitreV=D latnozirohanihtiwlanimretehtevobadetacol retnecehtmorf)mm854(sehcni81foecnatsid lanimretehtfoenil )mm854("81)mm854("81
tiffosdetalitnevnuotecnaraelC=E)mm503("21)mm503("21
renrocedistuootecnaraelC=Fmuminim)mc7.21("5muminim)mc7.21("5
renrocedisniotecnaraelC=Gmuminim)mc2.51("6muminim)mc2.51("6
enilretnecfoedisnihcaeotecnaraelC=H ylbmessarotaluger/retemevobadednetxe teef51fothgiehanihtiw)mc19(teef3 *ylbmessarotaluger/retemehtevoba teef51fothgiehanihtiw)mc19(teef3 **ylbmessarotaluger/retemehtevoba
teltuotnevrotalugerecivresotecnaraelC=I*)mc19(teef3**)mc19(teef3
telniylppusrialacinahcemnonotecnaraelC=J ynaottelnirianoitsubmocehtrognidliubot ecnailpparehto secnailpparof)mc51(ni6 )mc03(ni21,)Wk3(hutB000,01< dna)Wk3(hutB000,01>secnailpparof )mc19(sehcni63,)Wk03(hutB000,001< *)Wk03(hutB000,001>secnailpparof secnailpparof)mc51(ni6 )mc32(ni9,)Wk3(hutB000,01< dna)Wk3(hutB000,01>secnailpparof )mc03(sehcni21,)Wk51(hutB000,05< **)Wk51(hutB000,05>secnailpparof
telniylppusrialacinahcemaotecnaraelC=K*)m38.1(teef6 )m3(teef01nihtiwfievoba)mc19(teef3 **yllatnoziroh
devaproklawedisdevapevobaecnaraelC=L ytreporpcilbupnodetacolyawevid ‡)m31.2(teef7 ‡)m31.2(teef7
rokced,hcrop,adnarevrednuecnaraelC=M ynoclab ‡*)mc03(sehcni21 ‡)mc03(sehcni21
V
VV
V
V
F
C
Fixed
Closed
Window
Operable
Window
B
B
A
B
H
M
I
= Vent Terminal = Area where Terminal is not Permitted
= Air Supply Inlet
XV
D
V
3 ft.
3 ft.
AA
A
= 9”in U.S.
= 12”in Canada
V
L
B
J
XE
V
A
G
Inside
Corner Detail
*18”
Ventilated Soffit
Horizontal
Termination
Detail D
Exterior Wall Center Line
of Termination
18”
Inside Corner
B
C
C
C
* See Item D in the Text Below.
.edoCnoitallatsnIenaporPdnAsaGlanoitaN1.941B-ASCtnerrucehthtiwecnadroccanI* .sedoCsaGleuFlanoitaN45APFN/1.322ZSISNAtnerucehthtiwecnadroccanI** sevresdnasgnillewdylimafelgnisowtneewtebdetacolsihcihwyawevirddevaproklawedisaevobayltceridetanimrettonllahstnevA‡.sgnillewdhtob :roolfehthtaenebsedis2muminimanonepoyllufsiynoclabrokced,hcrop,adnarevfidettimrepylnO‡*

7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
*41¹⁄₂
(1054)
48¹⁄₂
(1108)
*This dimension can be reduced to 41 inches (1041 mm). This
results in 0 in. (0 mm) clearance between framing and unit framing
spacers. (The 41¹⁄₂ in. dimension permits easier fireplace
installation, if unit is installed after framing is erected.)
26³⁄₄
(679)
11³⁄₈
(267)
Dimension A
Secure Vent - 46 (1168)
Secure Flex - 47 ³⁄₄ (1213)
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
10¹⁄₂
22³⁄₄
(578)
CDST
(See-Through)
VENT FRAMING -
TOP VENT WITH
ONE 90ºELBOW
VENT FRAMING -
REAR VENT WITH
NO ELBOWS
inches (millimeters)
6¹⁄₄
(159)
A
Minimum Framing
Stud Size is 2x4
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
*41¹⁄₂
(1054)
43⁵⁄₈
(1108)
*This dimension can be reduced to 41 inches (1041 mm). This results
in 0 in. (0 mm) clearance between framing and unit framing spacers.
(The 41¹⁄₂ in. dimension permits easier fireplace installation, if unit
is installed after framing is erected.)
26³⁄₄
(679)
11³⁄₈
(267)
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
10¹⁄₂
22³⁄₄
(578)
CDPF (Peninsula)
VENT FRAMING -
TOP VENT WITH
ONE 90ºELBOW
VENT FRAMING -
REAR VENT WITH
NO ELBOWS
inches (millimeters)
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
6¹⁄₄
(159)
A
Minimum Framing
Stud Size is 2x4
7
(178)
12¹⁄₈
(308)
5¹⁄₈
(130)
Dimension A
Secure Vent - 46 (1168)
Secure Flex - 47 ³⁄₄ (1213)
*41¹⁄₂
(1054)
43⁵⁄₈
(1108)
*This dimension can be reduced to 41 inches (1041 mm). This results
in 0 in. (0 mm) clearance between framing and unit framing spacers.
(The 41¹⁄₂ in. dimension permits easier fireplace installation, if unit
is installed after framing is erected.)
26³⁄₄
(679)
10¹⁄₂
(267)
12¹⁄₂
(318)
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
10¹⁄₂
(267)
10³⁄₈
(264)
5¹⁄₄
(133)
5¹⁄₄ (133)
24
(610)
CDCL (Corner-Left)
VENT FRAMING -
TOP VENT WITH
ONE 90ºELBOW
VENT FRAMING -
REAR VENT WITH
NO ELBOWS
inches (millimeters)
6¹⁄₄
(159)
9³⁄₄
(248)
Optional Gas Line Location
Center of gas line is
3 in. (76 mm) up from floor.
A
Gas Line
Center of gas line
is 3 in. (76 mm)
up from floor.
Minimum Framing
Stud Size is 2x4
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
Dimension A
Secure Vent - 46 (1168)
Secure Flex - 47 ³⁄₄ (1213)
*41¹⁄₂
(1054)
43⁵⁄₈
(1108)
24
(610)
*This dimension can be reduced to 41 inches (1041 mm). This results
in 0 in. (0 mm) clearance between framing and unit framing spacers.
(The 41¹⁄₂ in. dimension permits easier fireplace installation, if unit is
installed after framing is erected.)
26³⁄₄
(679)
10¹⁄₂
( 267 )
12¹⁄₂
(318)
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
10¹⁄₂
( 267 )
10³⁄₈
( 264 )
5¹⁄₄
(133)
CDCR (Corner-Right)
VENT FRAMING -
TOP VENT WITH
ONE 90ºELBOW
VENT FRAMING -
REAR VENT WITH
NO ELBOWS
inches (millimeters)
Gas Line Center of
gas line is 3 in. (76 mm)
up from floor.
9⁷⁄₈
(251)
A
Minimum Framing
Stud Size is 2x4
5¹⁄₄
(133)
7
(178)
5¹⁄₈
(130)
12¹⁄₈
(308)
Dimension A
Secure Vent - 46 (1168)
Secure Flex - 47 ³⁄₄ (1213)
Figure 10
Figure 9
Figure 11 Figure 12
FIREPLACE FRAMING SPECIFICATIONS

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
CDPF (Peninsula)
12 (305)
10
(254)
TOP VIEW
40¹⁄₈
(1019) 3¹⁄₂ (89)
⁵⁄₈
(16)
Stepped to Accept Drywall on Two Corners
FRAMING SPACERS
(Top and Side)
FINISH WALL BRACKET
(Front, back, and left edge of unit top)
6⁷⁄₈
(175)
10¹⁄₄
(260)
12
(305)
(63.5)
RIGHT SIDE VIEW
3 (76)
(13)
DETAIL OF
FINISH WALL BRACKET
FLUE
(Top or Side)
2¹⁄₂
¹⁄₂
NOTE - Unit has a factory-installed
vent seal cap and vent cover plate
(see Figures 17 and 18 on page 10)
in each flue outlet. The vent seal
cap is not shown in this figure.
24
(610)
41
(1041)
37
(940)
43⁵⁄₈
(1108) ¹⁄₂ (13)
FRONT VIEW
4 (102)
GAS INLET
ELECTRICAL
INLETS
CONTROL COMPARTMENT
ACCESS PANEL
2¹⁄₂
(63.5)
LEFT SIDE VIEW
FLUE
(Top or Side)
Figure 13
Figure 14
CDST (See-Through)
6⁷⁄₈
(175)
10¹⁄₄
(260)
12
(305)
12 (305)
10
(254)
(63.5)
RIGHT SIDE VIEWLEFT SIDE VIEW
TOP VIEW
3 (76)
FLUE
(Top or Side)
10¹⁄₂
(267)
FLUE
(Top or Side)
GAS INLET
ELECTRICAL
INLETS
GAS INLET
40¹⁄₈
(1019)
⁵⁄₈
(16)
Stepped to Accept Drywall on All 4 Corners
3¹⁄₂ (89)
3
(76)
ELECTRICAL
INLETS
NOTE - Unit has a factory-installed
vent sea cap and vent cover plate
(see Figures 17 and 18 on page 10)
in each flue outlet. The vent seal
cap is not shown in this figure.
FRAMING SPACERS
(Top and Both Sides)
24
(610)
FINISH WALL BRACKET
(Front and back edge of unit top)
1/2
(13)
DETAIL OF
FINISH WALL
BRACKET 3¹⁄₂ (89)
2¹⁄₂
ELECTRICAL
INLETS
CONTROL
COMPARTMENT
ACCESS PANEL
FRONT VIEW
(940)
37
41
(1041)
4 (102)
¹⁄₂ (13)
(1197)
47¹⁄₈
¹⁄₂ (13)
2¹⁄₂
(63.5)
FIREPLACE SPECIFICATIONS

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
CDCL (Corner-Left)
CDCR
(Corner-Right)
6⁷⁄₈
(175)
10¹⁄₄
(260)
12
(305)
12
(305)
10
(254)
(63.6)
RIGHT SIDE VIEW
TOP VIEW
3 (76)
FLUE
(Top or Side)
40¹⁄₈
(1019) 3¹⁄₂
(89)
FLUE
(Top or Side)
GAS INLET
ELECTRICAL
INLETS
⁵⁄₈
(16)
Stepped to
Accept
Drywall
FRAMING SPACERS
(Top, Side and Back)
(13)
DETAIL OF FINISH
WALL BRACKET
(13)
FINISH WALL BRACKET
(Front and left edge of unit top)
¹⁄₂
2¹⁄₂ ¹⁄₂
9¹⁄₄
(235)
OPTIONAL GAS INLET
OPTIONAL
GAS INLET AT
CABINET REAR
3 (76)
NOTE - Unit has a factory-installed
vent seal cap and vent cover plate
(see Figures 17 and 18 on page 10)
in each flue outlet. The vent seal cap
is not shown in this figure.
24
(610) 43⁵⁄₈
(1108) (13)
¹⁄₂
4 (102)
(940)
37
(63.6)
2¹⁄₂
41
(1041)
CONTROL COMPARTMENT
ACCESS PANEL
FRONT VIEW
LEFT SIDE VIEW
FLUE
(Top or Side)
6⁷⁄₈
(175)
10¹⁄₄
(260)
12
(305)
2¹⁄₂
(63.5)
3 (76)
FLUE
(Top or Side)
(13)
12 (305)
10
(254)
LEFT SIDE VIEW
TOP VIEW
40¹⁄₈
(1019)
3 ¹⁄₂ (89)
ELECTRICAL
INLETS
5/8
(16)
Stepped
to Accept
Drywall
FRAMING SPACERS
(Top, Side and Back)
(13)
DETAIL OF
FINISH WALL
BRACKET
FINISH WALL BRACKET
(Front and right edge of unit top)
¹⁄₂
¹⁄₂
9⁷⁄₈
(251)
Gas Line Location
GAS INLET
AT REAR
OF UNIT
NOTE - Unit has a factory-installed
vent seal cap and vent cover plate
(see Figures 17 and 18 on page 10)
in each flue outlet. The vent seal cap
is not shown in this figure.
¹⁄₂
(13) 43⁵⁄₈
(1108)
4 (102)
(940)
37
41
(1041)
CONTROL COMPARTMENT
ACCESS PANEL
FRONT VIEW
2¹⁄₂
(63.5)
24
(610)
RIGHT SIDE VIEW
Figure 15
Figure 16
FIREPLACE SPECIFICATIONS CONTINUED

10 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
VENT RESTRICTOR INSTALLATION
(REAR VENT)
RESTRICTOR
APPLIANCE SIDE
VENT OUTLET
VENT RESTRICTOR INSTALLATION
(TOP VENT)
RESTRICTOR
APPLIANCE TOP
VENT OUTLET
Figure 19
Figure 20
Select Venting System - Horizontal or Vertical
With the appliance secured in framing, deter-
mineventroutingand identifytheexteriortermi-
nation location. The following sections describe
vertical (roof) and horizontal (exterior wall) vent
applications.Refertothesectionrelating toyour
installation. A list of approved venting compo-
nents is shown in the two tables on page 27.
A vent restrictor may be needed with this
appliance, install a vent restrictor (provided)
in the appliance top flue outlet as shown in
Figure 19 or side flue outlet as shown in
Figure 20 when vertically terminating the vent
system above the roof. It may be installed
either from inside or outside the unit, in the
inner fireplace collar. It is press-fitted in place.
Step 2. ROUTING GAS LINE
Routea¹⁄₂"(13mm)gaslineasshownin Figure
9 (CDST), 10 (CDPF), 11 (CDCL) or 12 (CDCR)
on pages 8 and 9 . Gas lines must be routed,
constructed and made of materials that are in
strict accordance with local codes and regula-
tions. All appliances are factory-equipped with
a flexible gas line connector and ¹⁄₂ inch shutoff
valve. (See step 6 on page 23).
TOP VENT SEAL CAP & COVER PLATE
REMOVAL WHEN USING THE TOP VENT
VENT SEAL CAP
FIREBOX TOP
CABINET TOP
SECURING SCREWS
VENT COVER PLATE
TOP VENT
COVER PLATE
SECURING SCREW
CROSS SECTION
(INSIDE UNIT)
(OUTSIDE UNIT)
INSULATION
VENT SEAL CAP
SECURING
SCREWS
CROSS SECTION
REAR VENT
COVER PLATE
SECURING SCREWS
CABINET BACK
(INSIDE UNIT)
(OUTSIDE UNIT)
INSULATION
COVER PLATE
REAR VENT SEAL CAP & COVER PLATE
REMOVAL WHEN USING THE REAR VENT
Figure 17
Figure 18
Step 3. INSTALL THE VENT SYSTEM
GENERAL INFORMATION
Theseinstructionsshouldbeusedasaguide-
line and do not supersede local codes in any
way. Install vent according to local codes,
these instructions, the current National Fuel
Gas Code (ANSI-Z223.1) in the USA or the
current standards of CAN/CGA-B149.1 and -
B149.2 in Canada.
These fireplaces are designed, tested
and listed for operation and installation
with,andonlywith,SecureVent™Direct
Vent System Components, Secure Flex™
Flexible Vent Components manufactured
by Security Chimneys International and
Z-FLEX™ModelGAVentingSystemslisted
toUL1777andULCS635manufacturedby
Flexmaster Canada Limited. These ap-
proved vent system components are la-
beled for identification. DO NOT use
any other manufacturer's vent com-
ponents with these appliances.
Thesefireplacesmustbeventeddirectly
to the outside.
The vent system must not service multiple
appliances, and must never be connected to a
flueserving a solid fuel burningappliance. The
vent pipe is tested to be run inside an enclo-
sure (such as a chase). There is no require-
ment for inspection openings in the enclosure
at any of the joints in the vent pipe.
Preparing the Appliance Vent Collar
Each of the unit's two vent collars are sealed
with a cover plate and a seal cap. The cover
plate and seal cap must be removed from the
vent collar being used. Refer to
Figure 17 for
top vent usage and Figure 18 for rear, and the
following steps to prepare the appropriate
collar for use.
From the vent collar being used, remove the
two screws securing the vent cap. Twist the
cap counterclockwise. Pull it away from the
unit and discard, along with the piece of
insulation.
Preparing the Appliance Top or Rear Vent
Outlet when vertically terminating the vent
system above the roof
When the top vent collar is being used, from
inside the firebox, loosen the two screws in the
keyhole slots of the cover plate and remove the
remaining two cover plate securing screws.
Remove and discard the cover plate. Reinstall
and securely tighten all four screws.
When the rear vent collar is being used, from
inside the firebox, loosen the two screws in the
keyhole slots of the cover plate and remove the
remaining two cover plate securing screws.
Remove and discard the cover plate. Reinstall
and securely tighten all four screws.
WARNING: FAILURE TO REINSTALL
ANDSECURELYTIGHTENCOVERPLATE
SCREWS COULD RESULT IN LEAKAGE
OF FLUE PRODUCTS INTO THE LIVING
SPACE. VENT COVER PLATE AND VENT
SEAL CAP MUST REMAIN SECURELY
INSTALLEDONUNUSEDVENTCOLLAR.
FAILURE TO DO SO COULD RESULT IN
LEAKAGE OF FLUE PRODUCTS INTO
LIVING SPACE.

11
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TRAHCHTGNELNOITCESTNEV
lanimoN htgneLnoitceS )sehcni( 621426384T
O
T
A
L
Q
T
Y
noitceSteN )sehcni(htgneL 2/1-42/1-012/1-222/1-432/1-64
tneVfothgieHsnoitceStneVforebmuN
sehcnitf
5.4573.0100001
957.0200002
5.01578.0010001
5152.1110002
5.91526.12100
03
1257.1020002
5.22578.1001001
5.52521.2120003
5.13526.2030003
5.43578.2000101
5.73521.3111003
5.34526.3021003
5457.3002002
5.64578.3000011
5.94521.4102003
1552.4100012
5.55526.4012003
7557.4001102
6652.5022004
5.76526.5003003
9657.5000202
27 6103004
5.37521.6100203
5.97526.6010203
1857.6000112
095.7021014
5.19526.7002013
3957.7000022
69 8101204
5.79521.8100023
2015.8200024
5.301526.8000303
801 9100304
4115.9020024
71157.9105006
5.811578.9110305
6215.01001304
5.031578.01101305
53152.11006006
8315.11000404
5.931526.11000033
5.241578.11100405
TRAHCHTGNELNOITCESTNEV
noitceSlanimoN )sehcni(htgneL 621426384T
O
T
A
L
Q
T
Y
noitceSteN )sehcni(htgneL 2/1-42/1-012/1-222/1-432/1-64
tneVfothgieHsnoitceStneVforebmuN
sehcnitf
44121100034
0515.21010034
5.451578.21110035
5.061573.31020035
5.271573.41000505
77157.41100506
38152.51010506
6815.51000044
5.091578.51100045
5.691573.61010045
5.502521.71011507
70252.71000606
5.112526.71100607
5.712521.81010607
5.922521.91001607
5.232573.91000055
73257.91100056
5.142521.02000707
6425.02100708
25212010708
46222001708
67232000808
97252.32000066
5.082573.32100809
5.382526.32100067
5.982521.42010067
5.103521.52001067
5.013578.52000909
5135.621009001
5.523521.72000077
0335.72100078
63382010078
54357.8200001001
5.943521.9210001011
27313000088
5.673573.13100089
5.973526.1300011011
5.814578.43000099
32452.531000901
56457.8300000101
SV4.5CGV-1
Termination SV4.5FA OR
SV4.5FB Flashing
AND SV4.5SC
STORM COLLAR
*SV4.5VF
Firestop/Spacer
SV4.5L6/12/24/36/48
Vent Sections
40' Max
(12.2 M)
1" (25.4 mm)
Minimum
Clearance to
Combustibles
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
Figure 21
VERTICAL TERMINATION SYSTEMS (ROOF)
Figure 21, and Figures 32 through 36 on
pages 14 and 15 and their associated Vertical
Vent Tables illustrate the vertical venting con-
figurationsthatareallowedtobeused withthese
appliances. Secure Vent pipe applications are
shown in these figures; Secure Flex pipe may
also be used. See page 21 . A Vertical Vent Table
summarizes each system’s minimum and maxi-
mum vertical and horizontal length values that
can be used to design and install the vent com-
ponents in a variety of applications.
Both these vertical vent systems terminate
through the roof. In the USA, the minimum
vent height above the roof and/or adjacent
walls is specified in ANSI Z223.1(latest edi-
tion); in Canada, by the current CAN-1 B149
installation code. It is also specified in major
building codes. Always consult your local
codes for specific requirements. A general
guide to follow is the Gas Vent Rule (refer to
Figure 4 on page 4).
Vertical (Straight) Installation
Determinethe number of straight ventsections
required. 4 ¹⁄₂" (114 mm), 10 ¹⁄₂" (267 mm), 22
¹⁄₂"(572mm),34¹⁄₂"(876mm)and46¹⁄₂"(1181
mm) net section lengths are available. Plan the
ventlengthssothatasectionjointdoesnotoccur
within the space defined by ceiling joists or roof
rafters. Refer to the Vent Section Length Chart.

12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
10¹⁄₂”Min.
(267 mm)
10¹⁄₂”Min. (267 mm)
First Vent
Component
Align the dimple (four places)
with the opening of the locking
incline channel on appliance
collar. Twist vent component
clockwise to engage and seal.
Locking
Incline Channel
Dimple
Appliance collar
Vent / Appliance Collar
Connection
Align the dimple (four places) of the
upper vent section with the opening of
the locking incline channel on the
lower vent section. Twist vent
component clockwise to engage and
seal until arrow and dimple align.
Locking
Incline Channel
Dimple
Arrow
Connected
Vent Sections
Vent / Vent Section
Connection
Arrow
Arrow
1 inch (25.4 mm)
minimum
clearance to
combustibles
8 feet (2.4 m)
Maximum
Blocking
Support
Straps
(Plumber’s
tape)
Figure 22
Figure 23
Figure 25
Figure 24
This seating position is indicated by the align-
ment of the arrow and dimple as shown in
Figure 24.
D. Install firestop/spacer at ceiling - When
usingSecureVent,useSV4.5VFfirestop/spacer
at ceiling joists; when using Secure Flex, use
SF4.5VF firestop/spacer. If there is living space
abovetheceilinglevel,thefirestop/spacermust
be installed on the bottom side of the ceiling. If
attic space is above the ceiling, the firestop/
spacer must be installed on the top side of the
joist.Routetheventsectionsthroughtheframed
opening and secure the firestop/spacer with 8d
nails or other appropriate fasteners at each
corner. Remember to maintain 1" (25 mm)
clearance to combustibles, framing mem-
bers, and attic or ceiling insulation when
runningvertical chimney sections.Attic insu-
lation shield (96K94) may be used to obtain
the required clearances indicated here. See
installation accessories table on page 26.
Vertical (Offset) Installation
Analyze the vent routing and determine the
number of vent sections and elbows required.
Refer to Vertical Vent Figures and Tables on
page 14 and 15 to select the type of vertical
installation desired. Vent sections are available
in net lengths of 4 ¹⁄₂" (114 mm), 10 ¹⁄₂" (267
mm),22 ¹⁄₂" (572 mm), 34¹⁄₂" (876 mm) and46
¹⁄₂" (1181 mm). Refer to the Vent Section
Length Chart on page 11 for an aid in selecting
length combinations. Elbows are available in
45°and 90°configurations. Refer to
Figure 27
for the SV4.5E45 and SV4.5E90 elbow dimen-
sional specifications.
Where required, a telescopic vent section
(SV4.5LA) may be used to provide the installer
with an option in installing in tight and con-
fined spaces or where the vent run made up of
fixed length pieces develops a joint in a unde-
sirable location, or will not build up to the
required length. The SV4.5LA Telescopic Vent
Section has an effective length of from 1 ¹⁄₂" (38
mm) to 7 ¹⁄₂" (191 mm). The SV4.5LA is fitted
with a locking inclined channel end (identical to
a normal vent section component) and a plain
end with 3 pilot holes. Slip the plain end over
the locking channel end of a standard SV4.5
vent component the required distance and se-
cure with three screws.
Maintain a minimum 1" (25 mm) clearance to
combustiblematerialsforallverticalelements.
Clearances for all horizontal elements are 3"
(76 mm) on top, 1" (25 mm) on sides and 1"
(25 mm) on the bottom.
A. Frame ceiling opening - Use a plumb
line from the ceiling above the appliance to
locate center of the vertical run. Cut and/or
frame an opening, 10¹⁄₂" x 10¹⁄₂" (267mm x
267mm) inside dimensions, about this cen-
ter mark (Figure 22) .
To attach a vent component to the appliance
collar, align the dimpled end over the collar,
adjusting the radial alignment until the four lock-
ing dimples are aligned with the inlet of the four
inclined channels on the collar (
refer to Figure
23) . Push the vent component against the collar
until it fully engages, then twist the component
clockwise, running the dimples down and along
theinclinechannelsuntiltheyseatattheendofthe
channels. The unitized design of the Secure
Vent components will engage and seal both
the inner and outer pipe without the need for
sealant or screws. If desired, a #6 x ¹⁄₂" screw
may be used at the joint, but is not required as
the pipe will securely lock when twisted.
C.Attachventcomponentstoeachother-Other
vent sections may be added to the previously
installed section in accordance with the require-
ments of the vertical vent figures and tables. To
add another vent component to a length of vent
run, align the dimpled end over the inclined
channel end of the previously installed section,
adjusting the radial alignment until the four
locking dimples are aligned with the inlets of the
four incline channels of the previous section.
Push the vent component against the previous
section until it fully engages, then twist the
componentclockwiserunningthedimplesdown
and along the incline channels until they seat at
the end of the channels.
E. Support the vertical vent run sections -
Note - Proper venting support is very impor-
tant. The weight of the vent must not be sup-
ported by the firplace in any degree.
Support the vertical portion of the venting sys-
temevery 8feet (2.4m) abovethe fireplacevent
outlet. One method of support is by utilizing
field provided support straps (conventional
plumber's tape). Secure the plumber's tape to
the framing members with nails or screws.
Loop the tape around the vent, securing the
ends of the tape to the framing. If desired,
sheet metal screws #6 x ¹⁄₂" length may be
used to secure the support straps to the vent
pipe. See
Figure 25.
Another method, where the vent is not adjacent
toawall,isillustratedin
Figure26 .Here,support
straps (96K93) and support plates (96K92) can
be used to support the weight of the vent.
B. Attach vent components to appliance - Se-
cure Vent SV4.5direct vent system components
are unitized concentric pipe components featur-
ing positive twist lock connections (
see Figure
23 ). All of the appliances covered in this docu-
ment are fitted with collars having locking in-
clined channels.
Thedimpled end of thevent components fit over
the appliance collar to create the positive twist
lock connection.

13
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
FramingDimensions for Roof
Pitch C D
0/12 10¹⁄₂ in. 10¹⁄₂ in.
(267 mm) (267 mm)
6/12 10¹⁄₂ in. 12 in.
(267 mm) (305 mm)
12/12 10¹⁄₂ in. 17 ³⁄₄ in.
(267 mm) (451 mm)
C
D
Storm
Collar
8 feet (2.4 m)
Maximum
SV4.5CGV-1
Termination
SV4.5FA OR
SV4.5FB Flashing
AND SV4.5SC
STORM COLLAR
**SV4.5VF
Firestop/Spacer
1" (25.4 mm)
Minimum Clearance
to Combustibles
*SV4.5SU
Support Strap
SV4.5SP
*Support Plate
*Secured to Vent
With Appropriate
Fasteners
Ceiling
Framing
**When using Secure Flex,
use Firestop/Spacer
SF4.5VF
SV4.5E90
(90°Elbow)
7 ⁵⁄₈"
(194 mm)
Swivel Joint
(360
° swivel)
4 ¹³⁄₁₆"
(122 mm)
SV4.5E45
(45°Elbow)
Swivel Joint
(360
° swivel)
Figure 28
Figure 29
Figure 31
Figure 30
If the vent system extends more than 5' (1.5 m)
above the roof flashing, stabilizers may be nec-
essary. Additional screws may be used at sec-
tion joints for added stability. Guide wires may
beattached to the jointfor additional supporton
multiple joint configurations.
G.Continueinstallationofhorizontal/inclined
sections - Continue with the installation of the
straight vent sections in horizontal/inclined run
as described in Step C. Install support straps
every 5 ft. (1.52 m) along horizontal/inclined
vent runs using conventional plumber’s tape.
See page 16, Figure 37. It is very important
thatthehorizontal/inclinedrunbemaintained
ina straight(nodips) andrecommended tobe
in a slightly elevated plane, in a direction
away from the fireplace of ¹⁄₄" rise per foot (20
mm per meter) which is ideal, though rise per
footrunratiosthataresmallerareacceptableall
the way down to at or near level.
Figure 27
F. Change vent direction to horizontal/in-
clined run - At transition from or to a horizon-
tal/inclined run, install the SV4.5E45 and
SV4.5E90 elbows in the same manner as the
straight vent sections. The elbows feature a
twist section to allow them to be routed about
the center axis of their initial collar section to
alignwith therequired directionof thenextvent
run element. Twist elbow sections in a clock-
wisedirectiononlysoastoavoidthepossiblity
of unlocking any of the previously connected
vent sections. See
Figure 27 .
Use a carpenter’s level to measure from a
constantsurface and adjust thesupport straps
as necessary.
Itis importantto maintainthe requiredclear-
ances to combustibles: 1" (25 mm) at all
sides for all vertical runs; and 3" (76 mm) at
the top, 1" (25 mm) at sides, and 1" (25 mm)
at the bottom for all horizontal/inclined runs.
K.Installtheverticaltermination-Thefinalstep
involves installation of the SV4.5CGV-1 Vertical
Termination. Extend the vent sections to the
height as shown in the "Vertical vent termination
section" on page 4. The SV4.5CGV-1 Vertical
Termination (Figure 31) can be installed in the
exact same fashion as any other Secure Vent
section. Align the termination over the end of the
previously installed section, adjusting the radial
alignment until the four locking dimples of the
termination are aligned with the inlets of the four
inclinechannelsofthe lastventsection. Pushthe
terminationdownuntilit fullyengages,thentwist
the termination clockwise running the dimples
downandalongtheinclinechannelsuntiltheyare
seated at the end of the channels.
I. Install the roof flashing - Extend the vent
sections through the roof structure. Install the
roof flashing over the vent section and posi-
tion such that the vent column rises vertically
(use carpenters level) (
Figure 29 ). Nail along
perimeter to secure flashing or adjust roofing
to overlap the flashing edges at top and sides
only and trim where necessary. Seal the top
and both sides of the flashing with waterproof
caulking.
H. Frame roof opening - Identify location for
vent at the roof. Cut and/or frame opening per
Roof Framing Chart and
Figure 28 .
J. Install the storm collar - Install the storm
collar, supplied with the flashing, over the vent/
flashing joint. See
Figure 30. Loosen the storm
collar screw. Slide collar down until it meets the
top of the flashing. Tighten the adjusting screw.
Apply non-combustible caulking or mastic
around the circumference of the joint to provide
a water tight seal.
Figure 26

14 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
40 feet (12.2 meters)
Maximum
*Ceiling
Firestop/Spacer
(SV4.5VF)
A Vent Restrictor, as
shown in Figure 19,
page 10, must be used
in this application
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
AELBAT
VM MUMINI mumixaMH
teef)m(teef)m(
1)503.0(2)16.0(
2)16.0(4 )222.1(
3)419.0(6)68.1(
4)22.1(8)4.2(
.xaM)m4.21(teef04=H+V .xaM)m4.2(teef8=H
BELBAT
VM MUMINI HmumixaM
teef)sretem(teef)sretem(
1*)503.0(5)25.1(
2)016.0(01)1.3(
3)419.0(51)56.4(
4)22.1(02)2.6(
V+V
1
.xaM)m4.21(teef04=H+
H.xaM)m2.6(teef02=
V
H
*Ceiling
Firestop/Spacer
(SV4.5VF)
**Wall
Firestop/Spacer
(SV4.5HF)
A Vent Restrictor, as
shown in Figure 20,
page 10, must be used
in this application
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
H
V
V1
*Ceiling
Firestop/Spacer
(SV4.5VF)
**Wall
Firestop/Spacer
(SV4.5HF) A Vent Restrictor, as
shown in Figure 19,
page 10, must be used
in this application
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
Figure 33 - Rear Vent - ONE 90 DEGREE ELBOW
Figure 32 - Top Vent - STRAIGHT
Figure 34 - Top Vent - TWO 90 DEGREE ELBOWS
*Whendevelopingchimney systems
with horizontal runs (H) that end with
a vertical run (V1), it is allowable to
use an elbow attached directly to the
top collar. Count the elbow attached
to the collar as 1 foot of (V) run.
VERTICAL VENT FIGURES/TABLES
Note: SV4.5VF (Secure Vent), SF4.5VF (Secure
Flex) firestop/spacer must be used anytime vent
pipe passes through a combustible floor or ceil-
ing. SV4.5HF (Secure Vent), SF4.5HF (Secure
Flex)firestop/spacer must be used anytime vent
pipe passes through a combustible wall.
Note: Two 45 degree elbows may be used in
place of one 90 degree elbow. The same rise to
run ratios, as shown in the venting figures for 90
elbows,mustbefollowedif45degreeelbowsare
used.
Note: It is very important that the horizontal/
inclined run be maintained in a straight (no
dips) and recommended to be in a slightly
elevated plane, in a direction away from the
fireplace of
¹⁄₄ " rise per foot (20 mm per
meter) which is ideal, though rise per foot run
ratios that are smaller are acceptable all the
way down to at or near level.
Note: Secure Vent (rigid vent pipe) is shown
in the figures; Secure Flex (flexible vent pipe)
may also be used (see page 21).
WARNING: UNDER NO CIRCUM-
STANCES MAY SEPARATE SECTIONS
OF CONCENTRIC FLEXIBLE VENT
PIPE BE JOINED TOGETHER.

15
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
CELBAT
muminiMVmumixaMHH+H
1
mumixaM
teef)m(teef)m(teef)m(
1)503.0(2)016.0(5)25.1(
2)016.0(4)22.1(01)1.3(
3)419.0(6)68.1(51)56.4(
4)22.1(8)84.2(02)2.6(
V+V
1
H+H+
1
.xaM)m4.21(teef04= .xaM)m84.2(teef8=HH+H
1
.xaM)m2.6(teef02=
DELBAT
VM MUMINI HH+
1
mumixaM
teef)m(teef)m(
1)503.0(5)25.1(
2)016.0(01)1.3(
3)419.0(51)56.4(
4)22.1(02)2.6(
H+H
1
.xaM)m2.6(teef02=
V+V
1
H+H+
1
.xaM)m4.21(teef04=
H1
V
V1
H
*Ceiling
Firestop/Spacer
(SV4.5VF)
**Wall
Firestop/Spacer
(SV4.5HF)
*Ceiling
Firestop/Spacer
(SV4.5VF)
A Vent Restrictor, as
shown in Figure 20,
page 10, may be used in
this application
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
**Wall
Firestop/Spacer
(SV4.5HF)
V
H1
H
*Ceiling
Firestop/Spacer
(SV4.5VF)
V1**Wall
Firestop/Spacer
(SV4.5HF)
A Vent Restrictor, as
shown in Figure 19,
page 10, may be used in
this application
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
Figure 35 - Rear Vent - THREE ELBOWS
Figure 36- Top Vent - THREE ELBOWS
VERTICAL VENT FIGURES/TABLES
(continued)

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Vertical
Rise
SV4.5E90
Elbow
Horizontal / Inclined Run SV4.5 HT
Termination
*Firestop/Spacer
SV4.5VF
SV4.5L6/12/24/36/48
Vent Sections
Support Bracket Spacing
Every 5 ft (1.52 m)
See Figure 25 on page 12
or Figure 26 on page 13
for vertical vent section
support.
Support
Brackets
Building
Support
Framing
Ceiling
Fireplace
Exterior
Wall
TYPICAL HORIZONTAL VENT INSTALLATION
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
SV4.5 HTS
Termination
Figure 37
Push the vent component against the collar
until it fully engages, then twist the compo-
nentclockwise,running thedimplesdown and
alongthe incline channels untilthey seat at the
endof thechannels. The unitized designof the
Secure Vent componentswill engage and seal
both the inner and outer pipe elements with
the same procedure. Sealant and securing
screws are not required.
E. Attach vent components to each other -
Other vent sections may be added to the previ-
ously installed section in accordance with the
requirementsoftheventtables. Toaddanother
vent component to a length of vent run, align
the dimpled end of the component over the
inclined channel end of the previously installed
section, adjusting the radial alignment until the
four locking dimples are aligned with the inlets
of the four incline channels of the previous
section. Push the vent component against the
previous section until it fully engages, then
twist the component clockwise running the
dimples down and along the incline channels
until they seat at the end of the channels.This
seatingpositionisindicated bythealignment
ofthearrow anddimpleas shownin Figure24
on page 12.
F. Install firestop/spacer at ceiling -
When using Secure Vent, use SV4.5VF fir-
estop/spacer at ceiling joists; when using Se-
cure Flex, use SF4.5VF firestop/spacer. Ifthere
is living space above the ceiling level, the fir-
estop/ spacer must be installed on the bottom
side of the ceiling. If attic space is above the
ceiling, the firestop/ spacer must be installed on
the top side of the joist. Route the vent sections
through the framed opening and secure the
firestop/spacerwith8dnailsorotherappropriate
fasteners at each corner.
Rememberto maintain1" (25mm) clearance
to combustibles, framing members, and at-
tic or ceiling insulation when running verti-
cal chimney sections. Attic insulation shield
(96K94) may be used to obtain the required
clearances indicated here. See installation
accessories table on page 27.
HORIZONTAL (OUTSIDE WALL)
TERMINATION SYSTEM
SecureVent SV4.5direct vent systemcompo-
nents are unitized concentric pipe compo-
nents featuring positive twist lock connection,
(
refer to Figure 23 on page 12). All of the
appliances covered in this document are fitted
with collars having locking inclined channels.
The dimpled end of the vent components fit
over the appliance collar to create the positive
twist lock connection.
A. Plan the vent run -
Analyze the vent routing and determine the
types and quantities of sections required
4 ¹⁄₂" (114 mm), 10 ¹⁄₂" (267 mm), 22 ¹⁄₂" (572
mm), 34 ¹⁄₂" (876 mm) and 46 ¹⁄₂" (1181 mm)
net section lengths are available. Make allow-
ances for elbows as indicated in
Figure 27 on
page 13 .
Maintain a minimum 1" (25 mm) clearance to
combustiblesontheverticalsections.Clearances
for the horizontal runs are; 3" (76 mm) on top, 1"
(25 mm) on sides, and 1" (25 mm) at the bottom.
B. Frame exterior wall opening -
Locate the center of the vent outlet on the exterior
wallaccordingtothedimensionsshownin
Figures
9(CDST),10(CDPF),11(CDCL),or12(CDCR) on
page7. Cutand/or frame anopening, 10¹⁄₂"x12¹⁄₈"
(267 mm x 308mm) inside dimensions, about this
center.
C. Frame ceiling opening - If the vertical
route is to penetrate a ceiling, use plumb line
to locate the center above the appliance. Cut
and/or frame an opening, 10¹⁄₂" x 10¹⁄₂" (267
mm x 267 mm) inside dimensions, about this
center (refer to
Figure 22 on page 12 ).
G. Support the vertical run sections -
See section E on page 12.
H. Change vent direction - At transition from
ortoahorizontal/inclinedrun,installtheSV4.5E45
and SV4.5E90 elbows in the same manner as the
straightvent sections. Theelbows featurea twist
section to allow them to be routed about the
center axis of their initial collar section to align
with the required direction of the next vent run
element. Twist elbow sections in a clockwise
direction only so as to avoid the possiblity of
unlocking any of the previously connected
vent sections.See
Figure 27 on page 12 .
D. Attach vent components to appliance - To
attach a vent component to the appliance collar,
alignthedimpledendoverthecollar,adjustingthe
radialalignment until the fourlocking dimples are
aligned with the inlets of the four incline channels
on the collar ( refer to Figure 23 on page 12).
I.Continueinstallationofhorizontal/inclined
sections - Continue with the installation of the
straight vent sections in horizontal/inclined
run as described in Step E. Install support
straps every 5 ft. (1.52 m) along horizontal/
inclinedventrunsusingconventionalplumber’s
tape. See
Figure 37. It is very important that
the horizontal/inclined run be maintained in a
straight (no dips) and recommended to be in
a slightly elevated plane, in a direction away
from the fireplace of ¹⁄₄" rise per foot (20 mm
per meter) which is ideal, though rise per foot
run ratios that are smaller are acceptable all the
way down to at or near level. Use a carpenter’s
level to measure from a constant surface and
adjust the support straps as necessary.
It is important to maintain the required clear-
ancesto combustibles:1"(25 mm)at allsides
for all vertical runs; and 3" (76 mm) at the top,
1" (25 mm) at sides, and 1" (25 mm) at the
bottom for all horizontal/inclined runs
Both of these horizontal vent systems terminate
through an outside wall. Building Codes limit or
prohibit terminating in specific areas. Refer to
Figure 8 on page 6 for location guidelines.
Figure 37, and Figures 40 to 46 on page 18 to
20
and their associated Horizontal Vent Table
illustrate the horizontal venting configurations
thatareallowedtobeusedwiththeseappliances.
Secure Vent pipe applications are shown in these
figures; Secure Flex pipe may also be used.
See
page 21.
A Horizontal Vent Table summarizes
each system’s minimum and maximum vertical
and horizontal length values that can be used to
design and install the vent components in a
variety of applications.

17
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
M. Install the termination -
J. Assemble vent run to exterior wall - If not
previously measured, locate the center of the
vent at the exterior wall. Prepare an opening as
described in Step B. Assemble the vent system
to point where the terminus of the last section is
within 7¹⁄₂ in. (191 mm) to 11³⁄₄ in. (298 mm)
inboard of the exterior surface to which the
SV4.5HT termination is to be attached, see
Fig-
ure 39 . If the terminus of the last section is not
within this distance, use the telescopic vent
section SV4.5LA, as the last vent section. For
wall thicknesses greater than that shown in
Figure38 ,referto Table3onpage18 .Thistable
lists the additional venting components needed
(in addition to the termination and adapter) for a
particular range of wall thicknesses.
K. Attach termination adapter - Attach the
adapter (adapter - SV4.5RCH - provided with
the termination) to the vent section or tele-
scoping vent section), elbow or appliance col-
lar as shown in Figure 38 in the same manner
as any SV4.5 vent component (refer to Step E).
L. Install Firestop/Spacer at exterior wall -
When using the square termination, install
SV4.5HF (Secure Vent), SF4.5HF (Secure Flex)
Firestop/Spacer over the opening at the exte-
rior side of the framing, long side up, with the
3 inch spacer clearance at the top as shown in
Figure 38 , and nail into place.
(TheFirestop/Spacermayalso beinstalledover
the opening at the interior side of the framing.)
When using the round termination, a separate
firestop/spacer is not required since this ter-
mination has integral spacers which provide
thesamefunctionasaseparatefirestop/spacer.
Installthesquaretermination(SV4.5HT)- For
the last step , from outside the exterior wall,
slide the collars of the termination onto the
adapter until the termination seats against the
exteriorwallsurfacetowhichit willbeattached.
Orient the housing of the termination with the
arrow pointed upwards. Secure the termina-
tion to the exterior wall. The horizontal termi-
nation must not be recessed into the exterior
wall or siding by more than the 1 ¹⁄₄" (32 mm)
as shown in Figure 39 .
SFHRK Snorkel Cap –The snorkel cap is de-
signed to be fitted into a basement window box.
The SFHRK cap is for use with flex vent pipe.
Vertical distance between the inlet and outlet of
the cap is 28 in. (711 mm).
*1¹⁄₄" Maximum Recess of
Square Termination into
Exterior Finishing Material
Exterior Surface of
Framing
7¹₂ in. (191 mm) to
11³₄ in. (298 mm)
Exterior Surface of Siding
Minimum wall thickness
*5 in. (127 mm)
Interior Surface of
Finished Wall
Maximum wall thickness
11³₄ in. (298 mm)
Maximum Extent of
Vent Run Sections
Relative to Exterior
Surface of Framing
Last Vent Section. Use
Telescopic Vent
Section (SV4.5LA), If
Necessary
Adapter
SV4.5RCH
SV4.5HT
Square
Termination
*Cut termination collar for wall
thicknesses less than 7¹₂ in. (191 mm)
Note - Firestop/Spacer (SV4.5HF)
required but not shown for clarity.
Note - When using Secure Flex,
use Firestop/Spacer SF4.5HF
Siding
Stucco
SV4.5HT
Square Termination
Stucco and Siding
Installation shown
Figure 38
Figure 39
Installing the Square Horizontal Termination (SV4.5HT)
Venting Connection and Exterior Wall Recessing of the
Square Horizontal Termination (SV4.5HT)
*When using Secure Flex, use
Firestop/Spacer SF4.5HF
Firestop/Spacer (SV4.5HF) shown
on the exterior side of the wall. It
may also be installed on the
interior side.
10¹⁄₂"
(267 mm)
7"
(178)
5¹⁄₈"
(130 mm)
12¹⁄₈"
(308 mm)
Note: Centerline of Vent Piping
is NOT the Same as the
Centerline of the Framed
Opening.
6 to 48 inch Vent Section,
Telescopic vent section,
Elbow or Appliance Collar
See Figure 9 (CDST), 10
(CDPF), 11 (CDCL) or 12
(CDCR) on page 7 for Min.
Distance to Base of Appliance.
Base of Appliance
3"
(76 mm)
1"
(25.4 mm)
Adapter
SV4.5RCH
SV4.5HT
Termination

18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
EELBAT
wobleeerged09en0=V .xaM)m419.0(teef3=H
ELBATF
muminiMVmumixaMH
teef)m(teef)m(
1)503.0(5)25.1(
2)16.0(01)1.3(
3)419.0(51)56.4(
4)22.1(02)2.6(
.xaM)m4.21(teef04=H+V .xaM)m2.6(teef02=H
*When using Secure Flex, use
Firestop/Spacer SF4.5HF
*Wall Firestop/Spacer
(SV4.5HF)
H = 28 in. (711 mm)
Maximum
7 in. (711 mm)
21 in. (533 mm)
Maximum
H
V
*Wall Firestop/Spacer
(SV4.5HF)
*When using Secure Flex, use
Firestop/Spacer SF4.5HF
H
V
**Wall Firestop/Spacer
(SV4.5HF)
*Ceiling
Firestop/Spacer
(SV4.5VF)
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure Flex,
use Firestop/Spacer
SF4.5HF
Figure 40 - Rear Vent - NO ELBOWS
Figure 41 - Top Vent -
ONE 90 DEGREE ELBOW - ELBOW CONNECTION AT APPLIANCE
Figure 42 - Top Vent - ONE 90 DEGREE ELBOW - ELBOW
CONNECTION NOT DIRECTLY AT APPLIANCE
Only the square termination (SV4.5HT) may be used.
HORIZONTAL VENT FIGURES/TABLES
Note:SV4.5VF(SecureVent),SF4.5VF(SecureFlex)firestop/spacermustbe
used anytime vent pipe passes through a combustible floor or ceiling.
SV4.5HF(Secure Vent),SF4.5HF(Secure Flex)firestop/spacer must beused
anytime vent pipe passes through a combustible wall.
Note: Two 45 degree elbows may be used in place of one 90 degree elbow.
The same rise to run ratios, as shown in the venting figures for 90 elbows,
must be followed if 45 degree elbows are used.
Square termination (SV4.5HT) shown.
Square termination (SV4.5HT) shown.
Note:Itisvery importantthatthehorizontal/inclinedrun bemaintained
in a straight (no dips) and recommended to be in a slightly elevated
plane, in a direction away from the fireplace of
¹⁄₄ " rise per foot (20 mm
per meter) which is ideal, though rise per foot run ratios that are smaller
are acceptable all the way down to at or near level.
*Note: See Figure 39 for wall thickness range reductions when using
SV4.5HT termination.
Note: Secure Vent components (rigid vent pipe and terminal) are shown
inthe figures; Secure Flex components(flexible vent pipe andterminal)may
also be used.
See Table 3 as an aid in venting component selection for a particular
range of exterior wall thicknesses.
WARNING: UNDER NO CIRCUMSTANCES MAY SEPARATE
SECTIONS OF CONCENTRIC FLEXIBLE VENT PIPE BE JOINED
TOGETHER.
suoiraVrofderiuqeRstnenopmoCgnitneV-3ELBAT ehTgnisUnehW,sessenkcihTllaWroiretxE )TH5.4VS(noitanimreTerauqS
deriuqeRstnenopmoCgnitneV sessenkcihTllaWroiretxE mm(sehcni )
ylnOtiKnoitanimreT2/171ot4/31)892ot191(
tnev.ni6dnatiKnoitanimreT )6L5.4VS(noitces 14/31)914ot892(2/161ot
tnev.ni21dnatiKnoitanimreT )21L5.4VS(noitces ot464(4/122*ot4/181 )565*
cipocseleTdnatiKnoitanimreT .ni6dna)AL5.4VS(noitces )6L5.4VS(noitcestnev 31)195*ot033(4/132*ot

19
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
H1
V
H
**Wall Firestop/Spacer
(SV4.5HF)
*Ceiling
Firestop/Spacer
(SV4.5VF)
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
**Wall
Firestop/Spacer
(SV4.5HF)
GELBAT
muminiMVmumixaMHH+H
1
mumixaM
teef)m(teef)m(teef)m(
1)503.0(2)016.0(5)25.1(
2)016.0(4)22.1(01)1.3(
3)419.0(6)68.1(51)56.4(
4)22.1(8)84.2(02)2.6(
H+H+V
1
.xaM)m4.21(teef04= .xaM)m84.2(teef8=HH+H
1
.xaM)m2.6(teef02=
HELBAT
VM MUMINI H+H
1
mumixaM
teef)m(teef)m(
1)503.0(5)25.1(
2)016.0(01)1.3(
3)419.0(51)56.4(
4)22.1(02)2.6(
H+H+V
1
.xaM)m4.21(teef04=
H+H
1
.xaM)m2.6(teef02=
V
H
H1
**Wall Firestop/Spacer
(SV4.5HF)
**Wall Firestop/Spacer
(SV4.5HF)
*Ceiling Firestop/Spacer
(SV4.5VF)
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
Figure 43 - Rear Vent - TWO 90 DEGREE ELBOWS
Figure 44 - Top Vent - TWO 90 DEGREE ELBOWS
HORIZONTAL VENT FIGURES/TABLES
(continued)
Square termination (SV4.5HT) shown.
See Table 3 as an aid in venting component selection for a particular range of exterior wall thicknesses.
See Table 3 as an aid in venting component selection for a particular range of exterior wall thicknesses.
Square termination (SV4.5HT) shown.

20 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
HORIZONTAL VENT FIGURES/TABLES
(continued)
V
H2
H1
H
*Ceiling Firestop/Spacer
(SV4.5VF)
**Wall Firestop/Spacer
(SV4.5HF)
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
**Wall Firestop/Spacer
(SV4.5HF)
JELBAT
muminiMVmumixaMH H+H
1
H+
2
mumixaM
teef)m(teef)m(teef)m(
1)503.0(2)016.0(5)25.1(
2)016.0(4)22.1(01)1.3(
3)419.0(6)68.1(51)56.4(
4)22.1(8)84.2(02)2.6(
H+H+V
1
H+
2
.xaM)m4.21(teef04= .xaM)m84.2(teef8=H
H+H
1
H+
2
.xaM)m2.6(teef02=
KELBAT
VM MUMINI HmumixaM
teef)m(teef)m(
1)503.0(5)25.1(
2)016.0(01)1.3(
3)419.0(51)56.4(
4)22.1(02)2.6(
H+H
1
.xaM)m2.6(teef02=
V+V
1
H+H+
1
.xaM)m4.21(teef04=
V
H
H1
V1
**Wall
Firestop/spacer
(SV4.5HF)
*Ceiling Firestop/spacer
(SV4.5VF)
**Wall
Firestop/spacer
(SV4.5HF)
*When using Secure Flex,
use Firestop/Spacer
SF4.5VF
**When using Secure
Flex, use Firestop/Spacer
SF4.5HF
*Ceiling Firestop/spacer
(SV4.5VF)
Figure 46 - Top Vent - THREE 90 DEGREE ELBOWS
Figure 45 - Rear Vent - THREE 90 DEGREE ELBOWS
Square termination (SV4.5HT) shown.
Square termination (SV4.5HT) shown.
See Table 3 as an aid in venting component selection for a particular range of exterior wall thicknesses.
See
Table 3 as an aid in venting component selection for a particular
range of exterior wall thicknesses.
