Superior SSBV-3530CNM User manual

INSTALLATION
INSTRUCTIONS
MODELS
POURVOTRESÉCURITÉ: Nepasentreposerniutiliser
d'essence ni d'autre vapeurs ou liquides inflam-
mables dans le voisinage de cet appareil ou de tout
autre appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez
une odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones se trouvant dans le batiment
où vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un
qualifié installeur, agence de service ou le fournis-
seur de gaz.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE
POURRÉDUIREAUMINIMUMLERISQUED'INCENDIE
OUPOURÉVITERTOUTDOMMAGEMATÉRIEL,TOUTE
BLESSURE OU LA MORT.
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by local
codes. This appliance is only for use with the type
of gas indicated on the rating plate. This appliance
is not convertible for use with other gases, unless
a certified kit is used.
FOR YOUR SAFETY: Do not store or use gasoline
or other flammables or liquids in the vicinity of
this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow your gas suppliers
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
WARNING: IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SIONMAYRESULTCAUSINGPROPERTYDAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
OTL Report No. 116-F-30-5
A French manual is available upon request. Order P/N 700,030CF
Ce manuel d’installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 700,030CF.
SSBV-3530CNM SSBV-3530CNE
SSBV-4035CNM SSBV-4035CNE
Millivolt Models Electronic Models
P/N 700,030M REV. B 08/2005
B-VENT GAS FIREPLACES
B-VENT
SSBV-35/40 SERIES
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
2
Input (BTU) Manually-Modulated Gas
Valves (millivolt models)
NATURAL GAS
Models Input Rate
(BTU / HR)
SSBV-3530CNM 23,000 high
17,500 low
SSBV-4035CNM 29,000 high
21,500 low
Table 1
Input (BTU) Manually-Modulated Gas
Valves (millivolt models)
PROPANE GAS
Requires Field Converion
Models Input Rate
(BTU / HR)
SSBV-3530CPM 23,000 high
17,500 low
SSBV-4035CPM 29,000 high
22,500 low
Table 2
TABLE OF CONTENTS
Packaging .........................................Page 2
Introduction ......................................Page 2
General Information ..........................Page 2
Massachusetts Requirements...........Page 3
Safety & Warning Information ..........Page 3
Location............................................Page 5
Cold Climate Insulation .....................Page 5
Manufactured Homes........................Page 5
Minimum Clearances to Combustibles..Page 6
Vent Termination Clearances ............Page 7
Typical Installation Sequence ...........Page 7
Step 1. Framing...............................Page 7
Step 2. Routing Gas Line ................Page 7
Fireplace Specifications.....................Page 8
Step 3. Position Unit in Framing .....Page 9
Step 4. Install the Venting System ..Page 9
Step 5. Field Wiring.........................Page 10
Step 6. Optional Blower Installation ..Page 11
Step 7. Connecting Gas Line ...........Page 11
Step 8. Outside Air Kit Installation ..Page 12
Step 9. Checking Unit Operation .....Page 13
Step 10. Install Volcanic Stone,
Embers & Logs ..................Page 14
Step 11. Installing Glass Door Panel Page 17
Step 12. Burner Adjustment..............Page 17
Step 13. Spillage Test and Safety
Limit Switch Operation..................Page 18
Step 14. Hood Installation.................Page 19
Finishing Requirements ....................Page 19
Installation Accessories ....................Page 18
Gas Conversion Kits .................. Page 19
INTRODUCTION
PACKAGING
The assembled vented gas fireplace heater is
packaged with:
1 - one log set located in firebox area.
2 - one envelope containing the literature pack-
age which consists of the homeowner's
manual, installation instructions, and war-
ranty; envelope is located in the control
compartment.
3 - one hood located behind the top panel.
4 - one bag of decorative volcanic stone located
in the control compartment.
5 - one bag of glowing embers located in the
control compartment.
These appliances comply with National Safety
Standards and are tested and listed by OMNI-
Test Laboratories, Inc. (Report No. 116-F-30-5)
to ANSI Z21.50 - 2003 (in Canada, CSA 2.22
- 2003), and CAN/CGA-2.17-M91 in both USA
and Canada, as vented gas fireplaces.
Bothmillivoltandelectronic versionsofthese
appliances are listed by OMNI-Test Laborato-
ries, Inc. for installation in bedrooms in the
United States (not approved in Canada) and
in Manufactured Homes.
Manufactured Homes -
See Manufactured Home Requirements on
Page 5 for additional information.
Outside Combustion Air Hook Up -
(All manufactured home installations require
the use of an Outside Combustion Air Hook-
Up Kit)
These appliances are equipped with an integral
combustion air door and actuator arm. Com-
bustion air kits are optional. Install as shown
in Step 8 on Page 12.
Misc. Codes / Standards -
The Installation must conform to local codes or,
in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54 - latest
edition, or the Natural Gas and Propane Instal-
lation Code, CSA B149.1 - latest edition.
The appliance, when installed, must be electri-
cally grounded inaccordance with local codesor,
in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70 - latest edition,
or the Canadian Electrical Code, CSA C22.1
- latest edition.
This installation manual will help you obtain a
safe, efficient, dependable installation for your
appliance and vent system.
Please read and understand these
instructions before beginning your
installation.
These vented gas fireplaces are designed for
residential applications. They must be installed
with approved type-B, 5 inch diameter double
wall vent pipe systems routed to the outside
atmosphere.
The Millivolt appliances have a millivolt gas
control valve with piezoignition system provides
safe, efficient operation. If any optional acces-
sories which require electrical power are being
installed, the electrical power must be provided
at the time of appliance installation.
The Electronic appliances have an electronic
intermittent pilot ignition system provides safe,
efficient operation. External electrical power is
required to operate these units.
GENERAL INFORMATION
Note: Installation and repair should be per-
formed by a qualified service person. The
appliance should be inspected annually by a
qualified professional service technician. More
frequent inspections and cleanings may be
required due to excessive lint from carpeting,
bedding material, etc.
S'assurer que le brùleur et le compartiment des
commandes sont propres. Voir les instructions
d'installation et d'utilisation qui accompagnent
l'apareil.\
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front, back and/or side viewing surfaces
of the appliance.
These appliances are designed to operate
on natural or propane gas only. To operate
on Propane Gas a field converion is neces-
sary (see Pages 19 to 22). The use of other
fuels or combination of fuels will degrade
the performance of this system and may be
dangerous.
Millivolt Models -
The millivolt appliances are manually controlled
and feature a spark igniter (piezo) that allows the
appliance's pilot gas to be lit without the use of
matchesorbatteries. This system providescon-
tinued service in the event of a power outage.
Millivolt models comestandard with a manually-
modulatedgasvalve; flame appearanceand heat
output can be controlled at the gas valve. Input
for these models are shown in Tables 1 & 2.
BTU Input - Millivolt Models
WARNING
Improper installation, adjust-
ment, alteration, service or
maintenance can cause injury
or property damage. Refer to
this manual. For assistance or
additional information consult
a qualified installer, service
agency or the gas supplier.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 3
Gas Pressure - All Models
Tables 4, 5 & 6 show the units' gas pressure
requirements:
Inlet Gas Supply Pressure (all models)
Fuel # Minimum Maximum
Natural Gas 5.0" WC
(1.24 kPa)
10.5" WC
(2.61 kPa)
Propane 11.0" WC
(2.74 kPa)
13.0" WC
(3.23 kPa)
Table 4
Gas Valve Diagrams
See Figures 1 & 2 for Millivolt models and
Figure 3 For Electronic Models.
Figure 3
Honeywell Electronic Gas Valve
FFO
NI
PSI
NO
L
O
R
T
N
O
C
G
INT
IER
Manifold Pressure
Port ON / OFF Switch
Inlet
Pressure
Port
Electronic Gas
Control Valve
H
I
LO
W
H
TPT
HT
P
T
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
IN OUT
Manifold Pressure Tap
Inlet Pressure Tap
SIT Millivolt Gas Valve
Pilot Adjustment
Screw
HI/LO Variable
Flame Height
Adjustment
Main Gas
Control Knob
OFF/PILOT/ON
Figure 1
Orifice Sizes - Sea Level to High Altitude
(All Models)
These appliances are tested and approved for
installation at elevations of 0-4500 feet (0-1372
meters)above sealevel usingthestandardburner
orifice sizes (marked with an "*" in Table 7). For
elevations above 4500 feet, contact your gas
supplier or qualified service technician. Install
the appliance according to the regulations of
the local authorities having jurisdiction and, in
the USA, the National Fuel Gas Code NFPA 54
/ ANSI Z223.1 - latest edition or, in Canada, the
CAN1-B149.1 and .2 codes - latest edition.
Electronic Models with Fixed Rate Gas Valve
Natural and Propane Gas
Model Series Input Rate (BTU / HR)
SSBV-3530CNE 23,000
SSBV-4035CNE 29,000
Table 3
Burner Orifice Sizes
Elevation 0-4500 feet ( 0-1372 meters)
Model
Series
Natural
Gas
drill size (inches)
Propane
Gas
drill size (inches)
SSBV-3530 2.3 mm (.090") *
37L70 •
#54 (.055") *
99K79 •
SSBV-4035 #36 (.1065") *
18L4001 •
#52 (.0635")*
LB-55874D •
* Standard size installed at factory
• Part /Cat. Number
Table 7
O
N
O
F
F
P
I
L
O
T
L
O
H
I
Figure 2
GAS CONTROL
KNOB
CONVERTIBLE
HI/LO REGULATOR
(adjusts flame height
and heat output)
INLET
PRESSURE
TAP
PILOT
ADJUSTMENT
SCREW
WIRING
TERM-
INALS
OUTLET
PRESSURE
TAP
TP/TH
PIEZO
IGNITER
TH
TP
Honeywell Millivolt Gas Valve
Electronic Models - Electronic models have a
fixed rate gas valve. Input of electronic models
is shown in Table 3.
MASSACHUSETTS REQUIREMENTS
Theseappliancesare approvedforinstallation in
the following USA locations listed below:
Installation of these fireplaces are approved
for installation in the US state of Massachu-
setts if the following additional requirements
are met -
• Installation and repair must be done by a
plumber or gas fitter licensed in the Com-
monwealth of Massachusetts.
• The flexible gas line connector used shall not
exceed 36 inches (92 centimeters) in length.
• The individual manual shut-off must be a
T-handle type valve.
Manifold Gas Supply Pressure
(millivolt models)
Fuel # Low High
Natural
Gas
(Lo) 2.2" WC
(.55 kPa)
(Hi) 3.5" WC
(.87 kPa)
Propane (Lo) 6.3" WC
(1.57 kPa)
(Hi) 10.0" WC
(2.49 kPa)
Table 5
Test gauge connections are provided on the
front of the millivolt gas control valve, identi-
fied IN for the inlet and OUT for the manifold
side. A 1/8" NPT Test gauge connection
is provided at the inlet and outlet side of
the electronic gas control valve.
These appliances and their individual shut-off
valves must be disconnected from the gas
supply piping system during any pressure
testing of that system at pressures greater
than 1/2 psig (3.5 kPa).
These appliances must be isolated from the gas
supplypipingsystem (byclosing theirindividual
manualshut-offvalve) duringanypressuretest-
ingof gassupplypipingsystemattestpressures
equal to or less than 1/2 psig (3.5 kPa).
BTU Input - Electronic Models
SAFETY WARNIINGS
WARNING
This appliance is only for use
with the type of gas indicated on
the rating plate. This appliance
is not convertible for use with
other gases, unless a certified
kit is used.
WARNING
If the information in this
manual is not followed
exactly,afireorexplosion
may result causing prop-
erty damage, personal
injury or loss of life.
AVERTISSEMENT
Cet appareil doit être utilisé
uniquement avec les types de
gaz indiqués sur la plaque sig-
nalétique. Ne pas l'utiliser avec
d'autres gaz sauf si un kit de con-
version certifié est installé.
Manifold Gas Supply Pressure
(electronic models)
Fuel # Max. Manifold Pressure
Natural Gas (Hi) 3.5" WC (.87 kPa)
Propane (Hi) 10.0" WC (2.49 kPa)
Table 6
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
4
WARNING
B-Ventappliancesarenotdesigned
tooperate in negatively pressured
environments (pressure within
the home is less than pressures
outside). Significant negatively
pressured environments caused
byweather, homedesign, or other
devices may impact the operation
of these appliances. Negative
pressuresmayresultinpoorflame
appearance, sooting, damage to
property and/or severe personal
injury. Do not operate these appli-
ances in negatively pressured
environments.Providingadequate
ventilation to the appiance for
combustion air will eliminate a
negative pressure environment.
WARNING
These fireplaces are vented
decorative gas appliances. Do
not burn wood or other material
in these appliances.
WARNING
Children and adults should be
alerted to the hazards of high
surface temperatures. Use cau-
tion around the appliance to avoid
burns or clothing ignition. Young
childrenshouldbecarefullysuper-
vised when they are in the same
room as the appliance.
Note: An Optional Screen for
the glass is available to prevent
inadvertant direct contact with the
glass (see Homeowners Manual
for ordering information).
IMPORTANT
These appliances must not be
connected to a chimney or flue
serving a separate solid fuel
burning appliance.
WARNING
Do not place clothing or other
flammable materials on or near
this appliance.
WARNING
Do not use these appliances if
any part has been under water.
Immediately call a qualified,
professional service technician
to inspect the appliances and to
replace any parts of the control
system and any gas controls
which have been under water.
WARNING
Do not attempt to alter or modify
theconstruction ofthe appliance
or its components. Any modi-
fication or alteration may void
the warranty, certification and
listings of this unit.
WARNING
Carbon monoxide poisoning:
early signs of carbon monoxide
poisoning are similar to the flu
withheadaches,dizzinessand/or
nausea. If you have these signs,
obtainfreshairimmediately.Turn
offthegassupplytotheappliance
and have it serviced by a quali-
fied professional, as it may not
be operating correctly.
WARNING
Failuretocomplywiththeinstal-
lationandoperatinginstructions
provided in this document will
result in an improperly installed
andoperatingappliance,voiding
its warranty. Any change to this
appliance and/or its operating
controlsisdangerous. Improper
installation or use of this appli-
ance can cause serious injury or
deathfromfire,burns,explosion
or carbon monoxide poisoning.
AVERTISSEMENT
Surveiller les enfants. Garder les
vêtements,lesmeubles,l'essence
ouautresliquidesà vapeurinflam-
mables lin de l'appareil.
Un écran facultatif pour le verre
est disponible pour empêcher le
contact direct inadvertant avec
le verre (voir les propriétaires
d’une maison manuels pour
l’information de commande).
AVERTISSEMENT
Nepasseservirdecetappareils'il
aétéplongédansl'eau,complète-
ment ou en partie. Appeler un
technicienqualifiépourinspecter
l'appareil et remplacer toute
partie du système de contrôle
et toute commande qui ont été
plongés dans l'eau.
AVERTISSEMENT
Cetappareilpeutêtreinstallédans
un maison préfabriquée (É.-U.
seulement)oumobile déjà instal-
lée à demeure si les réglements
locaux le permettent.
WARNING
This appliance may only be fitted
with doors certified for use with
the appliance.
AVERTISSEMENT
Pour utilisation uniquement
avec les portes en verre certi-
fiêes avec l'appareil.
IMPORTANT
It is imperative that the control
compartment, burners and
circulating air passage ways
of the appliance be kept clean.
SeeMaintenanceinstructionsin
Homeowner's Manual.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 5
Figure 4
LOCATION
In selecting the location, the aesthetic and
functional use of the appliance are primary
concerns. However, vent system routing to
the outside atmosphere and access to the fuel
supply are also important. Consideration should
be given to traffic ways, furniture, draperies,
etc., due to high surface temperatures (see
illustrations). The location should also be free
of electrical, plumbing or other heating/air
conditioning ducting.
The appliance should be mounted on a fully
supported base extending the full width and
depth of the unit. The appliance may be located
on or near conventional construction materials.
However, if installed on combustible materials,
such as carpeting, vinyl tile, etc., a metal or
wood barrier covering the entire bottom surface
must be used.
Offset
Venting
Vertical
Venting
Typical Installations
COLD CLIMATE INSULATION
For cold climate installations, seal all cracks
around the appliance with noncombustible
material and wherever cold air could enter
the room. It is especially important to insulate
outside chase cavity between studs and under
floor on which the appliance rests, if floor
is above ground level. Gas line holes and
other openings should be caulked with high
temperature caulk or stuffed with unfaced
fiberglass insulation. If the fireplace is being
installed on a cement slab, in cold climates, a
sheetofplywood or otherraisedplatform can be
placed underneath toprevent conducting coldup
into the room. It also helps to
sheetrock inside
surfaces and tape for maximum air tightness
and caulk firestops.
Locations
Manufactured Home installations must be
installed in accordance with these instructions
and the following standards / codes:
• Manufactured Home Construction and
Safety Standard Title 24 CFR, Part 3280, or
the current Standard for Fire Safety Criteria
for Manufactured Home Installations, Sites
and Communities ANSI / NFPA 501A in the
USA, and CAN / CSA Z240 MH Mobile Home
Standard in Canada.
• (when applicable) The American National
Standard for Manufactured Homes (NCSBCS
/ ANSI A225.1 - latest edition).
• An Outside Combustion Air Hook-Up Kit
must be installed (see Step 8,Page 12).
• Also see Manufactured Homes on Page 2.
Cet appareil peut être installé dans un maison
préfabriquée(É.-U.seulement)oumobile déjà
installée à demeure si les réglements locaux
le permettent.
CAUTIONS
Ensure that the cross members are not cut or weakened during installation.
The structural integrity of the manufactured home floor, wall, and ceiling /
roof must be maintained.
This appliance must be grounded to the chassis of the manufactured home
in accordance with local codes or in the absence of local codes, with the
National Electrical Code ANSI / NFPA 70 - latest edition or the Canadian
Electrical Code CSA C22.1 - latest edition.
MANUFACTURED HOME REQUIREMENTS
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
6
APPLIANCE AND VENT CLEARANCES
Maintainclearancesfrom appliance tocombus-
tible materials as detailed in Table 8 with the
following exception: When the unit is installed
with one side flush with a wall, the wall on the
other side of the unit must not extend beyond
the front edge of the unit. In addition, when
the unit is installed in the middle of a room,
the side walls surrounding the unit must not
extend beyond the front or rear edge of the
unit. See Figure 4.
Floor Protection /Hearth ExtensionThe appliance should be installed on top of a fully supported
base extending the full width and depth of the unit. The appliance may be located on or near con-
ventional construction materials or raised on a platform of an appropriate height. If installed on
combustible materials, such as carpeting, vinyl tile, etc., a hard surface covering the full width and
depth of the fileplace base must be installed (i.e. acceptable materials include flat wood, plywood,
particle board, metal or other hard surfaces). A hearth extension is not required (if used, do not
block the control compartment access panel). Any hearth extension used is for appearance only
and does not have to conform to standard hearth extension installation requirements.
Floor Support
Most installations require no special floor support. Check local code to determine if any additional
support is required for intended installation(see following):
Estimate the total weight of the fireplace system and surround materials including brick, stone,
etc. to be installed. Measure the square footage of the floor space to be occupied by the system,
surrounds and hearth extensions. Note the floor construction, i.e. 2 x 6’s, 2 x 8’s or 2 x 10’s,
single or double joists, type and thickness of floor boards. Use this information and consult
your local building code to determine if you need additional support. If you plan to raise the
fireplace and hearth extension, build the platform assembly, then position fireplace and hearth
extension on top. Secure the platform to the floor to prevent possible shifting.
Wall Finishes / Surrounds / Mantels
Note: Combustible wall finish materials and/or surround materials must not be allowed to encroach
the area defined by the appliance front face (black sheet metal). Never allow combustible materials
to be positioned in front of or overlapping the appliance front face. See Figure 35.
Non-combustible materials, such as surrounds and other appliance trim, may be installed on the
appliance front face with the following exception: The material must NOT cover any portion of
the glass or louvers.
Vertical installation clearances to combustible mantels vary according to the depth of the mantel.
(See Figure 5). Mantels constructed of non-combustible materials may be installed at any height
above the appliance opening; however, do not allow anything to hang below the hood.
These instructions should be used as a guideline and do not supersede local codes in any way.
MINIMUM CLEARANCES TO COMBUSTIBLES
MINIMUM CLEARANCES
Inches (millimeters)
Back 1/2 (13)
Sides 1/2 (13)
Top Spacers 0 (0)
Floor 0 (0)
Bottom of Appliance
To Ceiling 64 (1626)
Vent 1 (25.4)
SERVICE CLEARANCES Feet (meters)
Front 3 ft. (0.9 m)
Table 8
2
(51)
4
(102)
6
(152)
8
(203)
10
(254)
12
(305)
4 (102)
6 (152)
10 (254)
14 (356)
12 (305)
8 (203)
Mantel Depth
NOTE - The side walls of mantels may protrude
beyond the front face of the fireplace a maximum of
5 inches (127 mm) at 0 inch clearance to the sides
of the fireplace.
inches (millimeters)
Top Of Appliance
Figure 5 -
Hood
0” Clearance
to Combustible
Side Wall Ceiling
64 in.
(1626 mm)
Bottom of Fireplace
Minimum Mantel Clearances
Figure 6 - Clearances
*Note: See Page 9, Step 3 for clear-
ance requirements to the nailing flange
located at each side of the unit and any
screw heads adjacent to it.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 7
VENT TERMINATION CLEARANCES
Gas vent caps are not permitted within 8 feet
(2.4 mm) of a vertical wall or similar obstruc-
tion. Gas vent caps that are located 8' or more
from a portion of a building which extends at
an angle greater than 45° upward from the
horizontal may terminate in accordance with
(Figure 7 ), provided that in no case shall any
discharge opening on the cap be less than 2'
(610 mm) horizontally from the roof surface
(National Fuel Gas Code ANSI Z223.1 (NFPA
54) 7.6.2) (CAN/CGA B149).
Multiple Terminations
These appliances may vent adjacent to and at
the same level with any other gas appliances
(including b-vent appliances) provided that
there is at least2 ft. (0.6m) between theproximal
edges of the vent caps. These appliances may
be vented adjacent to a chimney vent servicing
a solid fuel fireplace provided the B-vent cap
is at least 2 ft. (0.6m) away from the nearest
point of the chimney opening.
TYPICAL INSTALLATION SEQUENCE
The typical sequence of installation follows,
however, each installation is unique resulting
in variations to those described.
See the Page number referencesin the following
steps for detailed procedures.
Step 1. (Page 7) Construct the appliance fram-
ing.
Step 2.(Page 7) Route gas supply line to appli-
ance location.
Step 3.(Page 9) Position the appliance within
the framing and secure with nailing
flanges.
Step 4 (Page 9) Install the vent system and
exterior termination.
Step 5. (Page 10) Field Wiring
a. Millivolt Appliances – Install the
OFF/ON burner control switch.
b. Electronic Appliances – Connect 120
VAC electrical power to the appliance
receptacle.
Step 6.(Page 11) Install the optional blower.
Step 7.(Page 11) Make connection to gas
supply.
Step 8.(Page 12) Outside Air Kit Installation.
Step 9. (Page 13) Checkout appliance opera-
tion.
Step 10.(Page 14) Install volcanic stone,
embers and logs.
Step 11. (Page 17) Install glass enclosure
panel.
Step 12(Page 17) Adjust burner primary air
shuttertoachieve proper flameappear-
ance.
Step 13.(Page 18) Spillage Test and (safety
limit) Switch Operation.
Step 14.(Page 19) Install the decorative trim
and hood.
Termination Heights For Vents
Above Flat Or Sloped Roofs
Ref. NFPA 54 / ANSI Z223.1, 7.6
Roof Pitch Feet Meters
Flat to 6/12 1.0 0.3
6/12 to 7/12 1.25 0.38
7/12 to 8/12 1.5 0.46
8/12 to 9/12 2.0 0.61
9/12 to 10/12 2.5 0.76
10/12 to 11/12 3.25 0.99
11/12 to 12/12 4.0 1.22
12/12 to 14/12 5.0 1.52
14/12 to 16/12 6.0 1.83
16/12 to 18/12 7.0 2.13
18/12 to 20/12 7.5 2.29
20/12 to 21/12 8.0 2.44
Figure 7 - Vertical Vent Termination Clearances
Roof Pitch is X/12
Minimum Height from Roof to
Lowest Discharge Opening
X
12
1" (25 mm)
Minimum
Note: Venting terminals shall not be recessed
into a wall or siding.
Gas Vent Rule
Step 1. FRAMING
Frame these appliances as illustrated in Figure
9. All framing details must allow for a minimum
clearance to combustible framing members as
shown in Table 8 on Page 6.
If the appliance is to be elevated above floor
level, a solid continuous platform must be
constructed. Headers may be in direct contact
with the appliance top spacers but must not
be supported by them or notched to fit around
them. All constructionabove the appliance must
be self supporting, DO NOT use the appliance
for structural support.
Side Nailing Flanges
The fireplace should be secured to the framing at
the side(s) of the unit using the factory-provided
nailing flanges. Install the 8 nailing flanges as
shown in Figure 10 using the existing screws.
Position the fireplace within the framing. When
required, the tabs may be bent 90 degrees by
hand or with the assistance of a hammer. Use
wood screws to secure the nailing flanges to the
framing. See Table 8 on Page 6 for clearances
of framing membersto cabinet parts. The nailing
flange itself can directly contact framing.
Step 2. Routing Gas Line
Route a gas line along the inside of the right side
framing as shown in Figure 8. Gas lines must
be routed, constructed and made of materials
that are in strict accordance with local codes
and regulations.
Schedule 40 (black iron) Pipe
Inside Diameter (Inches)
Schedule 40 Pipe
Length (feet)
Natural
Gas
Propane
Gas
0-10 1/2 3/8
10-40 1/2 1/2
40-100 1/2 1/2
100-150 3/4 1/2
150-200 3/4 1/2
Table 9
Proper Sizing of Gas Line
Properly size and route the gas supply line
from the supply regulator to the area where the
appliance is to be installed per requirements
outlined in the National Fuel Gas Code, NFPA
54 - latest edition (USA) or B149 - latest edition
(Canada). Never use galvanized or plastic pipe.
Refer to Table 9 for proper sizing of the gas
supply line, if black iron pipe is being used. Gas
lines must be routed, constructed and made
of materials that are in strict accordance with
local codes and regulations. We recommend
that a qualified individual such as a plumber
or gas fitter be hired to correctly size and route
the gas supply line to the appliance. Installing
a gas supply line from the fuel supply to the
applianceinvolvesnumerous considerations of
materials, protection, sizing,locations, controls,
pressure, sediment, and more. Certainly no one
unfamiliarandunqualified should attempt sizing
or installing gas piping.
Also see
Figure 9
6 1/2"
(152 mm)
3"
(76 mm)
Figure 8- ROUTE GAS LINE
Right Side Front Corner of
Fireplace Framing
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
8
FIREPLACE SPECIFICATIONS - SSBV-3530 & SSBV 4035
Figure 9
.oNledoMABCDEFGHJ
.ni538/1-8/1-23912/1-92538/1-8/7-42161/7-258
mm298618384947298236613721302
.ni8/1-048/1-73422/1-438/1-048/7-92161/51-458
mm91013490166789101957973721302
F
G
Top View
FRAMING
SPACERS
(Top and Sides
and Rear)
9
(229)
J
H
Flue Outlet For
B-Vent Connection
Flue Outlet Shield
OPTIONAL ELECTRICAL
INLET KNOCKOUT
REQUIRING A FIELD
PROVIDED JUNCTION
BOX (Either Side)
GAS INLET
(Either Side
and bottom)
NOTE - Hood shown
as positioned
in louvered
front model.
ELECTRICAL INLET
2³⁄₄ x 2 (70 x 51) Cover
Plate With Knockout
16
(406)
¹⁄₂ (13)
3 (76)
1³⁄₈
(35)
(140)
5¹⁄₂
9³⁄₈
(238)
2
(53)
Right Side View
(140)
5¹⁄₂
9³⁄₈
(238)
1³⁄₈
(35)
Left Side View
GAS INLET
(See Also
Right Side View)
ELECTRICAL INLET
(See Also
Right Side View)
3
(76)
OUTSIDE AIR
SHUTTER
8¹⁵⁄₁₆
(227)
7³⁄₈
(187)
ELECTRICAL
INLET
(Optional)
SSBV-3530
SSBV-4035
Front View
E
D
CB
3 (76)
A
.oNledoM
A
tinU
eziS
A
gnimarF
eziS
BCD
.ni538/1-534/1-534/1-918/5-91
mm298598598384894
.ni8/1-044/1-044/1-04428/5-42
mm910122012201016526
SSBV-3530
SSBV-4035
Header
B
A
Fireplace Framing
C
A
G
Inside Chase
Back Wall of Chase/Enclosure
Including Finishing Materials
if any
Roug
h
Framing Fac
e
(Unfinished Shown
)
HH
Corner Installation
KD
C
A
E
G
F
Back Wall of Chase/Enclosure
Including Finishing Materials
if any
Rough
Framing Face
(Unfinished Shown)
*Optional FOAK
Outside
Air Kit
A
Outside Chase
G
C
J
Back Wall of Chase/Enclosure
Including Finishing Materials
if any
Rough Framing Face
(Unfinished Shown)
Notes
Due to Lennox' ongoing commitment to quality, all
specifications, ratings and dimensions are subject to
change without notice.
Product Reference Information
Cat.
No. Model Ship Weight Shipping Volume
H3337 SSBV-3530CNM 115 lb. 37”W x 17”D x 36”H
(13.1 cu.ft)
H3338 SSBV-3530CNE 115 lb. 37”W x 17”D x 36”H
(13.1 cu.ft)
H3339 SSBV-4035CNM 125 lb. 42”W x 17”D x 41”H
(13.1 cu.ft)
H3340 SSBV-4035CNE 125 lb. 42”W x 17”D x 41”H
(13.1 cu.ft)
Input (BTU) - MV & Electronic
Natural (NG) & Propane (LP) Gas
Models Fuel Input Rate (BTU / HR)
SSBV-3530 NG High 23,000 (Low 17,500)
LP High 23,000 (Low 17,500)
SSBV-4035 NG High 29,000 (Low 21,500)
LP High 29000 (Low 22,500)
.oNledoM
SSBV-3530
SSBV-4035
EFGHJK
752/1-4/3-82614 61/9-68/5-04
06410376042017612301
61/31-1661/1-03614 61/9-623/11-34
07519776042017611011
The header may rest on the top metal spacers, but
must not be notched to fit around them.
The framing depth, 16 in. (406mm), must always be mea-
sured from a finished surface. If a wall covering, such as
drywall, is to be attached to the rear wall, then the 16 in.
(406 mm) must be measured from the drywall surface.
Important: Under no circum-
stances can the fireplace top
framing spacers be removed
or modified, nor may you
notch the header to fit around
or be installed lower than the
spacers. The header may be
in direct contact with the top
spacers but may not be sup-
ported by them.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE
fire-parts.com

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Notes:
• All appliances are factory-equipped with a
flexiblegas lineconnector and1/2inch shutoff
valve (see Figure 19 on Page 12 ).
• See Massachusetts Requirements on Page
3for additional requirements for installations
in the state of Massachusetts in the USA.
• The gas supply line should Not be connected
to the appliance until Step 7 (Page 11 ).
• A pipe joint compound rated for gas should be
used on the threaded joints. Ensure propane
resistant compounds are used in propane
applications. Be very careful that the pipe
compound does not get inside the pipe.
• It is recommended to install a sediment trap
in the supply line as close as possible to the
appliance (see Figure 19 , Page 12 ). Appli-
ances using Propane should have a sediment
trap at the base of the tank.
• Check with local building official for local code
requirements(i.e.arebelowgradepenetrations
of the gas line allowed?, etc).
Step 4. INSTALL VENT SYSTEM
Install the Vent System & Exterior Ter-
mination:
In the United States, vent installation must
conform with local building codes. In the
absence of local codes, vents must be installed
in accordance with the current edition of the
National Fuel Gas Code (ANSI-Z223.1).
In Canada, vent installation must conform with
local building codes. In the absence of local
codes, vents must be installed in accordance
with the current edition of the National Standard
of Canada CAN/CGA-B149.1 or B149.2 Instal-
lation Code.
This gas fireplace must be vertically vented
using listed 5 in. type-B, double-walled vent
pipe and a listed vent termination.
Slip the first 5 inch (127 mm) section of B-
Vent over the fireplace flue outlet and secure
with three (minimum) sheetmetal screws (#
8 or larger), and install the remainder of the
B-Vent to the outside. Minimum overall height
of the vent system and appliance must be 10'
(2.54 m) vertical - no offset (see Figure 13);
or 12' (3.7 m) when an offset up to 60 degrees
from the vertical is used - this offset may start
at the fireplace flue collar (see Figure 14 on
Page 10 ). The maximum overall height of
the vent system and appliance should not
exceed 40 feet.
Install the B-vent system in accordance with
the vent manufacturer's instructions.
Figure 13
1" (25 mm)
Minimum
Firestop
Step 3. POSITION APPLIANCE
Positiontheappliancewithintheframing
and secure with nailing brackets.
Flue Outlet
Collar
Securing
Screws
Figure 12
Note: Refer to the vent manufacturers instal-
lation instructions for variations of venting
techniques. If common venting of several units
is contemplated, it should be discussed with an
architect and the local Building Department.
Do not place insulation materials within 1 in.
of the gas vent system.
CAUTION
Thisappliancecannot bevented
horizontally.
IMPORTANT
If propane is used, be aware that
if tank size is too small (i.e. under
100-lbs, if this is the only gas
appliance in the dwelling. Ref.
NPFA 58), there may be loss of
pressure, resulting in insufficient
fuel delivery (which can result in
sooting, severedelayedignitionor
other malfunctions). Any damage
resulting from an improper instal-
lation, such as this, is not covered
under the limited warranty.
Figure 10 (see *Note)
Side
Framing
Unit Nailing Flange
(No clearance to
combustible
framing is required)
Left Side Front Corner of Fireplace Shown
(Right Side Requirements the Same)
Unit Being Secured By Its Nailing Flanges
To The Framing
Anchor
Tab
Figure 11
Floor Nailing Tabs
Secure the fireplace to the floor as shown in
Figure 11.
* Note: The nailing flanges, combustible mem-
bers and screw heads located in areas directly
adjacenttothe nailingflanges, areEXEMPT from
the 1/2” clearance to combustible requirements
for the firebox outer wrapper. Combustible
framing may be in direct contact with the nail-
ing flanges and may be located closer than 1/2”
from screw heads and the firebox wrapper in
areas adjacent to the nailing flanges. Frame the
opening to the exact dimensionsspecified in the
framing details of this manual.
Fireplacemaybeanchoredtofloor.Benddowntwo
anchor tabs (one on each side) located at the base
of the fireplace and secure to the floor by nailing
with 8d nails or equivalent (see Figure 11).
Note: Some units
only have one
anchor tab on
each side.
Type Type B-Vent 5 in. (127 mm)
10 Feet (3 Meters)
Minimum
fire-parts.com

Figure 15
TH
TP TH
TP
WT
BK
BK
BK
Spill Switch
If any of the original wire as supplied must
be replaced, it must be replaced with Type
AWM105 C - 18 gage wire.
* Optional Kits - OFF/ON wall
switch or remote control
receiver.
Millivolt Wiring Diagram
Appliance mounted OFF / ON Switch
Schematic Represen-
tation Only
Field Wired
Factory
Wired
60 Degrees
Maximum
BK = BLACK
WT = WHITE
Note: Offset can
start at appliance
collar.
CAUTIONS
Ensure that wires are positioned away
from hot surfaces and sharp edges.
DoNOTconnectoptionalwallswitch
to a 120 Volt AC power supply.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
10
Figure 14
*with an offset up to 45 degrees
** with an offset greater than 45 degrees and
up to 60 degrees
CAUTION
Labelallwirespriortodisconnection
when servicing controls. Wiring
errors can cause improper and dan-
gerous appliance operation.
Step 5. FIELD WIRING
Refer to Section A for millivolt appliances and
Section B for electronic appliances. The gas
valve is set in place and pre-wired at the factory
on both models.
A. SIT and Honeywell Millivolt Wiring
(See Figure 15) –
1. Select any ofthefollowing optional controls:
appliance-mounted (rocker switch) or wall-
mounted switch, thermostat, or one of the
optional remote control kits. If appliance-
mounted ON/OFF control is selected mount
it in the gas valve mounting bracket.
2. If wall-mounted ON/OFF control or ther-
mostat is selected mount it in a convenient
location on a wall near the fireplace.
3. Wire the control within the millivolt control
circuit using the 15 feet of 2 conductor wire
supplied with the unit . Caution: do not
connect the optional wall switch to a 120V
power supply.
B. Electronic Wiring (See Figures 17 & 18)
Note: The electronic appliance must be con-
nected to the main power supply.
The junction box is located on the right side of
the appliance. It contains a factory installed and
wired outlet box (duplex receptacle). Also, an
optional field-provided junction box with recep-
tacle may be installed at the front of the control
compartment on either side of the cabinet. See
Figure 16. It will be held in place by a conduit
fitting and locknut (field-provided).
1. Routea 3-wire120Vac60Hz 1phpowersupply
to the appliance junction box.
2. If the factory-provided outlet/junction box at
the right rear of the fireplace is being used,
remove the outlet box from the junction box
by removing two screws.
3. Connect the power supply wires (including
the ground supply wire) as shown in Figures
17 or 18. (If the field-provided J-box/outlet
box is being used, all of the outlet box wiring
must be field-provided).
4. Locate and install a low voltage (24V) wall-
mounted switch or thermostat (both field-
provided)in the desired location.
5. Connect the low voltage wire, located inside
the control compartment, to the wall-mounted
switch or thermostat.
Note: The supplied 15 feet of 2 conductor wire
has one end of each conductor connected to
the gas valve circuit and the other end of each
conductor placed loose inside the control
compartment.
6. Insert the control circuit plug into the
unswitched receptacle of the outlet box.
7. After wiring is complete, mount the outlet box
to the J-Box.
4. Alternatively, the appliance may be operated
without the use of the controls indicated in
step 1, solely by manipulating the gas valve
control knob. In order to use this method,
twist the free ends of the two conductor wire
(which would otherwise go to the standard
ON/OFF switch or Optional Switch) together
as shown in Figure44. Note: Wire is located
inside the control compartment
Note: The supplied 15 feet of 2 conductor wire
has one end of each conductor connected to
the gas valve circuit and the other end of each
conductor placed loose inside the control
compartment.
Figure 16
Optional J-Box/Outlet Box
(Left Side Shown)
See Figure 9 on Page 8 for
Optional Electrical Inlet
Knockout Location
*Field-Provided
Junction Box and
Duplex Receptacle
*Narrow (2 1/8 inch Wide)
J-Box Required
* 12 Feet (3.7 Meters)
** 15 Feet (4.6 Meters)
MINIMUM
40 Feet (12.2 Meters)
MAXIMUM
fire-parts.com

1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C – 18 GA. wire.
2. 120V, 60Hz – Less than 3 amps.
BK
Junction Box
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-100 and FBK-200 Kits
R
W
BL
OPT
BLOWER
G
W
*OPTIONAL
ACCESSORY
SWITCH
120
VAC.
BK
W
Gas Valve
B
R
IGNITER
PILOT
ASSEMBLY
Break Off
Tab
BK
G
*Blower speed control switch is provided in FBK200 blower kit.
Outlet Box
Green Ground
Screw
Hot side of Outlet
Schematic Representation Only
**ON/OFF Switch (Integral
with Gas Valve)
**Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
Red
pigtail
Black
pigtail
White Wire
to Opposite
Side
G
LIMIT SWITCH
OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT OR
OPTIONAL REMOTE RECEIVER
BK BK
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C – 18 GA. wire.
2. 120V, 60Hz – Less than 3 amps.
BK
Junction Box
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-250 Kits
R
BL
OPT
BLOWER
G
W
120
VAC.
BK
W
Gas Valve
B
R
IGNITER
PILOT
ASSEMBLY
BK
Outlet Box Green
Ground Screw
Hot side of Outlet
Schematic Representation Only
*ON/OFF Switch (Integral
with Gas Valve)
White Wire
To Opposite
Side
Optional FBK-250
Module
*Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
OPTIONAL ON/OFF SWITCH,
WALL SWITCH, THERMOSTAT
OR REMOTE CONTROL RECEIVER
G
W
LIMIT SWITCH
BK BK
Step 6. WIRING -
OPTIONAL FORCED AIR BLOWER KIT
FBK-100, FBK-200 and FBK250 Kits
(See Figure 17 for FBK-100, FBK-200 and
Figure 18 for FBK-250 wiring) -
An electrical outlet box (receptacle) is factory
-provided for the installation of the FBK-100,
FBK-200 and FBK-250 forced air blower kits.
(An optional field-provided outletbox/J-Box
may also be used. Electrical power must be
connected to either ofthese receptacles in order
to operate these blowers. Install the blower
kits according to the installation instructions
provided with the kits.
Note: The tab connecting the receptacles of
the outlet box must be broken in FBK-100
and FBK-200 blower kit applications.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 11
CAUTION
Ground supply lead must be con-
nected to the wire attached to the
green ground screw located on the
outletbox. SeeFigures 17 & 18.Fail-
ure to do so will result in a potential
safetyhazard. Theappliancemustbe
electrically grounded in accordance
with local codes or, in the absence of
local codes, the National Electrical
Code, ANSI/NFPA 70-latest edition.
(In Canada, the current CSA C22-1
Canadian Electrical Code).
Make gas line connections. All codes require a
shut-offvalvemounted in thesupplyline. Figure
19 illustrates two methods for connecting the
gas supply. The flex-line method is acceptable
in the U.S., however, Canadian requirements
vary depending on locality. Installation must
be in compliance with local codes.
These appliances are equipped with a gas flex
line for use (where permitted) in connecting
the appliance to the gas line. A gas flex line
is provided to aid in attaching the direct vent
appliance to the gas supply. The gas flex line
can only be used where local codes permit. See
Figure 19 for flex line description. The flex line
is rated for both natural gas and propane gas.
A manual shut off valve is also provided with
the flex line.
The incoming gas line should be piped into
the valve compartment and connected (see
Figures 19 & 20 ). The millivolt control
valve has a 3/8" (10 mm) NPT thread
inlet port. The electronic control valve
has a 1/2" (13 mm) NPT thread inlet port
and is fitted with a 1/2" x 3/8" (13 mm x
10 mm) NPT fitting.
Secure all joints tightly using appropriate
toolsandsealingcompounds(ensurepropane
resistant compounds are used in propane
applications).
Optional: Seal around the gas line to prevent
cold air leakage.
Step 7. CONNECTING GAS LINE
Figure 18
Turn on gas supply and test for gas leaks using a
gas leak test solution (also referred to as bubble
leaksolution). Note:Using asoapywater solution
(50% dish soap, 50% water) is an effective leak
test solution but it is not recommended, because
the soap residue that is left on the pipes/fittings
can result in corrosion over time.
A. Light the appliance (refer to the lighting
instructions label in control compartment or
homeowner's manual).
B. Brush all joints and connections with the gas
leak test solution to check for leaks. If bubbles
are formed, or gas odor is detected, turn the
gas control knob (off/pilot/on) to the “OFF”
position. Either tighten or refasten the leaking
connection, then retest as described above.
C. Whenthegas lines aretestedand leak freebe
sure to rinse off the leak testing solution,
D. Turn on burner then observe the individual
tongues of flame on the burner. Make sure
all ports are open and producing flame evenly
across the burner. If any ports are blocked, or
partially blocked, clean out the ports.
WARNING
Never use an open flame to check
for leaks.
Figure 17
TEST ALL CONNECTIONS FOR GAS LEAKS
(FACTORY AND FIELD):
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
12
CAUTION
Never locate inlet where it can
be blocked by shrubs, snow
drifts, etc. Never locate inlet in
garage or any area where there
isanotherfuelburningappliance
orproductsemittingcombustible
gases such as paint, gasoline,
etc. In cold climates, it is recom-
mended the combustion air duct
be insulated.
Step 8. OUTSIDE AIR KIT
Optional outside make-upair kits,Model FOAK-4
orFAOK-4LD, maybe usedwith theseappliances.
Refer to the installation instructions packaged
with the air kits for specific installation informa-
tion. If used, the outside air kit must be installed
before the fireplace is framed and enclosed in
the finished wall.
Outside air drawn into the fireplace supplies
air to the fire for combustion. Only one outside
air duct is necessary, if installed. See Figure
9, Page 8 for the location of the units outside
air inlet.
If additional length of duct is necessary, pur-
chase locally available U.L. Class 0 or Class 1
metallic ducting. The duct may extend up to 50
feet (15.24 meters) in any direction.
Note: When installing the air duct vertically,
DO NOT terminate the duct closer than 3 feet
below the chimney top.
Outside combustion air ducting may be run
upwards or vertically through framing and
ceiling joists, with the hood installed through
an outside wall and 3 feet (1 m) below the ter-
mination. Ducting may also be run downward
through floor Joists and under the home to a
ventilated crawlspace not considered part of
the living area of the home.
Note: Do not terminate outside air kit in attic
space under any circumstances.
After completing the installation of the optional
outside air vent system, the outside air control
lever must be put in service and tested to
ensure proper operation before completing
any enclosure around the firebox. Failure to do
so may result in extensive and costly rework.
Before the operation of the vent system can
be tested, the lever securing screw must be
removed. See Figure 21.
Figure 21
Operate the actuator through several cycles
including the closed position. Ensuring proper
operation and freedom of movement. Return
the actuator arm to the closed position.
Outside Air Control Lever and Securing
Screw Location on Left Side of Cabinet
in Lower Control Compartment Area
Note:The gas supply line must be installed in accordance with building codes by a qualified installer
approved and/or licensed as requed by the locality. In the Commonwealth of Massachusetts, instal-
lation must be performed by a licensed plumber or gas fitter.
Figure 19 - GAS CONNECTION
Gas
Valve 3/8" NPT x
Flare Fitting
3/8" Flex Tubing
3/8" Nipple
3/8" Union
3/8" Close Nipple
3/8" Shut-off Valve
1/2" x 3/8"
Reducer
Gas
Stub
1/2" x 3/8" Flare
Shut-off Valve
Gas Flex Line Connector
*Sediment Trap
*A Sediment Trap is recom-
mended to prevent moisture
and debris in gas line from
damaging the valve.
3"
Min
.
CONTROL COMPARTMENT ACCESS
INSTRUCTIONS (Ref. Figure 20 )
NOTE: The top louvered panel and the bottom
louvered control panel door remove and install
the same way as follows:
The gas controls canbe found behind the control
compartment access door.
Removing Control Compartment Door:
Open the door by gently lifting it upward until the
hook catches on boths sides clear the locating
slots. Then pull door out to remove.
On millivolt systems, the piezo igniter, HI/LO
flame adjustment knob, and pilot and main
gas OFF/ON control knob are located below
the glass panel enclosure. The gas valve for
electronic systems is also located below the
glass enclosure panel. See Figure 20.
Reinstalling Control Compartment Door:
To reinstall,insertthe hook catchesoneach side
of the door into the corresponding slots in the
controlcompartmentopening, then gentlypush
forward and side down until it locks in place.
Figure 20
Outside Air Control Lever
O
utside Air
C
ontrol Lever
Outside Air Control Lever
Outside Air Control Lever
Outside Air Control Lever
Securing Screw Removed
Air Shutter in
Closed Position
Air Shutter in
Open Position
Outside Air Control Lever
Securing Screw
OPENING CONTROL
COMPARTMENT DOOR
Control Valve
Lower Control
Compartment Door
Lift the Lower Control
Compartment Door
up and pull out to
remove.
Up
Out
Hook Catch
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 13
Replace logs if removed for pilot inspection.
To light the burner; turn “ON” the remote wall
switch and rotate the gas valve control knob
counterclockwise to the “ON” position.
Figure 25
Figure 24
Proper Pilot Flame Appearance
Thermocouple
Thermopile
Pilot
Nozzels
3/8" Min.
(9 mm)
1/8" Min.
(3 mm) Igniter RodHood
HONEYWELL MILLIVOLT PILOT ASSEMBLY
3/8" to 1/2"
(9 -13 mm)
Ground
Electrode
Flame Rod
Hot Surface
Igniter
Proper Flame
Adjustment
Pilot
Nozzels
ELECTRONIC PILOT ASSEMBLY
Proper Pilot Flame Appearance
Electronic Appliance Checkout
To light the burner, turn ‘ON’ the optional remote
wall switch and turn the gas control switch to
the “ON” position. Ensure the Igniter lights the
pilot. The pilot flame should engulf the flame
rod as shown in Figure 25.
Figure 23
Thermocouple
Thermopile
Pilot
Nozzels
SIT MILLIVOLT PILOT ASSEMBLY
Igniter Rod
Hood
Proper Pilot Flame Appearance
Figure 22
Step 9. CHECKING APPLIANCE
OPERATION
With the gas line installed, run initial system
checkout before closing up the front of the
appliance. Follow the pilot lighting instructions
provided in the Homeowner's Care and Opera-
tion Instructions. For piezo igniter location see
Figure 22 (millivolt appliances only).
Note: The (pull-out) Lightinginstructions label
can be found in the control compartment
(see Figure 20).
When first lighting the appliance, it will take
a few minutes for the line to purge itself of
air. Once purging is complete, the pilot and
burner will light and operate as indicated in
the instruction manual. Subsequent lightings
of the appliance will not require such purging.
Inspect the pilot flame.
SIT and Honeywell Millivolt Appliance
Checkout
The pilot flame should be steady, not lifting
or floating. Flame should be blue in color with
traces of orange at the outer edge.
The top 3/8" (10 mm) at the pilot generator
(thermopile) and the top 1/8" min (tip) of the
quick drop outthermocouple should be engulfed
inthepilot flame.Theflame should project 1" (25
mm) beyond the hood at all three ports (Figure
23 - SIT, Figure 24 - Honeywell )
To light the burner; rotate the gas valve control
knob counterclockwise to the “ON” position
then turn “ON” the optional control switch,
if applicable (see Installation Accessories on
Page 19).
Observe the individual tongues of flame on
the burner. Make sure all ports are open and
producing flame evenly across the burner. If
any ports are blocked, or partially blocked,
clean out the ports.
Sit and Honeywell Millivolt Gas Valve
Showing Piezo Igniter Location (Each Unit is
Equipped with Only One of these Gas Valves)
SIT Gas Valve
Shown with control
compartment door
removed
Piezo Igniter Honeywell
Gas Valve
GAS VALVE CONTROL COMPARTMENT
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
14
Glowing Embers
Bag of Glowing
Embers (rockwool)
Separate into Quarter
Size (separate) Pieces
WARNING
DO NOT attempt to install the
logs until the appliance instal-
lation has been completed, the
gas line connected and tested
for leaks and the initial burner
operation has been checked
out.
Figure 26
WARNING
This appliance is not designed
to burn wood. Any attempt to
do so could cause irreparable
damage to appliance and prove
hazardous to your safety.
WARNING
Iflogsarenotinstalledaccording
to the log installation instruc-
tions, flame impingement and
improper combustion could
occur and result in soot and/or
excessive production of carbon
monoxide (CO), a colorless,
odorless, toxic gas.
REFERENCE
Firebox Accessories / Parts
Cat. No. Model No. Description
88L53 FGE Bag of Glowing Embers
(1 oz. rockwool)
80L42 FDVS Bag of Decorative
Volcanic Stone
Table 10
WARNING
The size and position of the log
set is critical to achieve a safe,
reliable and attractive flame
pattern. Any attempt to use a
different log set in the fireplace
will void the warranty and will
result in incomplete combus-
tion, sooting, and poor flame
quality.
SSBV-4035 - Install as Follows
Carefully position the ceramic fiber logs into the
firebox as shown in Figure 28. Logs should be
placed in the order shown and per the following
instructions.
1. Place embers on the front burner tube and
volcanic stone in front of the burner as
shown and per instructions on this Page
(see Placement of Glowing Embers & Install
Decorative Volcanic Stone on this page).
2. Place the rear log (A) as shown. Position
the 2 notches on the bottom of the log over
the 2 corresponding locating brackets as
shown.
3. Place the center log (C) as shown. The 2
notches on the bottom of the log fit over
the corresponding locating brackets.
4. Place the top right log (D) as shown. The top
fork on log (D) fits into notch on log (A) as
shown. The bottom fork on log (D) rests on
subfloor flange (identified in photo #1).
5. Place the top left log (B) as shown. The top
fork on log (B) fits into notch on log (A). The
bottom of the log rests on the subfloor.
SSBV-3530 - Install as Follows
Carefully position the ceramic fiber logs into the
firebox as shown in Figure 27. Logs should be
placed in the order shown and per the following
instructions.
1. Place embers on the front burner tube and
volcanic stone in front of the burner as
shown and per instructions on this Page
(see Placement of Glowing Embers & Install
Decorative Volcanic Stone on this Page).
2. Place the rear log (A) as shown. Position
the 2 notches on the bottom of log (A) over
the 2 corresponding locating brackets as
shown.
3. Place the center log (C) as shown. The 2
notches on the bottom of log (C) fit over
the corresponding locating brackets.
4. Place the left log (B) as shown. The top fork
on log (B) fits into the notch on log (A). The
bottom of log (B) rests on the subfloor.
5. Place the top fork on log (D) into notch on
log (A) as shown. The bottom fork on log
(D) rests on the subfloor flange (identified
in photo #1).
Step 10. INSTALL VOLCANIC STONE,
GLOWING EMBERS AND LOGS
1. Remove the front glass enclosure panel
(see Glass Door Panel Removal Instructions
on Page 17).
2. Carefully remove the log set box from
the firebox. Next, remove embers and
volcanic stone from the control compart-
ment. Handle logs carefully to prevent
breakage.
3. Install decorative volcanic stone - Mound up
a portion of the volcanic stone in front of the
burner in a pleasing pattern.
4. Placement of Glowing Embers -
Separate the Embers (rockwool) into pieces
about the size of a quarter (see Figure 26).
Keep the pieces fluffed up, not matted.
Distribute these pieces over the surface of
the burner, as shown in Figures 27 or 28.
Do not use more than is necessary. Ensure
that the main burner slots remain uncovered
by the ember material.
Note: This appliance is provided with enough
Glowing Embers for several applications, do
not use all that is in a new bag at one time. For
bestglowing effect,replacetheembermaterial
annually.
5. Placement of Logs -
The logs have locating notches or slots to
help ensure that they are properly positioned.
Proper log placement is critical to prevent
sooting.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 15
Figure 27
MODEL SSBV-3530
Log Placement Instructions
LOG SET
Catalog Number H3367
* Item Description
A Log, Rear
B Log, Top Left
C Log, Center
D Log, Top Right
* Item "letters" above correspond to photos B
C
D
A
Install the Embers, Volcanic Stone and Logs in the order shown
here (1 through 5) and per the instructions on Page 14
A
Notch
Notch
2
C
3
Notches on bottom of log (C) fits over 2 locating brackets
Top fork on log (B) fits into notch on log (A)
B
A
4
D
A
5Top fork on log (D) fits into notch on log (A)
Place Embers & Volcanic Stone as Shown
1
Volcanic Stone
Embers
Locating Brackets
Notch for top
right log (D)
Notch for top
left log (B)
The 2 notches on the bottom of log (A) rest on the locating brackets
Sub-Floor
Sub-Floor
Flange
Bottom Fork of log (D) rests on Sub-Floor Flange
Bottom of log (B) rests on Sub-Floor
fire-parts.com

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 28
LOG SET
Catalog Number H3368
* Item Description
A Log, Rear
B Log, Top Left
C Log, Center
D Log, Top Right
* Item "letters" above correspond to photos
A
C
D
B
MODEL SSBV-4035
Log Placement Instructions
Install the Embers, Volcanic Stone and Logs in the order shown
here (1 through 5) and per the instructions on Page 14.
D
A
4
A
Bottom of log (B) rests on subfloor
B
Top fork on log (D) fits into notch on log (A) as shown
Top fork on log (B) fits into notch on log (A) as shown
1Place Embers and Volcanic Stone as Shown
Volcanic Stone Embers
2
Notch
Notch
Locating Brackets
A
3
C
Slots on bottom of Log (C) fits over 2 locating brackets
Notch for Top Left log (B) Notch for Top
Right log (D)
The 2 notches on the bottom of log (A) rest on the locating brackets
Sub-Floor
Sub-Floor
Flange
Bottom Fork of log (D) rests on Sub-Floor Flange
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 17
Glass Door Panel Removal Instructions (see
Figure 29 ) - Locate the two (2) latches at
the top of the control compartment. Open the
two latches from the bottom vee-flange of the
glass enclosure panel (reach for the handles
located towards the back of the latches and
pull the handles down toward the front of the
appliance).
Step 11. INSTALLING GLASS DOOR
WARNING
Airshutteradjustmentshouldonly
beperformedbyaqualifiedprofes-
sional service technician.
WARNING
Ensure front glass panel are in
place and sealed during adjust-
ment.
Air Shutter Adjustment Guidelines:
Amount of
Primary Air
Flame
Color
Air Shutter
Adjustment
If air shutter is
closed too far Flame will be orange Air shutter gap should be
increased
If air shutter is
open too far Flame will be blue Air shutter gap should be
decreased
CAUTION
Carbonwillbeproducediftheair
shutter is closed too much. Any
damageduetocarboningresult-
ing from improperly setting the
air shutter is not covered under
the warranty.
Figure 29 - INSTALLING GLASS DOOR
Top Flange on
Glass Door
Bottom Vee-flange
Glass Door
Glass Door Latch
Glass Door
Firebox Floor
1. Visually inspect the gasket on the backside
of the glass door assembly. The gasket
surface must be clean, free of irregularities
and seated firmly.
2. Position the glass enclosure panel in front
of the firebox opening at a 45 degree angle
and engage the top flange over the lip at the
top of the firebox opening. See Figure 29.
3. Swing the glass enclosure panel down and
back. Ensure the gasket seats evenly as the
panel draws shut. Engage the Vee-flange at
the bottom of the panel with the 2 latches and
close the latches to secure the glass panel.
4. Reinstall the top louver panel and the bottom
control compartment access door. See
Reinstalling Control Compartment Door on
Page 12.
Step 12. BURNER ADJUSTMENTS
Flame Appearance and sooting
Proper flame appearance is a flame which is
blue at the base and becomes yellowish-orange
in the body of the flame. When the appliance
is first lit, the entire flame may be blue and will
gradually turn yellowish-orange during the first
15 minutes of operation. If after a short period
the flame stays lowered blue, or if the flame is
orange with evidence of sooting (black tip), the
air shutter opening may need to be adjusted.
Iftheair shutter openingsclosedtoo far, sooting
maydevelop.Sooting is indicatedbyblack puffs
developingatthe tipsof very longorangeflames.
Sooting results in black deposits forming on the
logs, appliance inside surfaces and on exterior
surfaces adjacent tothevent termination. Soot-
ing is caused by incomplete combustion in the
flames and lack of combustion air entering the
air shutter opening. To achieve a warm yellow-
ish-orange flame with an orange body that does
not soot, the shutter opening must be adjusted
between these two extremes.
Air Shutter Adjustment Guidelines
• If there is smoke or soot present, first check
the log set positioning to ensure that the
flames are not impinging on any of the logs.
If the log set is properly positioned and a
sooting condition still exists, then the air
shutter opening should be increased.
• Themoreoffsets in thevent system, thelarger
the air shutter opening will need to be.
WARNING
Handle this glass with extreme
care! Temperedglassissuscep-
tible to damage – do not scratch
or handle roughly while rein-
stalling the glass door frame.
WARNING
Donotoperateappliancewiththe
glass front removed, cracked or
broken. Replacementoftheglass
should be done by a licensed or
qualified service technician.
WARNING
Do not attempt to substitute the
materials used on this door, or
replace cracked or broken glass
with any materials other than
those provided by the appliance
manufacturer.
WARNING
The glass door of this appli-
ance must only be replaced as a
complete unit as provided by the
manufacturer. Do not attempt to
replacebroken,crackedorchipped
glass separately.
WARNING
Do not attempt to touch the front
enclosure glass with your hands
while the fireplace is in use.
• An appliance operated with the air shutter
opened too far, may have flames that appear
blue and transparent. These weak, blue and
transparent flames are termed anemic.
• Propane models may exhibit flames which
candle or appear stringy. If this is present
and persists, adjust the air shutter to a more
closed position, then operate the appliance
for a few more minutes to ensure that the
flame normalizes and the flames do not
appear sooty.
The following chart is provided to aid you in
achieving the correct air shutter adjustment for
your installation.
CAUTION
The air shutter door and nearby
appliance surfaces are hot. Exer-
cise caution to avoid injury while
adjusting flame appearance.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
18
Figure 31
Main Burner Factory Air Shutter
Opening Setting - Inches (millimeter)
Model Natural
Gas
Propane
Gas
SSBV-3530 1/16"
(1.58 mm) 1/4" (6.35 mm)
SSBV-4035 1/16"
(1.58 mm) 1/4" (6.35 mm)
Figure 30
Burner Air Shutter Adjustment Procedure
1. Locate air shutter (see Figure 30 ).
2. Lightappliance(follow lighting procedureon
lighting label in control compartment or see
homeowners manual).
3. Allowthe burnertooperate forat least15 min-
utes while observing the flame continuously
to ensure that the proper flame appearance
has been achieved (see Figure 31 or 32). If
the following conditions are present, adjust
accordingly.
• If flame appears weak or sooty, adjust
the air shutter, incrementally, to a more
open position until the proper flame
appearance is achieved.
• If flame stays lowered blue, adjust the
air shutter, incrementally, to a more
closed position until the proper flame
appearance is achieved.
4. Leave the control knob (off/pilot/on) in the
ON position and the burner OFF/ON switch
OFF (& remote switches, if applicable).
5. When satisfied that the burner flame appear-
ance is normal, re-install the lower control
compartment door then proceed to finish
the installation.
Air Shutter
Venturi
Set Screw - Factory Located in the Natural Gas
Position; Relocate Set Screw for LP/Propane Gas
in the Alternate Position. See Table for Air Shut-
ter Openings for these Set Screw Locations.
Burner Flame Appearance Models -
SSBV-3530 & SSBV-4035 Series
Step 13. VENT SPILLAGE TEST
After appliance installation, perform this spill-
age test to verify that proper venting conditions
exist:
1- Placeunitin its normally-operatedcondi-
tion, that is, with the glass enclosure panel
in place.
2 - Close all doors and windows in the room.
Turn on all exhaust fans in the house.
3- Light the appliance.
4- Wait 15 minutes.
5- To check for venting action, start by
holding a smoke producing device within
an inch of one edge (side edge, not top or
bottom edge) of one glass enclosure panel.
The smoke should be drawn toward the edge
of the glass enclosure panel. Continue the
test by moving the smoke producing device
along the entire length of both side-edges of
the glass door.
6- If the smoke is not drawn towards the
edgesoftheglassdoorturnofftheappliance
and call a qualified service technican.
Manually-Reset Spill switch (limit disc)
ALLOW APPLIANCE TO COOL COMPLETELY
BEFORE ACCESSING AND RESETTING
This appliance is equipped with a manually-
reset blocked flue spill switch (limit disc).
Refer to Figure 32 to 35 for its location. If,
during appliance operation, the flame goes
out (independently of the burner on/off wall
switch), it may be due to the operation of this
spill switch (limit disc). First allow the appli-
ance to cool.
Remove top louver panel. Then reset the spill
switch (limit disc) by pushing the red reset
button, located between the wire terminals, on
the back of the switch. See Figure 32.
The appliance should then relight and remain
lit. Reinstall top louver panel. If the appliance
does not relight, turn off the appliance and call
for a qualified service technician.
To replace the blocked flue spill switch (limit
disc) refer to Figures 32, 33 & 34:
NOTE-This procedure should only beperformed
by a qualified service technician.
Important - Turn electrical power off before
beginning this procedure.
1 - Remove the bottom control compartment
access panel (see Figure 20 on Page 12).
Remove the glass enclosure panel (see
Glass Door Panel Removal Instructions
on Page 17).
2- Remove the lintel securing screws (3) and
thenremovethelintel.Oneofthelintelcabinet
top holes is shown in Figure 33).
3- Remove the scoop securing screws (3) and
then remove the scoop. See Figure 33.
4- Removethesafety switch bracketsecuring
screws (2), and pull the switch/bracket
assembly, with low voltage wires attached,
through the side panel slot into the firebox.
See Figure 34.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 19
Step 14. HOOD INSTALLATION
(Refer to Figure 35)
All of these appliances must have a hood
installed prior to operating.
Slide the hood into the slots on the lower edge
of the cabinet top.
FINISHING REQUIREMENTS -
Wall Details
Complete finished interior wall. To install the
appliance facing flush with the finished wall,
position framework to accommodate the thick-
ness of the finished wall (Figure 35).
See Page 5 for Cold Climate Insulation
and Page 6 for Clearances
5- Replace the switch.
6- Reinstall the switch/bracket assembly.
7 - Reinstall the scoop and lintel.
8 - Reinstall the glass enclosure panel.
9 - Reinstall the bottom control compartment
access panel and the top louver panel.
10 - The appliance should then relight and
remain lit. If this does not occur, check
unit for a blocked flue condition.
Blocked Flue Safety Limit Location - See
Figures 32, 33 & 34. Inside View of Firebox
- Top/Right Side Intersection
Figure 32
Figure 34
Figure 33
Combustible
Wall
Framing
Combustible
Finished Wall
Materials
Top of Appliance
Louvers
Top of Door
Frame
Hood must
be installed
as shown.
1 in. Min.
(25 mm)
Top
Spacers
Figure 35
Finishing Requirements
Remote Control Kit, Standard
Cat. No. Model No. Description
H0249 RCL Remote Control System
White Wall Switch Kit
Cat. No. Model No. Description
85L87 FWSK OFF/ON Wall Switch Kit
Rocker Switch Kit
Cat. No. Model No. Description
80L41 FRS Rocker Switch Kit
Outside Combustion Air Kits
Cat. No. Model No. Description
81L87 FOAK-4 Combustion Air Kit (w/duct)
81L88 FOAK-4LD Combustion Air Kit (w/o duct)
INSTALLATION ACCESSORIES
The following accessory items are available
for use in the installation of these appliances.
See Homeowners Manual for a complete list of
accessories and more detailed information on
the following installation accessories:
Forced Air Blower Kits
Cat.
No.
Model No. Description
80L84 FBK-100 Blower, Standard
(single speed)
80L85 FBK-200 Blower, Variable Speed
(w/wall-mounted switch)
80L86 FBK-250 Blower, Variable Speed
(w/unit-mounted switch)
94L89 FBK-100-36 Blower, Standard, 36 Pack
94L90 FBK-200-36 Blower - Variable, 36 Pack
H0543 FBK-250-36 Blower - Variable, 36 Pack
Wire
Terminals
Cabinet
Corner
Back of Spill
Switch (high
limit disc)
Firebox
Top
Door
Frame
Lintel Securing Screw
Hole in Cabinet Top
Scoop Securing Screws
Scoop
Firebox
Top Lintel Securing Screw
Hole in Cabinet Top
Spill Switch (limit disc)
Combustible
material may
touch the appli-
ance top
View Without Scoop
Spill Switch (limit disc)
Bracket Securing Screws
GAS CONVERSION KITS
Millivolt SIT Systems
Propane to Natural Gas
Conversion Kits
Models Cat. No.
SSBV-3530 85L66
SSBV-4035 85L67
Millivolt HONEYWELL Systems
Natural Gas To Propane Gas
Conversion Kits
Models Cat. No.
SSBV-3530 11M37
SSBV-4035 11M38
Electronic HONEYWELL Systems
Natural Gas To Propane Gas
Conversion Kits
Models Cat. No.
SSBV-3530 85L73
SSBV-4035 85L74
Millivolt SIT Systems
Natural Gas To Propane Gas
Conversion Kits
Models Cat. No.
SSBV-3530 85L59
SSBV-4035 85L60
Millivolt HONEYWELL Systems
Propane Gas To Natural Gas
Conversion Kits
Models Cat. No.
SSBV-3530 11M34
SSBV-4035 11M35
Electronic HONEYWELL Systems
Propane Gas To Natural Gas
Conversion Kits
Models Cat. No.
SSBV-3530 85L80
SSBV-4035 85L81
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
20
SIT Millivolt Gas Valve
Pressure
Regulator
Remove
These
Components
Figure 36
Gas conversion kits are available to adapt the
appliance from the use of one type of gas to
the use of another. These kits contain all the
necessary components needed to complete the
task including labeling that must be affixed to
ensure safe operation.
Kit part numbersare listed hereand the following
steps detail the conversion procedure.
Step1.Turn off the gas supply to the appliance.
Remove the front glass door/frame from the
appliance. Access the control compartment.
Step2.Carefully remove the logs. Exercise care
so as not to break the logs.
Step3.Locate the screws securing the burner
assembly to the appliance. Remove the burner
assembly and retain the securing screws.
Step 4. Millivolt Appliances - SIT Systems
a. See Figure 36 and the instructions
provided with the kit. Using a Torx T20,
tool or or standard flat screwdriver remove
and discard the three pressure regulator
mounting screws. Remove the pressure
regulator, spring, poppet, diaphragm and
bushing. Discard all removed components.
Ensure the rubber gasket installed on the
back of the replacement pressure regulator
is properly positioned and install the new
pressure regulator using the new screws
supplied with the kit. Tighten screws to 25
In. lb. torque.
WARNING
This conversion kit shall be
installed by a qualified service
agency in accordance with the
manufacturer's instructions and
allapplicablecodesandrequire-
ments of the authorized having
jurisdiction. If the information
in these instructions is not fol-
lowed exactly, a fire, explosion
or production of carbon monox-
ide may result causing property
damage, personal injury or loss
of life. The installation is not
proper and complete until the
operationoftheconvertedappli-
ance is checked as specified in
the owner instructions supplied
withthekit.Thequalifiedservice
agency performing this installa-
tion assumes responsibility for
this conversion.
IMPORTANT
CANADA ONLY
The conversion shall be carried
outinaccordancewiththerequire-
mentsof the provincialauthorities
having jurisdiction and in accor-
dance with the requirements of
the CAN1-B149.1 And B149.2
Installation code.
IMPORTANT
LE CANADA SEULEMENT
La conversion devra être effec-
tuée conformément aux recom-
mandations des autorités pro-
vinciales ayant juridiction et
conformémentauxexigencesdu
coded'installationCAN1-B149.1
ET.2.
AVERTISSEMENT
Cet équipement de conversion
sera installé par une agence
qualifiée de service conformé-
ment aux instructions du fabri-
cantettoutesexigencesetcodes
applicables de l'autorisés avoir
la juridiction. Si l'information
dans cette instruction n'est pas
suivieexactement,unfeu,explo-
sion ou production de protoxyde
de carbone peut résulter le
dommages causer de propriété,
perte ou blessure personnelle
de vie. L'agence qualifiée
de service est esponsable de
l'installation propre de cet
équipment. L'installation n'est
pas propre et compléte jusqu'à
l'opérationdel'appareilconverti
est chéque suivant les critères
établis dans les instructions de
propriétaire provisionnées avec
l'équipement.
fire-parts.com
