DRL4543 SERIES
P/N 900633-01, REV. D, 04/2020
Fireplace Dimensions
DIRECT-VENT FIREPLACES
Framing Dimensions
Diagrams, illustrations and photographs are not to
scale. Consult installation instructions. Product designs,
materials, dimensions, specifications, colors, and prices
are subject to change or discontinuance without notice.
2
1
/
8
"
(54 mm)
5
/
8
"
(16 mm)
11
3
/
4
"
(298 mm)
16
1
/
2
"
(419 mm)
8
1
/
4
"
(210 mm)
29
5
/
8
"
(753 mm) 29
5
/
8
"
(753 mm)
3
1
/
2
" (89 mm)
16
3
/
8
"
(416 mm)
7
1
/
8
"
(181 mm)
1
7
/
8
"
(48 mm)
8
1
/
4
"
(210 mm)
4
1
/
8
" (105 mm)
44
1
/
8
"
(1121 mm)
55
1
/
8
"
(1400 mm)
47"
(1194 mm)
1"
(25 mm)
1"
(25 mm)
52"
(1321 mm)
17
1
/
2
"
(445 mm)
8
1
/
8
"
(206 mm)
8
1
/
4
"
(210 mm)
43
7
/
8
"
(1114 mm)
Framing Dimensions for One Sided Application Framing Dimensions for See-Thru Application
53 1/4"
(1353 mm)
53 1/4"
(1353 mm)
38"
(965 mm)
38"
(965 mm)
STUDS MOUNTED (FLAT)
INSIDE OF NAILING FLANGE
15 1/4"
(387 mm)
MOUNTED INSIDE OF
NAILING FLANGE
(FLAT)
FOR ONE SIDED
APPLICATION, STUDS
ARE NOT MOUNTED
TO THE REAR
OF NAILING FLANGES
17 1/2"
(445 mm)

Printed in U.S.A. © 2016 Innovative Hearth Products
P/N 900633-01 REV. D 04/2020 Page 2 of 2
Specifications and clearances are subject to change without notice.
Refer to Installation Manual before installation of these appliances for
updated dimensions and instructions.
Clearances
DRL4543 SERIES
Side Wall Clearance
Ref. Mantel
Depth
Ref. Mantel from
Top of Opening
1. 12 (305) A 24 (610)
2. 9 (229) B 21 (554)
3. 6 (152) C 18 (458)
4. 4 (102) D 16 (407)
5. 2 (51) E 14 (356)
A
BC
DE
1
2
3
4
5
Wall
Vertical Termination Installation
Cat. No. Model Weight Cu. Ft.
F1262 DRL4543TEN 296 lb. 24.5
F1263 DRL4543TEP 296 lb. 24.5
Uses 4.5” / 7.5” Secure Vent®
Rigid and Secure Flex®Direct-
Vent Components
40 ft.
(12.192 m)
maximum
Ceiling
firestop/spacer
SV4.5VF
Ceiling firestop/
spacer SV4.5VF
40 ft.
(12.2 m)
maximum
TOP VIEW
SAFE
ZONE
Perpendicular
Wall
Combustible
Material May
Be Used
33°
8"
(204 mm)
to Face Opening
5"
(127 mm)
Listed by PFS Corporation to - ANSI
Z21.50/CSA 2.22 standard as vented
gas fireplace and applicable sections of
Z21.97 standard for outdoor decorative
gas appliance (When installed as a see-
thru unit using outdoor kit model LDSTO).
PFS
®
USC
Report No. F11-026
Product Info
Listing
Minimum clearances to combustibles for the
fireplace are as follows:
*Back and Sides 1” 26 mm
Perpendicular Walls 8” 203 mm
Floor (from bottom of fireplace) 0” 0 mm
Ceiling (from bottom of fireplace) 63” 1601 mm
Top of Standoffs 0” 0 mm
*For back and sides of fireplace, do not pack with insulation or other materials.
Hearth Extension
A hearth extension is not required with this fireplace. Any hearth extension used is for
appearance only and does not have to conform to standard hearth extension installa-
tion requirements.
Mantel
Clearance
Venting
Horizontal Termination Installation
Termination
T
ermination
10 1/2”
(267mm)
7”
(178)
5 1/8”
(130 mm)
12 1/8”
(308 mm)
Note: Centerline of Vent Piping is
NOT the Same as the Centerline of
the Framed Opening.
6 to 48” Vent Section,
Telescopic vent section,
Elbow or Appliance Collar
53” (1346 mm) Min.
Plus 1/4”(6 mm)
Rise per Foot
Base of Appliance
3”
(76 mm
)
1”
(26 mm)
Adaptor
SV4.5RCH
To help minimize water
infiltration it is recommended that
the Firestop/Spacer (SV4.5HF)
be installed on the exterior
side of the wall.
*Firestop/Spacer (SV4.5HF) shown
on the exterior side of the wall. It
may also be installed on the
interior side.
SV4.5 HTSS
Termination
Shown.
10-1/2"
(267 mm)
7"
(178)
5-1/8"
(130 mm) 12-1/8"
(308 mm)
NOTE: Centerline of Vent
Piping is NOT the Same as
the Centerline of the
Framed Opening.
6” to 48” Vent Section,
Telescopic vent section,
Elbow or Appliance Collar
Base of Appliance
3"
(77 mm)
1"
(26 mm)
Adaptor
SV4.5RCH or
SV4.5RCHA
*NOTE: When using Secure Flex
use Firestop/Spacer SF4.5HF
See Fireplace
Installation Instructions
For Min. Distance to
Base of Appliance.
