Supermicro SUPERSERVER 5028TK-HTTR User manual

User's Manual
Revision 1.0a
SUPERSERVER®
5028TK-HTR
5028TK-HTTR

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Manual Revision 1.0aRelease
Date: August 4,2016
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2016 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the SuperServer
5028TK-HTR/HTTR. Installation and maintenance should be performed by
experienced technicians only.
The SuperServer 5028TK-HTR/HTTR is a high-end server based on the
SC827HQ+-R2K04BP2 2U rackmount chassis and the single processor
K1SPi/K1SPi-T serverboard. All models have four serverboard nodes with three
hot-swap Hard Disk Drives (HDD) for each per node.
Manual Organization
Chapter 1: Introduction
The rst chapter provides a checklist of the main components included with the
server system and describes the main features of the K1SPi/K1SPi-T serverboard
and the SC827HQ+-R2K04BP2 chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer
5028TK-HTR/HTTR into a rack and check out the server conguration prior to
powering up the system. If your server was ordered without processor and memory
components, this chapter will refer you to the appropriate sections of the manual
for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: Standardized Safety Warnings
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 5028TK-HTR/HTTR.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the K1SPi/K1SPi-T serverboard,
including the locations and functions of connections, headers and jumpers. Refer
to this chapter when adding or removing processors or main memory and when
reconguring the serverboard.

SUPERSERVER 5028TK-HTR/HTTR User's Manual
iv
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC827HQ+-R2K04BP2 server
chassis. You should follow the procedures given in this chapter when installing,
removing or reconguring hard drives and when replacing system power supply
units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed information
on running the CMOS Setup Utility.
Appendix A: System Specications
Appendix B: UEFI BIOS Recovery

v
SUPERSERVER 5028TK-HTR/HTTR User's Manual
Notes

vi
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
Processors ...................................................................................................... 1-2
Memory ........................................................................................................... 1-2
SATA................................................................................................................ 1-2
PCI Expansion Slots ....................................................................................... 1-2
I/O Ports.......................................................................................................... 1-3
Graphics Controller ......................................................................................... 1-3
1-3 Server Chassis Features ................................................................................ 1-3
System Power................................................................................................. 1-3
Front Control Panel......................................................................................... 1-3
Cooling System............................................................................................... 1-3
Air Shrouds ..................................................................................................... 1-4
Mounting Rails ................................................................................................ 1-4
1-4 Contacting Supermicro.................................................................................... 1-6
1-5 2U Twin2: System Notes ................................................................................. 1-7
Nodes.............................................................................................................. 1-7
System Power................................................................................................. 1-7
Hard Drive Backplane/Drives.......................................................................... 1-7
Chapter 2 Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System .................................................................................... 2-1
2-3 Preparing for Setup......................................................................................... 2-1
2-4 Warnings and Precautions.............................................................................. 2-2
Choosing a Setup Location............................................................................. 2-2
Rack Precautions............................................................................................ 2-2
Server Precautions.......................................................................................... 2-2
Rack Mounting Considerations ....................................................................... 2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-3
2-5 Installing the System into a Rack ................................................................... 2-4
Separating the Sections of the Rack Rails..................................................... 2-4
Installing the Inner Rail Extension .................................................................. 2-5
SUPERSERVER 5028TK-HTR/HTTR User's Manual

vii
Outer Rack Rails............................................................................................. 2-6
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Button....................................................................................... 3-2
Power .............................................................................................................. 3-2
3-3 Control Panel LEDs ........................................................................................ 3-2
Overheat.......................................................................................................... 3-2
NIC1 ................................................................................................................ 3-2
3-4 Drive Carrier LEDs.......................................................................................... 3-3
SATA Drives .................................................................................................... 3-3
SAS Drives...................................................................................................... 3-3
Chapter 4 Standardized Warning Statements for AC Systems
4-1 About Standardized Warning Statements....................................................... 4-1
Warning Denition ........................................................................................... 4-1
Installation Instructions.................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning ........................................................................ 4-6
Equipment Installation..................................................................................... 4-8
Restricted Area................................................................................................ 4-9
Battery Handling............................................................................................ 4-10
Redundant Power Supplies .......................................................................... 4-12
Backplane Voltage ........................................................................................ 4-13
Comply with Local and National Electrical Codes........................................ 4-14
Product Disposal........................................................................................... 4-15
Hot Swap Fan Warning................................................................................. 4-16
Power Cable and AC Adapter ...................................................................... 4-18
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard ............................................................................... 5-1
Precautions ..................................................................................................... 5-1
Unpacking ....................................................................................................... 5-1
5-2 Connecting Cables.......................................................................................... 5-2
Connecting Data Cables ................................................................................. 5-2
5-3 Rear I/O Ports................................................................................................. 5-2
5-4 Processor and Heatsink.................................................................................. 5-3
5-5 Installing Memory............................................................................................ 5-4
Memory Support.............................................................................................. 5-4
5-6 Adding PCI Expansion Cards ......................................................................... 5-5
5-7 Serverboard Details ........................................................................................ 5-6
K1SPi/K1SPi-T Quick Reference .................................................................... 5-7
Table of Contents

viii
5-8 Connector Denitions...................................................................................... 5-8
5-9 Jumper Settings ............................................................................................ 5-10
Explanation of Jumpers ................................................................................ 5-10
5-10 Onboard Indicators........................................................................................ 5-12
5-11 PCI-Express Slots and SATA Ports .............................................................. 5-13
5-12 Onboard Battery............................................................................................ 5-14
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices.................................................................................. 6-1
Precautions ..................................................................................................... 6-1
Unpacking ....................................................................................................... 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 Chassis Cover................................................................................................. 6-3
6-4 Air Shrouds ..................................................................................................... 6-4
6-5 Checking the Airow ....................................................................................... 6-5
6-6 System Fans ................................................................................................... 6-5
Optional Fan Congurations ........................................................................... 6-5
6-7 Removing and Installing the Backplane.......................................................... 6-8
Removing the Backplane ................................................................................ 6-8
Installing the Backplane................................................................................ 6-10
6-8 Installing the Serverboard ..............................................................................6-11
I/O Shield .......................................................................................................6-11
Permanent and Optional Standoffs................................................................6-11
6-9 Adapter Card Replacement........................................................................... 6-13
Installing an Add-on Card ............................................................................. 6-14
6-10 Drive Bay Installation/Removal ..................................................................... 6-15
Accessing the Drive Bays ............................................................................. 6-15
6-11 Power Supply................................................................................................ 6-19
Power Supply Replacement.......................................................................... 6-19
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
Starting BIOS Setup Utility.............................................................................. 7-1
How To Change the Conguration Data ......................................................... 7-2
How to Start the Setup Utility ......................................................................... 7-2
7-2 Main Setup...................................................................................................... 7-3
7-3 Advanced Setup Congurations...................................................................... 7-4
7-4 Event Logs .................................................................................................... 7-36
7-5 IPMI............................................................................................................... 7-38
7-6 Security Settings ........................................................................................... 7-40
SUPERSERVER 5028TK-HTR/HTTR User's Manual

7-7 Boot Settings................................................................................................. 7-43
7-8 Save & Exit ................................................................................................... 7-45
Appendix A System Specications
Appendix B UEFI BIOS Recovery Instructions
ix
Table of Contents

x
Notes
SUPERSERVER 5028TK-HTR/HTTR User's Manual

Chapter 1
Introduction
1-1 Overview
The SuperServer 5028TK-HTR/HTTR is a high-end server comprised of two main
subsystems: the SC827HQ+-R2K04BP2 2U server chassis and the K1SPi/K1SPi-T
serverboard, which resides in four hot-swap nodes. Please refer to our website for
information on operating systems that have been certied for use with the system
(www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the SuperServer 5028TK-HTR/HTTR server, as listed below:
• Four 1U passive CPU heatsinks (SNK-P0060P)
• Four mylar air shrouds (MCP-310-21704-0B)
• Four 8-cm cooling fans (FAN-0162L4)
• SATA/SAS Backplane
Four HD backplanes (BPN-ADP-6SATA3)
One SAS backplane HDD (BPN-SAS3-827HQ)
Twelve hot-swap 3.5" HDD trays (MCP-220-00075-0B)
• Eight riser cards (4x RSC-R1UTP-E16R and 4x RSC-P-6)
• One rackmount rail kit (MCP-290-00053-0N)
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_
information.cfm
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 5028TK-HTR/HTTR User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 5028TK-HTR/HTTR lies
the K1SPi/K1SPi-T, a single processor serverboard based on the
Intel® PCH C612 chipset and designed to provide maximum performance.
Four of these serverboards can be mounted in the SC827HQ+-R2K04BP2
chassis.
The sections below cover the main features of the K1SPi/K1SPi-T serverboard (see
Figure 1-1 for a block diagram of the chipset).
Processors
The K1SPi/K1SPi-T supports a single Intel® Xeon Phi™ x200 processor. Refer to
the serverboard description pages on our website for a complete listing of supported
processors (www.supermicro.com).
Memory
The K1SPi/K1SPi-T has six DIMM slots supporting up to 384 GB of RDIMM
(Registered DIMM) DDR4-2400 ECC memory. See Chapter 5 for details.
Note: Check the Supermicro website (www.supermicro.com) for the latest memory
support information.
SATA
The 5028TK-HTR uses a controller integrated into the PCH C612 chipset to support
eight SAS3 hard drives per node. (RAID 0, 1 and 10 supported). The SATA drives
are hot-swappable units.
PCI Expansion Slots
The 5028TK-HTR/HTTR can support two PCI-E 3.0 expansion cards in each node
(eight total for the system). Expansion cards are mounted on riser cards. The RSC-
R1UTP-E16R riser supports a single PCI-E 3.0 x16 card on the right side of the
system (when viewed from the rear) and the RSC-P-6 riser supports one PCI-E 3.0
x16 card on the left side of the chassis.

1-3
Chapter 1: Introduction
I/O Ports
Each of the four K1SPi/K1SPi-T serverboards in the system include two USB 3.0
ports, an IPMI LAN port and a VGA port.
Note: For IPMI conguration instructions, please refer to the Embedded BMC
Configuration User's Guide available at http://www.supermicro.com/support/
manuals/.
Graphics Controller
The K1SPi/K1SPi-T features an integrated ASpeed 2400 BMC with an integrated
VGA/2D graphics controller.
1-3 Server Chassis Features
The following is a general outline of the main features of the SC827HQ+ server
chassis.
System Power
The SC827HQ+ chassis includes a redundant, high-efciency 80-plus Platinum
certied power supply rated at 2000 Watts (one active and one backup power supply
module). In the event your power supply fails, replacement is simple and can be
accomplished without tools.
Front Control Panel
The SC827HQ+-R2K04BP2 chassis includes four front panels on the handles of the
chassis which control each of the nodes. Each control panel on the SuperServer
5028TK-HTR/HTTR provides you with system monitoring and control for one server
node. LEDs indicate system power, HDD activity, network activity, system overheat
and power supply failure. A main power button and a system reset button are also
included.
Cooling System
The SC827HQ+ chassis includes four 8-cm system fans, which are powered from
the backplane.

1-4
SUPERSERVER 5028TK-HTR/HTTR User's Manual
Air Shrouds
Each node in the SC827HQ+ chassis includes one mylar air shroud per node that
directs the airow where cooling is needed on each serverboard. Always use the
air shroud included with each serverboard.
Mounting Rails
The SC827HQ+ includes a set of quick-release rails, and can be placed in a rack
for secure storage and use. To setup your rack, follow the step-by-step instructions
included in Chapter 2.

Chapter 1: Introduction
1-5
Figure 1-1. Intel PCH C612 Chipset:
System Block Diagram
Note: This is a general block diagram and may not exactly represent
the features on your serverboard. See the previous pages for the actual
specications of your serverboard. This block diagram is intended for
your reference only.
MUX
SPI
PCIe X16 G3
PCI-E X4
USB 3.0
Internal
Type A
USB
RJ45
NC_SI
RJ45
LPC
LAN2 MDI
LAN1 MDI
SPI
MDI
SXB3
DDR4
123
PCIe X16 G3
Intel Processor
PCI-E X16
DMI2
4GB/s
DMI2
PCI-E X4 G2
LAN
i350/X540
#1
Port 80
#2
USB 2.0
PCI-E X1 G2
PCH
USB 3.0
TPM
HEADER
USB
SPI
BIOS
#3
SXB2
6.0 Gb/S SATA
port<0:5>
SPI
LAN3
PHY
6.0 Gb/S
S-SATA
port<2:3>
RGRMII
SATA
DOM
RJ45
H/W Monitoring
* Temp. Sensor
*FAN PWM
BMC
AST2400
COM1
Header
VGA
CONN
BMC Boot
Flash
DDR3
LPC
SATA
5
4
DDR4
6
K1SPi(-T) System Diagram
(C612)
PCIe X4 G3
SXB1
PCI-E X16
Rear I/O
P5V_STBY
P12V_Vin
Hot Swap
Controller
P12V
VR
P5V
VR
P3V3
VR
P3V3_STBY
JF1
Connector
en_P12V
*Voltage Sensor

1-6
SUPERSERVER 5028TK-HTR/HTTR User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.supermicro.com.tw

1-7
Chapter 1: Introduction
1-5 2U Twin2: System Notes
As a 2U Twin2 conguration, the SuperServer 5028TK-HTR/HTTR is a unique server
system. With four system boards incorporated into a single chassis acting as four
separate nodes, there are several points you should keep in mind.
Nodes
Each of the four serverboards act as a separate node in the system. As independent
nodes, each may be powered off and on without affecting the others. In addition,
each node is a hot-swappable unit that may be removed from the rear of the chassis.
The nodes are connected to the server backplane by means of an adapter card.
Note: A guide pin is located between the upper and lower nodes on the inner chassis
wall. This guide pin also acts as a “stop” when a node is fully installed. If too much
force is used when inserting a node this pin may break off. Take care to slowly slide
a node in until you hear the “click” of the locking tab seating itself.
System Power
Dual 2000 Watt power supplies are used to provide the power for all four
serverboards. Each serverboard however, can be shut down independently of the
other with the power button on its own control panel.
Hard Drive Backplane/Drives
As a system, the SuperServer 5028TK-HTR/HTTR supports the use of 12 hard
drives. A single backplane works to apply system-based control for power and fan
speed functions, yet at the same time logically connects a set of three hard drives to
each of the four nodes. Consequently, RAID setup is limited to a three-drive scheme
(RAID cannot be spread across all 12 drives). See the Drive Bay Installation/
Removal section in Chapter 6 for the logical hard drive and node conguration.

1-8
SUPERSERVER 5028TK-HTR/HTTR User's Manual
Notes

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperServer
5028TK-HTR/HTTR up and running. Following these steps in the order given should
enable you to have the system operational within a minimum amount of time.
This quick setup assumes that your system has come to you with the processors
and memory preinstalled. If your system is not already fully integrated with a
serverboard, processors, system memory etc., please turn to the chapter or section
noted in each step for details on installing specic components.
2-2 Unpacking the System
You should inspect the box the SuperServer 5028TK-HTR/HTTR was shipped in and
note if it was damaged in any way. If the server itself shows damage you should
le a damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the SuperServer
5028TK-HTR/HTTR. It should be situated in a clean, dust-free area that is well
ventilated. Avoid areas where heat, electrical noise and electromagnetic elds are
generated. You will also need it placed near a grounded power outlet. Read the
Rack and Server Precautions in the next section.
2-3 Preparing for Setup
The box the SuperServer 5028TK-HTR/HTTR was shipped in should include two
sets of rail assemblies, two rail mounting brackets and the mounting screws you
will need to install the system into the rack. Follow the steps in the order given to
complete the installation process in a minimum amount of time. Please read this
section in its entirety before you begin the installation procedure outlined in the
sections that follow.

2-2
SUPERSERVER 5028TK-HTR/HTTR User's Manual
2-4 Warnings and Precautions
Choosing a Setup Location
• Leave enough clearance in front of the rack to enable you to open the front door
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for sufcient airow and ease in servicing.
• This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
• This product is not suitable for use with visual display work place devices
acccording to §2 of the German Ordinance for Work with Visual Display Units.
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are fully extended to
the oor with the full weight of the rack resting on them.
• In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
• Always make sure the rack is stable before extending a component from the
rack.
• You should extend only one component at a time - extending two or more
simultaneously may cause the rack to become unstable.
Server Precautions
• Review the electrical and general safety precautions in Chapter 4.
• Determine the placement of each component in the rack before you install the
rails.
• Install the heaviest server components on the bottom of the rack rst, and then
work up.
• Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
• Allow any hot plug drives and power supply modules to cool before touching
them.
• Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.
