Supermicro SUPERSERVER 6015C-NT User manual

SUPERSERVER 6015C-UR
S
UPERSERVER 6015C-U
SUPERSERVER 6015C-NTR
SUPERSERVER 6015C-NT
SUPER ®
USER’S MANUAL
1.0

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2008 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America
Manual Revision 1.0
Release Date: May 12, 2008
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
SUPER MICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documenta-
tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It pro-
vides information for the installation and use of the SuperServer 6015C-UR/6015C-
U/6015C-NTR/6015C-NT. Installation and maintenance should be performed by
experienced technicians only.
The SuperServer 6015C-UR/6015C-U/6015C-NTR/6015C-NT is a high-end
server based on the SC815TQ-R650U/SC815TQ-560U 1U rackmount chassis
and the Super X7DCU, a dual processor serverboard that supports Intel®Xeon®
5400/5300/5200/5100 series processors at a Front Side (System) Bus speed of
1333/1066 MHz and up to 48 GB of ECC registered DDR2-667 or DDR2-533
SDRAM.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the X7DCU serverboard and
the SC815TQ-R650U/SC815TQ-560U chassis, which comprise the SuperServer
6015C-UR/6015C-U/6015C-NTR/6015C-NT.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 6015C-UR/
6015C-U/6015C-NTR/6015C-NT into a rack and check out the server configuration
prior to powering up the system. If your server was ordered without processor and
memory components, this chapter will refer you to the appropriate sections of the
manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 6015C-UR/6015C-U/6015C-NTR/6015C-NT.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X7DCU serverboard, including the
locations and functions of connections, headers and jumpers. Refer to this chapter
when adding or removing processors or main memory and when reconfiguring the
serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC815TQ-R650U/SC815TQ-
560U server chassis. You should follow the procedures given in this chapter when
installing, removing or reconfiguring SATA or peripheral drives and when replacing
system power supply modules and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS POST Messages
Appendix B: BIOS POST Codes
Appendix C: System Specifications

v
Preface
Notes

vi
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
Processors ...................................................................................................... 1-2
Memory ........................................................................................................... 1-2
UIO.................................................................................................................. 1-2
Serial ATA ....................................................................................................... 1-2
Onboard Controllers/Ports .............................................................................. 1-2
Other Features ................................................................................................ 1-3
1-3 Server Chassis Features ................................................................................ 1-3
System Power ................................................................................................. 1-3
SATA Subsystem............................................................................................. 1-3
PCI Expansion Slots ....................................................................................... 1-3
Front Control Panel......................................................................................... 1-4
I/O Backplane.................................................................................................. 1-4
Cooling System ............................................................................................... 1-4
1-4 Contacting Supermicro.................................................................................... 1-6
Chapter 2 Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System .................................................................................... 2-1
2-3 Preparing for Setup......................................................................................... 2-1
Choosing a Setup Location............................................................................. 2-2
Rack Precautions ............................................................................................ 2-2
Server Precautions.......................................................................................... 2-2
Rack Mounting Considerations ....................................................................... 2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airflow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-3
2-4 Installing the System into a Rack ................................................................... 2-4
Identifying the Sections of the Rack Rails...................................................... 2-4
Installing the Inner Rails ................................................................................. 2-4
Installing the Outer Rails................................................................................. 2-5
Installing the Server into the Rack.................................................................. 2-6
Installing the Server into a Telco Rack ........................................................... 2-7

vii
Table of Contents
2-5 Checking the Serverboard Setup.................................................................... 2-8
2-6 Checking the Drive Bay Setup........................................................................ 2-9
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-1
UID .................................................................................................................. 3-1
Reset............................................................................................................... 3-1
Power .............................................................................................................. 3-2
3-3 Control Panel LEDs ........................................................................................ 3-2
Universal Information LED .............................................................................. 3-2
NIC2 ................................................................................................................ 3-3
NIC1 ................................................................................................................ 3-3
HDD................................................................................................................. 3-3
Power .............................................................................................................. 3-3
3-4 Hard Drive Carrier LEDs................................................................................. 3-4
Chapter 4 System Safety
4-1 Electrical Safety Precautions .......................................................................... 4-1
4-2 General Safety Precautions ............................................................................ 4-2
4-3 ESD Precautions............................................................................................. 4-3
4-4 Operating Precautions .................................................................................... 4-4
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard ............................................................................... 5-1
Precautions ..................................................................................................... 5-1
Unpacking ....................................................................................................... 5-1
5-2 Processor and Heatsink Installation ............................................................... 5-2
5-3 Connecting Cables.......................................................................................... 5-5
Connecting Data Cables ................................................................................. 5-5
Connecting Power Cables .............................................................................. 5-5
Connecting the Control Panel......................................................................... 5-5
5-4 I/O Ports .......................................................................................................... 5-6
5-5 Installing Memory ............................................................................................ 5-7
5-6 Adding PCI Cards ........................................................................................... 5-9
5-7 Serverboard Details ...................................................................................... 5-10
X7DCU Quick Reference ...............................................................................5-11
5-8 Connector Definitions.................................................................................... 5-12
5-9 Jumper Settings ............................................................................................ 5-19
5-10 Onboard Indicators........................................................................................ 5-21
5-11 Floppy, IDE and SATA Drive Connections .................................................... 5-22

viii
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
5-12 Installing Software......................................................................................... 5-24
Supero Doctor III........................................................................................... 5-25
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices.................................................................................. 6-1
Precautions ..................................................................................................... 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 System Fans ................................................................................................... 6-3
System Fan Failure......................................................................................... 6-3
6-4 Drive Bay Installation/Removal ....................................................................... 6-4
Removing the Front Bezel .............................................................................. 6-4
Accessing the Drive Bays ............................................................................... 6-5
SATA Drive Installation.................................................................................... 6-6
DVD-ROM and Floppy Drive Installation ........................................................ 6-8
6-5 Power Supply .................................................................................................. 6-9
6015C-UR/6015C-NTR ................................................................................... 6-9
Power Supply Failure ................................................................................. 6-9
6015C-U/6015C-NT ...................................................................................... 6-10
Power Supply Failure ............................................................................... 6-10
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
7-2 Running Setup ................................................................................................ 7-2
7-3 Main BIOS Setup ............................................................................................ 7-2
7-4 Advanced Setup.............................................................................................. 7-6
7-5 Security ......................................................................................................... 7-20
7-6 Boot............................................................................................................... 7-22
7-7 Exit ................................................................................................................ 7-23
Appendix A BIOS POST Messages
Appendix B BIOS POST Codes
Appendix C System Specifications

Chapter 1
Introduction
1-1 Overview
The SuperServer 6015C-UR/6015C-U/6015C-NTR/6015C-NT is a high-end server
comprised of two main subsystems: the SC815TQ-R650U (6015C-UR/6015C-
NTR)/SC815TQ-560U (6015C-U/6015C-NT) 1U server chassis and the X7DCU dual
processor serverboard. Please refer to our web site for information on operating
systems that have been certified for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have been
included with the 6015C-UR/6015C-U/6015C-NTR/6015C-NT, as listed below:
 One (1) slim DVD-ROM drive [DVM-PNSC-824(B/V)]
 Four (4) sets of 4-cm counter-rotating fans (FAN-0086L)
 One (1) DVD cable (CBL-0139L)
 Two (2) passive CPU heatsinks (SNK-P0017)
 Riser Cards: (see Section 5-6 for details)
One (1) RSC-R1UU-E8R for PCI-X card
One (1) RSC-R1UU-UE8 for PCI-E card (6015C-UR/6015C-U only)
One (1) RSC-R1UU-2E8 for two PCI-E cards (6015C-NTR/6015C-NT only)
 SATA Accessories
One (1) SATA backplane (BPN-SAS-815TQ)
One (1) SATA iPASS cable (CBL-0188L) (6015C-UR/6015C-U only)
Four (4) SAS drive carriers (MCP-220-00001-01)
One (1) SATA cable (CBL-0190L) (6015C-NTR/6015C-NT only)
One (1) SGPIO cable (CBL-0157) (6015C-NTR/6015C-NT only)
 One (1) rackmount kit (CSE-PT51L)
 One (1) CD containing drivers and utilities
 SuperServer 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
Note: a "V" at the end of a server name indicates the chassis is silver and "B"
indicates black..
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 6015C-UR/6015C-U/6015C-NTR/6015C-NT lies the
X7DCU, a dual processor serverboard based on the Intel 5100 chipset and designed
to provide maximum performance. Below are the main features of the X7DCU. (See
Figure 1-1 for a block diagram of the chipset).
Processors
The X7DCU supports single or dual 771-pin Intel Xeon 5400/5300/5200/5100 series
processors at a FSB speed of 1333/1066 MHz. Please refer to the serverboard
description pages on our web site for a complete listing of supported processors.
Memory
The X7DCU has six 240-pin DIMM sockets that can support up to 32 GB of ECC
registered DDR2-667 or DDR2-533 SDRAM. The memory is an interleaved configu-
ration, which requires modules of the same size and speed to be installed in pairs.
Please refer to Chapter 5 for memory speed jumper settings.
UIO
The X7DCU is a specially-designed serverboard that features Supermicro's UIO
(Universal I/O) technology. UIO serverboards have a PCI-Express x8 connector
that can support any one of several types of UIO card types to add SAS ports,
additional LAN ports, etc. to the serverboard. This allows the user to tailor the
serverboard to their own needs. Note: the 6025C-UR does not come with a UIO
card installed.
Serial ATA
An on-chip (ICH9R) SATA controller is integrated into the X7DCU to provide a
six-port, 3 Gb/sec Serial ATA subsystem, which is RAID 0, 1, 10 and 5 supported.
The Serial ATA drives are hot-swappable units. Note: You must have RAID set
up to enable the hot-swap capability of the Serial ATA drives. Documentation on
RAID setup guidelines can be found on our web site.
Onboard Controllers/Ports
One floppy drive controller and one onboard ATA/100 controller are provided to
support up to two IDE hard drives or ATAPI devices. The color-coded I/O ports
include one COM port, a VGA (monitor) port, two USB 2.0 ports, PS/2 mouse and
keyboard ports and two gigabit Ethernet ports.

1-3
Chapter 1: Introduction
ATI Graphics Controller
The X7DCU features an integrated ATI video controller based on the ES1000 graph-
ics chip. The ES1000 was designed specifically for servers, featuring low power
consumption, high reliability and superior longevity.
Other Features
Other onboard features that promote system health include onboard voltage moni-
tors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.
1-3 Server Chassis Features
The 6015C-UR/6015C-NTR is built upon the SC815TQ-R650U chassis while the
6015C-U/6015C-NT is built upon the SC815TQ-560U chassis. The following is a
general outline of the main features of both chassis.
System Power
The SC815TQ-R650U features a redundant 650W power supply consisting of two
power modules. The system does not need to be shut down when replacing or
removing a single power supply module.
The SC815TQ-560U features a single 560W power supply module. The system
must be shut down when replacing or removing this power supply module.
SATA Subsystem
The SC815TQ-R650U/SC815TQ-560U chassis was designed to support four
hot-swap SATA hard drives. Note: In the 6015C-NTR/6015C-NT, SATA drives are
connected to the onboard SATA ports.
PCI Expansion Slots
6015C-UR/6015C-U: A riser card on the right side of the chassis can support one
PCI-E x8 card. The left side supports a UIO card and one PCI-E x8 card. These two
systems can support four SAS/SATA drives with an optional UIO SAS card. See our
web site for details (http://www.supermicro.com/products/nfo/UIO.cfm).
6015C-NTR/6015C-NT: A riser card on the right side of the chassis can support
one PCI-E x8 card. The left side supports two PCI-E x8 cards. See section 5-6 for
details. (Right and left refer to the side when viewed from the front of the system.
The 6015C-NTR/6015C-NT does not support a UIO card.)

1-4
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
Front Control Panel
The chassis' control panel provides you with system monitoring and control. LEDs
indicate system power, HDD activity, network activity (two) and UID/overheat/fan
fail/power fail. A main power button and system reset button is also included.
I/O Backplane
The SC815TQ-R650U/SC815TQ-560U is an extended ATX form factor chassis that
is designed to be used in a 1U rackmount configuration. Ports on the I/O backplane
include one COM port, a VGA port, two USB 2.0 ports, PS/2 mouse and keyboard
ports and two gigabit Ethernet ports. A UID (Unit Identifier) button and LED are also
located beside the LAN2 Ethernet port.
Cooling System
The SC815TQ-R650U/SC815TQ-560U chassis has an innovative cooling design
that features four sets of 4-cm counter-rotating fans located in the middle section
of the chassis. There is a "Fan Speed Control Mode" setting in BIOS that allows
chassis fan speed to be determined by system temperature. The power supply
module also includes a cooling fan.

1-5
Chapter 1: Introduction
Figure 1-1. Intel 5100/ICH9R Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
USB 2.0
3.0 Gb/S
Ports
Ports
Port
#0
MCH
Processor#2
ICH9R
RJ45
LPC
COM1
External
SIO
W83627
VGA
PCI33MHz
RN50
VGA
CONN
KB
MS
VRM
#2,3
#4,5
VRM Processor#1
1067/1333
MT/S
1067/1333
MT/S
HF
USB
#0
#1
#2
#3
#4
PCIE x4
#1C
#1B
DDR2 667
SATA
#0
#1
#2
#3
Ports
#6,7
PCI-E x8
#2C
#2B
DDR2 667
#4
#5
ZOAR
DMI
Lanes 1/2/3/4
Lane 5
Lane 6
PCI-E x4
COM2
Internal/SOL
RJ45
PCI-E x8
UIO Right Hand Side
PCI-E x 16
UIO left hand side
SIMSO
CONN
#2A
#1A
PCI32-33MHz
DDR 2
16X16M
AD17
PCI-E x1
JMB368
IDE
IDE
SPI
SST
25VF016B
#5
PCI-E x8
PCI-E x8

1-6
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone], ext.132 or 139

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperServer 6015C-
UR/6015C-U/6015C-NTR/6015C-NT up and running. Following these steps in the
order given should enable you to have the system operational within a minimum
amount of time. This quick setup assumes that your system has come to you with the
processors and memory preinstalled. If your system is not already fully integrated
with a serverboard, processors, system memory etc., please turn to the chapter or
section noted in each step for details on installing specific components.
2-2 Unpacking the System
You should inspect the box the SuperServer 6015C-UR/6015C-U/6015C-NTR/
6015C-NT was shipped in and note if it was damaged in any way. If the server itself
shows damage you should file a damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the 6015C-UR/6015C-
U/6015C-NTR/6015C-NT. It should be situated in a clean, dust-free area that is well
ventilated. Avoid areas where heat, electrical noise and electromagnetic fields are
generated. You will also need it placed near a grounded power outlet. Be sure to
read the Rack and Server Precautions in the next section.
2-3 Preparing for Setup
The box the SuperServer 6015C-UR/6015C-U/6015C-NTR/6015C-NT was shipped
in should include two sets of rail assemblies, two rail mounting brackets and the
mounting screws you will need to install the system into the rack. Follow the steps
in the order given to complete the installation process in a minimum amount of time.
Please read this section in its entirety before you begin the installation procedure
outlined in the sections that follow.

2-2
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
!!
Warnings and Precautions!
Choosing a Setup Location
Leave enough clearance in front of the rack to enable you to open the front door
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for sufficient airflow and ease in servicing.This product is for
installation only in a Restricted Access Location (dedicated equipment rooms,
service closets and the like).
This product is not suitable for use with visual display work place devices
acccording to §2 of the the German Ordinance for Work with Visual Display
Units.
•
•
Rack Precautions
Ensure that the leveling jacks on the bottom of the rack are fully extended to
the floor with the full weight of the rack resting on them.
In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
Always make sure the rack is stable before extending a component from the
rack.
You should extend only one component at a time - extending two or more si-
multaneously may cause the rack to become unstable.
Server Precautions
Review the electrical and general safety precautions in Chapter 4.
Determine the placement of each component in the rack before you install the
rails.
Install the heaviest server components on the bottom of the rack first, and then
work up.
Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
•
•
•
•
•
•
•
•

Chapter 2: Server Installation
2-3
Allow the hot plug SATA drives and power supply modules to cool before touch-
ing them.
Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).
•
•

2-4
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
2-4 Installing the System into a Rack
This section provides information on installing the 6015C-UR/6015C-U/6015C-
NTR/6015C-NT into a rack unit with the rack rails provided. If the system has already
been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6.
There are a variety of rack units on the market, which may mean the assembly
procedure will differ slightly. You should also refer to the installation instructions that
came with the rack unit you are using.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner fixed chassis rail that secures directly
to the server chassis and an outer fixed rack rail that secures directly to the rack
itself (see Figure 2-1). Two pairs of short brackets to be used on the front side of
the outer rails are also included.
Installing the Inner Rails
Both the left and right side inner rails have been pre-attached to the chassis. Pro-
ceed to the next step.
Figure 2-1. Identifying the Sections of the Rack Rails
(right side rail shown)

Chapter 2: Server Installation
2-5
Installing the Outer Rails
Begin by measuring the distance from the front rail to the rear rail of the rack. Attach
a short bracket to the front side of the right outer rail and a long bracket to the rear
side of the right outer rail. Adjust both the short and long brackets to the proper
distance so that the rail can fit snugly into the rack. Secure the short bracket to the
front side of the outer rail with two screws and the long bracket to the rear side of
the outer rail with three screws. Repeat these steps for the left outer rail.
Locking Tabs: Both chassis rails have a locking tab, which serves two functions.
The first is to lock the server into place when installed and pushed fully into the
rack, which is its normal position. Secondly, these tabs also lock the server in place
when fully extended from the rack. This prevents the server from coming completely
out of the rack when you pull it out for servicing.
Figure 2-2. Installing the Rack Rails

2-6
SUPERSERVER 6015C-UR/6015C-U/6015C-NTR/6015C-NT User's Manual
Figure 2-3. Installing the Server into a Rack
Installing the Server into the Rack
You should now have rails attached to both the chassis and the rack unit. The next
step is to install the server into the rack. Do this by lining up the rear of the chassis
rails with the front of the rack rails. Slide the chassis rails into the rack rails, keeping
the pressure even on both sides (you may have to depress the locking tabs when
inserting). See Figure 2-3.
When the server has been pushed completely into the rack, you should hear the
locking tabs "click".
