SC743 CHASSIS
USER'S GUIDE

1-2
SC743 Chassis User’s Guide
The information in this User’s Guide has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be
contained in this document, makes no commitment to update or to keep current the
information in this manual, or to notify any person or organization of the updates. Please
Note: For the most up-to-date version of this manual, please see our
web site at www.supermicro.com.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in
this manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated
or reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGE ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of
Santa Clara shall be the exclusive venue for the resolution of any such disputes.
Supermicro's total liability for all claims will not exceed the price paid for the hardware
product.
Unless you request and receive written permission from SUPER MICRO COMPUTER, you
may not copy any part of this document.
Information in this document is subject to change without notice. Other products and
companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 2006 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America
Revision : 1.1b
Release Date: Jan. 3, 2006

1-3
Chapter 1: Safety Information and Technical Specifications
Table of Contents
Chapter I: Safety Information and Technical Specifications.......... 1-4
1-1. Electrical Safety Guidelines ............................................................. 1-4
1-2. General Safety Guidelines............................................................... 1-5
1-3. ESD Safety Guidelines ....................................................................... 1-6
1-4. Operation Safety Guidelines.......................................................... 1-6
1-5. Product Compliance Information................................................. 1-8
1-6. The SC743 Series: Packing List and Specifications ............. 1-9
1-7. The SC743 Series: Packing List, Specifications & Back Panels
......................................................................................................................... 1-10
Chapter 2: Chassis Description and Installation Procedures........ 2-1
2-1. Chassis Description ........................................................................... 2-1
A. Contents of the Accessory Kit ............................................................... 2-1
B. Chassis Front View and the Front Control Panel ................................ 2-2
C. Chassis Rear View and the Back Panel .............................................. 2-4
2-2. Chassis Installation ........................................................................... 2-6
A. Important Safety Guidelines ..................................................................... 2-6
B. Tools Needed.............................................................................................. 2-6
C. Accessing the SCA Drive Tray and Installing a Hard Drive .............. 2-7
D. Removing the Top Cover of the Chassis............................................... 2-8
E. Accessing the Front Chassis Fans ........................................................ 2-9
F. Accessing the Power Supply ................................................................ 2-12
G. Installing the Motherboard ...................................................................... 2-13
H. Accessing the Interior between the Back Panel and the Mid-plane ......
......................................................................................................................... 2-15
I. Installing the PCI cards ............................................................................. 2-16
J. Installing 5.25" or 3.5" Devices............................................................. 2-17
K. Installing the Air Shroud........................................................................ 2-20
L. Installing the Chassis Rails ................................................................... 2-21
Addendum A: Installing the CSE-M34T Mobile Rack ....................... A-1
Addendum B: Installing the CSE-M35S/T1 Mobile Rack ................. B-1

1-4
SC743 Chassis User’s Guide
Chapter 1-Safety Information and Technical
Specifications
1-1 Electrical Safety Guidelines
Warning: To avoid electrical shock, check the power
cords as follows:
Checking the Power Cords
zUse the exact type of power cords as required.
zBe sure to use power cord(s) that came with safety certifications.
zThe power cord(s) must be compliant with the AC voltage requirements in your
region.
zThe power cord plug cap must have an electrical current rating that is at least
125% of the electrical current rating of this product.
zThe power cord plug cap that plugs into the AC receptacle on the power
supply must be an IEC 320, sheet C13, type female connector.
zBe sure to disconnect the power supply before accessing the SC743 or its
components.
zPlug the Power cord(s) into a socket that is properly grounded before
turning on the power.
Warning: Follow the guidelines below to avoid possible
damage to the system or injury to yourself:
General Electrical Safety Guidelines
zBe aware of the locations of the power switches on the chassis and in the
room, so you can disconnect the power supply if an accident occurs.
zTake extra precautionary measures when working with high voltage
components. It is not recommended to work alone.
zBefore removing or installing main system components, be sure to
disconnect the power first. Turn off the system before you disconnect
the power supply.
Use only one hand when working with powered-on electrical equipment to
avoid possible electrical shock.
!
!

1-5
Chapter 1: Safety Information and Technical Specifications
Use rubber mats specifically designed as electrical insulators when working
with computer systems.
The power supply or power cord must include a grounding plug and must
be plugged into grounded outlets.
Motherboard Battery: CAUTION -Make sure not to install the onboard battery
upside down to avoid possible explosion. Make sure that the positive side
is facing up on the motherboard. This battery must be replaced only with
the same or an equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions.
CD-ROM Laser: CAUTION - Do not open the enclosures of power supplies
or CD ROM to avoid injury.
1-2 General Safety Guidelines
Warning!! Follow the guidelines below to avoid
possible damage to the system or injury to yourself:
Keep the area around the SC743 clean and free of clutter.
To avoid injuries to your back, be sure to use your leg muscles, keep your
back straight, and bend your knees, when lifting the system.
Avoid wearing loose clothing to preventing it from coming into contact with
electrical circuits or being pulled into a cooling fan.
The handles are for sliding the chassis in and out of the
racks only. Do not carry the chassis by the handles.
After removing the components or chassis covers from the system, place
them on a table for safeguard.
!

1-6
SC743 Chassis User’s Guide
1-3 ESD Safety Guidelines
Use a grounded wrist strap designed to prevent static discharge.
Keep all components and printed circuit boards (PCBs) in their antistatic
bags until ready for use.
Touch a grounded metal object before removing the board from the antistatic bag.
Do not let components or PCBs come into contact with your clothing, which may
retain a charge even if you are wearing a wrist strap.
Touch a grounded metal object before removing the board from the antistatic
bag.
Handle a board by its edges only; do not touch its components, peripheral
chips, memory modules or contacts.
When handling chips or modules, avoid touching their pins.
Put the motherboard and peripherals back into their antistatic bags when not in
use.
For grounding purposes, make sure your computer chassis provides excel-
lent conductivity between the power supply, the case, the mounting
fasteners and the motherboard.
Electric Static Discharge (ESD) can damage electronic com-
ponents. To prevent damage to your system board, it is
important to handle it very carefully. The following measures are
generally sufficient to protect your equipment from ESD.
1-4 Operation Safety Guidelines
Warning: For proper cooling, make sure to install all
chassis covers before turning on the system. If this rule is
not strictly followed, warranty may become void. Do not open
the casing of a power supply. Power supplies can only be
accessed and serviced by a qualified technician of the manufacturer.
!
!

1-7
Chapter 1: Safety Information and Technical Specifications
To avoid personal injury and property damage, please carefully
follow all the safety steps listed below:
Before accessing the chassis:
1. Turn off all peripheral devices connected to the SC743.
2. Press the power button to power off the system.
3. Unplug all power cords from the system or the wall outlets.
4. Disconnect all the cables and label the cables for easy identification.
5. Use a grounded wrist strap designed to prevent static discharge when
handling components.
Removing the chassis covers:
After completing the above steps, you can remove the covers and install
components/peripheral devices into the chassis as described in Chapter 2.
1. Unlock and remove the screws and fasteners to remove the cover or
components.
2. Save all the screws and fasteners for later use. (If necessary, label these
screws or fasteners for easy identification.)
3. Follow the instruction given in Chapter 2 to remove the chassis covers.
Reinstalling the chassis covers:
To maintain proper system cooling and airflow, do not operate the system
without installing all chassis covers back to the chassis. To reinstall the chassis
covers, please follow the steps listed below:
1. Make sure that all components and devices are securely fastened
on the chassis and there are no loose parts/screws inside the chassis.
2. Make sure that all cables are properly connected to the connectors and ports.
3. Use the original screws or fasteners to install the covers to the chassis.
4. Be sure to lock to the chassis or the system to prevent unauthorized access.
5. For proper cooling, enclose the chassis with covers before operating the
system.
STOP

1-8
SC743 Chassis User’s Guide
Before installing the chassis into a rack:
1. Make sure that the rack is securely anchored onto an unmovable surface or
structure before installing the chassis into the rack.
2. Unplug the power cord(s) of the rack before installing the chassis into the
rack.
3. Make sure that the system is adequately supported. Make sure that all the
components are securely fastened to the chassis to prevent components
falling off from the chassis.
4. Be sure to install an AC Power Disconnect for the entire rack assembly and
this Power Disconnect must be clearly marked.
5. The rack assembly shall be properly grounded to avoid electrical shock.
6. The rack assembly must provide sufficient airflow to the chassis for proper
cooling.
1-5 Product Compliance Information
The SC743 Chassis is compliant with the following safety standards/
requirements:
Product Safety
*Canada/USA--UL60 950-CSA60 950
*European Union--EN 60 950
*International--IEC60 950
Electromagnetic Compatibility (EMC)-Emissions
*European Union--EN55022: 1994
*International--CISPR22
*USA--Title 47 CFR, Part 15
Power Line Harmonics/Voltage Flicker
*European Union--EN61000-3-2/EN61000-3-3
*International--IEC61000-3-2
Electromagnetic Compatibility-Immunity
*European Union--EN55024: 1998
*International--CISPR24
All images and layouts shown in this manual were based upon the latest
chassis Revision available at the time of publishing. The chassis you’ve
received may or may not look exactly the same as the ones shown in this
manual.
1-6 An important note to the user

1-9
Chapter 1: Safety Information and Technical Specifications
A1. The SC743S1/743i-R760(B) chassis contains the following:
1-6A Packing List and Chassis Specifications for
the SC743S1/743i Series--Revision A
(*Note: Please refer to Page 1-13 for the Power Supply Specifica-
tions.)
Component Quantity Part Number
SCA 1” Drive Tray (*SC743S1 only) 8 CSE- PT17 (B)
IDE Drive Carriage (*SC743i only) 2 CSE- PT31 (B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Rear Chassis Fan (Hot Swap) 2 Fan-0073
760 W Triple Redundant (2+1) Power
Supply 1 PWS-0050
8-port SCSI Single-channel w/SAF-TE Back
plane (*SC743S1 only ) 1 CSE-SCA -743S1
Fan Shroud 1 CSE- PT54
SCSI Cable (”9”) (*SC743S1 only ) 1 CBL-033-U320
Component Quantity Part Number
SCA 1” Drive Tray (*SC743S1 only) 8 CSE- PT17 (B)
IDE Drive Carriage (*SC743i only) 2 CSE- PT31 (B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Rear Chassis Fan (Hot Swap) 2 Fan-0073
650W Power Supply 1 PWS-0056
8-port SCSI Single-channel w/SAF-TE Back
plane (*SC743S1 only ) 1 CSE-SCA -743S1
Fan Shroud 1 CSE- PT54
SCSI Cable (”9”) (*SC743S1 only ) 1 CBL-033-U320
Component Quantity Part Number
SCA 1” Drive Tray (*SC743S1 only) 8 CSE- PT17 (B)
IDE Drive Carriage (*SC743i only) 2 CSE- PT31 (B)
80mm Hot-Swap Chassis Fan 4 FAN-0074
645W Power Supply 1 PWS-0060
8-port SCSI Single-channel w/SAF-TE
Backplane (*SC743S1) 1 CSE-SCA-743S1
Fan Shroud 1 CSE- PT54
SCSI Cable (”9”) (SC743S1) 1 CBL-033-U320
A2. The SC743S1/743i-650(B) chassis contains the following:
A3. The SC743S1/743i-645(B) chassis contains the following:
B. The SC743S1/743i Accessory Box contains:
Component Qty
AC Power Cords (*SC743S1/743i-R760(B) only) 3
AC Power Cord (*SC743S1/743i-650,645 only) 1
Motherboard Screws and Standoffs 1 set
HDD Screws 1 set

1-10
SC743 Chassis User’s Guide
Component Quantity Part Number
SCA 1” Drive Tray (*SC743S1 only) 8 CSE-PT17 (B)
IDE Drive Carriage (*SC743i only) 2 CSE-PT31 (B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Rear Chassis Fan (Hot Swap) 2 Fan-0081
760 W Triple Redundant (2+1) Power
Supply 1 PWS-0050
8-port SCSI Single-channel w/SAF-TE Back
plane (*SC743S1 o nly) 1 CSE-SCA-743S1
Fan Shroud (Rev. B) 1 CSE-PT54
SCSI Cable (”9”) (*SC743S1 on ly) 1 CBL-033-U320
Component Quantity Part Number
SCA 1” Drive Tray (*SC743S1 only) 8 CSE-PT17 (B)
IDE Drive Carriage (*SC743i only) 2 CSE-PT31 (B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Rear Chassis Fan (Hot Swap) 2 Fan-0081
650W Power Supply 1 PWS-0056
8-port SCSI Single-channel w/SAF-TE Back
plane (*SC743S1 o nly) 1 CSE-SCA-743S1
Fan Shroud (Rev. B) 1 CSE-PT54
SCSI Cable (”9”) (*SC743S1 on ly) 1 CBL-033-U320
Component Quantity Part Number
SCA 1” Drive Tray (*SC743S1 only) 8 CSE-PT17 (B)
IDE Drive Carriage (*SC743i only) 2 CSE-PT31 (B)
80mm Hot-Swap Chassis Fan 4 FAN-0074
645W Power Supply 1 PWS-0060
8-port SCSI Single-channel w/SAF-TE
Backplane (*SC743S1) 1 CSE-SCA-743S1
Fan Shroud (Rev. B) 1 CSE-PT54
SCSI Cable (”9”) (SC743S1) 1 CBL-033-U320
A1. The SC743S1/743i/SC743S2-R760(B) chassis contains:
1-6B Packing List and Chassis Specifications for
the SC743S1/743i/SC743S2 Series--Revision B
A2. The SC743S1/743i/SC743S2-650(B) chassis contains:
A3. The SC743S1/743i-645(B) chassis contains the following:
Component Qty
AC Power Cords (*SC743S1/743i-R760(B) only) 3
AC Power Cord (*SC743S1/743i-650,645 only) 1
Motherboard Screws and Standoffs 1 set
HDD Screws 1 set
B. The SC743S1/743i/SC743S2 Accessory Box contains:
(*Note: Please refer to Page 1-13 for the Power Supply Specifica-
tions.)

1-11
Chapter 1: Safety Information and Technical Specifications
1-7A Packing List, Chassis Specifications and Back
Panels for the SC743T Series--Revision A
A1. The SC743T-760 (B) chassis contains the following:
B. The SC743 Accessory Box contains:
(*Note: Please refer to Page 1-13 for the Power Supply Specifica-
tions.)
Component Qty Part Number
SCA 1” Drive Trays 8 CSEPT17(B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Hot-Swap Rear Chassis Fan 2 FAN-0073
760W Triple Redundant (2+1) Power 1 PWS-0050
8-port SATA Backplane 1 CSE-SATA-743
Fan Shroud 1 CSE- PT54
Component Qty Part Number
SCA 1” Drive Trays 8 CSEPT17(B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Hot-Swap Rear Chassis Fan 2 FAN-0073
650W Power Supply 1 PWS-0056
8-port SATA Backplane 1 CSE-SATA-743
Fan Shroud 1 CSE- PT54
Component Qty Part Number
SCA 1” Drive Trays 8 CSEPT17(B)
80mm Hot-Swap Chassis Fan 4 FAN-0074
645W Power Supply 1 PWS-0060
8-port SATA Backplane 1 CSE-SATA-743
Fan Shroud 1 CSE- PT54
A2. The SC743T-650(B) chassis contains the following:
A3. The SC743T-645(B) chassis contains the following:
Component Qty
AC Power Cords (*SC743T-R760 (B) only) 3
AC Power Cord (*SC743T-650,645 only) 1
Motherboard Screws and Standoffs 1 set
HDD Screws 1 set
SATA Cable (CBL-0044) 4
SATA LED Cable (CBL-0077) 1

1-12
SC743 Chassis User’s Guide
Component Qty Part Number
SCA 1” Drive Trays 8 CSEPT17(B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Hot-Swap Rear Chassis Fan 2 FAN-0081
760W Triple Redundant (2+1) Power 1 PWS-0050
8-port SATA Backplane 1 CSE-SATA-743
Fan Shroud (Rev. B) 1 CSE-PT54
Component Qty Part Number
SCA 1” Drive Trays 8 CSEPT17(B)
80mm Hot-Swap Chassis Fan 4 FAN-0072
80mm Hot-Swap Rear Chassis Fan 2 FAN-0081
650W Power Supply 1 PWS-0056
8-port SATA Backplane 1 CSE-SATA-743
Fan Shroud (Rev. B) 1 CSE-PT54
Component Qty Part Number
SCA 1” Drive Trays 8 CSEPT17(B)
80mm Hot-Swap Chassis Fan 4 FAN-0074
645W Power Supply 1 PWS-0060
8-port SATA Backplane 1 CSE-SATA-743
Fan Shroud (Rev. B) 1 CSE-PT54
1-7B Packing List, Chassis Specifications and Back
Panels for the SC743T Series--Revision B
A2. The SC743T-650(B) chassis contains the following:
A3. The SC743T-645(B) chassis contains the following:
B. The SC743 Accessory Box contains:
(*Note: Please refer to the next page for the Power Supply Specifi-
cations.)
Component Qty
AC Power Cords (*SC743T-R760 (B) only) 3
AC Power Cord (*SC743T-650,645 only) 1
Motherboard Screws and Standoffs 1 set
HDD Screws 1 set
SATA Cable (CBL-0044) 4
SATA LED Cable (CBL-0077) 1
A1. The SC743T-760 (B) chassis contains the following:

1-13
Chapter 1: Safety Information and Technical Specifications
C. SC743 Power Supply Specifications
Power supply spec SC743 series
Mfr. model # SP762-TS(3xSP382-TS Models)
Mfr. part # PWS-0050
Rated AC input voltage 100-240V AC
Rated input frequency 50-60 Hz
Rated input current 14A (115V)
8A (230V)
Rated output power 760W
MaximumratedBTU 4350 BUTs/Hr
NominalDCoutput
+3.3V 36A
+5V 36A
+12V 50A combined
-12V 1A
+5VStandby 3.5A
(*Note: When connecting the 760W Power Supply to the Drive Backplane,
be sure to connect the power supply to the connectors labelled "PD", "PE"
and "PH" (with yellow/green stripes), and then, to the connector labelled
"PJ", colored in yellow/blue stripes.)

1-14
SC743 Chassis User’s Guide
GND
GND
GND
GND
+12V
+12V
+5V
+5V
IN
IN
1
1
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
1
1
I
I
C
C
2
2
+5V
+5V
GND
GND
GND
GND
+12V
+12V
BUZZER
BUZZER
IPMB
IPMB
DOORLOCK
DOORLOCK
RESET
RESET
1
1
1
1
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
ENABLE
ENABLE
+
+
1
1
D3:
D3:
1
1
1
1
REV 1.00
REV 1.00
SCA743S1
SCA743S1
S
S
UPER
UPER
R
R
OFF: DISABLE
OFF: DISABLE
ON: ENABLE
ON: ENABLE
JP19: BUZZER ENABLE
JP19: BUZZER ENABLE
D. SCSI 743 Back Panel (*SC743S1/SC743S2 Only)
D-1 Jumper Settings and Pin Definitions
D-2 Jumper Setting Locations
A
BCDEF
Note1: By default, we connect four chassis fans to the drive backpanel.
Note2: When connecting the 760W Power Supply to the Drive Backplane, be
sure to connect the power supply to the connectors labelled "PD", "PE" and
"PH" (with yellow/green stripes), and then, to the connector labelled "PJ",
colored in yellow/blue stripes.
Jumper Default Setting Note
JP19 Open Buzzer Reset (*Note Below)
(*Note: Press the button on the front panel once to disable the
buzzer. If the buzzer has been disabled, please be sure to press the
button once again to re-enable the buzzer.)
A. Jumper 19
B. SCSI Connector
C. IPMB
D. I2C
E/F 12V PWR Connectors

1-15
Chapter 1: Safety Information and Technical Specifications
(*Note: This driver is not necessary for other Operating Systems. If
you have two SCA backplanes, you will need to install the driver
twice.)
The driver is located on the Super Micro motherboard driver CD or is
available for download from our FTP site: ftp://ftp.supermicro.com/driver/
Qlogic/
Follow the procedure below to install this driver to your system.
Installing the driver:
1) Right click on “My Computer” and choose “Property”.
2) Select “Hardware” tab and click on “Device Manager”.
3) Open “Other Devices” or wherever “GEM318” is on.
4) Right click on this device and choose “Property”.
5) Click on “Driver” tab and choose “Update Driver”.
6) Click “Next” 2 times, uncheck both “Floppy disk drives” and “CD-ROM
drives”. Then, select the item- “Specify a location,” and choose
“Next”.
7) Click on “Browse” and choose D drive or wherever Supermicro Setup
CD is in.
8) Choose “Qlogic” folder and click on “Open”.
9) System will automatically detect GEM318 and install the drive from this
point on.
or,
1) Right click the "My Computer" icon on your desktop and choose
Properties.
2) Click on the Hardware tab and click on "Device Manager" to bring up
the list of system devices.
3) You may see one or two yellow question marks (?) that read QLogic
GEM354 or GEM318 SCSI Processor Device. Right click on these, and
choose to uninstall. If two such question marks are present, uninstall
both.
4) Click on Action tab and choose "Scan for Hardware Changes". The
Hardware Wizard program should start up. Click "Next".
5) At the first prompt, choose “Display a list of known device drivers for
the device so that I can choose a specific driver” and click "Next".
6) Choose “Other Devices” and click Next.
7) Choose “Have Disk”, and specify your floppy drive location in the
options box. Then, click "Next".
8) Highlight “Enclosure Services Device” and click "Next".
9) Ignore the warning prompt by clicking "Yes".
D-3 SCSI (Super) GEM Driver Installation (*for Windows OS)

1-16
SC743 Chassis User’s Guide
E. SATA743 Back Panel (*SC 743T Only)
E-1 Jumpers and Default Settings
Jumper Description Default
JP18 Buzzer Reset Open
*JP25 Overheat Temperature 50oC 1-2 (*Note 1)
*JP26 Common Act In and Act #0~#7 In Open (*Note 2)
(*Note1: Test if the buzzer is beeping to see if the OH temperature is >=50oC
(*Note2: Test to see if all 8 Activity. LEDs, 8 HDDs, and CBL-0077 are working
properly.)
E-2 Connectors/Jumpers Pin Definitions
(*Note: Please refer to Diagram 1 on the next
page for Jumpers/Connectors locations.) Pins #
1
2 & 3
4
Definition
+12V
Ground
+5V
Table 1
4-pin PWR Connecto
r
(JP10/JP13)
A1/A2. JP10/JP13: 4-Pin Power
Connectors
(*Refer to Table 1 on the right for pin
definitions.)
B. JP26: HDD Activity
(Refer to Table 2 on the right for pin
definitions.)
C. JP25: Overheat Temperatures
(Refer to Table 3 on the right for pin
definitions.)
D. JP35: GEM424 Reset
E. JP18: Buzzer Reset
Table 2
HDD Activity Pin Definitions
(JP26)
Pin Number Definition
1 ACT0
2 ACT1
3 ACT2
4 ACT3
5 COM_ACT
Pin Number Definition
6 ACT4
7 ACT5
8 ACT6
9 ACT7
10 Ground
Pins #
Open
1 & 2
2 & 3
Definition
450C
500C
550C
Table 3
OH Temperature
(JP25)
LED# Function
D5 FAIL0
D12 ACT0
D6 FAIL1
D13 ACT1
D7 FAIL2
D14 ACT2
D8 FAIL3
D15 ACT3
LED# Function
D19 FAIL4
D18 ACT4
D20 FAIL5
D21 ACT5
D23 FAIL6
D22 ACT6
D26 FAIL7
D25 ACT7
LED Indicators
E-3 LED Indicators
D5, D6, D7, D8, D19, D20, D23,
D26: SATA Slots (#0-#7 Fail)
D12, D13, D14, D15, D18, D21,
D22, D27: SATA Slots (#0-#7
Activity)

1-17
Chapter 1: Safety Information and Technical Specifications
++
1
+12V+12V GND GND GND GND +5V+5V
1
MM1
H6
H5
MT3
MT2
MT1
H2
H12
M7
SATA743
REV. 1.01
J1
J2
J3
J4
J9
J11
J13
J15
+12V GND GND +5V
E-4 Jumpers/Headers Locations
A1 A2
CD
E
D25
D26
D22 D23 D21 D20 D18 D19
B
A
Pin1
Pin2 Pin3
Pin4
Pin1
Pin2 Pin3 Pin4
Pin5
A1/A2:JP10/JP13:
PWR Connectors B:JP26: HDD ACT
Pin6 Pin7 Pin8
Pin9
Pin10
D15 D8 D14 D7 D13 D6 D12 D5
B
SATA0
SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
SATA7
SATA0
SATA1
SATA2 SATA3 SATA4
SATA5
SATA8
SATA7
JP18
JP25
JP35
JP10 JP13
JP26
Diagram1: Jumpers and Connectors Locations

1-18
SC743 Chassis User’s Guide
Notes

2-1
Chapter 2: Chassis Description and Installation Instructions
2-1 Chassis Description
A. Contents of the Accessory Kit:
The following items are included in the Accessory Kit:
Chapter 2: Chassis Description and Installation
Procedures
GH
F
F. Flat head M4 x 4 mm [0.157]
RAIL
I
G. Round head M4 x 4 mm [0.157]
H. Flat head M5 x 12 mm [0.472]
I. Washer for M5
B
B. Flat head 6-32 x 5 mm [0.197]
DRIVE
DE
E. Round head M3 x 5 mm [0.197]
D. Pan head 6-32 x 5 mm [0.197]
A
A. Pan head w/ lock
6-32 x 4.5 mm [0.177]
M/B
B
B. Flat head 6-32 x 5 mm [0.197]
HDD
J
J. M/B standoff, 6-32 to 6-32
M/B STANDOFF

2-2
SC743 Chassis User’s Guide
B. Chassis Front View and the Front Control Panel
Front LED
LED Button Definitions
A. PowerButton
Chassis Front Panel
Front Panel I/O Device Definitions
K
B. SystemReset
C. PowerIndicator
D. HDDActivityIndicator
E/F. LANIndicators
H. PowerFailure Indicator
K. Hot-Swappable DriveTrays(8)
I./J USB Ports
L. FloppyDriveBay
M. 5.25 Drive Trays (2)
A B C D E F G H
I
J
L
M
