Supero Supero SC825 Series User manual

SC825 CHASSIS
Series
SC825TQC-R740WB
SC825TQC-R740LPB SC825TQ-R740LPB
SC825TQ-R740UB SC825TQ-R740WB
SC825TQ-R720LPB SC825TQ-710LP
SC825TQ-R720UB SC825TQ-R700LP(V)(B)
SC825TQ-R700U(V)(B) SC825TQC-600LPB
SC825TQ-600LPB SC825TQC-600WB
SC835TQ-600WB SC825TQ-563UB
SC825TQ-560LP(V)(B) SC825TQ-563LPB
SC825TQ-R500WB SC825TQ-560U(V)(B)
USER’S MANUAL
2.0b
SUPER ®

SC825 Chassis Manual
ii iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SC825 2U chassis. Installa-
tion and maintenance should be performed by experienced technicians only.
Supermicro’s SC825 2U chassis features a unique and highly optimized design.
The chassis is equipped with a 560W (single), 563W (single) 600W (single), 700W
(redundant) 710W (single), 720W (redundant) or 740W (redundant) high-efciency
power supply for superb power savings. High-performance fans provide ample
optimized cooling for the chassis.
This document lists compatible parts and congurations available when this docu-
ment was published. Always refer to the our website for updates on supported
parts and congurations.
Manual Revision 2.0b
Release Date: October 26, 2016
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2016 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

SC825 Chassis Manual
iv v
Preface
Manual Organization
Chapter 1 Introduction
The rst chapter provides a checklist of the main components included with this
chassis and describes the main features of the SC825 chassis. This chapter also
includes contact information.
Chapter 2 Standardized Warning Statements for AC Systems
This chapter lists warnings, precautions, and system safety. You should thoroughly
familiarize yourself with this chapter for a general overview of safety precautions
that should be followed before installing and servicing this chassis.
Chapter 3 Chassis Components
Refer here for details on this chassis model including the fans, bays, airow shields,
and other components.
Chapter 4 System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 5 Chassis Setup and Maintenance
Refer to this chapter for detailed information on this chassis. You should follow the
procedures given in this chapter when installing, removing, or reconguring your
chassis.
Chapter 6 Rack Installation
Refer to this chapter for detailed information on chassis rack installation. You should
follow the procedures given in this chapter when installing, removing or reconguring
your chassis into a rack environment.
Appendices
This section lists compatible cables, power supply specications, and compatible
backplanes. Not all compatible backplanes may be listed. Refer to our website for
the latest compatible backplane information.
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Shipping List.................................................................................................... 1-1
1-3 Chassis Features ............................................................................................ 1-3
Hard Drives ..................................................................................................... 1-3
PCI Expansion slots........................................................................................ 1-3
Peripheral Drives............................................................................................. 1-3
Other Features................................................................................................ 1-3
1-4 Contacting Supermicro.................................................................................... 1-4
1-5 Returning Merchandise for Service................................................................. 1-5
Chapter 2 Standardized Warning Statements for AC Systems
2-1 About Standardized Warning Statements....................................................... 2-1
Warning Denition ........................................................................................... 2-1
Installation Instructions.................................................................................... 2-4
Circuit Breaker ................................................................................................ 2-5
Power Disconnection Warning........................................................................ 2-6
Equipment Installation..................................................................................... 2-8
Restricted Area................................................................................................ 2-9
Battery Handling............................................................................................ 2-10
Redundant Power Supplies .......................................................................... 2-12
Backplane Voltage ........................................................................................ 2-13
Comply with Local and National Electrical Codes........................................ 2-14
Product Disposal........................................................................................... 2-15
Hot Swap Fan Warning................................................................................. 2-16
Power Cable and AC Adapter ...................................................................... 2-18
Chapter 3 Chassis Components
3-1 Overview ......................................................................................................... 3-1
3-2 Components.................................................................................................... 3-1
Chassis............................................................................................................ 3-1
Backplane........................................................................................................ 3-1
Fans ................................................................................................................ 3-1
Mounting Rails ................................................................................................ 3-1
Power Supply.................................................................................................. 3-2
Air Shroud ....................................................................................................... 3-2
3-3 Where to get Replacement Components........................................................ 3-2

SC825 Chassis Manual
vi vii
Preface
Chapter 4 System Interface
4-1 Overview ......................................................................................................... 4-1
4-2 Control Panel Buttons ..................................................................................... 4-2
4-3 Control Panel LEDs ........................................................................................ 4-2
4-4 Drive Carrier LEDs.......................................................................................... 4-4
SAS/SATA Drives ............................................................................................ 4-4
Chapter 5 Chassis Setup and Maintenance
5-1 Overview ......................................................................................................... 5-1
5-2 Installation and General Maintnenance .......................................................... 5-1
Installation ....................................................................................................... 5-1
5-3 Removing the Chassis Cover ......................................................................... 5-2
5-4 Installing Hard Drives...................................................................................... 5-3
5-5 Installing an Optional Fixed Hard Drive.......................................................... 5-6
5-6 DVD-ROM Replacement or Installation .......................................................... 5-7
Replacing the DVD-ROM and Front Panel..................................................... 5-7
5-7 Installing the Motherboard .............................................................................. 5-8
I/O Shield ........................................................................................................ 5-8
Installing the I/O Shield................................................................................... 5-8
Permanent and Optional Standoffs................................................................. 5-9
Expansion Card PCI Slot Setup.....................................................................5-11
PCI Slot Setup in LP (Low-Prole) Chassis ..................................................5-11
PCI Slot Setup for SC825U (Universal Output) and SC825W ..................... 5-12
5-8 Installing the Air Shroud................................................................................ 5-13
Checking the Server's Airow ....................................................................... 5-14
Installation Complete..................................................................................... 5-14
5-9 System Fans ................................................................................................. 5-15
5-10 Power Supply ............................................................................................... 5-17
Power Supply Failure.................................................................................... 5-17
Replacing the Power Distributor ................................................................... 5-19
Replacing or Installing the Front Port Panel................................................. 5-20
5-11 Optional Front Bezel ..................................................................................... 5-21
Chapter 6 Rack Installation
6-1 Overview ......................................................................................................... 6-1
6-2 Unpacking the System .................................................................................... 6-1
6-3 Preparing for Setup......................................................................................... 6-1
Choosing a Setup Location............................................................................. 6-1
Rack Precautions............................................................................................ 6-2
General Server Precautions............................................................................ 6-2
Rack Mounting Considerations ....................................................................... 6-3
Ambient Operating Temperature ................................................................ 6-3
Reduced Airow ......................................................................................... 6-3
Mechanical Loading ................................................................................... 6-3
Circuit Overloading..................................................................................... 6-3
Reliable Ground ......................................................................................... 6-3
6-4 Rack Mounting Instructions............................................................................. 6-4
Separating the Sections of the Rack Rails..................................................... 6-4
Installing the Inner Rail Extension .................................................................. 6-5
Outer Rack Rails............................................................................................. 6-6
Appendix A SC825 Chassis Cables
Appendix B SC825 Power Supply Specications
Appendix C BPN-SAS-825TQ Backplane Specications
Appendix D BPN-SAS3-825TQ Backplane Specications

SC825 Chassis Manual
viii
Notes

Chapter 1
Introduction
1-1 Overview
Supermicro’s SC825 2U chassis features a unique and highly-optimized design.
The chassis is equipped with high efciency power supply.
1-2 Shipping List
Please visit the following link for the latest shipping lists and part numbers for your
particular chassis model www.supermicro.com
Chapter 1: Introduction
1-1
SC825 Chassis
Model HDD PCI Slots Power Supply
SC825TQ-R740WB 8x SAS / SATA 4x FF 3x LP 740W (Platnum Level
Redundant)
SC825TQ-R740UB 8x SAS / SATA 4x FH 3x LP 740W (Platnum Level
Redundant)
SC825TQC-R740WB 8x SAS/SATA 8x SAS3 / SATA 740W Redundant
(Platinum)
SC825TQC-R740LPB 8x SAS/SATA 8x SAS3 / SATA 740W Redundant
(Platinum)
SC825TQ-R740LPB 8x SAS / SATA 7x LF 740W (Platnum Level
Redundant)
SC825TQ-720LPB 8x SAS/SATA 7x LF 720W (Gold Level)
SC825TQ-720UB 8x SAS/SATA 4x FF 3x LP 720W (Gold Level)
SC825TQ-710LP 8x SAS/ SATA 7x LP, FL 710W
SC825TQ-R700UV /
SC825TQ-R700UB 8x SAS/SATA 4x FF 3x LP 700W Redundant
SC825TQ-R700LPV /
SC825TQ-R700LPB 8x SAS/SATA 7x LP 700W Redundant
SC825TQC-600LPB 8x SAS/SATA 8x SAS3 / SATA 600W
(Platinum)
SC825TQC-600WB 8x SAS/SATA 8x SAS3 / SATA 600W
(Platinum)
SC825TQ-600WB 8x SAS/SATA 8x SAS/SATA 600W (Platinum Level)
Legend: FF: Full-height, full length, FH: Full-height, half length. LF: Low-prole,
full-length. LP: Low-prole.

SC825 Chassis Manual
1-2 1-3
Chapter 1: Introduction
1-3 Chassis Features
The SC825 2U, high-performance chassis includes the following features:
Hard Drives
The SC825 chassis features eight slots for SAS3 and SAS/SATA drives. These
drives are hot-swappable. Once set up correctly, these drives can be removed with-
out powering down the server. In addition, these drives support SES2 (SAS/SATA).
PCI Expansion slots
Each SC825 chassis model includes seven low-prole I/O expansion slots.
Peripheral Drives
Each SC825 chassis supports one slim DVD-ROM drive (included) and one slim
oppy drive (optional). These drives allow you to quickly install or save data.
Other Features
Other onboard features are included to promote system health. These include
various three cooling fans, a convenient power switch, reset button, and ve LED
indicators.
SC825 Chassis
SC825TQ-600LPB 8x SAS/SATA 7x LF 600W
SC825TQ-563LPB
/ SC825TQ-563UB 8x SAS/SATA 7x LF / 3x FF, 3 LP, 1 UIO 560W
SC825TQ-560UV /
SC825TQ-560UB 8x SAS/SATA 4x FF 3x LP 560W
SC825TQ-560LPV /
SC825TQ-560LPB 8x SAS/SATA 7x LP 560W
SC825TQ-R500WB 8x SAS/SATA 4x FF 3x LP 500W (Platinum Level
Redundant)
Legend: FF: Full-height, full length, FH: Full-height, half length. LF: Low-prole,
full-length. LP: Low-prole.

SC825 Chassis Manual
1-4 1-5
Chapter 1: Introduction
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.supermicro.com.tw
1-5 Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required be-
fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning to
the manufacturer, the RMA number should be prominently displayed on the outside
of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling
charges will be applied for all orders that must be mailed when service is complete.
For faster service, RMA authorizations may be requested online (http://www.
supermicro.com/support/rma/).
Whenever possible, repack the chassis in the original Supermicro carton, using the
original packaging material. If these are no longer available, be sure to pack the
chassis securely, using packaging material to surround the chassis so that it does
not shift within the carton and become damaged during shipping.
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
During the warranty period, contact your distributor rst for any product problems.

SC825 Chassis Manual
1-6
Notes

2-1
Chapter 2: Warning Statements for AC Systems
Chapter 2
Standardized Warning Statements for AC Systems
2-1 About Standardized Warning Statements
The following statements are industry standard warnings, provided to warn the user
of situations which have the potential for bodily injury. Should you have questions
or experience difficulty, contact Supermicro's Technical Support department
for assistance. Only certied technicians should attempt to install or congure
components.
Read this appendix in its entirety before installing or conguring components in the
Supermicro chassis.
These warnings may also be found on our web site at http://www.supermicro.com/
about/policies/safety_information.cfm.
Warning!
This warning symbol means danger. You are in a situation that could cause bodily
injury. Before you work on any equipment, be aware of the hazards involved with
electrical circuitry and be familiar with standard practices for preventing accidents.
Warning Denition
警告の定義
この警告サインは危険を意味します。
人身事故につながる可能性がありますので、いずれの機器でも動作させる前に、
電気回路に含まれる危険性に注意して、標準的な事故防止策に精通して下さい。
此警告符号代表危险。
您正处于可能受到严重伤害的工作环境中。在您使用设备开始工作之前，必须充分
意识到触电的危险，并熟练掌握防止事故发生的标准工作程序。请根据每项警告结
尾的声明号码找到此设备的安全性警告说明的翻译文本。
此警告符號代表危險。
您正處於可能身體可能會受損傷的工作環境中。在您使用任何設備之前，請注意觸
電的危險，並且要熟悉預防事故發生的標準工作程序。請依照每一注意事項後的號
碼找到相關的翻譯說明內容。
