Supero 1027R-72BRFTP User manual

SUPERSERVER
1027R-72BRFTP
SUPER ®
USER’S MANUAL
1.0b

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful interference
with radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-
ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro-
ductive harm.
Manual Revision 1.0b
Release Date: July 22, 2014
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2014 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It pro-
vides information for the installation and use of the SuperServer 1027R-72BRFTP
Installation and maintenance should be performed by experienced technicians only.
Manual Organization
Chapter 1: Introduction
The rst chapter provides a checklist of the main components included with the
server system and describes the main features of the X9DRW-7TPF serverboard
and the SC119XTQ-R700WB chassis, which comprise the SuperServer 1027R-
72BRFTP
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer into a rack and
check out the server conguration prior to powering up the system. If your server
was ordered without processor and memory components, this chapter will refer you
to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 1027R-72BRFTP
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X9DRW-7TPF serverboard, includ-
ing the locations and functions of connections, headers and jumpers. Refer to this
chapter when adding or removing processors or main memory and when recong-
uring the serverboard.

SUPERSERVER 1027R-72BRFTP. User's Manual
iv
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC119XTQ-R700WB server chas-
sis. You should follow the procedures given in this chapter when installing, removing
or reconguring SAS or peripheral drives and when replacing system power supply
modules and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS Error Beep Codes
Appendix B: System Specications

v
Preface
Notes

vi
SUPERSERVER 1027R-72BRFTP. User's Manual
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
Processors ...................................................................................................... 1-2
Memory ........................................................................................................... 1-2
Onboard SAS.................................................................................................. 1-2
Onboard Serial ATA ........................................................................................ 1-2
Rear I/O Ports................................................................................................. 1-2
System Power................................................................................................. 1-3
Hard Drives ..................................................................................................... 1-3
PCI Expansion Slots ....................................................................................... 1-3
Front Control Panel......................................................................................... 1-3
Cooling System............................................................................................... 1-3
1-4 Contacting Supermicro.................................................................................... 1-5
Chapter 2 Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System .................................................................................... 2-1
2-3 Preparing for Setup......................................................................................... 2-1
Choosing a Setup Location............................................................................. 2-1
2-4 Warnings and Precautions.............................................................................. 2-2
Rack Precautions............................................................................................ 2-2
Server Precautions.......................................................................................... 2-2
Rack Mounting Considerations ....................................................................... 2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-3
2-5 Installing the System into a Rack ................................................................... 2-4
Identifying the Sections of the Rack Rails...................................................... 2-4
Inner Rails....................................................................................................... 2-5
Outer Rails ...................................................................................................... 2-6
Installing the Server into a Telco Rack ........................................................... 2-8
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-1

vii
Table of Contents
UID .................................................................................................................. 3-1
Power .............................................................................................................. 3-1
3-3 Control Panel LEDs ........................................................................................ 3-2
Information LED .............................................................................................. 3-2
NIC2 ................................................................................................................ 3-2
NIC1 ................................................................................................................ 3-2
HDD................................................................................................................. 3-3
Power .............................................................................................................. 3-3
3-4 Drive Carrier LEDs.......................................................................................... 3-3
Chapter 4 Standardized Warning Statements for AC Systems
4-1 About Standardized Warning Statements....................................................... 4-1
Warning Denition ........................................................................................... 4-1
Installation Instructions.................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning ........................................................................ 4-6
Equipment Installation..................................................................................... 4-8
Restricted Area................................................................................................ 4-9
Battery Handling............................................................................................ 4-10
Redundant Power Supplies .......................................................................... 4-12
Backplane Voltage ........................................................................................ 4-13
Comply with Local and National Electrical Codes........................................ 4-14
Product Disposal........................................................................................... 4-15
Hot Swap Fan Warning................................................................................. 4-16
Power Cable and AC Adapter ...................................................................... 4-18
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard ............................................................................... 5-1
Precautions ..................................................................................................... 5-1
Unpacking ....................................................................................................... 5-1
5-2 Processor and Heatsink Installation................................................................ 5-2
Installing an LGA 2011 Processor................................................................... 5-2
Removing the Heatsink................................................................................... 5-5
5-3 Connecting Cables.......................................................................................... 5-6
Connecting Data Cables ................................................................................. 5-6
Connecting Power Cables .............................................................................. 5-6
Connecting the Control Panel......................................................................... 5-6
5-4 I/O Ports.......................................................................................................... 5-7
5-5 Installing Memory............................................................................................ 5-8

viii
SUPERSERVER 1027R-72BRFTP. User's Manual
5-6 Adding PCI Cards ......................................................................................... 5-10
5-7 Serverboard Details .......................................................................................5-11
5-8 Connector Denitions.................................................................................... 5-14
5-9 Jumper Settings ............................................................................................ 5-22
5-10 Onboard Indicators........................................................................................ 5-25
5-11 SAS/SATA Port Connections......................................................................... 5-27
5-12 Installing Software......................................................................................... 5-28
SuperDoctor III.............................................................................................. 5-29
5-13 Onboard Battery............................................................................................ 5-31
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices.................................................................................. 6-1
Precautions ..................................................................................................... 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 System Fans ................................................................................................... 6-2
System Fan Failure......................................................................................... 6-3
Air Shroud ....................................................................................................... 6-4
Hard Drive Installation..................................................................................... 6-7
Hard Drive Backplane ..................................................................................... 6-9
6-4 Power Supply................................................................................................ 6-10
Battery Backup Power (BBP™) Feature....................................................... 6-10
Power Supply Failure.................................................................................... 6-10
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
Starting BIOS Setup Utility.............................................................................. 7-1
How To Change the Conguration Data ......................................................... 7-2
Starting the Setup Utility ................................................................................. 7-2
7-2 Main Setup...................................................................................................... 7-2
7-3 Advanced Setup Congurations...................................................................... 7-4
7-4 Event Logs .................................................................................................... 7-27
7-5 IPMI............................................................................................................... 7-29
7-6 Boot............................................................................................................... 7-31
7-7 Security......................................................................................................... 7-32
7-8 Save & Exit ................................................................................................... 7-33
Appendix A BIOS Error Beep Codes
Appendix B System Specications

Chapter 1
Introduction
1-1 Overview
The SuperServer 1027R-72BRFTP. is a high-end server comprised of two main
subsystems: the SC119XTQ-R700WB 1U server chassis and the X9DRW-7TPF
dual processor serverboard. Please refer to our web site for information on operating
systems that have been certied for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the 1027R-72BRFTP., as listed below:
•Two air shrouds (MCP-310-19003-0N and MCP-310-19013-0B)
•Two passive CPU heatsinks (SNK-P0047PS)
•Cables
One CBL-0097L-03
One CBL-0118L-03
•Riser Cards
One RSC-R1UW-2E16
One RSC-R1UW-E8R
•SAS Accessories
One SAS backplane (BPN-SAS-119XTQ)
Eight drive carriers (MCP-220-00047-0B)
•SuperServer 1027R-72BRFTP Quick Reference Guide
Note: For your system to work properley, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
•Product manuals: http://www.supermicro.com/support/manuals/
•Product drivers and utilities: ftp://ftp.supermicro.com
•Product safety information:
http://super-dev/about/policies/safety_information.cfm
For support, email [email protected].
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 1027R-72BRFTP User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 1027R-72BRFTP. lies the X9DRW-7TPF, a dual
processor serverboard based on the Intel® C606 chipset. Below are the main
features of the serverboard. (See Figure 1-1 for a block diagram of the chipset).
Processors
The X9DRW-7TPF supports single or dual Intel® E5-2600 Series (Socket R) pro-
cessors in LGA 2011 sockets. Please refer to our web site for a complete listing of
supported processors (www.supermicro.com).
Memory
The X9DRW-7TPF features 16 DIMM slots that can support up to 512 GB of ECC
DDR3-1600/1333/1066/800 RDIMM SDRAM or 128 GB ECC/non-ECC UDIMM type
memory. Please refer to Chapter 5 for installing memory.
Onboard SAS
A SAS controller is integrated into the chipset to support eight SAS 2.0 ports. The
hot-swap SAS drives are connected to a backplane that provides power, bus ter-
mination and conguration settings. Unless otherwise stated, SAS is used in this
server by default.
Note: RAID 0, 1, 5, 6, 10, 50 and 60 is supported. Refer to the following ftp site
for setup guidelines:
<ftp://ftp.supermicro.com/driver/SAS/LSI/LSI_SAS_EmbMRAID_SWUG.pdf>.
Onboard Serial ATA
An on-chip SATA controller is integrated into the X9DRW-7TPF to provide a six-
port, SATA subsystem (two SATA 3.0 ports and four SATA 2.0 ports), which is
RAID 0, 1, 5 and 10 supported (RAID 5 is supported with Windows OS only).
Note: You must have RAID set up to enable the hot-swap capability of the SATA
drives. Documentation on RAID setup guidelines can be found on our web site.
Rear I/O Ports
The color-coded I/O ports include one COM port, a VGA (monitor) port, two USB
2.0 ports, PS/2 mouse and keyboard ports, two 1Gb LAN ports, two 10Gb SFP+
LAN ports and one dedicated IPMI LAN port.

1-3
Chapter 1: Introduction
1-3 Server Chassis Features
The 1027R-72BRFTP is built upon the SC119XTQ-R700WB chassis. Details on
the chassis and on servicing procedures can be found in Chapter 6.The following
is a general outline of the main features of the chassis.
System Power
The SC119XTQ-R700WB features two redundant 700W power supplies. The sys-
tem does not need to be shut down when replacing or removing a single power
supply module. The system also has two Battery Backup Power units.
Hard Drives
The chassis was designed to support eight hot-swap SAS or SATA hard drives.
PCI Expansion Slots
Two riser cards are included. The RSC-R1UW-E8R is located on the right side of the
chassis and supports one low-prole (max. length = 4.1") PCI-E x8 card. The RSC-
R1UW-2E16 is located on the left side of the chassis and supports two full-height,
half-length PCI-E x16 add-on cards. See section 5-6 of this manual for details.
Front Control Panel
The chassis' control panel provides you with system monitoring and control. LEDs
indicate system power, HDD activity, network activity (2), system information and
UID (Unit Identication). A main power button and a UID button is also included.
Cooling System
The system has an innovative cooling design that features six sets of 4-cm counter-
rotating fans located in the middle section of the chassis. Fan speed may be varied
by IPMI to respond to uctuations in system temperature. The power supply module
also includes a cooling fan.

1-4
SUPERSERVER 1027R-72BRFTP User's Manual
Figure 1-1. Intel C606 Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
P0 P1
PE3 PE2 DMI
DDR3 DIMM
CPU2
F
ESocket 01
#2
#1
DDR3 DIMM
#2
#1
x16
x16
x8
x16
x16
#1~#8
#1~#6
#7~#10
x8 [7..0]
x8 [15..8]
x4
PE1
x8 Gen3
RJ45
CPU0
PE3
RJ45
VGA CONN
SFP+ Conn + Cage
SFP+ Conn + Cage
LAN
PHY1
RTL8201F
x16
CPU1
PE3
x16
CPU1
PE2
DDR3 DIMM
H
G
#2
#1
DDR3 DIMM
#2
#1
P1 P0
PE3 PE2 DMI
DMI
PCH C602/C602J
SPI
SATA
SCU
USBUSB
LPC
PEG0
PEG1 [4:1]
PEG1_8
PCI
AT25321
BMC57810S
10G SFP+
Chipset
SAS2208
DDR3 DIMM
CPU1
D
CSocket 00
#2
#1
#2
#1
PE1
DDR3 DIMM
B
A
#2
#1
DDR3 DIMM
QPI QPI
#2
#1
USB
SATA
SAS
SATA
Powerville-2
L1/L2
REAR
HDR 2X5
0,1
TYPE-A
2,3 4,5 6
HDR 2X5
TPM
Header
WPCM450
VGABMC
DDR2
BBU Conn
DDR3 DDR3 DDR3
DDR3 DDR3
DDR3 DIMM
Processor
E5-2600 Series
Processor
E5-2600 Series
to WIO
Left WI
O
to WIO
x8
CPU0
PE2 [7..0]
x8
CPU1
PE1
Right WIO

1-5
Chapter 1: Introduction
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Web Site: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web Site: www.supermicro.com.tw

1-6
SUPERSERVER 1027R-72BRFTP User's Manual
Notes

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your 1027R-72BRFTP. up and
running. Following these steps in the order given should enable you to have the
system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory pre-installed. If
your system is not already fully integrated with a serverboard, processors, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specic components.
2-2 Unpacking the System
You should inspect the box the 1027R-72BRFTP. was shipped in and note if it was
damaged in any way. If the server itself shows damage you should le a damage
claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be
situated in a clean, dust-free area that is well ventilated. Avoid areas where heat,
electrical noise and electromagnetic elds are generated. You will also need it placed
near a grounded power outlet. Be sure to read the Rack and Server Precautions
in the next section.
2-3 Preparing for Setup
The box the server was shipped in should include two sets of rail assemblies, two
rail mounting brackets and the mounting screws you will need to install the system
into the rack. Follow the steps in the order given to complete the installation process
in a minimum amount of time. Please read this section in its entirety before you
begin the installation procedure outlined in the sections that follow.
Choosing a Setup Location
•Leave enough clearance in front of the rack to enable you to open the front door
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for sufcient airow and ease in servicing.This product is for

2-2
SUPERSERVER 1027R-72BRFTP User's Manual
installation only in a Restricted Access Location (dedicated equipment rooms,
service closets and the like).
•This product is not suitable for use with visual display work place devices
acccording to §2 of the the German Ordinance for Work with Visual Display
Units.
2-4 Warnings and Precautions
Rack Precautions
•Ensure that the leveling jacks on the bottom of the rack are fully extended to
the oor with the full weight of the rack resting on them.
•In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
•Always make sure the rack is stable before extending a component from the
rack.
•You should extend only one component at a time - extending two or more si-
multaneously may cause the rack to become unstable.
Server Precautions
•Review the electrical and general safety precautions in Chapter 4.
•Determine the placement of each component in the rack before you install the
rails.
•Install the heaviest server components on the bottom of the rack rst, and then
work up.
•Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
•Allow the hot plug SAS drives and power supply modules to cool before touch-
ing them.
•Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airow
Equipment should be mounted into a rack so that the amount of airow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).
Warning! To prevent bodily injury when mounting or servicing this unit in a
rack, you must take special precautions to ensure that the system remains
stable. The following guidelines are provided to ensure your safety:
•This unit should be mounted at the bottom of the rack if it is the only unit in
the rack.
•When mounting this unit in a partially lled rack, load the rack from the bottom
to the top with the heaviest component at the bottom of the rack.
•If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.

2-4
SUPERSERVER 1027R-72BRFTP User's Manual
2-5 Installing the System into a Rack
This section provides information on installing the server into a rack unit with the
rack rails provided. There are a variety of rack units on the market, which may mean
the assembly procedure will differ slightly. You should also refer to the installation
instructions that came with the rack unit you are using.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner xed chassis rail that secures directly
to the server chassis and an outer xed rack rail that secures directly to the rack
itself (see Figure 2-1).
Note: The rails will t a rack between 26" and 33.5" deep.
Figure 2-1. Identifying the Inner Rails and Inner Rail Extensions
Inner Rails
(Inner rails are pre-installed
on the chassis)
Inner Rail
Extensions

Chapter 2: Server Installation
2-5
Inner Rails
The SC119 chassis inner rails are composed of two sections: inner rails and inner
rail extensions. The inner rails are pre-attached and do not interfere with normal use
of the chassis if you decide not to use a server rack. Attach the inner rail extension
to stabilize the chassis within the rack.
Installing the Inner Rails
1. Place the inner rail extensions on the side of the chassis aligning the hooks
of the chassis with the rail extension holes. Make sure the extension faces
"outward" just like the pre-attached inner rail.
2. Slide the extension toward the front of the chassis.
3. Secure the chassis with 2 screws as illustrated.
4. Repeat steps 1-3 for the other inner rail extension.
1
1
1
2
1
3
Figure 2-2: Identifying the Sections of the Rack Rails
(right side rail shown)

2-6
SUPERSERVER 1027R-72BRFTP User's Manual
Outer Rails
Installing the Outer Rails to the Rack
1. Attach the shorter outer rail to the outside of the longer outer rail. You must
align the pins with the slides. Both bracket ends must face the same direction.
2. Adjust the outer rails so that they t snugly within the rack.
3. Secure the longer outer rail to the front of the rackl with two screws
4. Secire the shorter outer rail to the rear rack with three screws.
5. Repeat steps 1-4 for the remaining outer rail.
Locking Tabs
Both chassis rails have a locking tab, which serves two functions. The rst is to
lock the server into place when installed and pushed fully into the rack, which is
its normal position. Secondly, these tabs also lock the server in place when fully
extended from the rack. This prevents the server from coming completely out of
the rack when you pull it out for servicing.
Secure to the
Front of the
Rack
Secure to the
Rear of the Rack
Figure 2-3. Assembling the Outer Rails
Attach Outer Rails
Together
