Supero AS-1011S-MR2 User manual

AS1011S-MR2
USER’S MANUAL
1.0a
®
SUPER

Manual Revision 1.0a
Release Date: October 10, 2008
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.
IN NO EVENT WILLSUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATASTORED OR USED WITH THE PRODUCT, INCLUDINGTHE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2008 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of theAS1011S-MR2 server. Instal-
lation and maintenance should be performed by experienced technicians only.
The AS1011S-MR2 is a high-end server based on the SC512F-260 1U rack-
mount chassis and the H8SSL-i2, a single processor motherboard that supports
AMD Opteron 1000 series processors and up to 8 GB of ECC/non-ECC DDR2-
800/667/533 SDRAM.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the H8SSL-i2 motherboard and
the SC512F-260 chassis, which comprise the 1011S-MR2.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the 1011S-MR2 into a rack and
check out the server configuration prior to powering up the system. If your server
was ordered without processor and memory components, this chapter will refer you
to the appropriate se ctions of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

AS1011S-MR2 User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
1011S-MR2.
Chapter 5: Advanced Motherboard Setup
Chapter 5 provides detailed information on the H8SSL-i2 motherboard, including the
locations and functions of connections, headers and jumpers. Refer to this chapter
when adding or removing processors or main memory and when reconfiguring the
motherboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC512F-260 server chassis.
You should follow the procedures given in this chapter when installing, removing
or reconfiguring SATA or peripheral drives and when replacing the system power
supply and cooling fan.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS Error Beep Codes
Appendix B: BIOS POST Checkpoint Codes
Appendix C: System Specifications

v
Preface
Notes

vi
Table of Contents
Preface
About This Manual ...................................................................................................... iii
Manual Organization ................................................................................................... iii
Chapter 1: Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Motherboard Features .................................................................................... 1-2
1-3 Server Chassis Features ................................................................................ 1-5
1-4 Contacting Supermicro ................................................................................... 1-6
Chapter 2: Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System ................................................................................... 2-1
2-3 Preparing for Setup ........................................................................................ 2-1
2-4 Installing the System into a Rack ................................................................... 2-4
2-5 Checking the Motherboard Setup ................................................................... 2-8
2-6 Checking the Drive Bay Setup ..................................................................... 2-11
Chapter 3: System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons .................................................................................... 3-1
Reset ........................................................................................................ 3-1
Power ....................................................................................................... 3-1
3-3 Control Panel LEDs ........................................................................................ 3-2
Overheat/Fan Fail .................................................................................... 3-2
NIC2 ......................................................................................................... 3-2
NIC1 ......................................................................................................... 3-2
HDD .......................................................................................................... 3-2
Power ....................................................................................................... 3-3
Chapter 4: System Safety
4-1 Electrical Safety Precautions .......................................................................... 4-1
4-2 General Safety Precautions ........................................................................... 4-2
4-3 ESD Precautions ............................................................................................ 4-3
4-4 Operating Precautions .................................................................................... 4-4
AS1011S-MR2 User's Manual

Chapter 5: Advanced Motherboard Setup
5-1 Handling the Motherboard .............................................................................. 5-1
5-2 Mounting the Motherboard into a Chassis ..................................................... 5-2
5-3 Processor and Heatsink Installation ............................................................... 5-2
5-4 Connecting Cables ......................................................................................... 5-5
Connecting Data Cables .......................................................................... 5-5
Connecting Power Cables ....................................................................... 5-5
Connecting the Control Panel .................................................................. 5-6
5-5 I/O Ports ......................................................................................................... 5-7
5-6 Installing Memory ........................................................................................... 5-7
5-7 Adding PCI Cards ........................................................................................... 5-9
5-8 Motherboard Details ..................................................................................... 5-10
H8SSL-i2 Layout .................................................................................... 5-10
H8SSL-i2 Quick Reference .................................................................... 5-11
5-9 Connector Definitions ................................................................................... 5-12
Primary ATX Power Connector .............................................................. 5-12
Secondary Power Connector ................................................................. 5-12
NMI Button ............................................................................................. 5-12
Power LED ............................................................................................. 5-12
HDD LED ............................................................................................... 5-13
NIC1 LED ............................................................................................... 5-13
NIC2 LED ............................................................................................... 5-13
Overheat/Fan Fail LED .......................................................................... 5-13
Power Fail LED ...................................................................................... 5-13
Reset Button .......................................................................................... 5-14
Power Button .......................................................................................... 5-14
USB0/1 (Universal Serial Bus Ports) ..................................................... 5-14
Serial ATA Activity LEDs ......................................................................... 5-14
USB2/3 Headers .................................................................................... 5-15
Serial Ports ............................................................................................. 5-15
Fan Headers .......................................................................................... 5-15
Overheat LED ........................................................................................ 5-15
Power LED/Speaker ............................................................................... 5-16
ATX PS/2 Keyboard and Mouse Ports .................................................. 5-16
Wake-On-Ring ........................................................................................ 5-16
Wake-On-LAN ........................................................................................ 5-16
LAN1/2 (Ethernet Ports) ......................................................................... 5-17
Chassis Intrusion .................................................................................... 5-17
Power I2C Header .................................................................................. 5-17
vii
Table of Contents

viii
Power Supply Fail Alarm Header ........................................................... 5-17
Power Supply Fail Alarm Reset Header ................................................ 5-17
5-10 Jumper Settings ............................................................................................ 5-18
Explanation of Jumpers ......................................................................... 5-18
CMOS Clear ........................................................................................... 5-18
Onboard Speaker Enable/Disable .......................................................... 5-19
PCI-X Slot Speed ................................................................................... 5-19
VGA Enable/Disable ............................................................................... 5-19
LAN Enable/Disable ............................................................................... 5-19
Watch Dog Enable/Disable .................................................................... 5-20
Power Force On Enable/Disable ............................................................ 5-20
I2C Enable/Disable ................................................................................. 5-20
5-11 Onboard Indicators ....................................................................................... 5-21
LAN1/LAN2 LEDs .................................................................................. 5-21
SATA Activity LEDs ................................................................................ 5-21
Onboard Power LED .............................................................................. 5-21
5-12 Floppy, IDE and SATA Drive Connections ................................................... 5-22
Floppy Connector ................................................................................... 5-22
IDE Connector ........................................................................................ 5-23
SATA Ports ............................................................................................. 5-23
5-13 Enabling SATA RAID .................................................................................... 5-24
Chapter 6: Advanced Chassis Setup
6-1 Static-Sensitive Devices ................................................................................. 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 System Fans ................................................................................................... 6-2
System Fan Failure .................................................................................. 6-3
Replacing System Cooling Fans .............................................................. 6-3
6-4 Drive Bay Installation/Removal ....................................................................... 6-4
Serial ATA Drive Installation ..................................................................... 6-4
CD-ROM Drive Installation ....................................................................... 6-5
6-5 Power Supply ................................................................................................. 6-6
Power Supply Failure ............................................................................... 6-6
Replacing the Power Supply .................................................................... 6-6
Chapter 7: BIOS
7-1 Introduction ..................................................................................................... 7-1
7-2 Main Menu ...................................................................................................... 7-2
7-3 Advanced Settings Menu ............................................................................... 7-2
7-4 Boot Menu .................................................................................................... 7-13
AS1011S-MR2 User's Manual

Table of Contents
ix
7-5 Security Menu ............................................................................................... 7-13
7-6 Exit Menu ...................................................................................................... 7-14
Appendices:
Appendix A: BIOS Error Beep Codes ...................................................................... A-1
Appendix B: BIOS POST Checkpoint Codes ........................................................... B-1
Appendix C: System Specifications ........................................................................ C-1

Notes
x
AS1011S-MR2 User's Manual

Chapter 1
Introduction
1-1 Overview
The AS1011S-MR2 is a high-end single processor, mini 1U rackmount server.
The 1011S-MR2 is comprised of two main subsystems: the SC512F-260 chassis
and the H8SSL-i2 motherboard. The H8SSL-i2 supports a single AMD Opteron
1000 series processor in a 940-pin AM2 socket and up to 8 GB of ECC/non-ECC
DDR2-800/667/533 SDRAM memory. Please refer to our web site for information
on operating systems that have been certified for use with the 1011S-MR2 and for
regular updates on supported processor speeds.
In addition to the motherboard and chassis, various hardware components may
have been included with the 1011S-MR2, as listed below.
 One (1) slim CD-ROM drive (CDM-TEAC-24)
 One (1) SATA cable (CBL-0178L)
 Two (2) 4-cm counter-rotating fans (FAN-0087)
 One (1) air shroud (MCP-310-00027-01)
 One (1) passive heatsink for AM2 CPU (SNK-P0026)
 One (1) 3.3V 64-bit, 66 MHz PCI-X slot riser card (CSE-RR1U-X)
 Rackmount hardware with screws (CSE-PT8) (optional):
Two (2) rack rail assemblies
Six (6) brackets for mounting the rack rails in a rack/telco rack
 One (1) CD containing drivers and utilities
Chapter 1: Introduction
1-1

1-2
AS1011S-MR2 User's Manual
1-2 Motherboard Features
At the heart of the 1011S-MR2 lies the H8SSL-i2, a single processor motherboard
designed to provide maximum performance. Below are the main features of the
H8SSL-i2. (See Figure 1-1 for a block diagram of the ServerWorks HT-1000
chipset.)
Processors
The H8SSL-i2 has a 940-pin AM2 type socket that supports a single AMD Opteron
Series 1000 processor. Please refer to the support section of our web site for a
complete listing of supported processors.
Memory
The H8SSL-i2 has four (4) 240-pin DIMM sockets that can support up to 8 GB of
ECC/non-ECC DDR2-800/667/533 SDRAM. (Memory can operate in either single
or dual dual-channel mode.)
Serial ATA
A Serial ATA controller is incorporated into the ServerWorks HT-1000 chipset. The
single Serial ATA drive in the 1011S-MR2 is not hot-swappable. No RAID is sup-
ported due to the single hard drive configuration.
PCI Expansion Slots
The H8SSL-i2 has one 64-bit, 133 MHz (3.3V) PCI-X slot and two 32-bit, 33 MHz
(5V) PCI slots. When incorporated into the 1011S-MR2 server system, a riser card
(CSE-RR1U-X) is included for use with the PCI-X slot to support one full-height,
half-length expansion card in the 133 MHz PCI-X slot.
Ethernet Ports
A Broadcom BCM5704 Ethernet controller is incorporated into the H8SSL-i2 to
support two Gigabit LAN ports.
Graphics Controller
The 1011S-MR2 features an integrated video controller based on the ES1000
graphics chip. The ES1000 was designed specifically for servers, featuring low
power consumption, high reliability and superior longevity.

Chapter 1: Introduction
1-3
Onboard Controllers/Ports
An onboard IDE controller supports one floppy drive and one Ultra ATA 100 hard
drive or ATAPI device. Onboard I/O backpanel ports include one serial COM port,
two USB ports, a VGA (monitor) port, PS/2 mouse and keyboard ports and two
GLAN (RJ45) ports.
Other Features
Other onboard features that promote system health include voltage monitors, a
chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.

1-4
AS1011S-MR2 User's Manual
Figure 1-1. ServerWorks HT-1000 Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
ServerWorks
HT-1000
AMD
Opteron
TM
Processor (AM2)
240-pin DIMMs
8x HT @ 1.6 GB/sec 144-bit, 200 -400 MT/s
ATI
ES1000
BCM5704C
PCI-X 133 MHz Slot
UDMA/100
USB 2.0
Winbond
83793G
Super I/O PS/2 Kybd/Mouse
Floppy Disk Drive
Serial Ports
BIOS
LPC Link
SATA
Ports (4)
33 MHz Bus
33 MHz PCI Slots (2)
133 MHz Bus

Chapter 1: Introduction
1-5
1-3 Server Chassis Features
The 1011S-MR2 is a mini 1U rackmount server platform configuration. The following
is a general outline of the main features of the SC512F-260 chassis.
System Power
When configured as a 1011S-MR2, the SC512F-260 chassis includes a single
260W power supply.
Control Panel
The SC512F-260's control panel provides important system monitoring and control
information. LEDs indicate power on, network activity, hard disk drive activity,
overheat warning and fan failure. The control panel also includes a main power
button and a system reset button.
Rear I/O Panel
The rear I/O panel on the SC512F-260 provides one motherboard expansion slot,
one COM port (another is internal), two USB ports, PS/2 mouse and keyboard ports,
a VGA (graphics) port and two Gb Ethernet ports. (See Chapter 6 for diagram.)
Cooling System
The SC512F-260/SC513F-260 chassis has an innovative cooling design that
features an air shroud and two sets of counter-rotating fans with user-defined fan
speed control.

1-6
AS1011S-MR2 User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone], ext.132 or 139

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your 1011S-MR2 up and run-
ning. Following the steps in the order given should enable you to have the system
operational within a minimal amount of time. This quick setup assumes that your
1011S-MR2 system has come to you with the processor and memory preinstalled.
If your system is not already fully integrated with a motherboard, processor, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specific components.
2-2 Unpacking the System
You should inspect the box the 1011S-MR2 was shipped in and note if it was dam-
aged in any way. If the server itself shows damage, you should file a damage claim
with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the 1011S-MR2. It should
be situated in a clean, dust-free area that is well ventilated. Avoid areas where
heat, electrical noise and electromagnetic fields are generated. You will also need
it placed near a grounded power outlet. Read the Rack and Server Precautions in
the next section.
2-3 Preparing for Setup
The 1011S-MR2 does not ship with a rack rail hardware package as the system
can be rack mounted without the use of rails. An optional rack rail package is
available if you wish to order from Supermicro. Follow the steps in the order given
to complete the installation process in a minimal amount of time. Please read this
section in its entirety before you begin the installation procedure outlined in the
sections that follow.

2-2
AS1011S-MR2 User's Manual
Choosing a Setup Location
- Leave enough clearance in front of the rack to enable you to open the front
door completely (~25 inches).
- Leave approximately 30 inches of clearance in the back of the rack to allow
for sufficient airflow and ease in servicing.
- This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
Rack Precautions
- Ensure that the leveling jacks on the bottom of the rack are fully extended to
the floor with the full weight of the rack resting on them.
- In a single rack installation, stabilizers should be attached to the rack.
- In multiple rack installations, the racks should be coupled together.
- Always make sure the rack is stable before extending a component from the
rack.
- You should extend only one component at a time - extending two or more
simultaneously may cause the rack to become unstable.
Server Precautions
- Review the electrical and general safety precautions in Chapter 4.
- Determine the placement of each component in the rack before you install the
rails.
- Install the heaviest server components on the bottom of the rack first, and then
work up.
- Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
-
Allow the power supply units to cool before touching them.
- Always keep the rack's front door and all panels and components on the serv-
ers closed when not servicing to maintain proper cooling.
!
!
Warnings and Precautions!

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).

2-4
AS1011S-MR2 User's Manual
2-4 Installing the System into a Rack
(Rack hardware optional)
This section provides information on installing the 1011S-MR2 into a rack unit. If
the system has already been mounted into a rack, you can skip ahead to Sections
2-5 and 2-6.
Basic Installation Procedure
The 1011S-MR2 server comes with two rack mounting brackets, which are located
on each side at the front of the chassis. To mount the system into a rack, simply
screw these brackets directly to the front of the rack (two screws for each bracket).
As Figure 2-1 shows, the brackets can be located at the front of the chassis (left
figure) or moved approximately one-third to the rear of the chassis (right figure).
Figure 2-1. Installing the Server into a Rack: Basic
