Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the AS1021M-T2R. Installation
and maintainance should be performed by experienced technicians only.
The AS1021M-T2R is a 1U server based on the SC815TQ-R650 rackmount chassis
and the Super H8DMR-i2, a dual processor serverboard that supports AMD Socket
F type processors and up to 16 GB of registered ECC DDR2-667/533 or 32 GB of
registered ECC DDR2-400 SDRAM.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the H8DMR-i2 serverboard and
the SC815TQ-R650 chassis, which comprise the AS1021M-T2R.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the AS1021M-T2R into a rack
and check out the server configuration prior to powering up the system. If your
server was ordered without processor and memory components, this chapter will
refer you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

AS1021M-T2R User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
AS1021M-T2R.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the H8DMR-i2 serverboard, including the
locations and functions of connections, headers and jumpers. Refer to this chapter
when adding or removing processors or main memory and when reconfiguring the
serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC815TQ-R650 server chassis.
You should follow the procedures given in this chapter when installing, removing or
reconfiguring SATA or peripheral drives and when replacing system power supply
modules and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS Error Beep Codes
Appendix B: BIOS POST Checkpoint Codes
Appendix C: System Specifications
