Supero SUPERSERVER 6014P-T User manual

SUPERSERVER 6014P-T
SUPERSERVER 6014P-TR
USER’S MANUAL
1.0a
SUPER ®

Manual Revision 1.0a
Release Date: October 8, 2007
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
SUPER MICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documenta-
tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2007 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the SuperServer 6014P-
T/6014P-TR. Installation and maintainance should be performed by experienced
technicians only.
The SuperServer 6014P-T/6014P-TR is a high-end server based on the SC814+T-
560/SC814+T-R560 1U rackmount chassis and the Super X6DHP-TG, a dual
processor serverboard that supports Intel®64-bit XeonTM processors at a Front
Side (System) Bus speed of 800 MHz and up to 12/24 GB of registered ECC
DDR333/266 SDRAM.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the X6DHP-TG serverboard
and the SC814+T-560/SC814+T-R560 chassis, which comprise the SuperServer
6014P-T/6014P-TR.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 6014P-
T/6014P-TR into a rack and check out the server configuration prior to powering
up the system. If your server was ordered without processor and memory com-
ponents, this chapter will refer you to the appropriate sections of the manual for
their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

SUPERSERVER 6014P-T/6014P-TR User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 6014P-T/6014P-TR.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X6DHP-TG serverboard, including
the locations and functions of connections, headers and jumpers. Refer to this
chapter when adding or removing processors or main memory and when reconfig-
uring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC814+T-560/SC814+T-R560
server chassis. You should follow the procedures given in this chapter when install-
ing, removing or reconfiguring Serial ATA or peripheral drives and when replacing
system power supply modules and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS POST Codes
Appendix B: Software Installation
Appendix C: System Specifications

v
Preface
Notes

vi
Table of Contents
Preface
About This Manual ...................................................................................................... iii
Manual Organization ................................................................................................... iii
Chapter 1: Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
1-3 Server Chassis Features ................................................................................ 1-3
1-4 Contacting Supermicro ................................................................................... 1-6
Chapter 2: Server Installation
2-1 Overview .......................................................................................................... 2-1
2-2 Unpacking the System ................................................................................... 2-1
2-3 Preparing for Setup ......................................................................................... 2-1
Choosing a Setup Location .................................................................... 2-2
Rack Precautions .................................................................................... 2-2
Server Precautions ................................................................................. 2-2
Rack Mounting Considerations ............................................................... 2-3
2-4 Installing the System into a Rack.................................................................... 2-4
2-5 Checking the Serverboard Setup .................................................................... 2-8
2-6 Checking the Drive Bay Setup ...................................................................... 2-10
Chapter 3: System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons .................................................................................... 3-1
UID .......................................................................................................... 3-1
Power ...................................................................................................... 3-1
3-3 Control Panel LEDs ........................................................................................ 3-2
UID ............................................................................................................ 3-2
Overheat/Fan Fail .................................................................................. 3-2
NIC2 ........................................................................................................ 3-2
NIC1 ........................................................................................................ 3-2
HDD ........................................................................................................ 3-3
Power ...................................................................................................... 3-3
3-4 Serial ATA Drive Carrier LED........................................................................... 3-3
SUPERSERVER 6014P-T/6014P-TR User's Manual

Chapter 4: System Safety
4-1 Electrical Safety Precautions........................................................................... 4-1
4-2 General Safety Precautions............................................................................. 4-2
4-3 ESD Precautions ............................................................................................ 4-3
4-4 Operating Precautions .................................................................................... 4-4
Chapter 5: Advanced Serverboard Setup
5-1 Handling the Serverboard................................................................................ 5-1
5-2 Processor and Heatsink Installation ................................................................ 5-2
5-3 Connecting Cables .......................................................................................... 5-5
Connecting Data Cables ........................................................................... 5-5
Connecting Power Cables......................................................................... 5-5
Connecting the Control Panel ................................................................... 5-6
5-4 I/O Ports ......................................................................................................... 5-7
5-5 Installing Memory............................................................................................. 5-7
5-6 Adding PCI Cards............................................................................................ 5-9
5-7 Serverboard Details ...................................................................................... 5-10
X6DHP-TG Layout .................................................................................. 5-10
X6DHP-TG Quick Reference .................................................................. 5-11
5-8 Connector Definitions .................................................................................... 5-12
ATX Power Connector .......................................................................... 5-12
Processor Power Connector ................................................................... 5-12
Power LED .............................................................................................. 5-12
NMI Button ............................................................................................ 5-12
HDD LED .............................................................................................. 5-13
NIC1/NIC2 LEDs ................................................................................... 5-13
Overheat/Fan Fail LED .......................................................................... 5-13
Power ail LED ........................................................................................ 5-13
UID Button & UID LED ......................................................................... 5-14
Power Button ........................................................................................ 5-14
Chassis Intrusion..................................................................................... 5-14
JLAN 1/2 (Ethernet Ports) ...................................................................... 5-14
Universal Serial Bus (USB0/1)................................................................ 5-15
Universal Serial Bus Headers ................................................................. 5-15
Fan Headers............................................................................................ 5-15
Serial Ports.............................................................................................. 5-15
Power LED/Speaker................................................................................ 5-16
Wake-On-Ring ......................................................................................... 5-16
ATX PS/2 Keyboard and PS/2 Mouse Ports ......................................... 5-16
vii
Table of Contents

viii
SMB......................................................................................................... 5-17
SMB Power Connector............................................................................ 5-17
5-9 Jumper Settings............................................................................................. 5-18
Explanation of Jumpers........................................................................... 5-18
CMOS Clear ............................................................................................ 5-18
VGA Enable/Disable................................................................................ 5-18
JLAN Enable/Disable ............................................................................. 5-19
SATA Enable/Disable............................................................................... 5-19
BIOS Debug ............................................................................................ 5-19
Watch Dog............................................................................................... 5-20
Memory Speed Select............................................................................. 5-20
5-10 Onboard Indicators ........................................................................................ 5-21
JLAN LEDs.............................................................................................. 5-21
Unit Identifier (UID) ................................................................................. 5-21
5-11 Floppy and Hard Disk Drive Connections ..................................................... 5-22
Floppy Connector .................................................................................... 5-22
IDE Connectors ....................................................................................... 5-23
Chapter 6: Advanced Chassis Setup
6-1 Static-Sensitive Devices .................................................................................. 6-1
6-2 Control Panel ................................................................................................... 6-2
6-3 System Fans.................................................................................................... 6-3
System Fan Failure ................................................................................... 6-3
Replacing System Cooling Fans............................................................... 6-3
6-4 Drive Bay Installation/Removal........................................................................ 6-4
Serial ATA Drive Installation ...................................................................... 6-5
DVD/CD-ROM and Floppy Drive Installation ............................................ 6-7
6-5 Power Supply................................................................................................... 6-8
6014P-TR: Power Supply Failure ............................................................. 6-8
6014P-TR: Removing/Replacing the Power Supply ................................. 6-8
6014P-T: Power Supply Failure ................................................................ 6-9
6014P-T: Removing/Replacing the Power Supply .................................... 6-9
Reconfiguring the Power Supply............................................................. 6-10
Chapter 7: BIOS
7-1 Introduction ...................................................................................................... 7-1
7-2 Running Setup ................................................................................................ 7-2
7-3 Main BIOS Setup ............................................................................................ 7-2
7-4 Advanced Setup ............................................................................................. 7-7
7-5 Security ......................................................................................................... 7-18
SUPERSERVER 6014P-T/6014P-TR User's Manual

Table of Contents
ix
7-6 Boot .............................................................................................................. 7-19
7-7 Exit ................................................................................................................ 7-20
Appendices:
Appendix A: BIOS POST Codes
Appendix B: Software Installation
Appendix C: System Specifications

Notes
x
SUPERSERVER 6014P-T/6014P-TR User's Manual

Chapter 1
Introduction
1-1 Overview
The SuperServer 6014P-T/6014P-TR is a high-end server comprised of two main
subsystems: the SC814+T-560/SC814+T-R560 1U server chassis and the X6DHP-
TG dual processor serverboard. Please refer to our web site for information on
operating systems that have been certified for use with the SuperServer 6014P-
T/6014P-TR (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the 6014P-T/6014P-TR, as listed below:
 One (1) slim floppy drive [FPD-TEAC-S(B)]
 One (1) slim 8x DVD/24x CD-ROM drive [DVM-PNSC-824(B)]
 Five (5) sets of 40-mm counter-rotating fans (FAN-0079)
 One (1) front control panel cable
 One (1) rackmount kit (CSE-PT51)
 One (1) rear COM port kit
 Riser Cards: (see section 5-6 for details)
6014P-T: One (1) riser card (CSE-RR1U-XR) for PCI-X add-on card
One (1) riser card (CSE-RR1U-X) for PCI-X add-on card
One (1) riser card (CSE-RR1U-ER) for PCI-E add-on card
One (1) riser card (CSE-RR1U-EL) for PCI-E add-on card
6014P-TR: One (1) riser card (CSE-RR1U-XR) for PCI-X add-on card
One (1) riser card (CSE-RR1U-ER) for PCI-E add-on card
 Serial ATA Accessories
One (1) Serial ATA backplane (CSE-SAS-814)
One (1) SATA 4-lane cable (CBL-0090)
Four (4) SATA drive carriers [CSE-PT39(B)]
 One (1) CD containing drivers and utilities
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 6014P-T/6014P-TR User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 6014P-T/6014P-TR lies the X6DHP-TG, a dual
processor serverboard based on Intel's E7520 chipset. Below are the main features
of the X6DHP-TG (see Figure 1-1 for a block diagram of the chipset).
Processors
The X6DHP-TG supports single or dual 604-pin Intel Xeon EM64T type processors
at a FSB speed of 800 MHz. Please refer to the serverboard description pages on
our web site for a complete listing of supported processors.
Memory
The X6DHP-TG has six 184-pin DIMM sockets that can support up to 12 GB of
registered ECC DDR333 (PC2700) or up to 24 GB of registered ECC DDR266
(PC2100) SDRAM. The memory is an interleaved configuration, which requires
modules of the same size and speed to be installed in pairs. Please refer to Chapter
5 for memory speed jumper settings.
Serial ATA
A Marvell SATA controller is integrated into the X6DHP-TG to provide a four-port
Serial ATA subsystem, which is RAID 0 and 1 supported. The ICH5R South Bridge
of the chipset also includes a Serial ATA controller that supports two SATA ports
(RAID 0, 1 and JBOD supported). The SATA drives are hot-swappable units.
Notes: The operating system you use must have RAID support to enable the
hot-swap capability and RAID function of the Serial ATA drives. The system sup-
ports Zero Channel RAID (ZCR) with an Adaptec 2020SA card (not included) in
the JPCIX1 slot (RAID levels 0, 1, 5 and 10 supported).
Onboard Controllers/Ports
One floppy drive controller and two onboard ATA/100 controllers are provided to
support up to four IDE hard drives or ATAPI devices. The color-coded I/O ports
include one COM port*, a VGA (monitor) port, two USB 2.0 ports, PS/2 mouse and
keyboard ports and two gigabit Ethernet ports.
*The backpanel COM port is available with the use of the rear COM port kit (included
with system). COM1 and COM2 are both headers on the X6DHP-TG.
 SuperServer 6014P-T/6014P-TR User's Manual

1-3
Chapter 1: Introduction
ATI Graphics Controller
The X6DHP-TG features an integrated ATI video controller based on the Rage XL
graphics chip. Rage XL fully supports sideband addressing and AGP texturing.
This onboard graphics package can provide a bandwidth of up to 512 MB/sec over
a 32-bit graphics memory bus.
Other Features
Other onboard features that promote system health include onboard voltage moni-
tors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.
1-3 Server Chassis Features
The SuperServer 6014P-T/6014P-TR is a high-end, scaleable server platform built
upon the SC814+T-560/SC814+T-R560 1U server chassis. The following is a gen-
eral outline of the main features of the SC814T-560/SC814T-R560 chassis.
System Power
6014P-T: the SC814+T-560 features a single 560W cold-swap power supply. Power
must be removed from the system before servicing or replacing the power supply.
6014P-TR: the SC814+T-R560 features a redundant 560W hot-swap power supply
that consists of two power modules. One power supply module will take over if the
other fails. The hot-swap capability allows you to replace a failed power supply
module without having to power down the system.
Serial ATA Subsystem
The SC814+T-560/SC814+T-R560 chassis was designed to support four Serial
ATA hard drives, which are hot-swappable units.
Note: The operating system you use must have RAID support to enable the hot-
swap capability of the Serial ATA drives.

1-4
SUPERSERVER 6014P-T/6014P-TR User's Manual
PCI Expansion Slots
6014P-T: supports the use of two standard size PCI-X add-on cards (of up to 100
MHz) or two standard size PCI-Express x8 add-on cards (with riser cards). See
section 5-6 for details.
6014P-TR: supports the use of one standard size 100 MHz PCI-X or PCI-Express
x8 add-on card (with riser card). See section 5-6 for details.
Front Control Panel
The SC814+T-560/SC814+T-R560's control panel provides you with system moni-
toring and control. LEDs indicate UID, system power, HDD activity, network activ-
ity (2) and overheat/fan failure. A main power button and a UID button are also
included. See page 5-21 for details on the UID (Unit Identifier).
I/O Backplane
The SC814+T-560/SC814+T-R560 is an ATX form factor chassis that is designed
to be used in a 1U rackmount configuration. Ports on the I/O backplane include
one COM port, a VGA port, two USB 2.0 ports, PS/2 mouse and keyboard ports
and two gigabit Ethernet ports. A UID button/LED is also included on the server
backplane.
Cooling System
The SC814+T-560/SC814+T-R560 chassis has an innovative cooling design that
features five sets of 40-mm counter-rotating fans located in the middle section of
the chassis. There is a "Fan Speed Control Mode" setting in BIOS (page 7-16)
that allows chassis fan speed to be determined by system temperature [recom-
mended setting is "3-pin (Server)]. The power supply module(s) also includes a
cooling fan.

1-5
Chapter 1: Introduction
Figure 1-1. Intel E7520 Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.

1-6
SUPERSERVER 6014P-T/6014P-TR User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro, Taiwan
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone], ext.132 or 139

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperServer 6014P-
T/6014P-TR up and running. Following these steps in the order given should enable
you to have the system operational within a minimum amount of time. This quick
setup assumes that your system has come to you with the processors and memory
preinstalled. If your system is not already fully integrated with a serverboard, pro-
cessors, system memory etc., please turn to the chapter or section noted in each
step for details on installing specific components.
2-2 Unpacking the System
You should inspect the box the SuperServer 6014P-T/6014P-TR was shipped in and
note if it was damaged in any way. If the server itself shows damage you should
file a damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the 6014P-T/6014P-TR.
It should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic fields are generated. You will also
need it placed near a grounded power outlet. Be sure to read the Rack and Server
Precautions in the next section.
2-3 Preparing for Setup
The box the SuperServer 6014P-T/6014P-TR was shipped in should include two
sets of rail assemblies, two rail mounting brackets and the mounting screws you
will need to install the system into the rack. Follow the steps in the order given to
complete the installation process in a minimum amount of time. Please read this
section in its entirety before you begin the installation procedure outlined in the
sections that follow.

2-2
SUPERSERVER 6014P-T/6014P-TR User's Manual
Choosing a Setup Location
- Leave enough clearance in front of the rack to enable you to open the front
door completely (~25 inches).
- Leave approximately 30 inches of clearance in the back of the rack to allow
for sufficient airflow and ease in servicing.
- This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
- This product is not suitable for use with visual display work place devices
acccording to §2 of the the German Ordinance for Work with Visual Display
Units.
Rack Precautions
- Ensure that the leveling jacks on the bottom of the rack are fully extended to
the floor with the full weight of the rack resting on them.
- In single rack installation, stabilizers should be attached to the rack.
- In multiple rack installations, the racks should be coupled together.
- Always make sure the rack is stable before extending a component from the
rack.
- You should extend only one component at a time - extending two or more
simultaneously may cause the rack to become unstable.
Server Precautions
- Review the electrical and general safety precautions in Chapter 4.
- Determine the placement of each component in the rack before you install the
rails.
- Install the heaviest server components on the bottom of the rack first, and then
work up.
- Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
-Allow the hot plug SATA drives and power supply modules to cool before touch-
ing them.
-
Always keep the rack's front door and all panels and components on the serv-
ers closed when not servicing to maintain proper cooling.
!!
Warnings and Precautions!

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).

2-4
SUPERSERVER 6014P-T/6014P-TR User's Manual
2-4 Installing the System into a Rack
This section provides information on installing the 6014P-T/6014P-TR into a rack
unit with the rack rails provided. If the system has already been mounted into a
rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack
units on the market, which may mean the assembly procedure will differ slightly.
You should also refer to the installation instructions that came with the rack unit
you are using.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner fixed chassis rail that secures directly
to the server chassis and an outer fixed rack rail that secures directly to the rack
itself (see Figure 2-1). Two pairs of short brackets to be used on the front side of
the outer rails are also included.
Installing the Inner Rails
Both the left and right side inner rails have been pre-attached to the chassis.
Proceed to the next step. A
Figure 2-1. Identifying the Sections of the Rack Rails
(right side rail shown)
