Supero SUPERSERVER 1026TT-TF User manual

SUPER
SUPERSERVER 1026TT-TF
SUPERSERVER 1026TT-IBXF
S
UPERSERVER 1026TT-IBQF
USER’S MANUAL
Revision 1.0a
®

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILLSUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATASTORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful interference
with radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-
ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro-
ductive harm.
Manual Revision 1.0a
Release Date: September 2, 2010
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2010 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the SuperServer 1026TT-
TF/1026TT-IBXF/1026TT-IBQF. Installation and maintenance should be performed
by experienced technicians only.
The SuperServer 1026TT-TF/1026TT-IBXF/1026TT-IBQF is a 1U Twin (two server-
boards in a 1U chassis) rackmount server based on the SC809TQ-1200B chassis
and two Super X8DTT-F/X8DTT-IBXF/X8DTT-IBQFserverboards.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the Super X8DTT-F/X8DTT-IBXF/
X8DTT-IBQF serverboard and the SC809TQ-1200B chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 1026TT-
TF/1026TT-IBXF/1026TT-IBQF into a rack and check out the server configuration
prior to powering up the system. If your server was ordered without the processor
and memory components, this chapter will refer you to the appropriate sections of
the manual for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
iii
Preface

SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 1026TT-TF/1026TT-IBXF/1026TT-IBQF.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X8DTT-F/X8DTT-IBXF/X8DTT-IBQF
serverboard, including the locations and functions of connectors, headers and jump-
ers. Refer to this chapter when adding or removing processors or main memory
and when reconfiguring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC809TQ-1200B 1U rackmount
server chassis. You should follow the procedures given in this chapter when install-
ing, removing or reconfiguring SATAor peripheral drives and when replacing system
power supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS Error Beep Codes
Appendix B: Installing Windows
Appendix C: System Specifications

v
Preface
Notes

vi
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
Table of Contents
Chapter 1 Introduction
1-1 Overview .........................................................................................................1-1
1-2 Serverboard Features..................................................................................... 1-2
Processors ......................................................................................................1-2
Memory ...........................................................................................................1-2
Serial ATA........................................................................................................1-2
PCI Expansion Slots....................................................................................... 1-2
Ethernet Ports................................................................................................. 1-2
Onboard Controllers/Ports ..............................................................................1-3
Graphics Controller......................................................................................... 1-3
Other Features................................................................................................1-3
InfiniBand ........................................................................................................1-3
1-3 Server Chassis Features ................................................................................1-5
System Power................................................................................................. 1-5
SATA Subsystem............................................................................................. 1-5
Control Panel ..................................................................................................1-5
Rear I/O Panel................................................................................................ 1-5
Cooling System...............................................................................................1-5
1-4 1U Twin: System Notes...................................................................................1-6
System Power................................................................................................. 1-6
SATA Backplane/Drives...................................................................................1-6
1-5 Contacting Supermicro....................................................................................1-7
Chapter 2 Server Installation
2-1 Overview .........................................................................................................2-1
2-2 Unpacking the System.................................................................................... 2-1
2-3 Preparing for Setup......................................................................................... 2-1
Choosing a Setup Location............................................................................. 2-1
Rack Precautions............................................................................................ 2-2
Server Precautions..........................................................................................2-2
Rack Mounting Considerations.......................................................................2-3
Ambient Operating Temperature................................................................2-3
Reduced Airflow .........................................................................................2-3
Mechanical Loading ...................................................................................2-3
Circuit Overloading..................................................................................... 2-3
Reliable Ground .........................................................................................2-3
2-4 Installing the Server into a Rack..................................................................... 2-4

vii
Table of Contents
Identifying the Sections of the Rack Rails......................................................2-4
Installing the Rack Rails .................................................................................2-5
Installing the Server into a Rack..................................................................... 2-6
Installing the Server into a Telco Rack........................................................... 2-7
2-5 Checking the Serverboard Setup.................................................................... 2-8
2-6 Preparing to Power On................................................................................... 2-9
Chapter 3 System Interface
3-1 Overview .........................................................................................................3-1
3-2 Control Panel Buttons..................................................................................... 3-1
Reset...............................................................................................................3-1
Power..............................................................................................................3-1
3-3 Control Panel LEDs ........................................................................................3-2
Overheat/Fan Fail ...........................................................................................3-2
NIC2................................................................................................................3-2
NIC1................................................................................................................3-2
HDD................................................................................................................. 3-2
Power..............................................................................................................3-3
3-4 Drive Carrier LEDs.......................................................................................... 3-3
Chapter 4 System Safety
4-1 Electrical Safety Precautions..........................................................................4-1
4-2 General Safety Precautions............................................................................ 4-2
4-3 ESD Precautions............................................................................................. 4-3
4-4 Operating Precautions ....................................................................................4-4
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard............................................................................... 5-1
Precautions .....................................................................................................5-1
Unpacking .......................................................................................................5-2
5-2 Serverboard Installation.................................................................................. 5-2
5-3 Connecting Cables.......................................................................................... 5-3
Connecting Data Cables................................................................................. 5-3
Connecting Power Cables .............................................................................. 5-3
Connecting the Control Panel.........................................................................5-3
5-4 I/O Ports.......................................................................................................... 5-4
5-5 Processor and Heatsink Installation................................................................5-5
Installing LGA1366 Processors....................................................................... 5-5
Installing a CPU Heatsink............................................................................... 5-7
Removing the Heatsink...................................................................................5-8
5-6 Installing Memory............................................................................................5-9

viii
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
5-7 Adding PCI Cards..........................................................................................5-11
5-8 Serverboard Details ......................................................................................5-12
X8DTT-F/X8DTT-IBXF/X8DTT-IBQF Quick Reference................................5-13
5-9 Connector Definitions....................................................................................5-14
5-10 Jumper Settings............................................................................................ 5-18
5-11 Onboard Indicators........................................................................................5-20
5-12 Installing Additional Drivers...........................................................................5-21
5-13 Configuring Supero Doctor III.......................................................................5-22
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices..................................................................................6-1
Precautions .....................................................................................................6-1
Unpacking .......................................................................................................6-1
6-2 Control Panel ..................................................................................................6-2
6-3 System Fans................................................................................................... 6-3
System Fan Failure.........................................................................................6-3
6-4 Air Shrouds .....................................................................................................6-4
6-5 Drive Bay Installation/Removal.......................................................................6-5
Accessing the Drive Bays............................................................................... 6-5
6-6 Power Supply..................................................................................................6-7
Power Supply Failure......................................................................................6-7
Replacing the Power Supply........................................................................... 6-7
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
Starting BIOS Setup Utility..............................................................................7-1
How To Change the Configuration Data......................................................... 7-1
Starting the Setup Utility................................................................................. 7-2
7-2 Main Setup......................................................................................................7-2
7-3 Advanced Setup Configurations......................................................................7-4
7-4 Security Settings........................................................................................... 7-24
7-5 Boot Configuration ........................................................................................ 7-25
7-6 Exit Options................................................................................................... 7-26
Appendix A BIOS Error Beep Codes
Appendix B Installing Windows
Appendix C System Specifications

Chapter 1
Introduction
1-1 Overview
The SuperServer 1026TT-TF/1026TT-IBXF/1026TT-IBQF is a "1U Twin" server
comprised of the SC809TQ-1200B 1U chassis and two (twin) X8DTT-F/X8DTT-
IBXF/X8DTT-IBQF serverboards. Please refer to our web site for information on
operating systems that have been certified for use with the 1026TT-TF/1026TT-
IBXF/1026TT-IBQF (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components may have
been included with the 1026TT-TF/1026TT-IBXF/1026TT-IBQF, as listed below.
Four passive CPU heatsinks (SNK-P0037P)
•
One air shroud (MCP-310-18008-0N)•
SATA Accessories:•
Eight SATA hard drive carriers (MCP-220-00047-0B)
One internal SATA backplane (BPN-SAS-809TQ)
Two 59-cm SATA cables (CBL-0207L)
Two 43-cm SATA cables (CBL-0226L)
Two 48-cm SATA cables (CBL-0227L)
Two 55-cm SATA cables (CBL-0228L)
Two SGPIO cables (CBL-0157L)
Two PCI Express x16 riser cards (RSC-R1U-E16R)
•
Six 4-cm high-performance fans (FAN-0085L4)•
Rackmount hardware with screws (CSE-PT51L):•
Two rack rail assemblies
Six brackets for mounting the rack rails in a rack/telco rack
One CD containing drivers and utilities
•
SuperServer 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual•
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 1026TT-TF/1026TT-IBXF/1026TT-IBQF lies two
X8DTT-F/X8DTT-IBXF/X8DTT-IBQF dual processor serverboards, which are based
on Intel's 5520 + ICH10R chipset. Below are the main features of the serverboards.
Note that the features on each board are doubled for the server, which includes
two nodes.
Processors
Each X8DTT-F/X8DTT-IBXF/X8DTT-IBQF supports two Intel® 5500 Series proces-
sors in LGA1366 sockets. Please refer to our web site for a complete listing of
supported processors (www.supermicro.com).
Memory
Each X8DTT-F/X8DTT-IBXF/X8DTT-IBQF has twelve DIMM sockets that can sup-
port up to 192 GB of registered ECC (or 48 GB of unbuffered) DDR3-1333/1066/800
SDRAM. See Chapter 5 Section 6 for more details on installing memory into the
system and refer to our web site for updates to supported memory.
Serial ATA
The South Bridge (ICH10R) of the chipset includes a Serial ATA controller for six
Gb/s SATA drives. The hot-swappable SATA drives are connected to a backplane
that provides power, bus termination and configuration settings. RAID 0, 1, 10 and
5 are supported. Refer to the support area of our web site for procedures on set-
ting up RAID on your system.
PCI Expansion Slots
Each X8DTT-F/X8DTT-IBXF/X8DTT-IBQF board has one PCI Express 2.0 x16
slot, so two PCI Express 2.0 x16 slots are provided in the server. In the 1026TT-
TF/1026TT-IBXF/1026TT-IBQF server configuration, riser cards have been pre-
installed to support two low-profile add-on cards.
Ethernet Ports
An Intel® network controller is integrated into each of the serverboards to support
two Gigabit LAN ports (100/1000Base-T/1000BaseTX, RJ45 output).

Chapter 1: Introduction
1-3
Onboard Controllers/Ports
Onboard I/O backpanel ports on each serverboard include one COM port, a VGA
port, two USB ports, a dedicated IPMI LAN port and two Gigabit LAN (NIC) ports.
An InfiniBand port is also included on the X8DTT-IBXF/X8DTT-IBQF serverboards
(the 1026TT-IBXF and 1026TT-IBQF only). There are two sets of I/O ports included
in the server (one set for each serverboard).
Graphics Controller
The X8DTT-F/X8DTT-IBXF/X8DTT-IBQF features an integrated Matrox G200eW
graphics chip, which includes 8 MB of DDR2 memory.
Other Features
Other onboard features that promote system health include voltage monitors, auto-
switching voltage regulators, chassis and CPU overheat sensors, virus protection
and BIOS rescue.
InfiniBand
Both the 1026TT-IBXF and 1026TT-IBQF include an InfiniBand port at DDR (dual
data rate) and QDR (quad data rate) speeds, respectively. InfiniBand is a scalable
serial communications link intended for connecting processors with high-speed
peripherals. (InfiniBand requires a QSFP connector.)
Model Variations (Differences between X8DTT models)
1026TT-TF 1026TT-IBXF 1026TT -IBQF
InfiniBand Connect No Yes Yes
DDR IB No Yes No
QDR IB No No Yes

1-4
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
Figure 1-1. Intel 5520/ICH10R Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
CPU#1 CPU#2
#1
#1
#1
#2
DDR3 DIMM
#2
#2
DDR3 DIMM
#1
#1
#1
DDR3 DIMM
#2
#2
#2
DDR3 DIMM
CC
AA
BB
DD
EE
F
F
Port1 Port0
Ports
Ports
3,4
7,8,9,10
PCI-E x16
ICH10R
Ports
2,1
Kawela
RJ45 RJ45
ESI
PE4-1
PE
5
WBD
BMC/VGA
VGA
DDR II
PCI
SATA #1
SATA #2
SATA #3
SATA #4
SATA
LPC
SPI
SST25
VF016
CLINK
CLINK
DMI
MT25408
Connect-X IB
PCI-E Gen2/DDR or QDR
QSFP
RTL8201N PHY
Dedicate LAN
5,6
Ports
LPCIO W83527
ACPI
KBC
SATA #5
SATA #6
Intel
5520

Chapter 1: Introduction
1-5
1-3 Server Chassis Features
The following is a general outline of the main features of the SC809TQ-1200B 1U
chassis. Details on the chassis can be found in Chapter 6.
System Power
When configured as a SuperServer 1026TT-TF/1026TT-IBXF/1026TT-IBQF, the
SC809TQ-1200B includes a single high-efficiency (Gold Level) 1200W cold-swap
power supply, which provides the power to both serverboards housed in the chas-
sis.
SATA Subsystem
The SC809TQ-1200B chassis was designed to support eight 2.5" SATA
hot-swappable hard drives.
Control Panel
The SC809 features two independant control panels associated with each node
(serverboard). Each control panel has LEDs to indicate power on, network activity,
hard disk drive activity and system overheat conditions. Each control panel also
includes a main power button and a system reset button.
Rear I/O Panel
The SC809TQ-1200B is a 1U rackmount chassis. Its I/O panel provides a slots for
two low-profile PCI-E x16 expansion cards, two COM ports, four USB ports, two
VGA ports, four Gb Ethernet ports and two dedicated IPMI LAN ports (one for each
node). See Chapter 6 for details.
Cooling System
The SC809TQ-1200B chassis has an innovative cooling design that features two
sets of triple (for a total of six) 4-cm high-performance PWM (Pulse Width Modu-
lated) fans. A fan speed control setting in BIOS allows fan speed to be determined
by system temperature.

1-6
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
1-4 1U Twin: System Notes
As a 1U Twin configuration, the 1026TT-TF/1026TT-IBXF/1026TT-IBQF is a unique
server system. With two nodes incorporated into a single chassis, there are several
points you should keep in mind.
System Power
A single power supply is used to provide the power for both serverboards. Each
serverboard however, can be shut down independently of the other with the power
button on its own control panel.
Although they share a common power supply, the I2C signals used for power supply
monitoring are received by the primary serverboard only. (When viewed from the
front of the chassis, the serverboard on the left is referred to as the primary board
and the serverboard on the right as the secondary.)
SATA Backplane/Drives
As a system, the 1026TT-TF/1026TT-IBXF/1026TT-IBQF supports the use of eight
SATA drives. The SATA backplane works as a single backplane divided into two
sections. This means that while a single power connector is used and functions
such as overheating apply to both sections together, the SATA drives are logically
connected to their own serverboard. Consequently, RAID setup is limited to a four-
drive scheme (RAID cannot be spread across all eight drives).

Chapter 1: Introduction
1-7
1-5 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone], ext.132 or 139

1-8
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
Notes

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your server system up and
running. Following these steps in the order given should enable you to have the
system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory preinstalled. If
your system is not already fully integrated with a serverboard, processors, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specific components.
2-2 Unpacking the System
You should inspect the box the server was shipped in and note if it was damaged
in any way. If the server itself shows damage you should file a damage claim with
the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the 1026TT-TF/1026TT-
IBXF/1026TT-IBQF. It should be situated in a clean, dust-free area that is well
ventilated. Avoid areas where heat, electrical noise and electromagnetic fields are
generated. You will also need it placed near a grounded power outlet. Be sure to
read the Rack and Server Precautions in the next section.
2-3 Preparing for Setup
The box the server was shipped in should include two sets of rail assemblies, two
rail mounting brackets and the mounting screws you will need to install the system
into the rack. Follow the steps in the order given to complete the installation process
in a minimum amount of time. Please read this section in its entirety before you
begin the installation procedure outlined in the sections that follow.
Choosing a Setup Location
Leave enough clearance in front of the rack to enable you to open the front•
door completely (~25 inches).
Leave approximately 30 inches of clearance in the back of the rack to allow for
•
sufficient airflow and ease in servicing.

2-2
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
This product is for installation only in a Restricted Access Location (dedicated•
equipment rooms, service closets and the like).
This product is not suitable for use with visual display work place devices accord-
•
ing to §2 of the the German Ordinance for Work with Visual Display Units.
!
!
Warnings and Precautions!
Rack Precautions
Ensure that the leveling jacks on the bottom of the rack are fully extended to•
the floor with the full weight of the rack resting on them.
In single rack installation, stabilizers should be attached to the rack.
•
In multiple rack installations, the racks should be coupled together.•
Always make sure the rack is stable before extending a component from the•
rack.
You should extend only one component at a time - extending two or more si-
•
multaneously may cause the rack to become unstable.
Server Precautions
Review the electrical and general safety precautions in Chapter 4.•
Determine the placement of each component in the rack• before you install the
rails.
Install the heaviest server components on the bottom of the rack first, and then
•
work up.
Use a regulating uninterruptible power supply (UPS) to protect the server from
•
power surges, voltage spikes and to keep your system operating in case of a
power failure.
Allow the hot plug hard drives and power supply modules to cool before touch-
•
ing them.

Chapter 2: Server Installation
2-3
Always keep the rack's front door and all panels and components on the servers•
closed when not servicing to maintain proper cooling.
Make sure all power and data cables are properly connected and not blocking
•
the chassis airflow. See Chapter 5 for details on cable connections.
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).

2-4
SUPERSERVER 1026TT-TF/1026TT-IBXF/1026TT-IBQF User's Manual
2-4 Installing the Server into a Rack
This section provides information on installing the server into a rack unit with the
rack rails provided. If the system has already been mounted into a rack, you can
skip ahead to Sections 2-5 and 2-6.
There are a variety of rack units on the market, which may mean the assembly
procedure will differ slightly. You should also refer to the installation instructions that
came with the rack unit you are using.
Note: This rail will fit a rack between 26" and 33.5" deep.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner fixed chassis rail that secures directly
to the server chassis and an outer fixed rack rail that secures directly to the rack
itself (see Figure 2-1).
Figure 2-1. Identifying the Sections of the Rack Rails
(right side rail shown)
Inner Rail Extension -
Attach to the Chassis
Outer Rack Rails -
Attach to the Rack
Inner Rail -
Preattached to the Chassis
