Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperServer 5015A-EHF-
D525. Installation and maintainance should be performed by experienced techni-
cians only.
The SuperServer 5015A-EHF-D525 is a single processor 1U mini rackmount server
based on the SC502L-200B server chassis and the Intel®Atom™ X7SPE-HF-D525
motherboard.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the Super X7SPE-HF-D525
motherboard and the SC502L-200B chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 5015A-
EHF-D525 into a rack and check out the server configuration prior to powering
up the system. If your server was ordered without the processor and memory
components, this chapter will refer you to the appropriate sections of the manual
for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
iii
Preface

SUPERSERVER 5015A-EHF-D525 User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 5015A-EHF-D525.
Chapter 5: Advanced Motherboard Setup
Chapter 5 provides detailed information on the X7SPE-HF-D525 motherboard,
including the locations and functions of connectors, headers and jumpers. Refer
to this chapter when adding or removing processors or main memory and when
reconfiguring the motherboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC502L-200B 1U rackmount
server chassis. You should follow the procedures given in this chapter when in-
stalling, removing or reconfiguring drives and when replacing system power supply
units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: POST Error Beep Codes
Appendix B: System Specifications

v
Preface
Notes

vi
SUPERSERVER 5015A-EHF-D525 User's Manual
Table of Contents
