SUPPO OSD v3.51 User manual

SUPPO OSD v3.51 10HZ
New feature: support distance unit in meter /km and feet/ML, speed at kmh / mph
Connetion Pins
Connector’s description
Config panel Connect to
button panel
Power in Connect to power source for your
OSD
(as Voltage 4.5V shown on left)
Video out For the OSD video output
RSSI Connect to your radio receiver’s
RSSI port
Main Batt
(to RC plane’s
battery)
Connect to your airplane’s battery
pack ( monitor plane’s voltage
Max 28V).
As 11.7v shown on left)
Camera Connect to
your camera
GPS Connect to GPS unit
Configuring OSD:
Press button “Menu” on “Config Panel” to enter system configuration
Use “Option SW” and “Select” button to configure

Button and Light
“Home” Record home location, Max RSSI,
Clear timer, clear distance value
“Menu” Enter configuration menu
“Switch” Switch between configuration options
“Select” Select each Option’s value
“Reset” Restart OSD
Signal Light Off : No power;
On: connecting GPS, waiting for GPS signal;
Flash: working good
Typical FPV with OSD set up:
1. Camera ------- ‘Video in” OSD “Video out” to ---- Suppo V-Tx , video transmitter.
2. Connect GPS, and Main Batt wire to --- RC main battery
3. Connect RSSI to your RC Receiver (Warning: potential dangerous, could damage your
RX. not recommend to do so if you don’t well understand your Radio RX)
4. Connect 9-12V power to Suppo V-tx to power up Suppo V-Tx, OSD and the camera.
Important Notice, care fully check the power wire connect Camera, OSD and Video Tx.
Wrong power wiring could damage your camera OSD and video transmitter.
Important : Never mix up the Video input (VI) wire with the Video output wire (marked VO),
otherwise, it could damage your cam or video transmitter!
System Config menu
description
NTSC ENABLE 0 – Disabled (for PAL) 1 – Enabled (for NTSC)
DISPLAY MODE
0 –Longitude and Latitude
1 – GMT time
LOCATION MODE
0 – ddd mm ssssss
Sample:
E111° 15' 45.1813"
N23° 28' 2.4255"
1 - dddmm.mmmm
Sample:
11115.4389
2328.22940
UNIT MODE
0 – Unit at meter (km when
over 10km),
Speed in km/h
1 – display Unit at feet (mile
when over 10mile),
speed in mph

Setting RSSI Min – Max value:
1. On ground power up TX and RX, press “set home” button, OSD will record RSSI
Max;
2. On ground, power off TX, press “Menu” button, OSD will record RSSI Min value.
3. Select Save and Exit to save RSSI Min Max value.
Notes:
GPS first start will take 1 minute. Re-start only 10 second.
Please note that you need to set “HOME” location (press home button) each time to get the
right “Flight Distance” and “Home Distance”, and “Return Course”
Specifications:
Input Volt Weight Size
OSD 7-12V * 10g 44*28*11mm
GPS 3.3V 10g
Power consumption：Max：1.1W
Plane batt detect max 28V
*When use voltage under 7V as power input, the voltage monitored will be in accurate.
The OSD will still work under 7v. The other information on screen such as speed, distance etc.
are correct but not the voltage info.
