Supra TRAC-Box BT User manual

10103030P1 • July 2011
© 2011 UTC Fire & Security. All rights reserved.
Installation Supplies Provided
• TRAC-Box BT Drill Template
• TRAC-Box BT
• TRAC-Box BT Mounting Bracket
• TRAC-Box BT Shackle
• Shackle Retainer Clip for BT
Hardware Not Provided
• (6) 5/16-18UNC all-thread rods
• (12) 5/16" lock washers
• (12) 5/16-18UNC nuts
• (6) 5/16" fender washers
An installation kit is available from Supra. The kit
contains all necessary hardware for installing the
TRAC-Box BT per recommended instructions.
Additionally, an interior cover plate is available.
Installation Tools Required
• Drill, Hammer Drill (as appropriate)
• Drill Bits (as appropriate)
• Wrenches (as appropriate)
• Pliers or Vice Grips
• Level or Punch
• Pen or pencil
• Dremel tool or Hacksaw
Overview
Mount the TRAC-Box BT in a location that is convenient
for your keyholders. To meet ADA requirements, the
units must be installed 48" or 4 feet from ground to
center of the device. If you choose an installation method
other than the one described in these instructions, Supra
will not be responsible for replacing the TRAC-Box BT if
it is damaged or destroyed upon removal.
Select a Location to Mount Bracket
1. Mount the bracket near the point of entry and, when
possible, mount the bracket under an awning or
cover in a lit area.
2. The bracket must be mounted upright against a at
surface.
3. The bracket must be mounted so the bottom of
the bracket is a minimum of 10" from any ledge or
obstruction (the key container drops from the bottom
of the TRAC-Box BT.
Install the Bracket
1. Before drilling, ensure that no interference will occur
with any plumbing, electrical, re or security systems,
etc.
Figure 1. Mounting Bracket Drill Locations
TRAC-Box BT™Bracket
Mounting Instructions
6 bolt locations —
Refer to drill template
for preferred locations
2. Once the location for the unit has been decided,
position and level the drilling template on the wall
and punch or mark the holes for drilling. Please use
the preferred hole locations, which are marked with
a ■ on the drilling template, to minimize physical
interference when the mounting hardware and TRAC-
Box BT are installed.
3. Using the correct bit for the type of wall, drill size 1/2"
holes to accommodate 5/16" bolts.
4. Insert a lock washer and a nut on all four of the all-
thread rods. It is important that each all-thread rod is
ush with the outside of each nut.
5. Position the bracket against the wall and insert the
four all-thread rods into the holes through the wall.
IMPORTANT: The bracket must have the top (closed
end) up and be mounted upright as the key container
must drop downward.
6. On the other side of the wall, mount the interior cover
plate (optional) onto the all-thread rods. Put a 5/16"
Page 1

fender washer, and a 5/16" lock washer on each of
the all-thread rods. Last, put a 5/16" nut on each rod
and hand tighten without letting the rod rotate. (See
Figure 2.)
7. With one hand, grip the end of the all-thread rod with
either pliers or a vice grip. Then, with the other hand,
tighten the nut with a 1/2" wrench while making sure
the bracket stays level. Repeat this procedure for
all six rods and tighten to approximately 50-75in-lb
or until rmly snug. Cut off the excess all-thread rod
using an appropriate tool.
Test the TRAC-Box BT Key Container
WARNING: Do not attach the TRAC-Box BT to the
bracket until opening of the key container has been
tested.
1. Use your Supra ActiveKEY, DisplayKEY, or eKEY to
perform the open key container function. Refer to the
user instructions provided with your key for step by
step operation.
2. When prompted, push up on the bottom of the key
container to remove it from the TRAC-Box BT.
Install the TRAC-Box BT in the Bracket
Important: When installing a TRAC-Box BT in a bracket
you MUST record the serial number of the TRAC-Box
BT installed at each location. This important information
is necessary for the integrity of the TRACcess database.
1. When properly installed, the shackle should be
hanging down from the inside of the bracket post with
the shackle legs pointing downward and located in
position with a retainer.
2. With the Supra logo of the TRAC-Box BT facing
outward toward the opening of the bracket, insert
the previously tested TRAC-Box BT into the bracket
assembly while aligning the shackle into the locking
holes of the TRAC-Box BT.
3. Push up on the TRAC-Box BT until you hear and
feel an audible "click" which indicates the shackle is
locked into place.
FCC Compliance
This device complies with part 15 of the FCC rules. Operation
is subject to the following three conditions:
1. This device may not cause harmful interference.
2. This device must not accept any interference received,
including interference that may cause undesired operation.
3. Changes or modications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
Warranty
UTC Fire & Security (UTCFS) warrants that this product will
be free of defects in material and workmanship for one year
from the date of purchase. This warranty is limited to repair
or replacement at the option of UTCFS. Damages caused
by modication, abuse or misuse, wear and tear, improper
installation, application, storage, or fault or negligence of
a party other than UTCFS are not covered. UTCFS will be
responsible for labor costs of removal or reinstallation of
products. The repaired or replaced product is then warranted
under the terms of this limited warranty for the balance of
the term of the warranty or for 90 days, whichever is longer.
UTCFS MAKES NO OTHER WARRANTY, EXPRESS OR
IMPLIED, OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL UTCFS
BE LIABLE FOR LOSS OF USE; LOST PROFITS; THEFT;
PROPERTY DAMAGE; OR SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES. To obtain repair or
replacement information under the terms of this warranty,
please contact your local supplier.
Figure 2. Installation Side View
Page 2
Wall
Back Plate
5/16-18UNC Nuts
6 each side
Lock Washers under each nut
Tip: Hold on to All Thread with pliers or
vide grips while tightening nuts to 50-75
foot-lbs or rmly snug
Possible blowout from drilling holes into
concrete or masonry
Fender Washer under
each lock washer
TRAC-Box BT Bracket
Retainer
BT Shackle
5/16-18UNC All Thread Rod
Lock Washers under each nut
5/16-18UNC Nuts
6 each side

(1) To minimize interference with the mounting hardware and the iBox BT
(2) To print this template full size, be sure to select Media Size = Letter (8.5 X 11”)
and select Options = “Do Not Scale”
PN 10103028P1 Installation Template, TRAC-BOX BT.pdf
RevA 7/19/2011
to top of 10103025P1; BACK PLATE,
REINFORCEMENT, TRAC-BOX BT WALLMOUNT
to top of 10103025P1; BACK PLATE,
REINFORCEMENT, TRAC-BOX BT WALLMOUNT
