GEM GEM GP001 User manual

LZ-500N Bracket
Typical mounting on IN-SWINGING door
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-LZ-500N Ver. D Published on 2011.09.08
190
63.5
8
63.5
6
63.5
63.5
190
68
265(267)
254(256)
38
76
Unit:mm
21
6 7 Finish
4
5
3
Power
Installation of LZ bracket on In-swing Doors
Install L bracket on the door frame.
M a k e s u r e t h e d o o r m a y b e
opened/closed.
Fas t en the e l ectromag net to L
bracket with fixing screws.
Assemble Z bracket. Make sure it is
still loose.
Insert the guide pins in t o t h e
armature plate.
Fasten the armature plate to Z
bracket. Insert the rubber washer
between them.
Close the door and turn on the
power.
L e t t h e a r m a t u r e p l a t e a n d
electromagnet bond together. Press
Z bracket to the door leaf.
Fasten Z bracket to the door leaf.
Minimal:76mm
L-Bracket
Z-Bracket
In-swing
Frame
Door
Armature
Plate
Application for the Electromagnet:
10010, EM-1200 , 10060(Double), EM-2200(Double) Series
