StarTech.com FPCEILBTB User manual

Manual Revision: 01/08/2019
User Manual
For the latest information and specications visit
www.startech.com/FPCEILBTB
Ceiling TV Mount | Back-to-Back | Dual Display
Actual product may vary from image shown
SKU#: FPCEILBTB

1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Compliance Statements
Use of Trademarks, Registered Trademarks, and other
Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and
other protected names and/or symbols of third-party companies not related in
any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service
by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com
hereby acknowledges that all trademarks, registered trademarks, service marks,
and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.

2
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Safety Statements
Safety Measures
• Product installation and/or mounting should be completed by a certied
professional as per the local safety and building code guidelines.
• Cables (including power and charging cables) should be placed and routed
to avoid creating electric, tripping or safety hazards.
Mesures de sécurité
• L’installation et/ou le montage du produit doit être réalisé par un
professionnel certié et dans le respect des normes locales et du code de
construction local.
• Les câbles (y compris les câbles d’alimentation et de chargement) doivent
être placés et acheminés de façon à éviter tout risque électrique, de chute ou
de sécurité
安全対策
• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に
従い、有資格の専門業者が行うようにしてください。
• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し
を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう
にしてください。
Misure di sicurezza
• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un
tecnico professionale certicato che conosca le linee guida locali sulle norme
edilizie e sulla sicurezza.
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati
e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o
pericoli per la sicurezza.

3
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Säkerhetsåtgärder
• Installation och/eller montering får endast göras av behöriga yrkespersoner
och enligt gällande lokala förordningar för säkerhet och byggnormer.
• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så
sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.
Warning Statements
• Make sure to assemble this product according to the instructions. Failure to
do so might result in personal injury or property damage.
• Never operate this product if parts are missing or damaged.
• Ceiling structures vary, and it’s important to make sure that the type of
ceiling structure and mounting hardware that you’re using will properly
support the mounted equipment. Failure to do so may result in personal
injury and/or equipment damage. The ceiling structure should be capable of
supporting at least four times the weight of the mounted equipment.
• The mounting hardware included with this product might not be adequate
for some ceiling structures. If you lack the necessary expertise to attach this
product to the ceiling structure that you’re using, contact a construction
professional to install the ceiling mount or to provide specic mounting
instructions for your ceiling structure.
Varningsmeddelanden
• Se till att du monterar produkten i enlighet med instruktionerna. Om du inte
gör det kan skada på person eller egendom uppstå.
• Använd aldrig produkten om delar saknas eller är skadade.
• Eftersom innertakstrukturer varierar är det viktigt att kontrollera att
innertakstrukturer och monteringsutrustningen som du använder klarar av
den monterade utrustningen. Om du inte gör det kan skada på person och/
eller utrustning uppstå. Innertakstrukturer ska kunna klara av minst fyra
gånger vikten av den monterade utrustningen.
• Monteringsutrustningen som medföljer produkten kanske inte är lämplig
för vissa innertakstrukturer. Om du saknar nödvändiga kunskaper för att
fästa denna produkt på innertakstrukturen som du använder, kontakta en
professionell konstruktör för att installera utrustning eller för att ge specika
monteringsinstruktioner för din innertakstruktur.

4
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Avertissements
• Assemblez ce produit conformément aux instructions. Si vous ne respectez
pas ces instructions, vous risquez de vous blesser ou d’endommager
l’équipement.
• N’utilisez pas ce produit si des pièces sont endommagées ou manquantes.
• Les types de plafonds varient. Vous devez impérativement vérier que le type
de plafond et le matériel de xation que vous utilisez permettent de soutenir
correctement l’équipement. Dans le cas contraire, vous risquez des blessures
corporelles ou des dommages matériels. La structure du plafond doit pouvoir
supporter au moins quatre fois le poids de l’équipement monté.
• Le matériel de xation inclus avec ce produit n’est pas forcément approprié
pour tous les types de plafond. Si vous ne disposez pas des compétences
nécessaires pour installer ce produit au plafond, contactez un professionnel
an qu’il installe l’équipment ou qu’il vous fournisse les instructions de
montage spéciques à votre type de plafond..
Warnhinweise
• Zorg dat dit product volgens de instructies in elkaar wordt gezet. Indien dit
niet goed gebeurt kan lichamelijk letsel of materiële schade ontstaan.
• Gebruik dit product nooit als er onderdelen ontbreken of beschadigd zijn.
• Omdat plafonds verschillen, is het belangrijk dat u ervoor zorgt dat de
plafondstructuur en de montagemiddelen die u gebruikt de te monteren
apparatuur goed ondersteunen. Indien u dit niet doet kan lichamelijk
letsel en/of schade aan de apparatuur ontstaan. De plafondstructuur moet
voldoende zijn om ten minste vier keer het gewicht van de gemonteerde
apparatuur te ondersteunen.
• Het kan zijn dat de bij dit product geleverde montagemiddelen niet geschikt
zijn voor sommige plafondstructuren. Als u onvoldoende kennis hebt om dit
product aan de door u gebruikte plafondstructuur te bevestigen, neem dan
contact op met een bouwkundige om de steun aan de muur te installeren of
specieke montage-instructies voor uw plafondstructuur te geven.

5
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Dichiarazioni di avvertenza
• Assemblare il prodotto rispettando le istruzioni. Il mancato rispetto delle
istruzioni potrebbe causare danni a persone o proprietà.
• Non utilizzare il prodotto in presenza di parti mancanti o danneggiate.
• Le caratteristiche il sotto sono variabili ed è importante vericare che
il sotto e l’hardware di montaggio in uso siano in grado di supportare
adeguatamente le apparecchiature montate. Il mancato rispetto delle
istruzioni potrebbe causare danni a persone o proprietà. Il sotto deve
essere in grado di supportare un peso almeno quattro volte superiore a
quello dell’apparecchiatura montata.
• L’hardware di montaggio incluso con il prodotto potrebbe non essere
adeguato ad alcun sotto. Se l’utente non dispone delle competenze
necessarie per agganciare il prodotto al sotto in uso, dovrà contattare un
professionista edile per installare il supporto a parete o ottenere istruzioni di
montaggio per il sotto in uso.
Mensagens de aviso
• Certique-se de que monta este produto de acordo com as instruções.
O incumprimento pode resultar em ferimentos pessoais ou danos de
propriedade.
• Nunca opere este produto se faltarem peças ou estas estiverem danicadas.
• As estruturas do teto variam e é importante certicar-se de que o tipo de
estrutura do teto e hardware de montagem que está a usar irá suportar
devidamente o equipamento montado. O incumprimento pode resultar em
ferimentos pessoais e/ou danos no equipamento. A estrutura do teto deve
ser capaz de suportar pelo menos quatro vezes o peso do equipamento
montado.
• O hardware de montagem incluído com este produto pode não ser
adequado para algumas estruturas do teto. Se não tiver o conhecimento
necessário para xar este produto à estrutura do teto que está a usar,
contacte um prossional de construção para fazer a instalação no teto ou
para fornecer instruções de montagem especícas para a sua estrutura do
teto.
Advertencias de uso
• Asegúrese de ensamblar este producto según las instrucciones. De lo
contrario, pueden producirse lesiones personales o daños de propiedad.
• Nunca opere o ponga en funcionamiento este producto si faltan piezas o hay
daños en las mismas.
• Las estructuras de los falsos techos pueden variar y, por tanto, es importante

6
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
determinar con certeza que el tipo de estructura del falso techo y el
hardware de montaje que se va a utilizar para soportar debidamente el
equipo. De lo contrario, se pueden producir lesiones personales o daños en
el mismo. La estructura del falso techo debe ser capaz de soportar al menos
cuatro veces el peso del componente instalado.
• El hardware de montaje incluido con este producto puede no ser adecuado
para algunas estructuras de falso techo. Si no tiene la experiencia suciente
para jar este producto a la estructura del falso techo correspondiente,
póngase en contacto con un profesional de la construcción para instalar el
soporte de falso techo o para que le proporcione las instrucciones especícas
de montaje para su estructura de falso techo..
Waarschuwingen
• Zorg dat dit product volgens de instructies in elkaar wordt gezet. Indien dit
niet goed gebeurt kan lichamelijk letsel of materiële schade ontstaan.
• Gebruik dit product nooit als er onderdelen ontbreken of beschadigd zijn.
• Omdat plafonds verschillen, is het belangrijk dat u ervoor zorgt dat de
plafondstructuur en de montagemiddelen die u gebruikt de te monteren
apparatuur goed ondersteunen. Indien u dit niet doet kan lichamelijk
letsel en/of schade aan de apparatuur ontstaan. De plafondstructuur moet
voldoende zijn om ten minste vier keer het gewicht van de gemonteerde
apparatuur te ondersteunen.
• Het kan zijn dat de bij dit product geleverde montagemiddelen niet geschikt
zijn voor sommige plafondstructuren. Als u onvoldoende kennis hebt om dit
product aan de door u gebruikte plafondstructuur te bevestigen, neem dan
contact op met een bouwkundige om de steun aan de muur te installeren of
specieke montage-instructies voor uw plafondstructuur te geven.

7
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
注意
• 必ず取扱説明書に従って本製品の組み立てを行って下さい。
• 本製品は、室内での使用を想定しています。戸外では使用しないで下さい。
• 本製品は、非常に重いエンクロージャです。絶対に一人で持ち上げたり動かしたりしないで下さ
い。
• 転倒注意！本製品から複数のコンポーネントが突き出した状態にしておくとエンクロージャが転
倒する恐れがあります。転倒リスクを回避するために、エンクロージャからはコンポーネントが突
き出な いようにして下さい。
• 本製品の上に何も載せないで下さい。複数のエンクロージャを重ねて設置しないで下さい。
• 液体物をエンクロージャに近づけないようにして下さい。
• エンクロージャ自身と中に積載する装置の総重量に耐えられるエリアに設置して下さい。
• この製品にはアースが必要です。アース接続をしていない状態で本製品を使用しないでくださ
い。

8
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Table of Contents
Compliance Statements........................................................................1
Safety Statements..................................................................................2
Warning Statements..............................................................................3
Product Diagram....................................................................................9
Product Information..............................................................................10
Package Contents ..................................................................................................................................... 10
Specications.............................................................................................................................................. 14
Requirements ............................................................................................................................................. 15
Installation ..............................................................................................16
Mounting the Ceiling Mount and Upper Pole Assembly............................................................ 16
Assembly .................................................................................................16
Attaching the Extension Pole to the Upper Pole........................................................................... 16
Attaching the Horizontal Bracket........................................................................................................ 18
Selecting the Appropriate Mounting Hardware............................................................................ 19
Attaching the Vertical Brackets to a TV ............................................................................................. 22
Attaching the Vertical Brackets to a TV Using Spacers ................................................................ 23
Attaching the TVs to the Horizontal Bracket................................................................................... 24
Adjusting the TVs ...................................................................................26
Adjusting the tilt........................................................................................................................................ 26
Adjusting the Swivel ................................................................................................................................ 27
Adjusting the Vertical Position of the Ceiling TV Mount............................................................. 27

9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Diagram
Ceiling
Mount
Upper
Pole
Vertical
Brackets
(4)
Horizontal
Brackets
(2)
Extension
Pole

10
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Information
Package Contents
Ceiling Mount and Upper Pole
Qty: 1
Extension Pole
Qty: 1
Vertical Bracket
Qty: 4
Horizontal Bracket
Qty: 2
1 2
3 4

11
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Bolts
Qty: 2
Nuts
Qty: 2
Wrench
Qty: 1
Hex Key
Qty: 1
Mounting Template
Qty: 1
M5x14 mm Screws
Qty: 8
5 6
78
9 10

12
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
M6x14 mm Screws
Qty: 8
M6x30 mm Screws
Qty: 8
M8x30 mm Screws
Qty: 8
M8x50 mm Screws
Qty: 8
Rectangular Washers
Qty: 8
Short Spacers
Qty: 16
11 12
13 14
15 16

13
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Long Spacers
Qty: 16
6.3x55 mm Screws
Qty: 4
Concrete Anchors
Qty: 4
Flat Washers
Qty: 4
Mounting Bracket
Qty: 1
17 18
19 20
21

14
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Specications
Type of Measurement Measurement
VESA
mounting
hole pattern
200x200
300x300
400x200
400x400
600x400
Weight capacity Up to 99 lb. per mount
(45 kg per mount)
Tilt +5 to -20
Extension
pole swivel
+180 to -180
Extension 42” to 61” (1060 to 1560
mm)
Level adjustment +3 to -3

15
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Screen size 32” to 75” (813 to 1905
mm)
Ceiling plate
swivel
-60 to +60
Requirements
Requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/FPCEILBTB
• Flat-panel TV (max. 75”, VESA mount compatible) x 2
• Phillips Head Screwdriver x 1

16
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installation
Mounting the Ceiling Mount and
Upper Pole Assembly
Notes: Product mounting should be completed by a certi-
ed professional as per the local safety and building code
guidelines.
Ceiling structures vary, and it’s important to make sure that
the type of structure and mounting hardware that you’re
using will properly support the mounted equipment. Failure
to do so may result in personal injury and/or equipment
damage.
1. Before installing the Ceiling TV Mount onto the mounting
surface, contact a professional.
2. After consulting a professional, the Ceiling Mount and
Upper Pole Assembly can be mounted using the Mounting
Hardware included.
Note: The mounting hardware provided may not be suitable
for all ceiling structures.
Assembly
Attaching the Extension Pole to the Upper Pole
1. Align the hole in the Mounting Bracket with the Extension
Pole and slide the Mounting Bracket down to the bottom
of the Extension Pole.
2. Feed the TV Cables through the Cable Hole in the Upper
Pole and into the Extension Pole.

17
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Note: At this step in the installation process, the Upper Pole
is not attached to the Extension Pole.
3. Feed the TV Cables through the Extension Pole, and out
the Cable Hole in the bottom of the Extension Pole.
Feeding the TV Cables through the Poles
4. Slide the Extension Pole into the Upper Pole, until the
Extension Pole is at the desired height.
5. Align the Adjustment Holes on the Extension Pole with the
Adjustment Holes on the Upper Pole.

18
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
6. Insert two Bolts through the Adjustment Holes on
the Upper Pole and into the Adjustment Holes on the
Extension Pole.
Installing the Nuts/Bolts through the Adjustment Holes
7. Screw one Nut onto the end of each of the Bolts and use the
Wrench to hold the Nuts in place while using the Hex Key
to tighten the Bolts.
Attaching the Horizontal Bracket
1. Using a Wrench, remove the Retainer Nut and loosen the
other two Nuts on the Horizontal Bracket.
Removing the Retainer Nut and Loosen the two other Nuts

19
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
2. Align the three Threaded Studs on the Horizontal Bracket
with the Mounting Hole and Mounting Slots on the
Mounting Bracket.
3. Reattach the Retainer Nut removed in Step 1 and use a
Wrench to tighten the Retainer Nut and the other two Nuts
that were loosened in Step 1.
Attaching the Mounting Bracket to the Horizontal Bracket
4. Repeat Steps 1 - 3 to install the other Horizontal Bracket.
Selecting the Appropriate Mounting Hardware
• Determine if the back of the TV is ush or inset.
• Determine the depth of the mounting holes on the TV.
• Determine the diameter of the mounting holes on the TV.
Note: If you’re using a TV with a ush mounting surface, you
don’t need to use any of the provided spacers.
