SUPRO DELAY User manual
All Contents © Bond Audio LLC 2021
DELAY
User Manual
2
3
3
5
CONTENTS
1) Introduction
2) Explanation of Controls
3) Warranty
3
1. INTRODUCTION
2. EXPLANATION OF CONTROLS
Our flagship pedal, the Supro Delay offers the vintage echo effects of the 60s and 70s while showcasing the
latest in pedal technology. The all-analog Supro Delay comes equipped with a pair of high-voltage MN3005
IC chips capable of producing up to 600ms of delay time, while providing dramatically increased headroom,
dynamic range, and clarity. The newly-designed Filter knob ranges from low-pass to band-pass functions,
spanning from dark, warm, and murky tones to crisp and bright tape echoes. Additionally, an assignable
Expression pedal control provides the player with the ability to switch between Repeats, Time, and Level
while maintaining custom knob settings. Runs on standard 9VDC.
Level: Sets the volume of the echo. At minimum, there is no echo, at maximum, the echo is louder
than the original signal. Noon is parity.
4
Filter: Sets the frequency response of the echo. At minimum, the filter control provides an overall
echo” effect.
Repeats: Sets the amount of feedback sent from the output of the delay line back into the input
of the delay line. At minimum, there is no feedback. In this setting, a single echo will be heard.
At maximum, the echo signal will regenerate to the point of self-oscillation, creating a resonant
Expression: Selects which knob function is controlled by the expression pedal. In the Up position,
Level is selected. In the Middle position, Time is selected. In the Down position, Repeats is selected.
Note: The Expression jack accepts a 1/4” TRS cable from a standard expression pedal.
The Supro delay runs on standard 9VDC neg. tip power only, using internal voltage-doubling to provide the
necessary headroom for world-class performance in an all-analog Stompbox.
The Supro Delay does not run on batteries.
Time: Sets the length of the echo. At minimum, the delay time is 20ms. At maximum, the delay
time is 600ms.
5
3. SUPRO LIMITED WARRANTY
Your new Supro product is warranted to be free from defects in materials and workmanship for 1 year from
the original date of purchase. If the product is registered at http://suprousa.com/warranty, coverage is
extended to two years. Tubes and speakers are covered for 90 days. Warranty applies only to the original
retail purchaser of a registered Supro product, subject to the limitations contained in this warranty.
THIS WARRANTY IS EXTENDED TO THE ORIGINAL RETAIL PURCHASER OF SUPRO PRODUCTS BOUGHT
ON OR AFTER JANUARY 1, 2020 ONLY AND MAY NOT BE TRANSFERRED OR ASSIGNED TO SUBSEQUENT
OWNERS. IN ORDER TO VALIDATE YOUR WARRANTY, AND AS A CONDITION PRECEDENT TO WARRANTY
ORIGINAL DATE OF PURCHASE. YOUR PROOF OF PURCHASE OR SALES RECEIPT MUST ACCOMPANY ALL
IF YOU DO NOT REGISTER THE PRODUCT WITHIN 60 DAYS OF PURCHASE, YOUR PRODUCT WILL NOT BE
SERVICED UNDER WARRANTY.
If your Supro product is destroyed, lost or damaged beyond repair while in the possession of Supro for
repair, Supro will replace that product with one of the same or most similar style of a value not in excess of
the original purchase price of your product. Any insurance covering the product, including but not limited to
collector’s value insurance, must be carried by you at your expense.
This warranty covers the cost of both labor and materials on repairs deemed necessary by our Customer
Service Representative which includes:
tampered with or altered.
service has been performed.
6
Product manuals are offered digitally in an attempt to be mindful of our environment.
We ask that you consider the same before printing at home. Thank you!
SUPRO MAKES NO OTHER EXPRESS WARRANTY OF ANY KIND WHATSOEVER. ALL IMPLIED, WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, EXCEEDING
THE SPECIFIC PROVISIONS OF THIS WARRANTY ARE HEREBY DISCLAIMED AND EXCLUDED FROM THIS
WARRANTY. SOME STATES AND/OR COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
IMPLIED WARRANTIES SO THAT THE ABOVE MAY NOT APPLY TO YOU. SUPRO SHALL NOT BE LIABLE FOR
ANY SPECIAL, INDIRECT CONSEQUENTIAL, INCIDENTAL OR OTHER SIMILAR DAMAGES SUFFERED BY THE
PURCHASER OR ANY THIRD PARTY, INCLUDING, WITHOUT LIMITATION. DAMAGES FOR LOSS OF PROFITS
OR BUSINESS OR DAMAGES RESULTING FROM USE OR PERFORMANCE OF THE PRODUCT, WHETHER IN
CONTRACT OR IN TORT, EVEN IF SUPRO OR ITS AUTHORIZED REPRESENTATIVE HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES, AND SUPRO SHALL NOT BE LIABLE FOR ANY EXPENSES, CLAIMS,
OR SUITS ARISING OUT OF OR RELATING TO ANY OF THE FOREGOING.
Steps To File for Warranty Coverage:
Register your new product at http://suprousa.com/warranty
Complete the warranty request form available at http://suprousa.com/support and we will handle it from there!
