SVANTTO IDS100 User manual

User Manual
IDS100 Pen Scanner
1.00

Page2of29
IDS100 Pen Scanner User Manual
Version 1.00
Version History
Date
By
Changes
Version
2022-3-15
Jackie Jian
Initial Version
1.00

Page3of29
IDS100 Pen Scanner User Manual
Version 1.00
Contents
Version History ........................................................................................................................ 2
1.0. Product Introduction ........................................................................................................ 5
1.1. What’s in the Box............................................................................................................... 5
1.2. Product Overview............................................................................................................... 5
1.3. Function Buttons.................................................................................................................6
1.4. Homepage Interface of Touch Screen.................................................................................6
1.5. Screen Operation Instruction.............................................................................................. 7
2.0. User Help Video ................................................................................................................ 8
3.0. Functions Instruction ....................................................................................................... 9
3.1. Scan Translation..................................................................................................................9
3.1.1. Scan Method.............................................................................................................. 9
3.1.2. Scan Translation Settings...........................................................................................9
3.1.3. Text To Speech Reader..............................................................................................9
3.2. Voice Translation..............................................................................................................10
3.2.1. Voice Translation Settings.......................................................................................10
3.3. Photo Translation ..............................................................................................................11
3.3.1. Photo Translation Setting.........................................................................................11
3.4. Excerpt..............................................................................................................................12
3.4.1. Synchronized the Excerpt Text................................................................................12
3.4.2. Excerpt Settings....................................................................................................... 13
3.5. Dictionary......................................................................................................................... 14
3.5.1. Query Text............................................................................................................... 14
3.6. Smart Record.................................................................................................................... 15
3.6.1. How to Start Recording........................................................................................... 15
3.6.2. Check the Contents of Recording............................................................................ 15
3.7. Favorites............................................................................................................................16
3.8. Vocabulary........................................................................................................................17
3.8.1. Query Word............................................................................................................. 17
3.8.2. Browse words settings............................................................................................. 18
3.9. Settings..............................................................................................................................18
3.9.1. Wi-Fi Setting............................................................................................................19
3.9.2. Bluetooth Setting..................................................................................................... 19
3.9.3. Scan Method Setting................................................................................................20
3.9.4. Brightness Setting.................................................................................................... 21
3.9.5. Sounds Setting......................................................................................................... 21
3.9.6. Language Setting..................................................................................................... 21
3.9.7. Auto-lock Setting.....................................................................................................23
3.9.8. Power-off Setting.....................................................................................................23
3.9.9. Speed Setting........................................................................................................... 23
3.9.10. Pronunciation Setting.............................................................................................24
3.9.11. Update Application................................................................................................25
3.9.12. About the Machine.................................................................................................25
3.9.13. Storage of the Machine .......................................................................................... 26
3.9.14. Reset the Machine ..................................................................................................26
3.9.15. System Upgrade.....................................................................................................27

Page4of29
IDS100 Pen Scanner User Manual
Version 1.00
3.9.16. Clean Data..............................................................................................................27
4.0. Product Specification ......................................................................................................28

Page5of29
IDS100 Pen Scanner User Manual
Version 1.00
1.0. Product Introduction
Thank you for choosing our pen scanner. Our product has functions such as voice translation, scan translation,
photo translation, text excerpt, recording, dictionary, etc. The excellent pen scanner is suitable for people with
dyslexia and reading difficulties, tourism, business negotiation, language learning, and studying abroad.
1.1. What’s in the Box
When you receive the package, open and check the items in it.
Figure 1-1 What’s in the Box
1.2. Product Overview
Figure 1-2 Pen Scanner Overview
Type-c Charging Port
Touch Screen
Home Button
Volume+/Voice
Translation Button
Volume-/Voice
Translation Button
Microphone
Camera
Trumpet
Scan Window
Power Button
User Manual
USB Cable
Pen Scanner

Page6of29
IDS100 Pen Scanner User Manual
Version 1.00
1.3. Function Buttons
Table 1-1 Function Buttons
1
Power Button
Power On/Off: press and hold this button for 3 seconds to turn
power on or off.
2
Home Button
Press the button to return to homepage.
3
Volume+/Voice
Translation Button
Short press to increase volume, long press to record voice and
translate.
4
Volume-/Voice
Translation Button
Short press to decrease volume, long press to record voice and
translate.
5
Scan Window
Press the scanning window to retract and start scanning
recognition, release the scanning window to rebound and end
scanning.
1.4. Homepage Interface of Touch Screen
Figure 1-3 Homepage Interface
Battery Display
Time Display
Wi-Fi Display
Scan Translation
Bluetooth Display
Voice Translation
Excerpt
Voice Record and
Translation
Vocabulary
Photo Translation
Dictionary
Favorites
Settings

Page7of29
IDS100 Pen Scanner User Manual
Version 1.00
1.5. Screen Operation Instruction
This machine adopts a touch-type color display, which can be operated by touching the sliding display with your
finger and clicking the corresponding function.
1. Swipe on the screen with your finger to switch the screen. The specific operation should be determined
according to the actual content.
2. Click each function icon on the home page to enter the function interface of the corresponding icon.

Page8of29
IDS100 Pen Scanner User Manual
Version 1.00
2.0. User Help Video
View the instructional video in the corresponding module.
Table 2-1 User Help Video Link and QR Code
How to Scan and Translation: https://bit.ly/IDS100Scan
How to Use Voice Translation：https://bit.ly/IDS100voice
How to Translate by Taking Photo: https://bit.ly/IDS100photo
How to Use the Smart Record: https://bit.ly/IDS100record
Synchronous Transmission of Scan Results: https://bit.ly/IDS100Syn
Dictionary and Vocabulary: https://bit.ly/IDS100DandV

Page9of29
IDS100 Pen Scanner User Manual
Version 1.00
3.0. Functions Instruction
3.1. Scan Translation
3.1.1. Scan Method
1) Hold the pen body, place the scanning head on the target scanning object, and the target font is on the
center line of the scanning window.
2) Gently press the scanning pen down, the scanning window emits light, and then move the translation pen at
a constant speed along the font content to complete the scan.
3) The examples of the scanning angle are shown in the figures below.
3.1.2. Scan Translation Settings
Before scanning, please select the language to be scanned and the language of the target translation; when the
"Multiline" button is turned on, multiple lines of text can be scanned continuously; when it is turned off, only
one line of text can be scanned at a time.
Figure 3-4 Scan Translation Settings
3.1.3. Text To Speech Reader
After the scan is complete, the scan content and translation results will be displayed on the screen, and the scan
content will be played automatically. Click the speaker icon to play the corresponding content, it is an effective
read tool to help the dyslexics to reach their potential improves independence and self-confidence.
√
Figure 3-1 Correct Example
×
Figure 3-2 Error Example
×
Figure 3-3 Error Example
Return Button
Scan Language
Translation Language
Multi-line Scan
Display the Content
of Scan
Display the Result of
Translation
Reading Aloud Scan
Content
Reading Aloud
Translation Content
Multi-line Scan
Add to Favorites

Page10of29
IDS100 Pen Scanner User Manual
Version 1.00
3.2. Voice Translation
There are two modes for voice translation. When the translation pen is connected to Wi-Fi, you can choose to
enter the online translation mode. When the translation pen is offline, you can choose to enter the offline
translation mode. There are four languages for selection in the offline translation mode, namely Chinese,
English, Korean, Japanese. After the voice is entered, the entered voice content and the translation result will be
displayed on the screen, so that it is easy to check whether the voice entered content is correct. Voice content
can also be viewed directly for those with hearing impairments.
Figure 3-5 Online/Offline Voice Translation
3.2.1. Voice Translation Settings
Figure 3-6 Voice Translation Settings
Notes: The color of the microphone matches the color of the selected language.
Demo Video: xxx
Return Button
Voice Translation
Language
Voice Translation
Language
Display the Result of
Voice Translation
Press and Hold to
Start Recording
Press and Hold to
Start Recording
Reading Aloud
Translation Content
Display entered
Voice

Page11of29
IDS100 Pen Scanner User Manual
Version 1.00
3.3. Photo Translation
3.3.1. Photo Translation Setting
Figure 3-7 Take Photo
Figure 3-8 Photo Translation
Return Button
Photo Language
Translation Language
Camera Fill Light
History Photos
Take Photo
Camera Direction
(Horizontal/Vertical)
Display Photo
Content
Return Button
Display the Photo
Photo Contents
Display the Photo
Contents and Translation
Contents
Download Translation
Contents
Broadcast Photo
Contents
Translation Contents
Broadcast Translation
Contents

Page12of29
IDS100 Pen Scanner User Manual
Version 1.00
3.4. Excerpt
3.4.1. Synchronized the Excerpt Text
Note: Please make sure that the scan translation pen is connected to Wi-Fi.
1) After entering the text excerpt mode, click the "YES" button, the page will display the simultaneous
interpretation text viewing URL and QR code (After exiting and re-entering the text excerpt module, the
URL and the QR code will be updated, so please pay attention to check whether it has changed when using
this function). Then click “Enter” to start scanning.
Figure 3-9 Synchronized the Excerpt Text
Figure 3-10 Synchronized the Excerpt Text
2) Enter the above URL in the browser or scan the QR code on the mobile phone to enter the simultaneous
interpretation text viewing page.
Figure 3-11 Text Viewing Page in Windows
Figure 3-12 Text Viewing Page in Mac

Page13of29
IDS100 Pen Scanner User Manual
Version 1.00
Figure 3-13 Text Viewing Page in iOS
Figure 3-14 Text Viewing Page in Android
3) After scanning the text, view the text content in the simultaneous interpretation webpage. Please refer to
section 2.1.1 for the scanning method.
Demo Video: xxx
3.4.2. Excerpt Settings
Figure 3-15 Excerpt Setting
Return Button
Scan Language
View History Record
Display the Contents
of Scanning
Delete the Contents
of Scanning
Finish Scan

Page14of29
IDS100 Pen Scanner User Manual
Version 1.00
3.5. Dictionary
There are 6 built-in dictionaries in the machine, namely English-Chinese dictionary, Chinese-English dictionary,
English/Japanese dictionary, Chinese dictionary, idiom dictionary, Tang poetry, as shown the figures below.
Figure 3-16 Built-in Dictionaries
Figure 3-17 Built-in Dictionaries
3.5.1. Query Text
1) Click any dictionary icon to be queried, enter the query content in the input box, and click the query button
to view the query result.
Figure 3-18 Query Text
Add to Favorites

Page15of29
IDS100 Pen Scanner User Manual
Version 1.00
3.6. Smart Record
Note: The recording time can be up to 4 hours.
3.6.1. How to Start Recording
1) Click the “+” icon to build a new recording, then choose the recording language. Click the “Microphone”
icon to start recording, click the “√” icon to end recording. As shown the figures below.
Figure 3-19 Build
Recording
Figure 3-20 Recording
Language
Figure 3-21 Start
Recording
Figure 3-22 End
Recording
3.6.2. Check the Contents of Recording
1) After the recording is completed, click the corresponding recording to enter the recording viewing interface.
Then click the “Pause” icon to broadcast the recording.
Figure 3-23 Recordings
Figure 3-24 Broadcast Recording

Page16of29
IDS100 Pen Scanner User Manual
Version 1.00
Note: 1. Position the recording playback position by dragging the progress bar. 2. Click the translation icon in
the upper right corner to translate the recording content. As shown the figure below.
Figure 3-25 Recording settings
3.7. Favorites
This module is used to collect some frequently forgotten words and sentences or voice recordings. During
subsequent use of the product, these contents can be viewed in Favorites. The contents of this module include
scan translation, Chinese-English dictionary, English/Chinese dictionary, English/Japanese dictionary, Chinese
dictionary, idiom dictionary, word bank, and voice translation. As shown in the images below.
Figure 3-26 Contents of Favorites
Figure 3-27 Contents of Scan Translation Favorites
Recording Progress
Bar
Translate Recording

Page17of29
IDS100 Pen Scanner User Manual
Version 1.00
3.8. Vocabulary
There are 10 built-in dictionaries, namely primary school dictionary, junior high school dictionary, high school
dictionary, college English CET-4 dictionary, college English CET-6 dictionary, postgraduate dictionary, IELTS
dictionary, TOEFL dictionary, SAT dictionary, GRE dictionary, as shown the figures below.
Figure 3-28 Built-in Vocabularies
Figure 3-29 Built-in Vocabularies
3.8.1. Query Word
1) Click any vocabulary icon to be queried, select the beginning letter of a word, and then click on any word
to view its details.
Figure 3-30 Query Word
Figure 3-31 Query Word
Figure 3-32 Query Word
Figure 3-33 Query Word

Page18of29
IDS100 Pen Scanner User Manual
Version 1.00
3.8.2. Browse words settings
Figure 3-34 Browse Words Settings
3.9. Settings
In the settings, click the corresponding system settings icon to set.
Figure 3-35 Settings
Figure 3-36 Settings
Return Button
Add to Favorites
British Pronunciation
Practice Pronunciation
Browse Next Words
Browse Previous Words
American Pronunciation

Page19of29
IDS100 Pen Scanner User Manual
Version 1.00
3.9.1. Wi-Fi Setting
1) After entering the Wi-Fi setting, turn on the Wi-Fi switch button, then click the “Refresh” button, select the
Wi-Fi network to be connected, enter the corresponding Wi-Fi password, and click “Join”. After the
connection is completed, a tick will be displayed in front of the corresponding Wi-Fi.
Figure 3-37 Connect WIFI
Figure 3-38 Connect WIFI
Figure 3-39 WIFI Connected
3.9.2. Bluetooth Setting
Note: The Bluetooth of this machine only supports connecting to devices such as Bluetooth earphones and
Bluetooth speakers.
1) After entering the Bluetooth setting, turn on the Bluetooth switch button, then click the “Refresh” button,
select the device to be connected in “Available devices”. After the connection is completed, the “Paired
devices” will display the connected device name.

Page20of29
IDS100 Pen Scanner User Manual
Version 1.00
Figure 3-40 Connect Bluetooth
Figure 3-41 Bluetooth Connected
3.9.3. Scan Method Setting
There are two scanning directions: horizontal scanning and vertical scanning, and there are left-hand and
right-hand scanning options for horizontal scanning. The selected options will be followed by a tick.
Figure 3-42 Scan Method Setting
