Sven AP-680MV User manual

USER’S MANUAL
Stereo Headphones
with Microphone
www.sven.fi
AP-680MV

ENG
1
User’s Manual
Congratulations on your purchase of the SVEN headphones!
APPLICATION
Sven АР-680MV stereo headphones with a microphone are designed for
operation with PC sound cards and other compatible systems. They can be
also used in VoIP telephony, video conferencing, multimedia applications,
interactive games, for speech recognition and learning foreign languages.
SAFETY PRECAUTIONS
•Don’t use the stereo headphones while driving.
•Don’t use the stereo headphones at high volume for a long time (more
than 15 minutes), as this may cause hearing impairment.
SPECIAL FEATURES
•Adjustable headband
•Rotary microphone arm
•SVEN PNC passive noise cancelling system
•Volume control on cable
CONNECTION AND OPERATION
•Connect the headphone plug to the audio output jack of your audio source
(PC, laptop, MP3 player), as shown in Fig. 1.
•Insert the microphone plug into the microphone input jack of your audio
source.
•Adjust the headphone volume level as desired with the volume control
wheel on the cable.
ap-680mV

Sound card
Phone out
Mic in
Phone jack
Mic jack
Volume control
TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information
and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the
improvement of SVEN production.
Technical support is on www.sven.fi
Fig. 1. Connection diagram
Parameter, measurement unit
Sensitivity, dB
Frequency range, Hz
Membrane, mm
Connection type
Cable length, m
Weight, г
Value
headphones: 105 ± 4
microphone: -58 ± 3
headphones: 20 – 20,000
microphone: 30 – 16,000
Ø 40
mini-jack (stereo)
2.5
195
ENG
2
Stereo Headphones with
Microphone

Модель: AP-680MV
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. AP-680MV
Stereo Headphones with
Microphone
