Swann SI9032N User manual




Instruction Manual
MODEL: SI9032N
CERAMIC


Important Safeguards 04
UK Wiring Instructions 05
Parts and Features 06
Fabric Setting Chart 08
Ironing Temperature Setting Guide 09
How to use your Steam Station
Prepare the Appliance for Use 10
Fill Water Tank 11
Steam Ironing 12
Dry Ironing 13
Vertical Steam Ironing 14
Auto Shut Off Function 14
Handle 15
Cord Storage 16
Replacement of Filter 16
Anti-Calc System 17
Emptying and Storing 17
Cleaning and Maintenance 17
Troubleshooting 18
Additional Information 19


1. Make sure to read all the safety precautions below and look at the illustrations
before you start using the appliance.
2. Use the appliance for its intended use only.
3. The appliance is intended for household use only.
4. In order to protect against the risk of electric shock, do not immerse iron power
base into water or any other liquids
5. Connect the appliance only to an alternating current of the voltage specied on
the rating plate and only to an earthed socket. To avoid a circuit overload, do not
operate another high wattage appliance in the same circuit.
6. Never yank cord to disconnect from outlet; instead, grasp plug and pull to disconnect.
7. During use, do not lift the appliance by power cord/supply hose.
8. Always disconnect the plug of the appliance from electrical outlet when lling with
water or emptying and when not in use.
9. Do not operate the appliance with a damaged cord or if the appliance has been
dropped or damaged, it must be taken to a qualied serviceman or manufacturer or
its service agent for examination and repair. Incorrect re-assembly can cause a risk
of electric shock when the iron is used.
10. Keep the iron and its cord out of reach of children less than 8 years of age when it
is energized or cooling down.
11. During use, always place the power base on a stable, level and horizontal surface
or ironing board, and then place the iron on the power base.
12. Place the iron on the power base. Do not allow power cord or supply hose to
touch hot surface.
13. Burns can occur from touching hot metal parts, hot water or steam. Use caution
when using the appliance. If the iron is placed onto the iron rest plate during in use,
the iron rest plate may become a hot surface. Do not touch the iron rest plate and
the soleplate until they have cooled down completely.
14. Never use the iron facing towards people because the steam can cause burns.
15. Never twist the supply hose during use.




16. The iron must not left unattended while it is connected to the supply mains.
17. The appliance must be used or stored in a level and horizontal surface.
18. When placing the iron on its stand, ensure that the surface on which the stand is
placed is stable.
19. The iron is not to be used if it has been dropped, if there are visible signs of
damage or if it is leaking.
20. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
21. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
konwledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
22. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.


The wires in the mains lead are coloured in accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of this appliance may not correspond
with the colour markings identifying the terminals on your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked
with the letter N or coloured black. The wire which is coloured BROWN must be
connected to the terminal which is marked with the letter L or coloured red.
The wire which is coloured GREEN/YELLOW must be connected to the terminal
which is marked with the letter E or (earth symbol) and is coloured GREEN
or GREEN/YELLOW.
WARNING: THIS APPLIANCE MUST BE EARTHED

1. Water tank
2. Handle
3. Soleplate
4. Temperature selection button
5. Steam button
6. Steam button lock
7. Steam release button
8. Ready indicator light
9. Control panel



1
2
3
4
5
6
78
9


Fabric setting display
Water tank


Temperature
Setting
Fabric
Ironing
Instruction
Steam
Selection
Synthetics
low setting
Synthetics
Silk
Nylon
Acrylic
Acetate
Dry iron
on the
opposite
side of the
fabric
Wool
medium setting
Use a
press cloth
and steam
iron on the
opposite
side of the
fabric
Wool
Polyester
Cottton
high setting
Iron while
fabric is
still damp
Rayon
Cotton
Linen
Linen
max setting
Steam iron
Rayon
Cotton
Linen

1. Follow the ironing instructions on the garment label. If there is no
instruction label, but you know what kind of fabric it is, please refer to the fabric
setting chart described opposite.
2. The fabric setting chart is only valid for plain fabrics and not for materials to which
nishes, glosses etc, have been applied. Textiles to which some kind of nish has
been applied (gloss, crinkle, relief etc.) is best ironed at a lower temperature.
3. First sort laundry according to ironing temperature setting guide: wool with wool,
cotton with cotton, etc.
4. The iron heats up more quickly than it cools down. Therefore, start ironing articles
that need to be ironed at the lowest temperature, such as those made of
synthetic bres.
5. If the fabric consists of various kinds of bres, always select the temperature
required by the most delicate bres, i.e. the lowest temperature. If, for example,
an article consists of 60% polyester and 40% cotton, according to the fabric setting
chart it should be ironed for polyester.
6. If you do not know what kind of fabric the article is made of, iron a piece of the
material which is not visible when you wear it to nd out the appropriate
temperature for your articles.
7. Pure woolen fabrics (100% wool) should be ironed with the iron setting to steam
ironing position. It is advisable to set the selection control button to "COTTON"
position and use a dry pressing cloth.
8. When steam ironing woolen fabrics, shiny patches may occur. You may prevent
this by turning the article inside out and ironing the reverse side.
9. After using steam ironing for cotton fabrics, do not iron articles requiring a lower
temperature (such as nylon etc.) immediately. It is advisable to adjust the selection
button to the lower setting, waiting for about 2-4 minutes until the blue indicator
light turns off, and then you can start ironing.
Important Hints
Do not ll water tank with vinegar, starch, chemically descaled water or
descaling agents.






1. Check if the rating indicated in the rating plate corresponds to the main
voltage in your home.
2. Press handle button to lay handle down.
(When handle is lifted up, the unit is shut off. It will be ON when
handle is laid down).
3. Remove the protective foil or sticker or card from the sole-plate.
4. Fully unwind and straighten the power cord and the supply hose.
5. Place the appliance on a stable, level and horizontal surface such
as an ironing board.
6. Place the iron onto the iron rest plate horizontally at the base unit.





If there is no water or not enough water in the tank, the lling indicator light on con-
trol panel will start blinking. An alarm will sound 5 BEEPs to indicate lling is needed.
1. Press the water tank lock upwards and slide the detachable water tank outwards
from the base.
2. Take the lter upwards out from the water ll hole.
(You can take the lter out of the opening for lling water into water tank,
or ll water into water tank directly with the lter already in the opening).
3. Fill the water tank up to or below the “MAX” ll line with clean tap water.
4. Replace lter back into water lling hole.
5. Replace the water tank into the base unit again. It will be locked in place with
the base when a “click” sound is heard.
6. Always pour out the remaining water after use.
Note:
When the water level in the tank falls below a certain level, the pump will
make a noise. When this happens, stop ironing and rell the tank.




1. Fill water tank with clean tap water refering to the lling instructions.
For better performance, please immerse lter in water for several minutes
before installing it into the water tank.
2. Connect the appliance to a suitable socket outlet. The power indicator light
(red) “ ” will light up on the iron unit showing that the unit has been connected
to the power supply.
3. Set selection button to desired position according to fabric setting chart
on page 08. The setting indicator light (blue) on the iron unit will blink slowly
to indicate the unit is heating up. When the blue indicator light changes to a steady
light and an audible “Bi” signal is produced, the desired temperature has been
reached and it is ready for steam ironing. During use, temperature indicator light
will sometimes blink and sometimes be a steady light. This does not indicate a
defect or hazard - this is because the appliance temperature is constant.
4. Before rst use, clean the iron unit as following methods:
Take the iron up from the base unit, press steam button underneath the handle
to allow steam ON for 30 seconds, and then OFF for 30 seconds. This cycle
should be repeated for 2 times. When blue indicator light stop blinking, it is ready
for use.
5. During steam ironing, steam should be automatically adjusted according to
sole-plate temperature.
6. After use, put iron unit back onto the base unit again, set selection button to “ ”,
and then unplug the appliance from main socket .
7. Slide out the water tank and pour out the remaining water.


Note:
a. For rst use, it is normal that a slight vibrating sound may occur from
the electrical pump inside the base unit for a few seconds when steam
ironing is started. It is because there is air inside the lter. It will stop when
the air inside the lter has been pumped out. If this abnomal condition
continues to happen for more than 60 seconds, please check whether
water tank and lter is assembled correctly.
b. When set at “NYLON” position, no steam is released since dry ironing
is most suitable.
c. When fabric setting is set at “POLYESTER” / “RAYON” / “COTTON”
“LINEN”, steam will automatically vary according to sole-plate
temperature. The pump will stop working and no steam released when the
sole-plate temperature becomes too low. It will resume once reheated
to the desired temperature.



1. Connect the appliance to a suitable socket outlet and lay handle down. Power
indicator light (red) “ ” on iron unit will light up indicating that the unit has been
connected to the power supply.
2. Set selection button to desired position according to fabric setting chart (page 08).
Blue indicator light on iron unit will blink slowly to indicate the unit being heated
up. When the blue indicator light changes to a steady light and an audible “Bi”
signal produced, the desired temperature has been reached. During use, blue
indicator light will cycle from blinking to a steady light and then from steady
mode to ON.
3. After use, put iron unit back onto the base unit again, turn selection button to
“ ” and then unplug the appliance from main socket.
Note:
When changing your temperature setting from higher setting to lower, you
should not start ironing immediately since it may cause burns to your fabrics.
Please wait till blue indicator light lights up steadily, and then start ironing.


• Follow the steam ironing process, and then hold the iron in a vertical position
between 5cm and 15cm away from the hanged fabrics.
• Press down steam switch, this will create vertical steam.
• This feature is especially used for removing creases from hanging clothes
and curtains.
• Never directly perform steam ironing on people.

The appliance will come into auto shut off mode along with audible “Bi... “ signal
when it has been used for 60 minutes continuously with temperature set at any
setting and power indicator light “ ” will blink. Press selection button to reset
another 60 minutes cycle if continuous use is necessary.
(Once each setting is pressed, the unit will reset time)
This appliance has a safety protection device in the base unit. If the supply hose is
blocked accidentally, the safety valve will be opened to release steam from the safety
vents under the base unit along with high pitch sounds. If this happens, unplug the
appliance immediately, and check whether any damage is found in the supply hose.


vertical


A handle is attached to the base unit for carrying the appliance. It also serves as a
power on/off switch: Lifting the handle up turns power OFF and putting the handle
down turns power ON.
Before use, please put the handle in the down position as follows:
• Press down the two handle buttons at the same time, and then lay the
handle down.
• After use, allow the appliance to completely cool down then wind the power cord
around the cord storage of base unit and put the iron onto the base unit.
• Lift the handle up until a “click” sound is heard. This indicates that the handle has
been locked in place and you can now carry the appliance by the handle.




Method:
1. The lter replacemnent indicator light will blink continuosly when the lter
needs to be replaced.
2. To replace; slide water tank out from base unit, take the lter out from the
water tank, and then replace with a new one.
3. After new lter has been installed into water tank, ll water into water tank
to MAX ll level, and then slide water tank back into base unit.
(Immerse lter in water for several minutes in order to gain better performance
in future use).
4. Press steam selection switch and power ON/OFF buttons concurrently to reset
blinking indicator light




1. The lter is designed to reduce the build-up of limescale which occurs during
steam ironing to prolong the working life of your iron. However, please
note that the lter will not completely stop the natural process of limescale
build-up.
2. The lter should be replaced with a new one after 2-3 months. The iron can still
be used with a clogged lter. However, limescale will most probably be built up
in the steam chamber. This happens depending on the quality of your local
water quality. You should replace the lter as soon as possible or mix your
water with 50% distilled water.

canti-cal
1. Disconnect the appliance from the power supply and allow the
appliance to cool down for at least 60 minutes.
2. After use, slide out the water tank and pour out all of the remaining water.
3. Wind the power cord around cord storage of the base unit.
4. The iron should be placed on the iron rest plate and they can be stored
together.
1. Unplug the appliance from the mains supply and let the iron cool down.
2. Clean the iron with a damp cloth.
3. Wipe off limescale and any other deposits from the soleplate with a damp cloth
or non-abrasive (liquid) cleaner.
4. Never clean the iron under the tap.




Problems Possible Causes Solution
Iron won't heat. Incorrect connection to
the mains socket.
Temperature setting is at
NYLON position.
Defects with internal circuit
causing unit to enter self
protect mode.
No water in water tank.
Filter has not been properly
installed into water tank.
Water tank has not been
properly installed.
Re-plug the unit to mains
socket.
Lay down handle.
Select the required ironing
temperature according to
Fabric Setting Chart.
Take to a qualied service-
man or manufacturer or its
service agent for
examination and repair.
Select the required ironing
temperature according to
fabric setting chart.
Re-power the unit again.
If it still can not resume,
please take it to its service
agent or similarly qualied
persons for repair.
Fill water into water tank.
Install lter into water tank.
Slide water tank into the
power base until a “click”
sound is produced and it
will be locked into place.
Handle has not been laid
down.
Temp setting is at " "
position.
Unknown malfunctions.
No steam
comes out
when pressing
steam switch after
the desired
temperature
is reached.
“ ” blinks quickly,
other fabric
indicators turn off,
buzzer sound a
“Bi”. No buttons
work. It will resume
when re-powered
again.





Disposal instructions for Swan items in accordance with the WEEE directive.
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately. Please visit www.recyclemore.co.uk, or www.recylcenow.co.uk for
access to information about the recycling of electrical items. The WEEE directive,
introduced in August 2006, states that all electrical items must be recycled, rather than
taken to landll. Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.

This product is guaranteed for two years from the date of original purchase.
If any defect arises due to faulty materials or workmanship faulty products must be
returned to place of purchase. Refunds or replacement is at the discretion of the store.
The following conditions apply:
• The product must be returned to the retailer with original proof of purchases.
• The product must be installed and used in accordance with the instruction
contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan has no responsibility for incidental or consequential loss or damage.
• Valid in the UK and Eire only.

01733 404703

SI9020TTN-001: Anti-Calc Filter

Distributed by
Swan Products Ltd
PO Box 3117
Stoke-on-Trent
ST4 9GD
Made in China
Please note the photographs and illustrations within
this manual are for illustration purposes only.

