Swann SM22070 User manual

Help line: 01733 404703
Microwave
Model: SM22070 (all colours)
SM22070_IM.indd 1 01/09/2015 08:59

2
IMPORTANT SAFEGUARDS
Installation
1. Take out all the packing. If there is a safe film over the oven, tear it off before Use. Check carefully for damage. if any, immediately notify
dealer or send to the manufacturer’s service center.
2. Microwave ovens must be placed under dry and non-corrosive environments, kept away from heat and humidity, such as gas burner or
water tank.
3. To ensure sufficient ventilation, the distance of the back of microwave to the wall should be at least 10 cm, the side to the wall should be at
least 5 cm, the free distance above the top surface at least 20 cm. the distance of the microwave to the ground should be at least 85 cm.
4. The position of the oven shall be such that it is far from the TV, Radio or antenna as picture disturbance or noise may occur.
5. The appliance must be positioned so that the plug is accessible, and must ensure a good earth connection
6. The microwave oven must be operated with the door closed.
7. The microwave oven must not be placed in a cabinet. The microwave oven is intended to be used freestanding.
8. The back of the oven must be placed against a wall.
The following basic precautions should always be followed when using electrical appliances:
1. Read all instructions before using .
2. Make sure the voltage in your living area corresponds to the one shown on the rating label of the appliance . And the wall socket is
properly earthed.
3. To reduce the risk of fire in the oven cavity :
• Do not overcook the food .
• Remove wire twist -ties from paper or plastic bags before placing bags in the oven .
• Do not heat oil or fat for deep drying as the temperature of oil cannot be controlled .
• After use wipe the waveguide cover with a damp cloth, followed by dry cloth to remove any food splashes and grease. Built -up grease
may overheat and begin to cause smoke or catch fire .
• If materials inside the oven should smoke or ignite , keep oven door closed, turn oven off and disconnect the power supply.
• Close supervision is necessary when using disposable containers made from plastic, paper or other combustible material .
4. To reduce the risk of explosion and sudden boiling:
SM22070_IM.indd 2 01/09/2015 08:59

IMPORTANT SAFEGUARDS
• Do not place sealed containers in the oven . Baby bottles fitted with a screw cap or teat are considered to be sealed containers .
• When boiling liquid in the oven, use a wide-mouthed container and stand about 20 seconds at the end of cooking to avoid delayed erup-
tion boiling of liquids .
• Potatoes, sausage and chestnuts should be peeled or pierced before cooking. Eggs in their shell, whole hard-boiled eggs should not be
heated in microwave ovens since they may explode, even after microwave heating has ended.
• The cooked liquid should not be removed immediately. Wait several moments before removing in order to avoid possible hazards
caused by delayed eruption boiling of liquids.
• The contents of feeding bottles and baby food jars should be stirred or shaken and the temperature should be checked before con-
sumption, in order to avoid burns .
5. Don’t operate the oven further if the door or door seal is damaged, or if the oven is malfunctioning, or supply cord is damaged . Return
the appliance to the nearest authorised service center for repair and maintenance . Never try to adjust or repair the oven yourself .
6. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard .
7. After cooking, the container could be very hot . Use gloves to take out the food and avoid steam burns by directing steam away from the
face and hands .
8. Slowly lift the furthest edges of dish cover and microwave plastic wraps and carefully open popcorn and oven cooking bags away from
the face.
9 . To prevent the turntable from breaking:
• Let the turntable cool down before cleaning.
• Do not place hot foods or utensils on the cold turntable .
• Do not place frozen foods or utensils on the hot turntable .
10. Make sure the utensils do not touch the interior walls during cooking .
11. Failure to maintain the oven in a clean condition could lead to a deterioration of the surface that could adversely affect the life of the ap-
pliance and possibly result in a hazardous situation.
12 . Only use utensils that are suitable for use in microwave ovens.
13 . Do not store food or any other things inside the oven .
14 . Do not operate the oven without any liquid or food inside the oven . This would damage the oven.
15 . This appliance is not intended for using by young children or infirm persons without supervision .
3
SM22070_IM.indd 3 01/09/2015 08:59

IMPORTANT SAFEGUARDS
16 . When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the tempera-
tures generated .
17. Any accessories not recommended by the manufacturer may cause injuries to persons.
18. Do not use outdoors.
19. Save these instructions.
20. WARNING : It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the
removal of a cover which gives protection against exposure to microwave energy
21. WARNING: Liquids and other foods must not be heated sealed container since they are liable to explode
22. WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able
to use the oven in a safe way and understands the hazards of improper use
23. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition
24. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames
25 . The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption in order
to avoid burns
26. WARNING: Accessible parts may become hot during use . Young children should be kept away .
27. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which
may result in shattering of the glass .
28. This appliance is not intended for use by persons ( including children) with reduced physical , sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible
for their safety .
29 . Children should be supervised to ensure that they do not play with the appliance .
30 . The appliance is not intended to be operated by means of an external timer or separate remote -control system
31. This appliance is intended to be used in household and similar applications such as:
•staffkitchenareasinshops,officesandotherworkingenvironments;
•farmhouses;
•byclientsinhotels,motelsandotherresidentialenvironments;
•bedandbreakfasttypeenvironments.
32. The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers,
SM22070_IM.indd 4 01/09/2015 08:59

SPECIFICATIONS
Capacity: 25L,
Output: 900 Watts
Input voltage: 220-240V ~ 50Hz
Input power: 1400 Watts
Microwave frequency: 2450MHz HOT SURFACES
5
IMPORTANT SAFEGUARDS
sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
33. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised. Keep the appliance and its cord out of reach of children less than 8 years. Cleaning and user
maintenance shall not be made by children without
supervision.
34. The door or the outer surface may get hot when the appliance is operating.
Household use only
SM22070_IM.indd 5 01/09/2015 08:59

GET TO KNOW YOUR MICROWAVE
UTENSILS GUIDELINE
It is strongly recommended to use containers which are suitable and safe for microwave cooking. Generally speaking, the
containers which are made of heat-resistant ceramic, glass or plastic are suitable for microwave cooking. Never use metal
containers for microwave cooking and combination cooking as sparks are likely to occur.
a. Do not remove the Waveguide cover (7) during cleaning
b. Make sure the Waveguide cover (7) is properly in place during cooking
Control Panel (6)
6
1. Door latches. Door must be closed before
microwave will operate
2. Viewing window. So you can monitor
cooking progress
3. Rotating axis. The glass turntable sits on
theaxis;themotorunderneathitdrives
the turntable to rotate
4. Rotating ring. The glass turntable sits on
itswheels;itsupportstheturntableand
helps it to balance when rotating
5. Turntable. The food sits on the turntable,
its rotation during operation helps to cook
food evenly. Place the rotating ring first,
and then fit the turntable onto the rotating
axis and make sure that it is geared in
properly
6. Control panel. See diagram on the left
7. Waveguide cover
1
SM22070_IM.indd 6 01/09/2015 08:59

HOW TO USE YOUR MICROWAVE
TIMER CONTROL
The max cooking time length that can be set is 30 minutes. Each
setting is 1 minute. A bell ring will sound when the timer times
out and returns to zero position
FUNCTION / POWER CONTROL
There are 6 power levels:
HIGH 100% power Quick
M.HIGH 85% power Normal
MED 66% power Slow
M.LOW 40% power Drinks or soup
DEFROST 37% power Defrost
LOW 17% power Keep warm
Guidelines for defrost times:
WEIGHT RANGE DEFROST LENGTH
Meat 0.1 - 1.0 kg 1:30 - 26:00
Poultry 0.2 - 1.0kg 2:30 - 22:00
Seafood 0.1 - 0.9kg 1:30 - 14:00
7
OPERATION
1. Before connecting the cord, make sure the timer is set
to “0” position. Connect the cord
2. Do not block the ventilation
3. Place the food on the glass turntable and close the door.
Food must be contained in a container or on a plate
4. Select the desired power level
5. Set the timer. If desired time is less than 10 minutes,
turn the timer knob to over 10 minutes position and
then turn back to the desired time setting.
6. Once the desired time is set, the cooking begins. If
pausing in between is needed, just open the door at any
time, and close it to resume operation
7. When it times out and cooking ends, the microwave
oven produces a bell ring, the inside lamp will also turn
off
8. If food is removed before time out, make sure to set
back the timer to “0” position, this avoids the microwave
oven from operating with empty oven
9. ALWAYS WIPE THE INSIDE OF THE MICROWAVE WITH
KITCHEN TOWEL OR CLOTH AFTER EVERY USE. PLEASE
ENSURE THE OVEN IS BOTH CLEAN AND DRY. NOT
DOING THIS CAN CAUSE BUILD-UP OF BACTERIA AND
LONG TERM CORROSION OF OVEN PARTS
SM22070_IM.indd 7 01/09/2015 08:59

HOW TO USE YOUR MICROWAVE
• The max time which can be set is 30minutes.
• Never operate the oven empty.
• If you need to turn the food during operation, open the door, re-position the food and close the door again. The cooking
procedure will continue.
• If you intend to remove the food before the preset time, you must turn the timer back to 0 position so the oven will not
switch back on when you close the door
• Usually defrosting will need longer time than that of cooking the food.
• If the food can be cut by a knife, the defrosting process can be considered completed.
• Microwavee penetrate around 4cm into most food
• Defrosted food should be consumed as soon as possible, it is not advised to put back in the freezer again.
8
Cooking Tips
The following factors may affect the cooking result:
Food arrangement
Place thicker areas towards outside of dish, the thinner part towards the Centre and spread it evenly. Do not overlap if possible.
Cooking time length
Start cooking with a short time setting, evaluate it after it times out and extend it according to the actual need. Over cooking may
result in smoke and burns.
Cooking food evenly
Food such as chicken, hamburger or steak should be turned once during cooking. Depending on the type of food, if applicable,
stir it from outside to centre of dish once or twice during cooking
SM22070_IM.indd 8 01/09/2015 08:59

HOW TO USE YOUR MICROWAVE
9
Allow standing time
After cooking time ends, leave the food in the oven for an adequate length of time, this allows it to complete its cooking cycle and
cools it down in a gradual manner
Whether the food is done.
Color and hardness of food help to determine if it is done, these include:
- Steam coming out from all parts of food, not just the edge
- Joints of poultry can be moved easily
- Pork or poultry shows no signs of blood
- Fish is opaque and can be sliced easily with a fork
Browning dish
When using a browning dish or self-heating container, always place a heat-resistant insulator such as a porcelain plate under it
to prevent damage to the turntable and rotating ring.
Microwave safe plastic wrap
When cooking food with high fat content, do not allow the plastic wrap come into contact with food as it may melt
Microwave safe plastic cookware
Some microwave safe plastic cookware might not be suitable for cooking foods with high fat and sugar content. Also, the
preheating time specified in the dish instruction manual must not be exceeded
SM22070_IM.indd 9 01/09/2015 08:59

10
HOW TO USE YOUR MICROWAVE
COOKWARE MICROWAVE
Heat resistant glass Yes
Non heat-resistant glass No
Heat-resistant ceramic Yes
Microwave-safe plastic dish Yes
Kitchen paper Yes
Metal tray No
Metal rack No
Aluminium foil & foil containers No
GENERAL GUIDE TO CORRECT UTENSILS SPARES
If you lose or break anything and need a spare part for your
microwave, use the following references:
SM22070-001 Rotating axis (3)
SM22070-002 Rotating ring (4)
SM22070-003 Turntable (5)
Call: 01703 404703 for spares
SM22070_IM.indd 10 01/09/2015 08:59

CLEANING & MAINTENANCE
The oven should be cleaned regularly and any food deposits removed.
1. It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the
removal of a cover which gives protection against exposure to microwave energy
2. Remove the power cord from the wall outlet before cleaning. Don’t immerse the appliance in water or other fluids when
cleaning.
3. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the
life of the appliance and possibly result in a hazardous situation
4. The oven should be cleaned regularly and any food deposits removed
5. Details for cleaning door seals, cavities and adjacent parts.
6. Never use hard detergent, gasoline, abrasive powder or metal brush to clean any part of the appliance
7. Do not remove the waveguide cover
8. When the microwave oven has been used for a long time, there may be some strange odors exist in oven, Following 3
methods can get rid of them: a. Place several lemon slices in a cup, then heat with high power for 2-3 min. b. Place a cup
of red tea in oven, then heat with high power. c. Put some orange peel into oven, and then heat them with high power for 1
minute.
Wipe exterior parts with a dampened soft cloth
Wipe clean the interior surfaces with a dampened soft cloth
Wipe clean the waveguide cover to remove any food splashed on it
Turntable / Rotation ring / Rotation axis:
Wash with mild soapy water. Rinse with clean water and allow drying thoroughly. Glass turntable is OK to put in the dishwasher
11
SM22070_IM.indd 11 01/09/2015 08:59

SERVICING
Please check the following before calling for service:
a. Place one cup of water (approx.150ml)in a glass measure in the oven and close the door securely. Oven lamp should go off if
the door is closed properly. Let the oven work for 1 min.
b. Does the oven lamp light?
c. Does the cooling fan work? (Put your hand over the rear ventilation openings.)
d. Does the turntable rotate? (The turntable can rotate Clockwise or counter Clockwise. This is quite normal.)
e. Is the water inside the oven hot?
If “NO” is the answer to any of the above questions, please check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly, CONTACT SERVICE on 01733 404703
Ifthedoorordoorsealsaredamaged,theovenmustnotbeoperateduntilithasbeenrepairedbyacompetentperson;
It is hazardous for anyone, other than a qualified service technician, to carry out any service for repairing operation which
involves removal of any cover which gives protection against exposure to microwave energy.
Liquids or other foods must not be heated in sealed containers since they are liable to explode.
12
SM22070_IM.indd 12 01/09/2015 08:59

MICROWAVE RADIATION!
It is hazardous for anyone, other than a qualified service technician, to carry out any service for repairing operation which
involves removal of any cover which gives protection against exposure to microwave energy. The temperature of accessible
surfaces may be high when the appliance is operating
Thehighvoltagecapacitorremainschargeafterdisconnection;shortthenegativeterminalofH.Vcapacitortotheovenchas-
sis (use a screwdriver) to discharge before touching.
During servicing below listed parts are liable to be removed and give access to potentials above 250V to earth.
1. Magnetron
2. High voltage transformer
3. High voltage capacitor
4. High voltage diode
5. High voltage fuse
The following conditions may cause undue microwave exposure during servicing. Improperfittingofmagnetron;Improper
matchingofdoorinterlock,doorhingeanddoor;Improperfittingofswitchsupport;Door,doorsealorenclosurehasbeen
damaged.
SERVICING SAFEGUARDS
13
SM22070_IM.indd 13 01/09/2015 08:59

BS Plug Wiring
The wires in the mains lead are coloured in accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as
follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN
must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the
terminal which is marked with the letter E or (earth symbol) and is coloured GREEN or GREEN/YELLOW.
WARNING: THIS APPLIANCE MUST BE EARTHED
WEEE Directive
Disposal of Unit
Disposal instructions for Swan items in accordance with the
WEEE directive. Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish. You are required
to dispose of old electrical and electronic appliances like this
separately. Please visit www.recyclemore.co.uk, or www.
recyclenow.co.uk for access to information about the recycling
of electrical items. The WEEE directive, introduced in August
2006, states that all electrical items must be recycled, rather
than taken to landfill. Please arrange to take this appliance to
your local Civic Amenity site for recycling, once it has reached
the end of its life.
Warranty
This product is guaranteed for 2 years from the date of original purchase. If
any defect arises due to faulty materials of workmanship the faulty products
must be returned to the place of purchase. Refunds or replacement is at the
discretion of the store.
The following conditions apply:
The product must be returned to the retailer with proof of purchase.
The product must be installed and used in accordance with the instructions
contained in this instruction guide. It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts. Swan
Products Ltd has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire Only.
14
SM22070_IM.indd 14 01/09/2015 08:59

www.swan-brand.co.uk
Copyright © 2013
Swan Products Ltd. PO Box 3117, Stoke-on-Trent ST4 9GD
Est.1931
We love
what we do
s
2year
GUARANTEE
we’re proud
of our quality
Scan this QR code
to hear about
our story
Find us on Facebook
SM22070_IM.indd 15 01/09/2015 08:59
