Swann Retro SM22085 User manual

Help line: 0333 220 6050 v1.0
25L Microwave
Model: SM22085 (all colours)
SM22085_IM.indd 1 02/01/2019 08:05

2
IMPORTANT SAFEGUARDS
Installation
1. Take out all the packing. If there is a safe film over the oven, tear it off before Use. Check
carefully for damage. if any, immediately notify dealer or send to the manufacturer’s
service centre.
2. Microwave ovens must be placed under dry and non-corrosive environments, kept away
from heat and humidity, such as gas burner or water tank.
3. To ensure sufficient ventilation, the distance of the back of microwave to the wall should
be at least 10 cm, the side to the wall should be at least 5 cm, the free distance above
the top surface at least 20 cm. the distance of the microwave to the ground should be
at least 85 cm.
4. The position of the oven shall be such that it is far from the TV, Radio or antenna as
picture disturbance or noise may occur.
5. The appliance must be positioned so that the plug is accessible, and must ensure a good
earth connection
6. The microwave oven must be operated with the door closed.
7. The microwave oven must not be placed in a cabinet. The microwave oven is intended to
be used freestanding.
SM22085_IM.indd 2 02/01/2019 08:05

IMPORTANT SAFEGUARDS
8. The back of the oven must be placed against a wall.
The following basic precautions should always be followed when using electrical appli-
ances:
1. Read all instructions before using .
2. Make sure the voltage in your living area corresponds to the one shown on the rating
label of the appliance . And the wall socket is properly earthed.
3. To reduce the risk of fire in the oven cavity :
• Do not overcook the food .
• Remove wire twist -ties from paper or plastic bags before placing bags in the oven .
• Do not heat oil or fat for deep frying as the temperature of oil cannot be controlled .
• After use wipe the waveguide cover with a damp cloth, followed by dry cloth to remove
any food splashes and grease. Built -up grease may overheat and begin to cause
smoke or catch fire .
• If materials inside the oven should smoke or ignite , keep oven door closed, turn oven
off and disconnect the power supply.
• Close supervision is necessary when using disposable containers made from plastic,
3
SM22085_IM.indd 3 02/01/2019 08:05

IMPORTANT SAFEGUARDS
• paper or other combustible material .
4. To reduce the risk of explosion and sudden boiling:
• Do not place sealed containers in the oven . Baby bottles fitted with a screw cap or
teat are considered to be sealed containers .
• When boiling liquid in the oven, use a wide-mouthed container and stand about 20 sec-
onds at the end of cooking to avoid delayed eruption boiling of liquids .
• Potatoes, sausage and chestnuts should be peeled or pierced before cooking. Eggs in
their shell, whole hard-boiled eggs should not be heated in microwave ovens since they
may explode, even after microwave heating has ended.
• The cooked liquid should not be removed immediately. Wait several moments before
removing in order to avoid possible hazards caused by delayed eruption boiling of liq-
uids.
• The contents of feeding bottles and baby food jars should be stirred or shaken and the
temperature should be checked before consumption, in order to avoid burns .
5. Don’t operate the oven further if the door or door seal is damaged, or if the oven is
malfunctioning, or supply cord is damaged . Return the appliance to the nearest author-
ised service centre for repair and maintenance . Never try to adjust or repair the oven
yourself .
4
SM22085_IM.indd 4 02/01/2019 08:05

IMPORTANT SAFEGUARDS
6. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a qualified technician in order to avoid a shock hazard .
7. After cooking, the container could be very hot . Use gloves to take out the food and
avoid steam burns by directing steam away from the face and hands .
8. Slowly lift the furthest edges of dish cover and microwave plastic wraps and carefully
open popcorn and oven cooking bags away from the face.
9 . To prevent the turntable from breaking:
• Let the turntable cool down before cleaning.
• Do not place hot foods or utensils on the cold turntable .
• Do not place frozen foods or utensils on the hot turntable .
10. Make sure the utensils do not touch the interior walls during cooking .
11. Failure to maintain the oven in a clean condition could lead to a deterioration of the
surface that could adversely affect the life of the appliance and possibly result in a hazard-
ous situation.
12 . Only use utensils that are suitable for use in microwave ovens.
13 . Do not store food or any other things inside the oven .
14 . Do not operate the oven without any liquid or food inside the oven . This would dam-
age the oven.
5
SM22085_IM.indd 5 02/01/2019 08:05

IMPORTANT SAFEGUARDS
15 . This appliance is not intended for using by young children or infirm persons without
supervision .
16 . When the appliance is operated in the combination mode, children should only use
the oven under adult supervision due to the temperatures generated .
17. Any accessories not recommended by the manufacturer may cause injuries to per-
sons.
18. Do not use outdoors.
19. Save these instructions.
20. WARNING : It is hazardous for anyone other than a competent person to carry out
any service or repair operation that involves the removal of a cover which gives protection
against exposure to microwave energy
21. WARNING: Liquids and other foods must not be heated in a sealed container since
they are liable to explode
22. WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use
23. When heating food in plastic or paper containers, keep an eye on the oven due to the
possibility of ignition
6
SM22085_IM.indd 6 02/01/2019 08:05

IMPORTANT SAFEGUARDS
24. If smoke is observed, switch off or unplug the appliance and keep the door closed in
order to stifle any flames
25 . The contents of feeding bottles and baby food jars should be stirred or shaken and
the temperature checked before consumption in order to avoid burns
26. WARNING: Accessible parts may become hot during use . Young children should be
kept away .
27. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass since they can scratch the surface, which may result in shattering of the glass .
28. This appliance is not intended for use by persons ( including children) with reduced
physical , sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety .
29 . Children should be supervised to ensure that they do not play with the appliance .
30 . The appliance is not intended to be operated by means of an external timer or sepa-
rate remote -control system
31. This appliance is intended to be used in household and similar applications such as:
• staff kitchen areas in shops, offices and other working environments;
• farm houses;
7
SM22085_IM.indd 7 02/01/2019 08:05

IMPORTANT SAFEGUARDS
• by clients in hotels, motels and other residential environments;
• bed and breakfast type environments.
32. The microwave oven is intended for heating food and beverages. Drying of food or clothing
and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury,
ignition or fire.
33. This appliance can be used by children aged from 8 years and above and persons with re-
duced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and under-
stand the hazards involved. Children shall not play with the appliance. Cleaning and user mainte-
nance shall not be made by children unless they are older than 8 and supervised. Keep the appli-
ance and its cord out of reach of children less than 8 years. Cleaning and user maintenance shall
not be made by children without
supervision.
34. The door or the outer surface may get hot when the appliance is operating.
We do not recommend the use of microwave popcorn in bags. Many of these produce PFOA
chemicals, which have been identified as a potential carcinogen. Instead we recommend using
a microwave-approved bowl and lid.
8
SM22085_IM.indd 8 02/01/2019 08:05

GET TO KNOW YOUR MICROWAVE
UTENSILS GUIDELINE
It is strongly recommended to use containers which are suitable and safe for microwave cooking. Generally speaking, the
containers which are made of heat-resistant ceramic, glass or plastic are suitable for microwave cooking. Never use metal
containers for microwave cooking and combination cooking as sparks are likely to occur.
a. Do not remove the Waveguide cover during cleaning
b. Make sure the Waveguide cover is properly in place during cooking
CONTROL PANEL
9
SM22085_IM.indd 9 02/01/2019 08:05

HOW TO USE YOUR MICROWAVE
1. POWER ON SELF CHECKING
The LED flashes 3 times when plugged in power supply. Then it
shows “1:00”,
”:” flashing to indicate standby status.
2. TIME/WEIGHT/ENTER KNOB
You can increase or decrease cooking time or weight or during
operation by turning Time/Weight/Enter knob. You may need to
press the knob (Enter) to access further settings.
3. PAUSE/CANCEL
Press Pause/Cancel button to cancel setting power, cooking
or defrost program. During cooking: press once to stop oven
operation, press twice to cancel cooking programs.
4. AUTO REMINDER
When the cooking or defrost process is completed, you will hear
3 beeps. If the door is not opened or Pause/Cancel button is not
pressed, the microwave will beep every 3 minutes.
5. CLOCK SETTING
In the standby state, turn knob to Clock position, press and hold
Enter button for 3 seconds to enter clock input state.
10
Turn Time/Weight knob, enter the hour; press Enter, enter
the minute setting, turn the Time/Weight knob, enter the
minute, finally press Enter button to confirm (or automatically
confirm the time just set after 60 seconds delay).
The clock is now set and running. Repeat the above operation.
Make clock changes or settings.
6. MICROWAVE COOKING
Turn the knob switch, respectively, to M.Low, M.high, High, the
display shows 40P, 80P, 100P, respectively representing low
power, medium and high power, high power, after selecting
power, turn Time/Weight knob to set the working time,
clockwise rotation to increase, counterclockwise to decrease.
The maximum time that can be set is 60 minutes.
High Power 100% power. Microwave always on
Medium High
Power
Microwave cycles on for 26 seconds
and off for 7 seconds.
Medium Low
Power
Microwave cycles on for 13 seconds
and off for 20 seconds.
SM22085_IM.indd 10 02/01/2019 08:05

HOW TO USE YOUR MICROWAVE
a. The max time which can be set is 60 minutes.
b. Never operate the oven empty.
c. If you turn the food during operation, press the Start button
once and the preset cooking procedure will continue.
d. If you intend to remove the food before the preset time, you
must press Pause/Cancel button once to clear the preset
procedure to avoid unintended operation during next use.
e. At the maximum microwave power, the oven will automatical-
ly lower the power after a certain time of cooking to lengthen
the service life
11
Example: To cook at M.high for 10 minutes.
Steps Display
1. Power up the oven 1:00
2. Select the desired microwave power by
turning knob to M.high position.
80P
3. Set cooking time by turning Time/
Weight knob
10:00
4. Press Start button and LED will show
the remaining working time.
You can change the cooking time during the working pro-
cess. It is recommended to turn the food during cooking.
Open door (microwave stops), turn the food and close the
oven door, press Start button to continue.
7. SPEED COOKING
In the standby state, turn knob to Speed cooking position. The
LED display shows “SPE”. At this time, you can directly press
Start button, and the microwave oven will start working in the
microwave high setting for 1:00. Press START or turn Time/
Weight knob to increase working time.
Example: Speed Cooking
Steps Display
1. Power up the oven 1:00
2. Turn knob to speed cooking SPE
3. Press Start button to start cooking
8. DEFROST
Use to defrost food; turning knob to Defrost “dEF” will be
displayed on LED. The weight range to defrost is 0.1 kg to 2.0
kg, which is suitable for defrosting meat.
SM22085_IM.indd 11 02/01/2019 08:05

HOW TO USE YOUR MICROWAVE
a. It is necessary to turn over the food during operation
to obtain uniform effect.
b. Usually defrosting will need longer time than that of
cooking the food.
c. If the food can be cut by knife, the defrosting process
can be considered completed.
d. Microwave penetrates around 4cm into most food
e. Defrosted food should be consumed as soon as
possible, it is not advised to put back to fridge and freeze
again
Auto cooking
In the standby state, turn knob to Auto Cooking position,
the “AUTO COOKING” symbol of the LED lights up, the
digital position displays “A.1”, turn Time/Weight knob,
and the LED cycle displays A-01, A-02 ...... A-12, after
selecting, press Enter button to enter the weight
selection, turn Time/Weight knob to select the weight,
then press Start button to start.
12
Example: To defrost 0.4kg poultry
Press Display
1. Power up the oven 0:00
2. Turn Menu Selector to Defrost dEF
3. Turn Time/Weight knob to set the defrost
weight
0.4
4. Start cooking by pressing Start button. LED
will show the remaining time.
5. Half way through defrosting process, 2 beeps
will be heard two times to prompt you turn
over the food. Open the door and turn over
the food. Then close the door. Press Start
button again to continue defrosting till the
countdown time is 0.
SM22085_IM.indd 12 02/01/2019 08:05

Cooking weight is 0.1kg
a. The temperature of food before cooking should be 20-25C
Higher or lower temperature of the food before cooking would
require an increase or decrease of cooking time accordingly.
b. The temperature, weight and shape of food will largely influence
the cooking effect. If any deviation has been found to the factor
noted on above menu, you can adjust the cooking time for best
result.
Child lock function
Use this feature to lock the control panel when you are cleaning or
so that children can not use the oven unsupervised. All the buttons
are rendered inoperable in this mode.
1) To set child lock, press and hold Pause/Cancel button about 3
seconds.
2) To cancel child lock, press and hold Pause/Cancel button about
3 seconds.
13
Example: Steam 0.3kg fish
Steps Display
1. Power up the oven 1:00
2. Turn knob to Auto cooking, and then
turn Time/Weight knob to select
auto cooking menu.
A-05
3. Press Enter to weight choice, and
then turn Time/Weight knob to
choose weight.
0.3
4. Start cooking by pressing Start but-
ton. LED will show remaining time.
SM22085_IM.indd 13 02/01/2019 08:05

HOW TO USE YOUR MICROWAVE
Cooking Tips
The following factors may affect the cooking result:
Food arrangement
Place thicker areas towards outside of dish, the thinner part towards the Centre and spread it evenly. Do not overlap if possible.
Cooking time length
Start cooking with a short time setting, evaluate it after it times out and extend it according to the actual need. Over cooking may
result in smoke and burns.
Cooking food evenly
Food such as chicken, hamburger or steak should be turned once during cooking. Depending on the type of food, if applicable,
stir it from outside to centre of dish once or twice during cooking
Allow standing time
After cooking time ends, leave the food in the oven for an adequate length of time, this allows it to complete its cooking cycle and
cools it down in a gradual manner
Whether the food is done. Colour and hardness of food help to determine if it is done, these include:
- Steam coming out from all parts of food, not just the edge
- Joints of poultry can be moved easily
- Pork or poultry shows no signs of blood
- Fish is opaque and can be sliced easily with a fork
14
SM22085_IM.indd 14 02/01/2019 08:05

HOW TO USE YOUR MICROWAVE
Browning dish
When using a browning dish or self-heating container, always place a heat-resistant insulator such as a porcelain plate under it
to prevent damage to the turntable and rotating ring.
Microwave safe plastic wrap
When cooking food with high fat content, do not allow the plastic wrap come into contact with food as it may melt
Microwave safe plastic cookware
Some microwave safe plastic cookware might not be suitable for cooking foods with high fat and sugar content. Also, the
preheating time specified in the dish instruction manual must not be exceeded
15
SPECIFICATIONS
,
Output: 900 Watts
Input voltage: 220-240V ~ 50Hz
Input power: 1400 Watts
Microwave frequency: 2450MHz
Cavity size: 36.1 x 33.8 x 21cm.
HOT SURFACES
SM22085_IM.indd 15 02/01/2019 08:05

CLEANING & MAINTENANCE
The oven should be cleaned regularly and any food deposits removed.
1. It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the
removal of a cover which gives protection against exposure to microwave energy
2. Remove the power cord from the wall outlet before cleaning. Don’t immerse the appliance in water or other fluids when
cleaning.
3. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the
life of the appliance and possibly result in a hazardous situation
4. The oven should be cleaned regularly and any food deposits removed
5. Details for cleaning door seals, cavities and adjacent parts.
6. Never use hard detergent, gasoline, abrasive powder or metal brush to clean any part of the appliance
7. Do not remove the waveguide cover
8. When the microwave oven has been used for a long time, there may be some strange odors exist in oven, Following 3
methods can get rid of them: a. Place several lemon slices in a cup, then heat with high power for 2-3 min. b. Place a cup
of red tea in oven, then heat with high power. c. Put some orange peel into oven, and then heat them with high power for 1
minute.
Wipe exterior parts with a dampened soft cloth
Wipe clean the interior surfaces with a dampened soft cloth
Wipe clean the waveguide cover to remove any food splashed on it
Turntable / Rotation ring / Rotation axis:
Wash with mild soapy water. Rinse with clean water and allow drying thoroughly. Glass turntable is OK to put in the dishwasher
16
SM22085_IM.indd 16 02/01/2019 08:05

SERVICING
Please check the following before calling for service:
a. Place one cup of water (approx.150ml)in a glass measure in the oven and close the door securely. Oven lamp should go off if
the door is closed properly. Let the oven work for 1 min.
b. Does the oven lamp light?
c. Does the cooling fan work? (Put your hand over the rear ventilation openings.)
d. Does the turntable rotate? (The turntable can rotate Clockwise or counter Clockwise. This is quite normal.)
e. Is the water inside the oven hot?
If “NO” is the answer to any of the above questions, please check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly, CONTACT SERVICE using number on front of this manual
If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person;
It is hazardous for anyone, other than a qualified service technician, to carry out any service for repairing operation which
involves removal of any cover which gives protection against exposure to microwave energy.
Liquids or other foods must not be heated in sealed containers since they are liable to explode.
SPARES
The following spares are available for this microwave via our web site at: www.swan-brand.co.uk:
SM22030N001 - glass turntable
SM22030N001 - plastic rotating ring
17
SM22085_IM.indd 17 02/01/2019 08:05

MICROWAVE RADIATION!
It is hazardous for anyone, other than a qualified service technician, to carry out any service for repairing operation which
involves removal of any cover which gives protection against exposure to microwave energy. The temperature of accessible
surfaces may be high when the appliance is operating
The high voltage capacitor remains charge after disconnection; short the negative terminal of H. V capacitor to the oven chas-
sis (use a screwdriver) to discharge before touching.
During servicing below listed parts are liable to be removed and give access to potentials above 250V to earth.
1. Magnetron
2. High voltage transformer 3. High voltage capacitor
4. High voltage diode
5. High voltage fuse
The following conditions may cause undue microwave exposure during servicing. Improper fitting of magnetron; Improper
matching of door interlock, door hinge and door; Improper fitting of switch support; Door, door seal or enclosure has been
damaged.
SERVICING SAFEGUARDS
1. If LED displays Err0 during working ,it indicates that sensor has been short circuited and you need replace it at the near-
est repaired department.
2. If LED displays Err1 during working, it indicates that sensor is open circuit and you need replace it at the nearest service-
centre
18
SM22085_IM.indd 18 02/01/2019 08:05

BS Plug Wiring
The wires in the mains lead are coloured in accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as
follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN
must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the
terminal which is marked with the letter E or (earth symbol) and is coloured GREEN or GREEN/YELLOW.
WARNING: THIS APPLIANCE MUST BE EARTHED
WEEE Directive
Disposal of Unit
Disposal instructions for Swan items in accordance with the
WEEE directive. Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish. You are required
to dispose of old electrical and electronic appliances like this
separately. Please visit www.recyclemore.co.uk, or www.
recyclenow.co.uk for access to information about the recycling
of electrical items. The WEEE directive, introduced in August
2006, states that all electrical items must be recycled, rather
than taken to landfill. Please arrange to take this appliance to
your local Civic Amenity site for recycling, once it has reached
the end of its life.
Warranty
This product is guaranteed for 2 years from the date of original purchase. If
any defect arises due to faulty materials of workmanship the faulty products
must be returned to the place of purchase. Refunds or replacement is at the
discretion of the store.
The following conditions apply:
The product must be returned to the retailer with proof of purchase.
The product must be installed and used in accordance with the instructions
contained in this instruction guide. It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts. Swan
Products Ltd has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire Only.
19
SM22085_IM.indd 19 02/01/2019 08:05

www.swan-brand.co.uk
Copyright © 2013
Swan Products Ltd. PO Box 3117, Stoke-on-Trent ST4 9GD
Est.1931
We love
what we do
s
2year
GUARANTEE
we’re proud
of our quality
Scan this QR code
to hear about
our story
Find us on Facebook
SM22085_IM.indd 20 02/01/2019 08:05
