Swedstyle Cascading User manual
/ M1057
Cascading
Operating Manual to connect several
control boxes SWT to each other
2 3
2. ACTIVATE CASCADED NETWORK WITH 2 CONTROLL BOXES
For your own safety, read the complete product documentation before connecting
the devices to form a cascaded network and putting it into operation.
A x4
C x2
E
D x2
E
Before you start!
The control boxes has to be brand new
boxes that has never been connected to
a frame before.
B
1. Make sure the control boxes are not plugged
in, unplug the power cords. Connect the
motor cables to the control boxes.
2. Connect the two control boxes using
the cascading cable.
3. Connect each control box to a seperate
power supply cable.
4. Connect the power supply cables to
the power supply. NOW WAIT FOR
10 SECONDS.
5. Reset the table by lower the frame to its
lowest position by pressing the down arrow
on the hand control. Press the button and
keep it pressed for 10 seconds. OK! Now all
4 columns will move.
1. REQUIRED COMPONENTS
A. 2 to 4 motor columns
B. Hand control
C. 2 control boxes
D. Power supply cables
E. 1 cascading cable
D
1:1 A3
Skala:
PRESS!
Nollställning:
Kör bordet till stativets bottenläge genom att trycka på knappen ”pil ned”, när
stativet nått lägsta läget så släpp knappen.
Tryck sedan in den på nytt och håll inne ytterligare 10 sek.
Stativet är nu nollställt och redo att användas.
Reset procedure:
Lower the frame to its lowest position by pressing the down arrow on the
hand control. Release the button.
Press the button again and keep it pressed
for 10seconds, the reset is now carried out and the frame is ready to use.
Resetten:
Fahren Sie die Tischplatte mit der Taste “Pfeil nach unten“ zum
tiefsten Punkt! Die Taste loslassen.
Die Taste noch einmal herunterdrücken
und sie ca. 10 Sekunden halten bis Sie eine kleine Bewegung der
Tischplatte bemerken.
3. REPLACING A CONTROL BOX IN A CASCADED NETWORK
To exchange control boxes in an existing cascading network, proceed as follows:
1. Disconnect the control boxes from the power supply.
2. Rebuild the cascaded network, see chapter2.
4. REPLACING A MOTOR COLUMN IN A CASCADED NETWORK
To replace motor columns in an existing cascaded network, proceed as follows:
1. Disconnect the current motor column from the control box.
2. Connect the new motor column to the control box.
3. Perform a reset proceedure, see chapter 2.5 on page 3.
NOTICE! Risk of damage to the system.
Ensure that all drives are moving in the same direction and are adjusting the
height of the desktop during the reference drive. Misaligned drives may cause
damage to the system.
Swedstyle AB.
Box 171, SE-567 24 Vaggeryd, Sweden
info@swedstyle.se
+46 393-363 60
www.swedstyle.com
